CN103004571A - Household vertical soil-less cultivation device - Google Patents
Household vertical soil-less cultivation device Download PDFInfo
- Publication number
- CN103004571A CN103004571A CN2012105189487A CN201210518948A CN103004571A CN 103004571 A CN103004571 A CN 103004571A CN 2012105189487 A CN2012105189487 A CN 2012105189487A CN 201210518948 A CN201210518948 A CN 201210518948A CN 103004571 A CN103004571 A CN 103004571A
- Authority
- CN
- China
- Prior art keywords
- filler
- soil
- frame support
- frame
- shaped bracket
- Prior art date
- Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
- Pending
Links
- 239000000945 filler Substances 0.000 claims abstract description 21
- 239000002689 soil Substances 0.000 claims abstract description 19
- 235000015097 nutrients Nutrition 0.000 claims abstract description 5
- 239000012530 fluid Substances 0.000 claims description 8
- 239000000463 material Substances 0.000 claims description 3
- 229920000915 polyvinyl chloride Polymers 0.000 claims description 3
- 239000007788 liquid Substances 0.000 abstract description 8
- 241000238631 Hexapoda Species 0.000 abstract description 5
- 241000894006 Bacteria Species 0.000 abstract description 4
- 238000005034 decoration Methods 0.000 abstract description 2
- 230000001488 breeding Effects 0.000 abstract 1
- 235000013311 vegetables Nutrition 0.000 description 3
- 241001464837 Viridiplantae Species 0.000 description 1
- 201000010099 disease Diseases 0.000 description 1
- 238000011031 large scale production Methods 0.000 description 1
- 238000004519 manufacturing process Methods 0.000 description 1
- 239000003595 mist Substances 0.000 description 1
- 235000016709 nutrition Nutrition 0.000 description 1
- 230000035764 nutrition Effects 0.000 description 1
- 235000008935 nutritious Nutrition 0.000 description 1
- 230000029058 respiratory gaseous exchange Effects 0.000 description 1
- 239000000758 substrate Substances 0.000 description 1
Classifications
-
- Y—GENERAL TAGGING OF NEW TECHNOLOGICAL DEVELOPMENTS; GENERAL TAGGING OF CROSS-SECTIONAL TECHNOLOGIES SPANNING OVER SEVERAL SECTIONS OF THE IPC; TECHNICAL SUBJECTS COVERED BY FORMER USPC CROSS-REFERENCE ART COLLECTIONS [XRACs] AND DIGESTS
- Y02—TECHNOLOGIES OR APPLICATIONS FOR MITIGATION OR ADAPTATION AGAINST CLIMATE CHANGE
- Y02P—CLIMATE CHANGE MITIGATION TECHNOLOGIES IN THE PRODUCTION OR PROCESSING OF GOODS
- Y02P60/00—Technologies relating to agriculture, livestock or agroalimentary industries
- Y02P60/20—Reduction of greenhouse gas [GHG] emissions in agriculture, e.g. CO2
- Y02P60/21—Dinitrogen oxide [N2O], e.g. using aquaponics, hydroponics or efficiency measures
Abstract
The invention relates to a household vertical soil-less cultivation device, which comprises a liquid storage tank, a liquid supply pump, a pipeline, a frame-shaped bracket and a filler. A cultivation groove is reserved in the middle part of the front surface of the frame-shaped bracket. The filler is filled in the frame-shaped bracket, and consists of two pieces of which an interface is overlapped with the centerline of the cultivation groove. The lower end of the frame-shaped bracket and the liquid supply pump are arranged in the liquid storage tank. Nutrient liquid in the liquid supply pump reaches the filler through the pipeline and a liquid inlet hole in the upper end of the frame-shaped bracket. A plurality of cultivated plants are clamped in the interface of the filler. The problems of high bacterium and insect breeding rate, inconvenience for soil maintenance and high environment pollution rate of soil cultivation are solved; the purchase cost is saved, a floor space is reduced, and the device can be used for realizing three-dimensional planting; and the bracket is attractive and elegant in appearance, and can be integrated with indoor furniture to realize a good decoration function. The invention is applied to soil-less cultivation devices on balconies and roofs and in rooms.
Description
Technical field
The present invention relates to a kind of cultivation apparatus without soil, particularly relate to a kind of Household vertical cultivation apparatus without soil.
Background technology
Soilless culture refers to utilize non-soil-medium to cultivate the method for plant, mainly comprises water planting, mist training, substrate culture.Soilless culture have good quality and high output, product damage by disease and insect few, be not subjected to the land resources restriction, be convenient to the advantage such as large-scale production, the problems such as existing cultivation apparatus without soil can fine solution plant root adheres to, breathing, moisture supply, nutrition supply.At present, traditional balcony or indoor growing vegetables all are by flowerpot the soil cultivation to be arranged, and exist easy breed bacteria, insect, soil maintenance inconvenience, the problems such as easy contaminated environment, the especially winter in the north, except balcony and indoor pot flowers, some months be can not see green plant basically.
At present, introduce existing the delivering of patent of cultivation apparatus without soil, such as the Chinese utility model patent of patent No. ZL201120184114.8---it is high that a kind of Simple vegetable soilless culture device of household balcony exists price; The Chinese utility model patent of patent No. ZL201020143348.3---balcony or indoor soilless culture device exist complex structure, poor operability; The Chinese invention patent of patent No. ZL200910232740.7---a kind of wall type soilless culture method for vegetables is applicable to plant layout production, is not suitable for the family expenses cultivation.
Summary of the invention
The object of the present invention is to provide a kind of Household vertical cultivation apparatus without soil, solving family has the easy breed bacteria of soil cultivation, insect, soil maintenance inconvenience, the problems such as easy contaminated environment.
In order to achieve the above object, the technical solution used in the present invention is:
Comprise fluid storage tank, solution feed pump, pipeline, frame support and filler; Have a cultivating groove in the middle of the frame support front, be filled with filler in the frame support, filler consists of by two, the central lines of its interface and cultivating groove, the lower end of frame support and solution feed pump are all put into fluid storage tank, nutrient solution in the solution feed pump is through the inlet opening access filler of the upper end of pipeline and frame support, and a plurality of cultivated plants are clamped in the interface of filler.
Described frame support is that PVC sheet material surrounds, and it is shaped as square cylinder, rectangular cylinder or cylindrical.
All there is inlet opening both sides, described frame support upper end, and pipeline can be in arbitrary inlet opening access of both sides.
Described frame support has fixing hole in the middle of the upper end.
Compare with background technology, the beneficial effect that the present invention has is:
1, solution has the easy breed bacteria of soil cultivation, insect, soil maintenance inconvenience, the problems such as easy contaminated environment.
2, save purchase cost, reduce floor space, realize the three-dimensional plantation.
3, support Design is elegant in appearance, and selection is various, can combine together with indoor furniture, plays good decoration function.
The present invention is applicable to the cultivation apparatus without soil on balcony, indoor, roof.
Description of drawings
Fig. 1 is front view of the present invention.
Fig. 2 is the vertical view of Fig. 1.
Among the figure: 1. fluid storage tank, 2. solution feed pump, 3. pipeline, 4. frame support, 5. filler, 6. cultivated plant, 7. fixing hole.
Embodiment
The present invention is further illustrated below in conjunction with drawings and embodiments.
As shown in Figure 1 and Figure 2, the present invention includes fluid storage tank 1, solution feed pump 2, pipeline 3, frame support 4 and filler 5; The frame support 4 positive middle cultivating grooves that have, be filled with filler 5 in the frame support 4, filler 5 consists of by two, the central lines of its interface and cultivating groove, the lower end of frame support 4 and solution feed pump 2 are all put into fluid storage tank 1, nutrient solution in the solution feed pump 2 is through the inlet opening access filler 5 of the upper end of pipeline 3 and frame support 4, and a plurality of cultivated plants 6 are clamped in the interface of filler 5.
Frame support 4 surrounds for PVC sheet material, and it is shaped as square cylinder, rectangular cylinder or cylindrical.
All there is inlet opening both sides, frame support 4 upper end, and pipeline 3 can be in arbitrary inlet opening access of both sides.
Have fixing hole 7 in the middle of frame support 4 upper ends, frame support 4 is screwed in wall or other fixture place by fixing hole 7.
Filler 5 is the ventilative black sponge in the large aperture that can store nutrient solution.
Operation principle of the present invention is:
Fluid storage tank 1 interior nutritious liquid utilizes solution feed pump 2 by pipeline 3 pouring cultivated plants 6.
Above-described embodiment only is giving an example of the specific embodiment of the invention, and protection scope of the present invention is as the criterion with claims.Any according to the present patent application equivalent substitute that claim is done and variation, all belong to the protection domain of patent of the present invention.
Claims (4)
1. a Household vertical cultivation apparatus without soil is characterized in that: comprise fluid storage tank (1), solution feed pump (2), pipeline (3), frame support (4) and filler (5); Have a cultivating groove in the middle of frame support (4) is positive, be filled with filler (5) in the frame support (4), filler (5) consists of by two, the central lines of its interface and cultivating groove, the lower end of frame support (4) and solution feed pump (2) are all put into fluid storage tank (1), nutrient solution in the solution feed pump (2) is through the inlet opening access filler (5) of the upper end of pipeline (3) and frame support (4), and a plurality of cultivated plants (6) are clamped in the interface of filler (5).
2. according to claims 1 described a kind of Household vertical cultivation apparatus without soil, it is characterized in that: described frame support (4) surrounds for PVC sheet material, and it is shaped as square cylinder, rectangular cylinder or cylindrical.
3. according to claims 1 described a kind of Household vertical cultivation apparatus without soil, it is characterized in that: all there is inlet opening both sides, described frame support (4) upper end, and pipeline (3) can be in arbitrary inlet opening access of both sides.
4. according to claims 1 described a kind of Household vertical cultivation apparatus without soil, it is characterized in that: described frame support (4) has fixing hole in the middle of the upper end.
