JP2012527199A - バランスｉ／ｑ変換器を用いる受信機 - Google Patents

バランスｉ／ｑ変換器を用いる受信機 Download PDF

Info

Publication number
JP2012527199A
JP2012527199A JP2012511065A JP2012511065A JP2012527199A JP 2012527199 A JP2012527199 A JP 2012527199A JP 2012511065 A JP2012511065 A JP 2012511065A JP 2012511065 A JP2012511065 A JP 2012511065A JP 2012527199 A JP2012527199 A JP 2012527199A
Authority
JP
Japan
Prior art keywords
signal
differential
primary coil
coil
ended
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Pending
Application number
JP2012511065A
Other languages
English (en)
Japanese (ja)
Other versions
JP2012527199A5 (enExample
Inventor
チャン、リ−チュン
バガット、マウリン・ピー．
リ、ハニル
スリダラ、ラビ
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
Qualcomm Inc
Original Assignee
Qualcomm Inc
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by Qualcomm Inc filed Critical Qualcomm Inc
Publication of JP2012527199A publication Critical patent/JP2012527199A/ja
Publication of JP2012527199A5 publication Critical patent/JP2012527199A5/ja
