JP6266240B2 - ランプユニット及び車両用照明システム - Google Patents

ランプユニット及び車両用照明システム Download PDF

Info

Publication number
JP6266240B2
JP6266240B2 JP2013146136A JP2013146136A JP6266240B2 JP 6266240 B2 JP6266240 B2 JP 6266240B2 JP 2013146136 A JP2013146136 A JP 2013146136A JP 2013146136 A JP2013146136 A JP 2013146136A JP 6266240 B2 JP6266240 B2 JP 6266240B2
Authority
JP
Japan
Prior art keywords
light source
substrate
light
source array
lamp unit
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Active
Application number
JP2013146136A
Other languages
English (en)
Japanese (ja)
Other versions
JP2014019436A5 (OSRAM
JP2014019436A (ja
Inventor
チョ・ユンミン
イ・ゴンギョ
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
LG Innotek Co Ltd
Original Assignee
LG Innotek Co Ltd
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by LG Innotek Co Ltd filed Critical LG Innotek Co Ltd
Publication of JP2014019436A publication Critical patent/JP2014019436A/ja
Publication of JP2014019436A5 publication Critical patent/JP2014019436A5/ja
Application granted granted Critical
Publication of JP6266240B2 publication Critical patent/JP6266240B2/ja
Active legal-status Critical Current
Anticipated expiration legal-status Critical

Links

Images

Classifications
