KR20170100493A - 도광체를 포함하는 조명 시스템 - Google Patents

도광체를 포함하는 조명 시스템 Download PDF

Info

Publication number
KR20170100493A
KR20170100493A KR1020177014822A KR20177014822A KR20170100493A KR 20170100493 A KR20170100493 A KR 20170100493A KR 1020177014822 A KR1020177014822 A KR 1020177014822A KR 20177014822 A KR20177014822 A KR 20177014822A KR 20170100493 A KR20170100493 A KR 20170100493A
Authority
KR
South Korea
Prior art keywords
light
light guide
extractor
along
extracted
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Withdrawn
Application number
KR1020177014822A
Other languages
English (en)
Korean (ko)
Inventor
타오 리우
마크 이 나피에랄라
Original Assignee
쓰리엠 이노베이티브 프로퍼티즈 컴파니
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by 쓰리엠 이노베이티브 프로퍼티즈 컴파니 filed Critical 쓰리엠 이노베이티브 프로퍼티즈 컴파니
Priority claimed from PCT/US2015/058926 external-priority patent/WO2016077110A1/en
Publication of KR20170100493A publication Critical patent/KR20170100493A/ko
