KR20160105442A - 시준 반사 편광기를 포함하는 광학 필름 - Google Patents

시준 반사 편광기를 포함하는 광학 필름 Download PDF

Info

Publication number
KR20160105442A
KR20160105442A KR1020167020406A KR20167020406A KR20160105442A KR 20160105442 A KR20160105442 A KR 20160105442A KR 1020167020406 A KR1020167020406 A KR 1020167020406A KR 20167020406 A KR20167020406 A KR 20167020406A KR 20160105442 A KR20160105442 A KR 20160105442A
Authority
KR
South Korea
Prior art keywords
optical film
optical
reflective polarizer
light
array
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Withdrawn
Application number
KR1020167020406A
Other languages
English (en)
Korean (ko)
Inventor
종석 신
Original Assignee
쓰리엠 이노베이티브 프로퍼티즈 컴파니
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by 쓰리엠 이노베이티브 프로퍼티즈 컴파니 filed Critical 쓰리엠 이노베이티브 프로퍼티즈 컴파니
Publication of KR20160105442A publication Critical patent/KR20160105442A/ko
