JP4129687B2 - マニュアル釦付き電磁弁 - Google Patents

マニュアル釦付き電磁弁 Download PDF

Info

Publication number
JP4129687B2
JP4129687B2 JP2004127129A JP2004127129A JP4129687B2 JP 4129687 B2 JP4129687 B2 JP 4129687B2 JP 2004127129 A JP2004127129 A JP 2004127129A JP 2004127129 A JP2004127129 A JP 2004127129A JP 4129687 B2 JP4129687 B2 JP 4129687B2
Authority
JP
Japan
Prior art keywords
manual button
lock
manual
safety member
pilot
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Expired - Lifetime
Application number
JP2004127129A
Other languages
English (en)
Japanese (ja)
Other versions
JP2005308125A5 (enExample
JP2005308125A (ja
Inventor
真司 宮添
克之 仙波
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
SMC Corp
Original Assignee
SMC Corp
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by SMC Corp filed Critical SMC Corp
Priority to JP2004127129A priority Critical patent/JP4129687B2/ja
Priority to US11/054,382 priority patent/US7316244B2/en
Priority to TW94105904A priority patent/TWI293672B/zh
Priority to CNB2005100542877A priority patent/CN100386545C/zh
Priority to DE200510015201 priority patent/DE102005015201B4/de
Priority to KR1020050033109A priority patent/KR100718885B1/ko
Publication of JP2005308125A publication Critical patent/JP2005308125A/ja
Publication of JP2005308125A5 publication Critical patent/JP2005308125A5/ja
Application granted granted Critical
Publication of JP4129687B2 publication Critical patent/JP4129687B2/ja
