JP6637312B2 - 温度管理を備えるランプヘッドを有する基板処理システム - Google Patents

温度管理を備えるランプヘッドを有する基板処理システム Download PDF

Info

Publication number
JP6637312B2
JP6637312B2 JP2015509061A JP2015509061A JP6637312B2 JP 6637312 B2 JP6637312 B2 JP 6637312B2 JP 2015509061 A JP2015509061 A JP 2015509061A JP 2015509061 A JP2015509061 A JP 2015509061A JP 6637312 B2 JP6637312 B2 JP 6637312B2
Authority
JP
Japan
Prior art keywords
lamp
passages
reflector
structural member
disposed
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Active
Application number
JP2015509061A
Other languages
English (en)
Japanese (ja)
Other versions
JP2015522939A5 (enExample
JP2015522939A (ja
Inventor
ジョゼフ エム． ラニッシュ，
ジョゼフ エム． ラニッシュ，
ポール ブリルハート，
ポール ブリルハート，
サティシュ クップラオ，
サティシュ クップラオ，
トンミン イウ，
トンミン イウ，
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
Applied Materials Inc
Original Assignee
Applied Materials Inc
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by Applied Materials Inc filed Critical Applied Materials Inc
Publication of JP2015522939A publication Critical patent/JP2015522939A/ja
Publication of JP2015522939A5 publication Critical patent/JP2015522939A5/ja
Application granted granted Critical
Publication of JP6637312B2 publication Critical patent/JP6637312B2/ja
