KR20180088798A - 얇은 솔더 정지 층을 갖는 전기 디바이스 및 제조를 위한 방법 - Google Patents

얇은 솔더 정지 층을 갖는 전기 디바이스 및 제조를 위한 방법 Download PDF

Info

Publication number
KR20180088798A
KR20180088798A KR1020187011776A KR20187011776A KR20180088798A KR 20180088798 A KR20180088798 A KR 20180088798A KR 1020187011776 A KR1020187011776 A KR 1020187011776A KR 20187011776 A KR20187011776 A KR 20187011776A KR 20180088798 A KR20180088798 A KR 20180088798A
Authority
KR
South Korea
Prior art keywords
stop layer
carrier
solder stop
lss
top surface
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Ceased
Application number
KR1020187011776A
Other languages
English (en)
Korean (ko)
Inventor
알렉산더 슈마예브
Original Assignee
스냅트랙, 인코포레이티드
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by 스냅트랙, 인코포레이티드 filed Critical 스냅트랙, 인코포레이티드
Publication of KR20180088798A publication Critical patent/KR20180088798A/ko
Ceased legal-status Critical Current

Links
