CN102272974B - 具有边缘光提取的拼接oled装置 - Google Patents

具有边缘光提取的拼接oled装置 Download PDF

Info

Publication number
CN102272974B
CN102272974B CN200980154398.1A CN200980154398A CN102272974B CN 102272974 B CN102272974 B CN 102272974B CN 200980154398 A CN200980154398 A CN 200980154398A CN 102272974 B CN102272974 B CN 102272974B
Authority
CN
China
Prior art keywords
edge
substrate
area
light
pixels
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Active
Application number
CN200980154398.1A
Other languages
English (en)
Chinese (zh)
Other versions
CN102272974A (zh
Inventor
迈克尔·尤金·米勒
约翰·威廉·哈默
罗纳德·史蒂文·科克
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
Global OLED Technology LLC
Original Assignee
Global OLED Technology LLC
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by Global OLED Technology LLC filed Critical Global OLED Technology LLC
Publication of CN102272974A publication Critical patent/CN102272974A/zh
Application granted granted Critical
Publication of CN102272974B publication Critical patent/CN102272974B/zh
Active legal-status Critical Current
Anticipated expiration legal-status Critical

Links

Images

Classifications

    • H—ELECTRICITY
    • H10—SEMICONDUCTOR DEVICES; ELECTRIC SOLID-STATE DEVICES NOT OTHERWISE PROVIDED FOR
    • H10K—ORGANIC ELECTRIC SOLID-STATE DEVICES
    • H10K59/00—Integrated devices, or assemblies of multiple devices, comprising at least one organic light-emitting element covered by group H10K50/00
    • H10K59/10—OLED displays
    • H10K59/18—Tiled displays
    • H—ELECTRICITY
    • H10—SEMICONDUCTOR DEVICES; ELECTRIC SOLID-STATE DEVICES NOT OTHERWISE PROVIDED FOR
    • H10K—ORGANIC ELECTRIC SOLID-STATE DEVICES
    • H10K50/00—Organic light-emitting devices
    • H10K50/80—Constructional details
    • H10K50/85—Arrangements for extracting light from the devices
    • H—ELECTRICITY
    • H10—SEMICONDUCTOR DEVICES; ELECTRIC SOLID-STATE DEVICES NOT OTHERWISE PROVIDED FOR
    • H10K—ORGANIC ELECTRIC SOLID-STATE DEVICES
    • H10K50/00—Organic light-emitting devices
    • H10K50/80—Constructional details
    • H10K50/85—Arrangements for extracting light from the devices
    • H10K50/854—Arrangements for extracting light from the devices comprising scattering means
    • H—ELECTRICITY
    • H10—SEMICONDUCTOR DEVICES; ELECTRIC SOLID-STATE DEVICES NOT OTHERWISE PROVIDED FOR
    • H10K—ORGANIC ELECTRIC SOLID-STATE DEVICES
    • H10K50/00—Organic light-emitting devices
    • H10K50/80—Constructional details
    • H10K50/85—Arrangements for extracting light from the devices
    • H10K50/856—Arrangements for extracting light from the devices comprising reflective means
    • H—ELECTRICITY
    • H10—SEMICONDUCTOR DEVICES; ELECTRIC SOLID-STATE DEVICES NOT OTHERWISE PROVIDED FOR
    • H10K—ORGANIC ELECTRIC SOLID-STATE DEVICES
    • H10K59/00—Integrated devices, or assemblies of multiple devices, comprising at least one organic light-emitting element covered by group H10K50/00
    • H10K59/80—Constructional details
    • H10K59/875—Arrangements for extracting light from the devices
    • H10K59/877—Arrangements for extracting light from the devices comprising scattering means
    • H—ELECTRICITY
    • H10—SEMICONDUCTOR DEVICES; ELECTRIC SOLID-STATE DEVICES NOT OTHERWISE PROVIDED FOR
    • H10K—ORGANIC ELECTRIC SOLID-STATE DEVICES
    • H10K59/00—Integrated devices, or assemblies of multiple devices, comprising at least one organic light-emitting element covered by group H10K50/00
    • H10K59/80—Constructional details
    • H10K59/875—Arrangements for extracting light from the devices
    • H10K59/878—Arrangements for extracting light from the devices comprising reflective means
    • H—ELECTRICITY
    • H10—SEMICONDUCTOR DEVICES; ELECTRIC SOLID-STATE DEVICES NOT OTHERWISE PROVIDED FOR
    • H10K—ORGANIC ELECTRIC SOLID-STATE DEVICES
    • H10K59/00—Integrated devices, or assemblies of multiple devices, comprising at least one organic light-emitting element covered by group H10K50/00
    • H10K59/80—Constructional details
    • H10K59/875—Arrangements for extracting light from the devices
    • H10K59/879—Arrangements for extracting light from the devices comprising refractive means, e.g. lenses
    • H—ELECTRICITY
    • H10—SEMICONDUCTOR DEVICES; ELECTRIC SOLID-STATE DEVICES NOT OTHERWISE PROVIDED FOR
    • H10K—ORGANIC ELECTRIC SOLID-STATE DEVICES
    • H10K59/00—Integrated devices, or assemblies of multiple devices, comprising at least one organic light-emitting element covered by group H10K50/00
    • H10K59/80—Constructional details
    • H10K59/8791—Arrangements for improving contrast, e.g. preventing reflection of ambient light

Landscapes

  • Physics & Mathematics (AREA)
  • Optics & Photonics (AREA)
  • Electroluminescent Light Sources (AREA)
CN200980154398.1A 2008-11-17 2009-11-03 具有边缘光提取的拼接oled装置 Active CN102272974B (zh)

Applications Claiming Priority (3)

Application Number Priority Date Filing Date Title
US12/271,978 US8222804B2 (en) 2008-11-17 2008-11-17 Tiled OLED device with edge light extraction
US12/271,978 2008-11-17
PCT/US2009/005947 WO2010056288A1 (en) 2008-11-17 2009-11-03 Tiled oled device with edge light extraction

Publications (2)

Publication Number Publication Date
CN102272974A CN102272974A (zh) 2011-12-07
CN102272974B true CN102272974B (zh) 2014-03-12

Family

ID=41664783

Family Applications (1)

Application Number Title Priority Date Filing Date
CN200980154398.1A Active CN102272974B (zh) 2008-11-17 2009-11-03 具有边缘光提取的拼接oled装置

Country Status (6)

Country Link
US (1) US8222804B2 (enExample)
EP (1) EP2359421B1 (enExample)
JP (1) JP5242803B2 (enExample)
KR (1) KR101231109B1 (enExample)
CN (1) CN102272974B (enExample)
WO (1) WO2010056288A1 (enExample)
