RU2562889C1 - Подшипник скольжения из синтетической смолы - Google Patents

Подшипник скольжения из синтетической смолы Download PDF

Info

Publication number
RU2562889C1
RU2562889C1 RU2014117262/11A RU2014117262A RU2562889C1 RU 2562889 C1 RU2562889 C1 RU 2562889C1 RU 2014117262/11 A RU2014117262/11 A RU 2014117262/11A RU 2014117262 A RU2014117262 A RU 2014117262A RU 2562889 C1 RU2562889 C1 RU 2562889C1
Authority
RU
Russia
Prior art keywords
annular
cylindrical
synthetic resin
inner peripheral
outer peripheral
Prior art date
Application number
RU2014117262/11A
Other languages
English (en)
Russian (ru)
Inventor
Коуичи МОРИШИГЕ
Такаши ХОРИГУЧИ
Original Assignee
Оилз Корпорейшн
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by Оилз Корпорейшн filed Critical Оилз Корпорейшн
Application granted granted Critical
Publication of RU2562889C1 publication Critical patent/RU2562889C1/ru
