JP5203293B2 - 表示装置および電子機器 - Google Patents

表示装置および電子機器 Download PDF

Info

Publication number
JP5203293B2
JP5203293B2 JP2009123261A JP2009123261A JP5203293B2 JP 5203293 B2 JP5203293 B2 JP 5203293B2 JP 2009123261 A JP2009123261 A JP 2009123261A JP 2009123261 A JP2009123261 A JP 2009123261A JP 5203293 B2 JP5203293 B2 JP 5203293B2
Authority
JP
Japan
Prior art keywords
electrode
detection
signal
display
display device
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Expired - Fee Related
Application number
JP2009123261A
Other languages
English (en)
Japanese (ja)
Other versions
JP2010271925A5 (enExample
JP2010271925A (ja
Inventor
幸治 野口
貴之 中西
剛司 石崎
剛也 竹内
康幸 寺西
Original Assignee
株式会社ジャパンディスプレイウェスト
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by 株式会社ジャパンディスプレイウェスト filed Critical 株式会社ジャパンディスプレイウェスト
Priority to JP2009123261A priority Critical patent/JP5203293B2/ja
Priority to US12/765,592 priority patent/US8976123B2/en
Priority to CN2010101809509A priority patent/CN101893957B/zh
Publication of JP2010271925A publication Critical patent/JP2010271925A/ja
Publication of JP2010271925A5 publication Critical patent/JP2010271925A5/ja
Application granted granted Critical
Publication of JP5203293B2 publication Critical patent/JP5203293B2/ja
Priority to US14/606,818 priority patent/US20150199051A1/en
Expired - Fee Related legal-status Critical Current
Anticipated expiration legal-status Critical
