KR20140018742A - 백라이트 유닛 및 이를 갖는 표시 장치 - Google Patents

백라이트 유닛 및 이를 갖는 표시 장치 Download PDF

Info

Publication number
KR20140018742A
KR20140018742A KR1020120085384A KR20120085384A KR20140018742A KR 20140018742 A KR20140018742 A KR 20140018742A KR 1020120085384 A KR1020120085384 A KR 1020120085384A KR 20120085384 A KR20120085384 A KR 20120085384A KR 20140018742 A KR20140018742 A KR 20140018742A
Authority
KR
South Korea
Prior art keywords
light
protrusion
region
incident
guide plate
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Ceased
Application number
KR1020120085384A
Other languages
English (en)
Korean (ko)
Inventor
김형주
하상우
남지은
류태용
최진성
Original Assignee
삼성디스플레이 주식회사
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by 삼성디스플레이 주식회사 filed Critical 삼성디스플레이 주식회사
Priority to KR1020120085384A priority Critical patent/KR20140018742A/ko
Priority to US13/755,327 priority patent/US9291765B2/en
Priority to EP13157367.7A priority patent/EP2693115A3/en
Priority to CN201310180686.2A priority patent/CN103576381B/zh
Priority to JP2013112543A priority patent/JP6178114B2/ja
Publication of KR20140018742A publication Critical patent/KR20140018742A/ko
Ceased legal-status Critical Current
