CN100541746C - 电抛光具有带虚设结构的沟槽或者通路的晶片上的金属层 - Google Patents

电抛光具有带虚设结构的沟槽或者通路的晶片上的金属层 Download PDF

Info

Publication number
CN100541746C
CN100541746C CNB028088344A CN02808834A CN100541746C CN 100541746 C CN100541746 C CN 100541746C CN B028088344 A CNB028088344 A CN B028088344A CN 02808834 A CN02808834 A CN 02808834A CN 100541746 C CN100541746 C CN 100541746C
Authority
CN
China
Prior art keywords
concave area
metal level
layer
barrier layer
metal
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Expired - Fee Related
Application number
CNB028088344A
Other languages
English (en)
Chinese (zh)
Other versions
CN1663036A (zh
Inventor
王晖
易培豪
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
ACM Research Inc
Original Assignee
ACM Research Inc
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by ACM Research Inc filed Critical ACM Research Inc
Publication of CN1663036A publication Critical patent/CN1663036A/zh
Application granted granted Critical
Publication of CN100541746C publication Critical patent/CN100541746C/zh
Anticipated expiration legal-status Critical
Expired - Fee Related legal-status Critical Current

Links

Images

Classifications
