RU2502962C2 - Способ и устройство для измерения параметра флюида в вибрационном измерителе - Google Patents

Способ и устройство для измерения параметра флюида в вибрационном измерителе Download PDF

Info

Publication number
RU2502962C2
RU2502962C2 RU2011123896/28A RU2011123896A RU2502962C2 RU 2502962 C2 RU2502962 C2 RU 2502962C2 RU 2011123896/28 A RU2011123896/28 A RU 2011123896/28A RU 2011123896 A RU2011123896 A RU 2011123896A RU 2502962 C2 RU2502962 C2 RU 2502962C2
Authority
RU
Russia
Prior art keywords
mass flow
flow rate
fluid
fluid property
density
Prior art date
Application number
RU2011123896/28A
Other languages
English (en)
Russian (ru)
Other versions
RU2011123896A (ru
Inventor
Джоэл ВАЙНШТЕЙН
Марк Джеймс БЕЛЛ
Эндрю Тимоти ПЭТТЕН
Original Assignee
Майкро Моушн, Инк.
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by Майкро Моушн, Инк. filed Critical Майкро Моушн, Инк.
Publication of RU2011123896A publication Critical patent/RU2011123896A/ru
Application granted granted Critical
Publication of RU2502962C2 publication Critical patent/RU2502962C2/ru
