JP2010527498A - バッテリーを冷却するシステム及び方法 - Google Patents

バッテリーを冷却するシステム及び方法 Download PDF

Info

Publication number
JP2010527498A
JP2010527498A JP2010507496A JP2010507496A JP2010527498A JP 2010527498 A JP2010527498 A JP 2010527498A JP 2010507496 A JP2010507496 A JP 2010507496A JP 2010507496 A JP2010507496 A JP 2010507496A JP 2010527498 A JP2010527498 A JP 2010527498A
Authority
JP
Japan
Prior art keywords
energy storage
cooling
storage system
storage device
inner casing
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Pending
Application number
JP2010507496A
Other languages
English (en)
Japanese (ja)
Other versions
JP2010527498A5 (enExample
Inventor
クマール，アジス・クッタンナイール
バッティン，ジョン・ディー
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
General Electric Co
Original Assignee
General Electric Co
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by General Electric Co filed Critical General Electric Co
Publication of JP2010527498A publication Critical patent/JP2010527498A/ja
Publication of JP2010527498A5 publication Critical patent/JP2010527498A5/ja
Pending legal-status Critical Current

Links
