JP2007310334A - ハーフトーン露光法を用いた液晶表示装置の製造法 - Google Patents

ハーフトーン露光法を用いた液晶表示装置の製造法 Download PDF

Info

Publication number
JP2007310334A
JP2007310334A JP2006166674A JP2006166674A JP2007310334A JP 2007310334 A JP2007310334 A JP 2007310334A JP 2006166674 A JP2006166674 A JP 2006166674A JP 2006166674 A JP2006166674 A JP 2006166674A JP 2007310334 A JP2007310334 A JP 2007310334A
Authority
JP
Japan
Prior art keywords
electrode
pixel electrode
layer
pixel
region
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Pending
Application number
JP2006166674A
Other languages
English (en)
Japanese (ja)
Inventor
Sakae Tanaka
栄 田中
Toshiyuki Samejima
俊之 鮫島
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
MIKUNI DENSHI KK
Original Assignee
MIKUNI DENSHI KK
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by MIKUNI DENSHI KK filed Critical MIKUNI DENSHI KK
Priority to JP2006166674A priority Critical patent/JP2007310334A/ja
Priority to TW096106310A priority patent/TW200744216A/zh
Priority to CN2007100937512A priority patent/CN101075584B/zh
Priority to KR1020070042053A priority patent/KR100934590B1/ko
Priority to GB0709203A priority patent/GB2438490A/en
Priority to US11/749,190 priority patent/US7602456B2/en
Publication of JP2007310334A publication Critical patent/JP2007310334A/ja
