CN101421557B - 用于引导照明的光学装置 - Google Patents

用于引导照明的光学装置 Download PDF

Info

Publication number
CN101421557B
CN101421557B CN2007800130643A CN200780013064A CN101421557B CN 101421557 B CN101421557 B CN 101421557B CN 2007800130643 A CN2007800130643 A CN 2007800130643A CN 200780013064 A CN200780013064 A CN 200780013064A CN 101421557 B CN101421557 B CN 101421557B
Authority
CN
China
Prior art keywords
light
angle
ramp
structures
axis
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Expired - Fee Related
Application number
CN2007800130643A
Other languages
English (en)
Chinese (zh)
Other versions
CN101421557A (zh
Inventor
S·H·查克马可吉安
D·J·谢尔特勒
T·塞尔斯
M·G·莫里斯
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
RPC Photonics Inc
Original Assignee
RPC Photonics Inc
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by RPC Photonics Inc filed Critical RPC Photonics Inc
Publication of CN101421557A publication Critical patent/CN101421557A/zh
Application granted granted Critical
Publication of CN101421557B publication Critical patent/CN101421557B/zh
Expired - Fee Related legal-status Critical Current
Anticipated expiration legal-status Critical

Links

Images

Classifications
