KR20140103172A - 광학 필름 스택 - Google Patents

광학 필름 스택 Download PDF

Info

Publication number
KR20140103172A
KR20140103172A KR1020147019766A KR20147019766A KR20140103172A KR 20140103172 A KR20140103172 A KR 20140103172A KR 1020147019766 A KR1020147019766 A KR 1020147019766A KR 20147019766 A KR20147019766 A KR 20147019766A KR 20140103172 A KR20140103172 A KR 20140103172A
Authority
KR
South Korea
Prior art keywords
light
directing film
diffuser
asymmetric
light directing
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Abandoned
Application number
KR1020147019766A
Other languages
English (en)
Korean (ko)
Inventor
게리 티 보이드
칭빙 왕
트라이 디 팜
Original Assignee
쓰리엠 이노베이티브 프로퍼티즈 컴파니
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by 쓰리엠 이노베이티브 프로퍼티즈 컴파니 filed Critical 쓰리엠 이노베이티브 프로퍼티즈 컴파니
Publication of KR20140103172A publication Critical patent/KR20140103172A/ko
Abandoned legal-status Critical Current

Links
