KR900006877B1 - 내연기관의 점화시기 제어장치 - Google Patents

내연기관의 점화시기 제어장치 Download PDF

Info

Publication number
KR900006877B1
KR900006877B1 KR1019870014600A KR870014600A KR900006877B1 KR 900006877 B1 KR900006877 B1 KR 900006877B1 KR 1019870014600 A KR1019870014600 A KR 1019870014600A KR 870014600 A KR870014600 A KR 870014600A KR 900006877 B1 KR900006877 B1 KR 900006877B1
Authority
KR
South Korea
Prior art keywords
output
knock
ignition
cylinder
voltage
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Expired
Application number
KR1019870014600A
Other languages
English (en)
Korean (ko)
Other versions
KR880007918A (ko
Inventor
사끼 사또시 고무라
Original Assignee
미쯔비시덴끼 가부시끼가이샤
시끼 모리야
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Priority claimed from JP61307387A external-priority patent/JPS63159668A/ja
Priority claimed from JP62010779A external-priority patent/JPS63179177A/ja
Application filed by 미쯔비시덴끼 가부시끼가이샤, 시끼 모리야 filed Critical 미쯔비시덴끼 가부시끼가이샤
Publication of KR880007918A publication Critical patent/KR880007918A/ko
Application granted granted Critical
Publication of KR900006877B1 publication Critical patent/KR900006877B1/ko
