CN1662852B - 多层光刻模板 - Google Patents

多层光刻模板 Download PDF

Info

Publication number
CN1662852B
CN1662852B CN038141620A CN03814162A CN1662852B CN 1662852 B CN1662852 B CN 1662852B CN 038141620 A CN038141620 A CN 038141620A CN 03814162 A CN03814162 A CN 03814162A CN 1662852 B CN1662852 B CN 1662852B
Authority
CN
China
Prior art keywords
layer
patterning
template
patterned layer
etch stop
