JP5587219B2 - ステンレス鋼への導電材料の接合方法 - Google Patents

ステンレス鋼への導電材料の接合方法 Download PDF

Info

Publication number
JP5587219B2
JP5587219B2 JP2011016476A JP2011016476A JP5587219B2 JP 5587219 B2 JP5587219 B2 JP 5587219B2 JP 2011016476 A JP2011016476 A JP 2011016476A JP 2011016476 A JP2011016476 A JP 2011016476A JP 5587219 B2 JP5587219 B2 JP 5587219B2
Authority
JP
Japan
Prior art keywords
stainless steel
conductive material
base plate
passive film
conductive paste
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Active
Application number
JP2011016476A
Other languages
English (en)
Japanese (ja)
Other versions
JP2012155820A5 (enExample
JP2012155820A (ja
Inventor
健二 真下
修一 樫本
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
Suncall Corp
Original Assignee
Suncall Corp
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by Suncall Corp filed Critical Suncall Corp
Priority to JP2011016476A priority Critical patent/JP5587219B2/ja
Priority to US13/339,911 priority patent/US8920887B2/en
Publication of JP2012155820A publication Critical patent/JP2012155820A/ja
Publication of JP2012155820A5 publication Critical patent/JP2012155820A5/ja
Application granted granted Critical
Publication of JP5587219B2 publication Critical patent/JP5587219B2/ja
Active legal-status Critical Current
Anticipated expiration legal-status Critical
