KR20140033173A - 상이하게 패턴 경화된 미세구조화 용품을 제조하는 방법 - Google Patents

상이하게 패턴 경화된 미세구조화 용품을 제조하는 방법 Download PDF

Info

Publication number
KR20140033173A
KR20140033173A KR1020137034710A KR20137034710A KR20140033173A KR 20140033173 A KR20140033173 A KR 20140033173A KR 1020137034710 A KR1020137034710 A KR 1020137034710A KR 20137034710 A KR20137034710 A KR 20137034710A KR 20140033173 A KR20140033173 A KR 20140033173A
Authority
KR
South Korea
Prior art keywords
region
radiation
patterned
radiation curable
curable resin
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Abandoned
Application number
KR1020137034710A
Other languages
English (en)
Korean (ko)
Inventor
올스터 이세 벤슨
캐스린 엠 스퍼전
스티븐 알 반후스
타데스 지 니가투
Original Assignee
쓰리엠 이노베이티브 프로퍼티즈 캄파니
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by 쓰리엠 이노베이티브 프로퍼티즈 캄파니 filed Critical 쓰리엠 이노베이티브 프로퍼티즈 캄파니
Publication of KR20140033173A publication Critical patent/KR20140033173A/ko
