CN111837245A - 发光器件封装 - Google Patents

发光器件封装 Download PDF

Info

Publication number
CN111837245A
CN111837245A CN201880082405.0A CN201880082405A CN111837245A CN 111837245 A CN111837245 A CN 111837245A CN 201880082405 A CN201880082405 A CN 201880082405A CN 111837245 A CN111837245 A CN 111837245A
Authority
CN
China
Prior art keywords
coating layer
layer
reflective layer
reflective
light emitting
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Pending
Application number
CN201880082405.0A
Other languages
English (en)
Chinese (zh)
Inventor
李舒
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
Bright Sharp LLC
Lumileds LLC
Original Assignee
Bright Sharp LLC
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Priority claimed from US15/788,347 external-priority patent/US10672960B2/en
Application filed by Bright Sharp LLC filed Critical Bright Sharp LLC
Publication of CN111837245A publication Critical patent/CN111837245A/zh
Pending legal-status Critical Current

Links

Images

Classifications

    • H—ELECTRICITY
    • H10—SEMICONDUCTOR DEVICES; ELECTRIC SOLID-STATE DEVICES NOT OTHERWISE PROVIDED FOR
    • H10H—INORGANIC LIGHT-EMITTING SEMICONDUCTOR DEVICES HAVING POTENTIAL BARRIERS
    • H10H20/00—Individual inorganic light-emitting semiconductor devices having potential barriers, e.g. light-emitting diodes [LED]
    • H10H20/80—Constructional details
    • H10H20/85—Packages
    • H10H20/852—Encapsulations
    • H10H20/854—Encapsulations characterised by their material, e.g. epoxy or silicone resins
