JP4493646B2 - 後続のターゲット材堆積のためのシリコン基板を改質するバッファ構造および該バッファ構造を形成する方法 - Google Patents

後続のターゲット材堆積のためのシリコン基板を改質するバッファ構造および該バッファ構造を形成する方法 Download PDF

Info

Publication number
JP4493646B2
JP4493646B2 JP2006502270A JP2006502270A JP4493646B2 JP 4493646 B2 JP4493646 B2 JP 4493646B2 JP 2006502270 A JP2006502270 A JP 2006502270A JP 2006502270 A JP2006502270 A JP 2006502270A JP 4493646 B2 JP4493646 B2 JP 4493646B2
Authority
JP
Japan
Prior art keywords
buffer
layer
target material
buffer structure
alloy
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Expired - Fee Related
Application number
JP2006502270A
Other languages
English (en)
Japanese (ja)
Other versions
JP2006518104A5 (enExample
JP2006518104A (ja
Inventor
ウオーリス，デイビツド・ジヨン
Original Assignee
キネテイツク・リミテツド
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by キネテイツク・リミテツド filed Critical キネテイツク・リミテツド
Publication of JP2006518104A publication Critical patent/JP2006518104A/ja
Publication of JP2006518104A5 publication Critical patent/JP2006518104A5/ja
Application granted granted Critical
Publication of JP4493646B2 publication Critical patent/JP4493646B2/ja
Anticipated expiration legal-status Critical
Expired - Fee Related legal-status Critical Current
