EP1830373A1 - Raw material coal composition for carbon material for electrode in electric double layer capacitor - Google Patents

Raw material coal composition for carbon material for electrode in electric double layer capacitor Download PDF

Info

Publication number
EP1830373A1
EP1830373A1 EP05820126A EP05820126A EP1830373A1 EP 1830373 A1 EP1830373 A1 EP 1830373A1 EP 05820126 A EP05820126 A EP 05820126A EP 05820126 A EP05820126 A EP 05820126A EP 1830373 A1 EP1830373 A1 EP 1830373A1
Authority
EP
European Patent Office
Prior art keywords
raw material
carbon
electrode
double layer
electric double
Prior art date
Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
Granted
Application number
EP05820126A
Other languages
German (de)
French (fr)
Other versions
EP1830373A4 (en
EP1830373B1 (en
Inventor
Tamotsu Nippon Petroleum Refining Co. Ltd. TANO
Shiro Nippon Petroleum Refining Co. Ltd. NAKAMO
Takashi Nippon Petroleum Refining Co. Ltd OYAMA
Hideki c/o Nippon Oil Corporation ONO
Keizou c/o Nippon Oil Corporation IKAI
Kiwamu c/o Nippon Oil Corporation TAKESHITA
Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)
Eneos Corp
Original Assignee
Nippon Oil Corp
Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)
Filing date
Publication date
Application filed by Nippon Oil Corp filed Critical Nippon Oil Corp
Publication of EP1830373A1 publication Critical patent/EP1830373A1/en
Publication of EP1830373A4 publication Critical patent/EP1830373A4/en
Application granted granted Critical
Publication of EP1830373B1 publication Critical patent/EP1830373B1/en
Anticipated expiration legal-status Critical
Expired - Lifetime legal-status Critical Current

Links

Images

Classifications

    • CCHEMISTRY; METALLURGY
    • C01INORGANIC CHEMISTRY
    • C01BNON-METALLIC ELEMENTS; COMPOUNDS THEREOF; METALLOIDS OR COMPOUNDS THEREOF NOT COVERED BY SUBCLASS C01C
    • C01B32/00Carbon; Compounds thereof
    • C01B32/30Active carbon
    • C01B32/312Preparation
    • C01B32/342Preparation characterised by non-gaseous activating agents
    • C01B32/348Metallic compounds
    • CCHEMISTRY; METALLURGY
    • C01INORGANIC CHEMISTRY
    • C01BNON-METALLIC ELEMENTS; COMPOUNDS THEREOF; METALLOIDS OR COMPOUNDS THEREOF NOT COVERED BY SUBCLASS C01C
    • C01B32/00Carbon; Compounds thereof
    • C01B32/30Active carbon
    • C01B32/312Preparation
    • C01B32/318Preparation characterised by the starting materials
    • HELECTRICITY
    • H01ELECTRIC ELEMENTS
    • H01GCAPACITORS; CAPACITORS, RECTIFIERS, DETECTORS, SWITCHING DEVICES, LIGHT-SENSITIVE OR TEMPERATURE-SENSITIVE DEVICES OF THE ELECTROLYTIC TYPE
    • H01G11/00Hybrid capacitors, i.e. capacitors having different positive and negative electrodes; Electric double-layer [EDL] capacitors; Processes for the manufacture thereof or of parts thereof
    • H01G11/22Electrodes
    • HELECTRICITY
    • H01ELECTRIC ELEMENTS
    • H01GCAPACITORS; CAPACITORS, RECTIFIERS, DETECTORS, SWITCHING DEVICES, LIGHT-SENSITIVE OR TEMPERATURE-SENSITIVE DEVICES OF THE ELECTROLYTIC TYPE
    • H01G11/00Hybrid capacitors, i.e. capacitors having different positive and negative electrodes; Electric double-layer [EDL] capacitors; Processes for the manufacture thereof or of parts thereof
    • H01G11/22Electrodes
    • H01G11/30Electrodes characterised by their material
    • H01G11/32Carbon-based
    • H01G11/34Carbon-based characterised by carbonisation or activation of carbon
    • HELECTRICITY
    • H01ELECTRIC ELEMENTS
    • H01GCAPACITORS; CAPACITORS, RECTIFIERS, DETECTORS, SWITCHING DEVICES, LIGHT-SENSITIVE OR TEMPERATURE-SENSITIVE DEVICES OF THE ELECTROLYTIC TYPE
    • H01G11/00Hybrid capacitors, i.e. capacitors having different positive and negative electrodes; Electric double-layer [EDL] capacitors; Processes for the manufacture thereof or of parts thereof
    • H01G11/22Electrodes
    • H01G11/30Electrodes characterised by their material
    • H01G11/32Carbon-based
    • H01G11/44Raw materials therefor, e.g. resins or coal
    • YGENERAL TAGGING OF NEW TECHNOLOGICAL DEVELOPMENTS; GENERAL TAGGING OF CROSS-SECTIONAL TECHNOLOGIES SPANNING OVER SEVERAL SECTIONS OF THE IPC; TECHNICAL SUBJECTS COVERED BY FORMER USPC CROSS-REFERENCE ART COLLECTIONS [XRACs] AND DIGESTS
    • Y02TECHNOLOGIES OR APPLICATIONS FOR MITIGATION OR ADAPTATION AGAINST CLIMATE CHANGE
    • Y02EREDUCTION OF GREENHOUSE GAS [GHG] EMISSIONS, RELATED TO ENERGY GENERATION, TRANSMISSION OR DISTRIBUTION
    • Y02E60/00Enabling technologies; Technologies with a potential or indirect contribution to GHG emissions mitigation
    • Y02E60/13Energy storage using capacitors

Definitions

  • the present invention relates to a raw material carbon composition for a carbon material for an electrode in an electric double layer capacitor (hereinafter referred to as an EDLC), a carbon material for an electrode obtained from the composition, and an electric double layer capacitor using the carbon material as the material for an electrode.
  • an EDLC electric double layer capacitor
  • An example of a conventional method for manufacturing a carbon material for an EDLC electrode is a method in which raw material carbon (pitch) undergoes alkali activation directly or after carbonization (dry distillation).
  • Patent Document 1 Japanese Patent Laid-Open No. 2002-25867 discloses (in the claim 8) a method for manufacturing nonporous carbon containing microcrystalline carbon similar to graphite and having a specific surface area of 270 m 2 /g or smaller and an interlayer distance d 002 of 0.360 to 0.380 for the microcrystalline carbon.
  • the method includes the steps of allowing readily-graphitizing carbon in which multilayer graphite microcrystals have been grown to undergo dry distillation at 700 to 850°C so as to provide calcined carbon, thermally processing the resultant calcined carbon along with a caustic alkali at 800 to 900°C, and removing residual alkali.
  • An EDLC using the carbon electrode obtained in this method has a high electrostatic capacity of 29 F/cc or greater.
  • the EDLC provided in this method uses a carbon material obtained by thermally processing (calcining) petroleum-based needle coke or infusibly-treated pitch as the raw material at 650 to 850°C in a nitrogen stream for 2 to 4 hours followed by activation.
  • Patent Document 4 Japanese Patent Laid-Open No. 2004-182504 proposes a method in which pitch having a crystallite thickness in the c-axis direction Lc(002) of 5.0 nm or greater, which is measured by X-ray diffraction, is carbonized and then activated.
  • the raw material pitch having such characteristics is preferably synthetic pitch, which is obtained by polymerizing fused polycyclic hydrocarbon having at least one alkyl substituent group as the raw material at 100 to 400°C under the presence of hydrogen fluoride and boron trifluoride. It has been also proposed that 5 mass.% of the above synthetic pitch or greater is added to inexpensive pitch having no alkyl substituent group, such as naphthalene pitch and anthracene pitch.
  • Patent Document 5 Japanese Patent Laid-Open No. 2003-51430 discloses a method in which raw material carbon containing microcrystalline carbon having a layered crystal structure similar to graphite is heated to 600 to 900°C and then activated.
  • the raw material carbon used in this method is a raw material carbon composition in which the interlayer distance d 002 determined by X-ray diffraction is 0.343 nm or smaller and the size LC 002 of the crystallites of the microcrystalline carbon determined by X-ray diffraction is 3.0 nm, an EDLC having electrostatic capacity of 30 F/cc or greater is obtained.
  • crystallites determined by X-ray diffraction does not necessarily shomasshe characteristics of the entire bulk of a raw material carbon composition. This will be understood from the description in "Handbook: carbon family” (editor: Michio Inagaki, Agne Shofu Publishing Inc.), "When selective orientation of crystallites is found (selective orientation is found in almost all carbon materials), X-ray diffraction may provide information on limited crystallites.” Probably from this reason, petroleum coke and the like have not particularly been able to develop a high level of electrostatic capacity in a reproducible manner.
  • An object of the present invention is to provide a raw material carbon composition that is converted to a carbon material for an electrode in an electric double layer capacitor that can develop a high level of electrostatic capacity with good reproducibility without producing any synthetic pitch.
  • the present inventors have conducted intensive studies to solve the above problems and found that selective use of a raw material carbon composition that exhibits a specific property in a carbonized region (1000 to 1500°C) provides a carbon material for an EDLC electrode that can develop a high level of electrostatic capacity with good reproducibility.
  • the present invention also relates to a method for manufacturing a raw material carbon composition that is converted to a carbon material for an electrode in an electric double layer capacitor, characterized in that the method comprises steps of:
  • the crystallizability based on RD/TH is a meaning that the entire bulk of the raw material carbon composition is measured, and appropriate adjustment of the crystallizability can provide a carbon material for an EDLC electrode that develops a high level of electrostatic capacity with good reproducibility without producing any synthetic pitch in a stable manner, allowing an EDLC having a high electrostatic capacity of 30 F/cc or greater to be provided.
  • Figure 1 is a graph showing the relationship between RD and TH.
  • the present inventors have investigated the relationship between RD and TH of burned coke from such a viewpoint and found that an unburned carbon material, which is used as an EDLC electrode material, can be made to a carbon material having excellent characteristics by evaluating the crystallizability as burned coke.
  • Figure 1 shows graphs illustrating the relationship between RD and TH when three kinds of raw material carbon compositions (A, B and C) are burned at 1000 to 1500°C in an inert gas atmosphere. As shown in Figure 1, the results for all the kinds fit on respective straight lines, each having a slope of -0.75. RD and TH have been investigated for other raw material carbon compositions using similar approaches, and it has been verified that all results fit on straight lines having slopes of about -0.75.
  • the intercept at which TH% is 0 has been obtained and it is 2.160 or greater, it has been verified that electrostatic capacity higher than conventionally achievable is obtained.
  • an excellent EDLC having an electrostatic capacity of 30 F/cc or greater is obtained. More preferably, the intercept is 2.173 or greater.
  • a raw material carbon composition having such a large intercept can be prepared, for example, by coking heavy hydrocarbon, which contains a minimum amount of impurities such as sulfur and metals and has an appropriate aromaticity, in an appropriate condition.
  • Examples of the "heavy hydrocarbon which has an appropriate aromaticity” include bottom oil in a fluid catalytic cracker for petroleum heavy oil, a vacuum residue (VR) in a vacuum distillation apparatus, and tar of aromatic compounds.
  • a raw material carbon composition having a large intercept in formula (1) is obtained.
  • bottom oil in a fluid catalytic cracker for petroleum heavy oil is mixed with a vacuum residue in a vacuum distillation apparatus to obtain a heavy oil mixture containing a relatively small amount of sulfur and asphaltene.
  • the heavy oil mixture is coked at a temperature of about 400 to 600°C for several hours in an autoclave under pressure (1 MPa, for example), and then a raw material carbon composition defined in the present invention is obtained.
  • Such heavy hydrocarbon has a readily graphitizing property, so that in the coking process, condensed polycyclic aromatic rings produced in the thermal decomposition reaction is stacked to form raw material carbon containing microcrystalline carbon similar to graphite.
  • raw material carbon obtained from such heavy hydrocarbon also has a high readily-graphitizing property as described above.
  • a raw material carbon composition preferably contains such microcrystalline carbon similar to graphite.
  • the inert gas which is an atmospheric gas used in carbonization at 1000 to 1500°C, is not limited to a specific one, but an inert gas typically used in this field, such as nitrogen and argon, is used. To minimize the amount of oxygen, the atmospheric gas is desirably replaced with an inert gas after temporarily reducing the pressure.
  • RD and TH are measured in the following method, but not limited thereto. Other known methods may be used as long as equivalent evaluation is possible.
  • the carbonized specimen is completely combusted at 750°C in an oxygen stream and the amount of water produced from the combusted gas is determined by coulometric titration (Karl Fischer method). ln the Karl Fischer method based on coulometric titration, an electrolyte mainly containing iodide ions, sulfur dioxide, base (RN) and alcohol is poured in a titration cell and then the specimen is put in the titration cell. The moisture in the specimen then reacts according to formula (2).
  • the resultant amount of water is converted into the amount of hydrogen, which is divided by the mass of the specimen used in the measurement so as to calculate the total hydrogen content (TH (mass.%)).
  • RD is measured according to JIS K2151.
  • a carbon material for an EDLC electrode is obtained by activating a raw material carbon composition having the above characteristics.
  • Known conventional methods can be applied to the activation treatment, and examples of which include chemical activation reactions and gas activation reactions.
  • the chemical activation reaction is more preferable, and an activation reaction using an alkali metal compound is particularly preferable. According to such an activation treatment using an alkali metal compound, the alkali metal intrudes between graphite crystal layers and then starts the activation reaction, so that the specific surface area of the resultant carbon material is improved.
  • Various carbonates and hydroxides can be used as the alkali metal compound, and specifically, examples of the carbonates and hydroxides include sodium carbonate, potassium carbonate, potassium hydroxide, sodium hydroxide, lithium hydroxide, rubidium hydroxide and cesium hydroxide. Among them, an alkali metal hydroxide, such as potassium hydroxide and sodium hydroxide, is preferable, and potassium hydroxide is particularly preferable. In addition, two or more kinds of these alkali metal compounds (potassium hydroxide and sodium hydroxide, for example) may be used at the same time.
  • the activation is typically performed by mixing an activation agent, such as an alkali metal compound, with a raw material carbon composition and heating the mixture.
  • the mixing ratio of the raw material carbon composition to the activation agent, such as an alkali metal hydroxide is not limited to a specific value, but the mass ratio between the two (raw material carbon composition : activation agent) is preferably in the range from 1:0.5 to 1:10, more preferably 1:1 to 1:5.
  • the amount of the activation agent such as an alkali metal compound
  • the activation reaction will not sufficiently proceed, so that necessary surface area may not be obtained.
  • a greater amount of the activation agent increases the specific surface area, not only will the activation cost increase but also the activation yield will decrease. In this case, the volume density of the resultant carbon material also tends to decrease, so that electrostatic capacity per unit volume decreases.
  • the heating temperature in the activation treatment is not limited to a specific one.
  • the lower limit of the heating temperature is typically 500°C, preferably 600°C, and the upper limit thereof is typically 1000°C, preferably 900°C, particularly preferably 800°C.
  • the raw material carbon composition according to the present invention is thus activated and then typically undergoes alkali washing, acid washing, rinsing, drying and grinding processes into a carbon material for an EDLC electrode.
  • an alkali metal compound used as the activation agent
  • the amount of the alkali metal left in the carbon material is not limited to a specific value as long as it is lower than the level at which the residual alkali metal adversely affects the resultant EDLC (preferably 1000 ppm or lower).
  • it is typically desirable that the washing is performed in such a way that pH of the washing wastewater is on the order of 7 to 8 and the amount of the alkali metal is minimized.
  • the grinding process is performed in a known method to desirably provide fine particles typically having an average diameter on the order of 0.5 to 50 ⁇ m, preferably 1 to 20 ⁇ m.
  • the EDLC according to the present invention will now be described.
  • the EDLC according to the present invention is characterized in that it comprises electrodes containing a carbon material for an electrode prepared as described above.
  • the electrode is made of, for example, a carbon material for an electrode and a binder, more preferably a conductive agent added thereto.
  • the electrode may also be integrated with a current collector.
  • the binder used herein can be a known binder.
  • the binder include polyolefins such as polyethylene and polypropylene; fluoropolymers such as polytetrafluoroethylene, polyvinylidene fluoride, crosslinked fluoroolefin/vinylether copolymer; cellulose such as carboxymethylcellulose ; vinyl-based polymers such as polyvinyl pyrrolidone and polyvinyl alcohol; and polyacrylic acid.
  • the content of the binder in the electrode is not limited to a specific value, but it is selected as appropriate to be typically within a range from about 0.1 to 30 mass.% with respect to the total amount of the carbon material for an electrode and the binder.
  • the conductive agent examples include powder of carbon black, powdery graphite, titanium oxide, ruthenium oxide and the like.
  • the blending amount of the conductive agent in the electrode which is selected as appropriate according to the purpose of blending, is selected as appropriate to be typically within a range from about 1 to 50 mass.%, preferably about 2 to 30 mass.% with respect to the total amount of the carbon material for an electrode, the binder and the conductive agent.
  • examples of the method to be employed include a method in which a solvent having a property of dissolving the binder is added to the above components and the resultant slurry mixture is uniformly coated on the current collector, and a method in which the above components without any solvent is kneaded and then formed under pressure at normal or elevated temperature.
  • the current collector known materials and shapes can be used.
  • the material of the current collector include metals such as aluminum, titanium, tantalum and nickel, and alloys such as stainless steel.
  • a unit cell of the EDLC according to the present invention is typically formed by using a pair of the above electrodes as positive and negative electrodes, disposing the electrodes in such a way that they face each other with a separator (such as polypropylene-fiber non-woven fabric, glass-fiber non-woven fabric and synthetic cellulose) interposed therebetween, and submerging them in an electrolyte.
  • a separator such as polypropylene-fiber non-woven fabric, glass-fiber non-woven fabric and synthetic cellulose
  • electrolyte known water-based electrolyte and organic electrolyte can be used, and organic electrolyte is more preferably used.
  • organic electrolyte those used as a solvent of an electrolyte in electrochemistry can be used.
  • electrolyte examples include propylene carbonate, ethylene carbonate, butylene carbonate, ⁇ -butyrolactone, sulfolane, sulfolane derivatives, 3-methylsulfolane, 1,2-dimethoxyethane, acetonitrile, glutaronitrile, valeronitrile, dimethylformamide, dimethyl sulfoxide, tetrahydrofuran, dimethoxyethane, methyl formate, dimethyl carbonate, diethyl carbonate and ethyl methyl carbonate. These electrolytes may be mixed for use.
  • a supporting electrolyte in the organic electrolyte is not limited to a specific one, and various supporting electrolytes, such as salts, acids and alkalis typically used in the fields of electrochemistry and batteries, can be used.
  • the supporting electrolyte include inorganic ion salts such as alkali metal salts and alkaline-earth metal salts, quaternary ammonium salts, cyclic quaternary ammonium salts and quaternary phosphonium salts.
  • Preferred examples of the supporting electrolyte include (C 2 H 5 ) 4 NBF 4 , (C 2 H 5 ) 3 (CH 3 )NBF 4 , (C 2 H 5 ) 4 PBF 4 and (C 2 H 5 ) 3 (CH 3 )PBF 4 .
  • the concentration of the salt in the electrolyte is selected as appropriate to be typically within the range from about 0.1 to 5 mol/liter, preferably about 0.5 to 3 mol/liter.
  • a more specific configuration of the EDLC is not limited to a particular one, examples thereof include a coin type in which a pair of thin sheet-like or disc-like (positive and negative) electrodes, each having a thickness of 10 to 500 ⁇ m, with a separator interposed therebetween are housed in a metallic container, a coiled type in which a pair of electrodes are coiled with a separator interposed therebetween, and a stacked type in which a large number of electrode groups are stacked with a separator interposed therebetween.
  • the total hydrogen content (TH) and the true relative density (RD) of a specimen were measured in the following methods:
  • m1 is the mass (g) when the specimen is placed in the pycnometer
  • m2 is the mass (g) of the pycnometer
  • m3 is the mass (g) when the distilled water (at 30°C) is filled in the pycnometer with the specimen placed therein
  • m4 is the mass when the empty pycnometer is filled with the distilled water (at 30°C).
  • the constant 0.99567 is the density of water (g/cm 3 ) at 30°C.
  • the specific surface area of the resultant carbon material was measured using the BET method.
  • Bottom oil in a fluid catalytic cracker for petroleum heavy oil was mixed with a vacuum residue in a vacuum distillation apparatus to provide a heavy oil mixture containing 0.17 mass.% of sulfur and 0.9 mass.% of asphaltene.
  • the heavy oil mixture was coked in an autoclave under a pressure of 1 MPa at 550°C for 2 hours to provide a raw material composition.
  • the resultant raw material carbon composition was burned at 1000 to 1500°C in an inert gas atmosphere and the total hydrogen content and the true relative density were determined. Table 1 shows the results.
  • the raw material carbon composition (100 mass parts) was mixed with potassium hydroxide (200 mass parts).
  • the mixture underwent an activation reaction at 750°C for 1 hour in a nitrogen gas atmosphere.
  • the resultant product repeatedly underwent rinsing and acid washing (using HCl) to remove metal potassium left in the carbon material.
  • the resultant product was then dried to provide a carbon material for an EDLC electrode.
  • the carbon material (80 mass parts) ground into particles having an average diameter of 40 ⁇ m was mixed with carbon black (10 mass parts) and polytetrafluoroethylene powder (10 mass parts). The mixture was kneaded into paste in a mortar. Then, the resultant paste was rolled with a 180 kPa-class roller press into an electrode sheet having a thickness of 200 ⁇ m.
  • the electrode sheet was punched into two discs having a diameter of 16 mm.
  • the discs were subjected to a vacuum dry at 120°C under a pressure of 13.3 Pa (0.1 Torr) for 2 hours, and then underwent vacuum impregnation of an organic electrolyte (propylene carbonate solution of triethylmethylammonium tetrafluoroborate, concentration: 1 mol/liter) in a glove box in a nitrogen atmosphere with a dew point of -85°C.
  • an organic electrolyte propylene carbonate solution of triethylmethylammonium tetrafluoroborate, concentration: 1 mol/liter
  • a glass-fiber separator (Advantec Toyo Kaisha, Ltd., model: GA-200, thickness: 200 ⁇ m) was interposed between the two electrodes, one used as a positive electrode and the other used as a negative electrode, and an aluminum-foil current collector was attached to each end of the electrodes.
  • the assembled structure was then incorporated into a two-electrode cell (Hohsen Corporation).
  • An electric double layer capacitor (coin-type cell) was thus fabricated.
  • Example 1 The activation, the fabrication of the electrode, and the assembly of the cell were conducted in the same way as Example 1 to determine electrostatic capacity except that the raw material carbon composition was prepared according to the following procedure.
  • Bottom oil in a fluid catalytic cracker for petroleum heavy oil was mixed with a vacuum residue in a vacuum distillation apparatus to provide a heavy oil mixture containing 0.26 mass.% of sulfur and 1.5 mass.% of asphaltene.
  • the heavy oil mixture was coked in an autoclave under a pressure of 1 MPa at 550°C for 2 hours to provide the raw material composition.
  • the resultant raw material carbon composition was burned at 1000 to 1500°C in an inert gas atmosphere and the total hydrogen content and the true relative density were determined. Table 1 shows the results.
  • Example 1 The activation, the fabrication of the electrode, and the assembly of the cell were conducted in the same way as Example 1 to determine electrostatic capacity except that the raw material carbon composition was prepared according to the following procedure.
  • Bottom oil in a fluid catalytic cracker for petroleum heavy oil was mixed with a vacuum residue in a vacuum distillation apparatus to provide a heavy oil mixture containing 0.19 mass.% of sulfur and 9.0 mass.% of asphaltene.
  • the heavy oil mixture was coked in an autoclave under a pressure of 1 MPa at 550°C for 2 hours to provide the raw material composition.
  • the resultant raw material carbon composition was burned at 1000 to 1500°C in an inert gas atmosphere and the total hydrogen content and the true relative density were determined. Table 1 shows the results.
  • Example 1 The activation, the fabrication of the electrode, and the assembly of the cell were conducted in the same way as Example 1 to determine electrostatic capacity except that the raw material carbon composition was prepared according to the following procedure. Bottom oil (15 vol.%) in a fluid catalytic cracker for petroleum heavy oil was blended with a vacuum residue (85 vol.%) in a vacuum distillation apparatus (0.18 mass.% of sulfur and 8.5 mass.% of asphaltene). The heavy oil mixture was coked in an autoclave under a pressure of 1MPa at 550°C for 2 hours to provide the raw material composition. The resultant raw material carbon composition was burned at 1000 to 1500°C in an inert gas atmosphere and the total hydrogen content and the true relative density were determined. Table 1 shows the results.
  • Table 1 apparently shows that there is substantially proportional relationship between the intercept and the electrostatic capacity. In particular, when the intercept is 1.170 or greater, it is indicated that a electrostatic capacity of 30 F/cc or more is obtained.

Landscapes

  • Engineering & Computer Science (AREA)
  • Chemical & Material Sciences (AREA)
  • Power Engineering (AREA)
  • Materials Engineering (AREA)
  • Organic Chemistry (AREA)
  • Microelectronics & Electronic Packaging (AREA)
  • Inorganic Chemistry (AREA)
  • Electric Double-Layer Capacitors Or The Like (AREA)
  • Carbon And Carbon Compounds (AREA)

Abstract

The present invention provides a raw material carbon composition that is converted to a carbon material for an electrode in an electric double layer capacitor that can develop a high level of electrostatic capacity with good reproducibility without producing any synthetic pitch. The raw material carbon composition is converted to a carbon material for an electrode in an electric double layer capacitor upon activation treatment and is characterized in that, when the raw material carbon composition is carbonized in an inert gas atmosphere at a temperature of 1000 to 1500°C, the true relative density (RD) and the total hydrogen content (TH%) in the carbonized material obtained after the burning satisfy the following formula (1): RD = - 0.75 TH % + intercept
Figure imga0001

wherein the intercept is 2.160 or greater.

Description

    Technical Field
  • The present invention relates to a raw material carbon composition for a carbon material for an electrode in an electric double layer capacitor (hereinafter referred to as an EDLC), a carbon material for an electrode obtained from the composition, and an electric double layer capacitor using the carbon material as the material for an electrode.
  • Background Art
  • An example of a conventional method for manufacturing a carbon material for an EDLC electrode is a method in which raw material carbon (pitch) undergoes alkali activation directly or after carbonization (dry distillation).
  • A problem with the method in which raw material pitch is directly activated is that an EDLC to be provided has electrostatic capacity only on the order of 20 F/cc. On the other hand, it is known that the method in which raw material pitch is activated after dry distillation provides a high level of electrostatic capacity.
  • For example, Patent Document 1 ( Japanese Patent Laid-Open No. 2002-25867 ) discloses (in the claim 8) a method for manufacturing nonporous carbon containing microcrystalline carbon similar to graphite and having a specific surface area of 270 m2/g or smaller and an interlayer distance d002 of 0.360 to 0.380 for the microcrystalline carbon. The method includes the steps of allowing readily-graphitizing carbon in which multilayer graphite microcrystals have been grown to undergo dry distillation at 700 to 850°C so as to provide calcined carbon, thermally processing the resultant calcined carbon along with a caustic alkali at 800 to 900°C, and removing residual alkali. An EDLC using the carbon electrode obtained in this method has a high electrostatic capacity of 29 F/cc or greater. Specifically, the EDLC provided in this method uses a carbon material obtained by thermally processing (calcining) petroleum-based needle coke or infusibly-treated pitch as the raw material at 650 to 850°C in a nitrogen stream for 2 to 4 hours followed by activation.
  • To manufacture activated carbon for an EDLC electrode by allowing mesophase pitch to undergo an infusibilizing treatment, carbonization and alkali activation, there has been proposed a method in which a massive mesophase pitch undergoes grinding, an infusibilizing treatment, carbonization and alkali activation (Patent Document 2 ( Japanese Patent Laid-Open No. 2001-52972 )). There have been also proposed a method including the steps of thermally processing (at 400 to 800°C) raw material pitch having a softening point of 150 to 350°C, an H/C of 0.5 to 0.9, and an optical anisotropic content of 50% or greater, grinding the thermally-processed pitch into particles having an average diameter of 5 to 90 µm, and activating the resultant particles (at 400 to 900°C) (Patent Document 3 ( Japanese Patent Laid-Open No. 2002-93667 )). These methods provide a carbon material for an electrode in an electric double layer capacitor having a high electrostatic capacity of 30 F/cc or greater. These methods, however, have a disadvantage that the high electrostatic capacity is not reproducibly obtained and hence cannot develop a high level of electrostatic capacity in a stable manner. To solve this problem, Patent Document 4 ( Japanese Patent Laid-Open No. 2004-182504 ) proposes a method in which pitch having a crystallite thickness in the c-axis direction Lc(002) of 5.0 nm or greater, which is measured by X-ray diffraction, is carbonized and then activated. The raw material pitch having such characteristics is preferably synthetic pitch, which is obtained by polymerizing fused polycyclic hydrocarbon having at least one alkyl substituent group as the raw material at 100 to 400°C under the presence of hydrogen fluoride and boron trifluoride. It has been also proposed that 5 mass.% of the above synthetic pitch or greater is added to inexpensive pitch having no alkyl substituent group, such as naphthalene pitch and anthracene pitch.
  • Patent Document 5 ( Japanese Patent Laid-Open No. 2003-51430 ) discloses a method in which raw material carbon containing microcrystalline carbon having a layered crystal structure similar to graphite is heated to 600 to 900°C and then activated. When the raw material carbon used in this method is a raw material carbon composition in which the interlayer distance d002 determined by X-ray diffraction is 0.343 nm or smaller and the size LC002 of the crystallites of the microcrystalline carbon determined by X-ray diffraction is 3.0 nm, an EDLC having electrostatic capacity of 30 F/cc or greater is obtained.
    • Patent Document 1: Japanese Patent Laid-Open No. 2002-25867 (in the claim 8)
    • Patent Document 2: Japanese Patent Laid-Open No. 2001-52972
    • Patent Document 3: Japanese Patent Laid-Open No. 2002-93667
    • Patent Document 4: Japanese Patent Laid-Open No. 2004-182504
    • Patent Document 5: Japanese Patent Laid-Open No. 2003-51430
    Disclosure of the Invention Problems to be solved by the Invention
  • Although the conventional methods provide a high level of electrostatic capacity, inter-lot variation of raw material pitch disadvantageously prevents development of desired characteristics, particularly, a high level of electrostatic capacity with good reproducibility. According to Patent Document 4, although the reproducibility is ensured, the need to manufacture synthetic pitch is disadvantageous in terms of cost.
  • Furthermore, the definition of crystallites determined by X-ray diffraction does not necessarily shomasshe characteristics of the entire bulk of a raw material carbon composition. This will be understood from the description in "Handbook: carbon family" (editor: Michio Inagaki, Agne Shofu Publishing Inc.), "When selective orientation of crystallites is found (selective orientation is found in almost all carbon materials), X-ray diffraction may provide information on limited crystallites." Probably from this reason, petroleum coke and the like have not particularly been able to develop a high level of electrostatic capacity in a reproducible manner.
  • An object of the present invention is to provide a raw material carbon composition that is converted to a carbon material for an electrode in an electric double layer capacitor that can develop a high level of electrostatic capacity with good reproducibility without producing any synthetic pitch.
    Means for Dissolving the Problem
  • The present inventors have conducted intensive studies to solve the above problems and found that selective use of a raw material carbon composition that exhibits a specific property in a carbonized region (1000 to 1500°C) provides a carbon material for an EDLC electrode that can develop a high level of electrostatic capacity with good reproducibility.
  • That is, the present invention relates to a raw material carbon composition that is converted to a carbon material for an electrode in an electric double layer capacitor upon activation treatment characterized in that, when the raw material carbon composition is carbonized in an inert gas atmosphere at a temperature of 1000 to 1500°C, the true relative density (RD) and the total hydrogen content (TH%) in the carbonized material obtained after the burning satisfy the following formula (1): RD = - 0.75 TH % + intercept
    Figure imgb0001

    wherein the intercept is 2.160 or greater.
  • The present invention also relates to a method for manufacturing a raw material carbon composition that is converted to a carbon material for an electrode in an electric double layer capacitor, characterized in that the method comprises steps of:
    • blending multiple kinds of starting raw material oils after adjusting the combination and/or the blending ratio thereof and
    • coking the blended oils to provide a raw material carbon composition that satisfies formula (1) according to claim 1 wherein the intercept is 2.160 or greater.
    Effects of the Invention
  • According to the present invention, the crystallizability based on RD/TH is a meaning that the entire bulk of the raw material carbon composition is measured, and appropriate adjustment of the crystallizability can provide a carbon material for an EDLC electrode that develops a high level of electrostatic capacity with good reproducibility without producing any synthetic pitch in a stable manner, allowing an EDLC having a high electrostatic capacity of 30 F/cc or greater to be provided.
  • Brief Description of the Drawing
  • Figure 1 is a graph showing the relationship between RD and TH.
  • Best Mode for Carrying Out the Invention
  • Although the crystallizability of raw material carbon has conventionally been evaluated by measuring the interlayer distance or the size of crystallites directly in X-ray diffraction, the present inventors have found correlation between the true relative density (RD) and the total hydrogen content (TH) of burned coke in association with the crystallizability of the burned coke.
  • It has been found that the relationship between the values of RD and TH (mass.%) of burned coke greatly differs depending on the kinds of starting raw material oil (a vacuum residue (VR), CLO and the like) and the blending ratio thereof, and that adjustment of these parameters can control the crystallizability of the entire bulk.
  • Furthermore, according to the investigation conducted by the present inventors, it is considered that the influence of the crystallizability similarly affect in raw coke before burning and intermediate processes.
  • The present inventors have investigated the relationship between RD and TH of burned coke from such a viewpoint and found that an unburned carbon material, which is used as an EDLC electrode material, can be made to a carbon material having excellent characteristics by evaluating the crystallizability as burned coke.
  • Figure 1 shows graphs illustrating the relationship between RD and TH when three kinds of raw material carbon compositions (A, B and C) are burned at 1000 to 1500°C in an inert gas atmosphere. As shown in Figure 1, the results for all the kinds fit on respective straight lines, each having a slope of -0.75. RD and TH have been investigated for other raw material carbon compositions using similar approaches, and it has been verified that all results fit on straight lines having slopes of about -0.75.
  • When the intercept at which TH% is 0 has been obtained and it is 2.160 or greater, it has been verified that electrostatic capacity higher than conventionally achievable is obtained. In particular, when a raw material carbon composition having the intercept of 2.170 or greater is used, an excellent EDLC having an electrostatic capacity of 30 F/cc or greater is obtained. More preferably, the intercept is 2.173 or greater.
  • A raw material carbon composition having such a large intercept can be prepared, for example, by coking heavy hydrocarbon, which contains a minimum amount of impurities such as sulfur and metals and has an appropriate aromaticity, in an appropriate condition.
  • Examples of the "heavy hydrocarbon which has an appropriate aromaticity" include bottom oil in a fluid catalytic cracker for petroleum heavy oil, a vacuum residue (VR) in a vacuum distillation apparatus, and tar of aromatic compounds.
  • In the present invention, by appropriately selecting kinds of starting crude oils and the blending ratio thereof, a raw material carbon composition having a large intercept in formula (1) is obtained. For example, bottom oil in a fluid catalytic cracker for petroleum heavy oil is mixed with a vacuum residue in a vacuum distillation apparatus to obtain a heavy oil mixture containing a relatively small amount of sulfur and asphaltene. The heavy oil mixture is coked at a temperature of about 400 to 600°C for several hours in an autoclave under pressure (1 MPa, for example), and then a raw material carbon composition defined in the present invention is obtained.
  • Such heavy hydrocarbon has a readily graphitizing property, so that in the coking process, condensed polycyclic aromatic rings produced in the thermal decomposition reaction is stacked to form raw material carbon containing microcrystalline carbon similar to graphite. Thus, raw material carbon obtained from such heavy hydrocarbon also has a high readily-graphitizing property as described above. In the present invention, in particular, a raw material carbon composition preferably contains such microcrystalline carbon similar to graphite.
  • The inert gas, which is an atmospheric gas used in carbonization at 1000 to 1500°C, is not limited to a specific one, but an inert gas typically used in this field, such as nitrogen and argon, is used. To minimize the amount of oxygen, the atmospheric gas is desirably replaced with an inert gas after temporarily reducing the pressure.
  • RD and TH are measured in the following method, but not limited thereto. Other known methods may be used as long as equivalent evaluation is possible.
  • <<Total hydrogen content (TH)>>
  • In the measurement of TH, the carbonized specimen is completely combusted at 750°C in an oxygen stream and the amount of water produced from the combusted gas is determined by coulometric titration (Karl Fischer method). ln the Karl Fischer method based on coulometric titration, an electrolyte mainly containing iodide ions, sulfur dioxide, base (RN) and alcohol is poured in a titration cell and then the specimen is put in the titration cell. The moisture in the specimen then reacts according to formula (2). H 2 O + I 2 + SO 2 + CH 3 OH + 3 RN 2 RN HI + RN HSO 4 CH 3
    Figure imgb0002
  • Iodine necessary for this reaction is obtained by allowing the iodide ions to react in an electrochemical manner (two-electron reaction) (the following formula (3)). 2 I - - 2 e I 2
    Figure imgb0003

    Since 1 mol of water reacts with 1 mol of iodine, the amount of electricity necessary to titrate 1 mg of water is determined by Faraday's law as follows: 2 × 96478 / 18.0153 × 10 3 = 10.71 coulomb
    Figure imgb0004

    where the constant 96478 is Faraday's constant and 18.0153 is the molecular weight of water.
    By measuring the amount of electricity required to produce iodine, the amount of water is determined.
  • Then, the resultant amount of water is converted into the amount of hydrogen, which is divided by the mass of the specimen used in the measurement so as to calculate the total hydrogen content (TH (mass.%)).
  • «True relative density (RD)»
  • RD is measured according to JIS K2151.
  • <Activation treatment>
  • A carbon material for an EDLC electrode is obtained by activating a raw material carbon composition having the above characteristics. Known conventional methods can be applied to the activation treatment, and examples of which include chemical activation reactions and gas activation reactions. The chemical activation reaction is more preferable, and an activation reaction using an alkali metal compound is particularly preferable. According to such an activation treatment using an alkali metal compound, the alkali metal intrudes between graphite crystal layers and then starts the activation reaction, so that the specific surface area of the resultant carbon material is improved.
  • Various carbonates and hydroxides can be used as the alkali metal compound, and specifically, examples of the carbonates and hydroxides include sodium carbonate, potassium carbonate, potassium hydroxide, sodium hydroxide, lithium hydroxide, rubidium hydroxide and cesium hydroxide. Among them, an alkali metal hydroxide, such as potassium hydroxide and sodium hydroxide, is preferable, and potassium hydroxide is particularly preferable. In addition, two or more kinds of these alkali metal compounds (potassium hydroxide and sodium hydroxide, for example) may be used at the same time.
  • The activation is typically performed by mixing an activation agent, such as an alkali metal compound, with a raw material carbon composition and heating the mixture. The mixing ratio of the raw material carbon composition to the activation agent, such as an alkali metal hydroxide, is not limited to a specific value, but the mass ratio between the two (raw material carbon composition : activation agent) is preferably in the range from 1:0.5 to 1:10, more preferably 1:1 to 1:5. In general, if the amount of the activation agent, such as an alkali metal compound, is too small, the activation reaction will not sufficiently proceed, so that necessary surface area may not be obtained. On the other hand, although a greater amount of the activation agent increases the specific surface area, not only will the activation cost increase but also the activation yield will decrease. In this case, the volume density of the resultant carbon material also tends to decrease, so that electrostatic capacity per unit volume decreases.
  • The heating temperature in the activation treatment is not limited to a specific one. However, the lower limit of the heating temperature is typically 500°C, preferably 600°C, and the upper limit thereof is typically 1000°C, preferably 900°C, particularly preferably 800°C.
  • The raw material carbon composition according to the present invention is thus activated and then typically undergoes alkali washing, acid washing, rinsing, drying and grinding processes into a carbon material for an EDLC electrode. When an alkali metal compound is used as the activation agent, the amount of the alkali metal left in the carbon material is not limited to a specific value as long as it is lower than the level at which the residual alkali metal adversely affects the resultant EDLC (preferably 1000 ppm or lower). For example, it is typically desirable that the washing is performed in such a way that pH of the washing wastewater is on the order of 7 to 8 and the amount of the alkali metal is minimized. The grinding process is performed in a known method to desirably provide fine particles typically having an average diameter on the order of 0.5 to 50 µm, preferably 1 to 20 µm.
  • The EDLC according to the present invention will now be described.
    The EDLC according to the present invention is characterized in that it comprises electrodes containing a carbon material for an electrode prepared as described above.
  • The electrode is made of, for example, a carbon material for an electrode and a binder, more preferably a conductive agent added thereto. The electrode may also be integrated with a current collector.
  • The binder used herein can be a known binder. Examples of the binder include polyolefins such as polyethylene and polypropylene; fluoropolymers such as polytetrafluoroethylene, polyvinylidene fluoride, crosslinked fluoroolefin/vinylether copolymer; cellulose such as carboxymethylcellulose ; vinyl-based polymers such as polyvinyl pyrrolidone and polyvinyl alcohol; and polyacrylic acid. The content of the binder in the electrode is not limited to a specific value, but it is selected as appropriate to be typically within a range from about 0.1 to 30 mass.% with respect to the total amount of the carbon material for an electrode and the binder.
  • Examples of the conductive agent include powder of carbon black, powdery graphite, titanium oxide, ruthenium oxide and the like. The blending amount of the conductive agent in the electrode, which is selected as appropriate according to the purpose of blending, is selected as appropriate to be typically within a range from about 1 to 50 mass.%, preferably about 2 to 30 mass.% with respect to the total amount of the carbon material for an electrode, the binder and the conductive agent.
  • As a method for mixing the carbon material for an electrode, the binder and the conductive agent, known methods are applied as appropriate. For example, examples of the method to be employed include a method in which a solvent having a property of dissolving the binder is added to the above components and the resultant slurry mixture is uniformly coated on the current collector, and a method in which the above components without any solvent is kneaded and then formed under pressure at normal or elevated temperature.
  • As the current collector, known materials and shapes can be used. Examples of the material of the current collector include metals such as aluminum, titanium, tantalum and nickel, and alloys such as stainless steel.
  • A unit cell of the EDLC according to the present invention is typically formed by using a pair of the above electrodes as positive and negative electrodes, disposing the electrodes in such a way that they face each other with a separator (such as polypropylene-fiber non-woven fabric, glass-fiber non-woven fabric and synthetic cellulose) interposed therebetween, and submerging them in an electrolyte.
  • As the electrolyte, known water-based electrolyte and organic electrolyte can be used, and organic electrolyte is more preferably used. As the organic electrolyte, those used as a solvent of an electrolyte in electrochemistry can be used. Examples of the electrolyte include propylene carbonate, ethylene carbonate, butylene carbonate, γ-butyrolactone, sulfolane, sulfolane derivatives, 3-methylsulfolane, 1,2-dimethoxyethane, acetonitrile, glutaronitrile, valeronitrile, dimethylformamide, dimethyl sulfoxide, tetrahydrofuran, dimethoxyethane, methyl formate, dimethyl carbonate, diethyl carbonate and ethyl methyl carbonate. These electrolytes may be mixed for use.
  • A supporting electrolyte in the organic electrolyte is not limited to a specific one, and various supporting electrolytes, such as salts, acids and alkalis typically used in the fields of electrochemistry and batteries, can be used. Examples of the supporting electrolyte include inorganic ion salts such as alkali metal salts and alkaline-earth metal salts, quaternary ammonium salts, cyclic quaternary ammonium salts and quaternary phosphonium salts. Preferred examples of the supporting electrolyte include (C2H5)4NBF4, (C2H5)3(CH3)NBF4, (C2H5)4PBF4 and (C2H5)3(CH3)PBF4. The concentration of the salt in the electrolyte is selected as appropriate to be typically within the range from about 0.1 to 5 mol/liter, preferably about 0.5 to 3 mol/liter.
  • Although a more specific configuration of the EDLC is not limited to a particular one, examples thereof include a coin type in which a pair of thin sheet-like or disc-like (positive and negative) electrodes, each having a thickness of 10 to 500 µm, with a separator interposed therebetween are housed in a metallic container, a coiled type in which a pair of electrodes are coiled with a separator interposed therebetween, and a stacked type in which a large number of electrode groups are stacked with a separator interposed therebetween.
  • Examples
  • Although the present invention will be described below with reference to examples, the present invention is not limited to only these examples.
  • The total hydrogen content (TH) and the true relative density (RD) of a specimen were measured in the following methods:
    • · Total hydrogen content: The specimen ground into particles, each having a size of 74 µm or smaller (at least 200 mesh), was completely combusted in an oxygen stream in a movable furnace at 750°C. The combusted gas was allowed to pass a stationary furnace filled with copper-copper oxide-copper-desulfurizing agent-copper at 750°C. After desulfurization and denitrification, coulometric titration (Karl Fischer method) using a coulometric titration apparatus was used to determine the amount of generated water so as to calculate the total hydrogen content.
    • · True relative density: A water displacement method using a pycnometer was used to measure the true relative density. Specifically, the specimen was ground into particles, each having a size of 74 µm or smaller (at least 200 mesh). Nine to eleven grams of the ground specimen was collected in the pycnometer, submerged in distilled water, boiled and degassed. Then, the true volume of the specimen was determined. The weight of the collected specimen was divided by the true volume to calculate the true relative density. The following formula was used for the calculation:
  • Formula 1 RD = m 1 - m 2 m 1 - m 3 + m 4 - m 2 ÷ 0.99567
    Figure imgb0005
  • In the above formula, m1 is the mass (g) when the specimen is placed in the pycnometer; m2 is the mass (g) of the pycnometer; m3 is the mass (g) when the distilled water (at 30°C) is filled in the pycnometer with the specimen placed therein; m4 is the mass when the empty pycnometer is filled with the distilled water (at 30°C). The constant 0.99567 is the density of water (g/cm3) at 30°C.
  • The specific surface area of the resultant carbon material was measured using the BET method.
  • [Example 1] (i) Preparation of raw material carbon composition
  • Bottom oil in a fluid catalytic cracker for petroleum heavy oil was mixed with a vacuum residue in a vacuum distillation apparatus to provide a heavy oil mixture containing 0.17 mass.% of sulfur and 0.9 mass.% of asphaltene. The heavy oil mixture was coked in an autoclave under a pressure of 1 MPa at 550°C for 2 hours to provide a raw material composition.
    The resultant raw material carbon composition was burned at 1000 to 1500°C in an inert gas atmosphere and the total hydrogen content and the true relative density were determined. Table 1 shows the results.
  • (ii) Manufacture of carbon material
  • The raw material carbon composition (100 mass parts) was mixed with potassium hydroxide (200 mass parts). The mixture underwent an activation reaction at 750°C for 1 hour in a nitrogen gas atmosphere. After the reaction, the resultant product repeatedly underwent rinsing and acid washing (using HCl) to remove metal potassium left in the carbon material. The resultant product was then dried to provide a carbon material for an EDLC electrode.
  • (iii) Fabrication of electrode
  • The carbon material (80 mass parts) ground into particles having an average diameter of 40 µm was mixed with carbon black (10 mass parts) and polytetrafluoroethylene powder (10 mass parts). The mixture was kneaded into paste in a mortar. Then, the resultant paste was rolled with a 180 kPa-class roller press into an electrode sheet having a thickness of 200 µm.
  • (iv) Assembly of cell
  • The electrode sheet was punched into two discs having a diameter of 16 mm. The discs were subjected to a vacuum dry at 120°C under a pressure of 13.3 Pa (0.1 Torr) for 2 hours, and then underwent vacuum impregnation of an organic electrolyte (propylene carbonate solution of triethylmethylammonium tetrafluoroborate, concentration: 1 mol/liter) in a glove box in a nitrogen atmosphere with a dew point of -85°C. A glass-fiber separator (Advantec Toyo Kaisha, Ltd., model: GA-200, thickness: 200 µm) was interposed between the two electrodes, one used as a positive electrode and the other used as a negative electrode, and an aluminum-foil current collector was attached to each end of the electrodes. The assembled structure was then incorporated into a two-electrode cell (Hohsen Corporation). An electric double layer capacitor (coin-type cell) was thus fabricated.
  • (v) Measurement of electrostatic capacity
  • The above coin-type cell was subjected to constant-current charge with a current of 10 mA per farad to achieve a voltage of 2.7 V. After the charge was completed, the cell was held at 2.7 V for 12 hours, and then underwent a 10-mA constant current discharge process. The amount of energy during the discharge was used to calculate electrostatic capacity according to the following formula: Total discharge energy W W s = { electronic capacity C F × ( discharge initiation voltage V V ) 2 } / 2
    Figure imgb0006
  • [Example 2]
  • The activation, the fabrication of the electrode, and the assembly of the cell were conducted in the same way as Example 1 to determine electrostatic capacity except that the raw material carbon composition was prepared according to the following procedure.
    Bottom oil in a fluid catalytic cracker for petroleum heavy oil was mixed with a vacuum residue in a vacuum distillation apparatus to provide a heavy oil mixture containing 0.26 mass.% of sulfur and 1.5 mass.% of asphaltene. The heavy oil mixture was coked in an autoclave under a pressure of 1 MPa at 550°C for 2 hours to provide the raw material composition.
    The resultant raw material carbon composition was burned at 1000 to 1500°C in an inert gas atmosphere and the total hydrogen content and the true relative density were determined. Table 1 shows the results.
  • [Comparative Example 1]
  • The activation, the fabrication of the electrode, and the assembly of the cell were conducted in the same way as Example 1 to determine electrostatic capacity except that the raw material carbon composition was prepared according to the following procedure.
    Bottom oil in a fluid catalytic cracker for petroleum heavy oil was mixed with a vacuum residue in a vacuum distillation apparatus to provide a heavy oil mixture containing 0.19 mass.% of sulfur and 9.0 mass.% of asphaltene. The heavy oil mixture was coked in an autoclave under a pressure of 1 MPa at 550°C for 2 hours to provide the raw material composition.
    The resultant raw material carbon composition was burned at 1000 to 1500°C in an inert gas atmosphere and the total hydrogen content and the true relative density were determined. Table 1 shows the results.
  • [Comparative Example 2]
  • The activation, the fabrication of the electrode, and the assembly of the cell were conducted in the same way as Example 1 to determine electrostatic capacity except that the raw material carbon composition was prepared according to the following procedure.
    Bottom oil (15 vol.%) in a fluid catalytic cracker for petroleum heavy oil was blended with a vacuum residue (85 vol.%) in a vacuum distillation apparatus (0.18 mass.% of sulfur and 8.5 mass.% of asphaltene). The heavy oil mixture was coked in an autoclave under a pressure of 1MPa at 550°C for 2 hours to provide the raw material composition.
    The resultant raw material carbon composition was burned at 1000 to 1500°C in an inert gas atmosphere and the total hydrogen content and the true relative density were determined. Table 1 shows the results.
  • [Table 1]
    RD TH RD-TH% intercept Specific surface area Electrostatic capacity
    g/cm3 mass.% m2/g F/cc
    Ex. 1 2.131 0.059 2.175 1900 33
    Ex. 2 2.139 0.043 2.171 1600 31
    Com. Ex. 1 2.135 0.028 2.156 1850 21
    Com. Ex. 2 2.139 0.026 2.159 1900 24
  • Table 1 apparently shows that there is substantially proportional relationship between the intercept and the electrostatic capacity. In particular, when the intercept is 1.170 or greater, it is indicated that a electrostatic capacity of 30 F/cc or more is obtained.

Claims (7)

  1. A raw material carbon composition that is converted to a carbon material for an electrode in an electric double layer capacitor upon activation treatment, the raw material carbon composition characterized in that, when the raw material carbon composition is carbonized in an inert gas atmosphere at a temperature of 1000 to 1500°C, the true relative density (RD) and the total hydrogen content (TH%) in the carbonized material obtained after the burning satisfy the following formula (1): RD = - 0.75 TH % + intercept
    Figure imgb0007

    wherein the intercept is 2.160 or greater.
  2. The raw material carbon composition that is converted to a carbon material for an electrode in an electric double layer capacitor according to claim 1, characterized in that the raw material carbon composition has microcrystalline carbon similar to graphite.
  3. A method for manufacturing a raw material carbon composition that is converted to a carbon material for an electrode in an electric double layer capacitor, characterized in that the method comprises the steps of:
    blending multiple kinds of starting raw material oils after adjusting the combination and/or the blending ratio thereof and
    coking the blended oils to provide a raw material carbon composition that satisfies the formula (1) in claim 1 wherein the intercept is 2.160 or greater.
  4. A carbon material for an electrode in an electric double layer capacitor obtained by activating the raw material carbon composition according to claim 1 or 2.
  5. The carbon material for an electrode in an electric double layer capacitor according to claim 4, characterized in that the activation treatment uses an alkali metal compound.
  6. The carbon material for an electrode in an electric double layer capacitor according to claim 4 or 5, characterized in that the activation treatment is performed at a temperature ranging from 500 to 1000°C.
  7. An electric double layer capacitor characterized in that the electric double layer capacitor comprises an electrode containing the carbon material for an electrode according to any one of claims 4 to 6.
EP05820126.0A 2004-12-22 2005-12-21 Raw material coal composition for carbon material for electrode in electric double layer capacitor Expired - Lifetime EP1830373B1 (en)

Applications Claiming Priority (2)

Application Number Priority Date Filing Date Title
JP2004371611A JP2006179697A (en) 2004-12-22 2004-12-22 Raw carbon composition of carbon material for electrode of electric double layer capacitor
PCT/JP2005/023479 WO2006068173A1 (en) 2004-12-22 2005-12-21 Raw material coal composition for carbon material for electrode in electric double layer capacitor

Publications (3)

Publication Number Publication Date
EP1830373A1 true EP1830373A1 (en) 2007-09-05
EP1830373A4 EP1830373A4 (en) 2011-01-26
EP1830373B1 EP1830373B1 (en) 2014-04-02

Family

ID=36601771

Family Applications (1)

Application Number Title Priority Date Filing Date
EP05820126.0A Expired - Lifetime EP1830373B1 (en) 2004-12-22 2005-12-21 Raw material coal composition for carbon material for electrode in electric double layer capacitor

Country Status (6)

Country Link
US (1) US7582902B2 (en)
EP (1) EP1830373B1 (en)
JP (1) JP2006179697A (en)
KR (1) KR20070087047A (en)
CN (1) CN101124646B (en)
WO (1) WO2006068173A1 (en)

Cited By (1)

* Cited by examiner, † Cited by third party
Publication number Priority date Publication date Assignee Title
WO2016123172A1 (en) * 2015-01-30 2016-08-04 Corning Incorporated Coke sourced carbon anode for lithium ion capacitor

Families Citing this family (35)

* Cited by examiner, † Cited by third party
Publication number Priority date Publication date Assignee Title
US7723262B2 (en) 2005-11-21 2010-05-25 Energ2, Llc Activated carbon cryogels and related methods
KR101340194B1 (en) * 2005-12-27 2014-01-02 제이엑스 닛코닛세키에너지주식회사 Original coal and stock oil composition for needle coke and for electricity storing carbon material
KR101496934B1 (en) 2006-11-15 2015-03-03 유니버시티 오브 워싱톤 스루 이츠 센터 포 커머셜리제이션 electric double layer capacitance device
JP2008085352A (en) * 2007-10-19 2008-04-10 Power System:Kk Separator for electric double layer capacitor having rough and fine structure
WO2011002536A2 (en) 2009-04-08 2011-01-06 Energ2, Inc. Manufacturing methods for the production of carbon materials
JP5344972B2 (en) * 2009-04-10 2013-11-20 Jx日鉱日石エネルギー株式会社 Carbon material for electric double layer capacitor electrode and manufacturing method thereof
CN105226284B (en) * 2009-07-01 2017-11-28 巴斯夫欧洲公司 Ultrapure synthetic carbon materials
WO2011053811A1 (en) * 2009-10-30 2011-05-05 The Board Of Trustees Of The Leland Stanford Junior University Conductive fibrous materials
US8895142B2 (en) 2009-11-02 2014-11-25 Cabot Corporation High surface area and low structure carbon blacks for energy storage applications
EP2497137B1 (en) 2009-11-02 2019-07-24 Cabot Corporation Lead-acid batteries and pastes therefor
EP2510569B1 (en) * 2009-12-11 2020-07-22 Basf Se Carbon materials comprising an electrochemical modifier
US8916296B2 (en) 2010-03-12 2014-12-23 Energ2 Technologies, Inc. Mesoporous carbon materials comprising bifunctional catalysts
WO2012045002A1 (en) 2010-09-30 2012-04-05 Energ2 Technologies, Inc. Enhanced packing of energy storage particles
JP6324726B2 (en) 2010-12-28 2018-05-16 ビーエーエスエフ ソシエタス・ヨーロピアBasf Se Carbon materials with improved electrochemical properties
KR102008534B1 (en) 2011-03-30 2019-08-07 제이엑스티지 에네루기 가부시키가이샤 Coking coal composition of carbon material for negative electrode of lithium ion secondary battery, and production method thereof
US20120262127A1 (en) 2011-04-15 2012-10-18 Energ2 Technologies, Inc. Flow ultracapacitor
CN103947017B (en) 2011-06-03 2017-11-17 巴斯福股份公司 Carbon-lead blends for use in hybrid energy storage devices
WO2013120011A1 (en) 2012-02-09 2013-08-15 Energ2 Technologies, Inc. Preparation of polymeric resins and carbon materials
US9552930B2 (en) 2015-01-30 2017-01-24 Corning Incorporated Anode for lithium ion capacitor
CN110112377A (en) 2013-03-14 2019-08-09 14族科技公司 The complex carbon material of electrochemical modification agent comprising lithium alloyage
US10195583B2 (en) 2013-11-05 2019-02-05 Group 14 Technologies, Inc. Carbon-based compositions with highly efficient volumetric gas sorption
KR102663138B1 (en) 2014-03-14 2024-05-03 그룹14 테크놀로지스, 인코포레이티드 Novel methods for sol-gel polymerization in absence of solvent and creation of tunable carbon structure from same
US9607778B2 (en) 2015-01-30 2017-03-28 Corning Incorporated Poly-vinylidene difluoride anode binder in a lithium ion capacitor
US9911545B2 (en) 2015-01-30 2018-03-06 Corning Incorporated Phenolic resin sourced carbon anode in a lithium ion capacitor
US9679704B2 (en) 2015-01-30 2017-06-13 Corning Incorporated Cathode for a lithium ion capacitor
US20190097222A1 (en) 2015-08-14 2019-03-28 Energ2 Technologies, Inc. Composites of porous nano-featured silicon materials and carbon materials
CN119419246A (en) 2015-08-28 2025-02-11 14集团技术公司 New materials with extremely durable lithium intercalation and methods for making them
EP3593369A4 (en) 2017-03-09 2021-03-03 Group14 Technologies, Inc. DECOMPOSITION OF SILICON-CONTAINING PRECURSORS ON POROUS FRAMEWORK MATERIALS
JP2023537954A (en) 2020-08-10 2023-09-06 グループ14・テクノロジーズ・インコーポレイテッド vibration heat assisted chemical vapor infiltration
US11639292B2 (en) 2020-08-18 2023-05-02 Group14 Technologies, Inc. Particulate composite materials
EP4146595A1 (en) 2020-08-18 2023-03-15 Group14 Technologies, Inc. Manufacturing of silicon-carbon composites materials
US11174167B1 (en) 2020-08-18 2021-11-16 Group14 Technologies, Inc. Silicon carbon composites comprising ultra low Z
US11335903B2 (en) 2020-08-18 2022-05-17 Group14 Technologies, Inc. Highly efficient manufacturing of silicon-carbon composites materials comprising ultra low z
WO2022046808A1 (en) 2020-08-28 2022-03-03 Hempax, LLC Biomass-based method and composition
CN116457309B (en) 2020-09-30 2025-02-14 14集团技术公司 Passivation method to control oxygen content and reactivity of silicon-carbon composites

Family Cites Families (10)

* Cited by examiner, † Cited by third party
Publication number Priority date Publication date Assignee Title
JP3093015B2 (en) * 1991-12-12 2000-10-03 新日鐵化学株式会社 Needle coke manufacturing method
CN1048954C (en) 1995-03-30 2000-02-02 日本酸素株式会社 Porous carbonaceous material, process for producing same
JP2001052972A (en) 1999-08-10 2001-02-23 Honda Motor Co Ltd Method for producing alkaline activated carbon for electrode of electric double layer capacitor
JP2002025867A (en) 2000-07-04 2002-01-25 Jeol Ltd Electric double layer capacitor and carbon material for electric double layer capacitor
JP2002093667A (en) 2000-09-13 2002-03-29 Mitsubishi Gas Chem Co Inc Carbon material for electrode of electric double layer capacitor
US20020122985A1 (en) * 2001-01-17 2002-09-05 Takaya Sato Battery active material powder mixture, electrode composition for batteries, secondary cell electrode, secondary cell, carbonaceous material powder mixture for electrical double-layer capacitors, polarizable electrode composition, polarizable electrode, and electrical double-layer capacitor
JP4294246B2 (en) 2001-05-31 2009-07-08 新日本石油精製株式会社 Carbon material for electric double layer capacitor electrode and method for producing the same, electric double layer capacitor and method for producing the same
JP2004182504A (en) * 2002-12-02 2004-07-02 Mitsubishi Gas Chem Co Inc Activated carbon for capacitor electrode and method for producing the same
JP2004247433A (en) 2003-02-12 2004-09-02 Nippon Oil Corp Raw carbon composition of carbon material for electrode of electric double layer capacitor
JP2005142439A (en) * 2003-11-07 2005-06-02 Honda Motor Co Ltd Method for producing activated carbon for electric double layer capacitor electrode and carbon material thereof

Cited By (1)

* Cited by examiner, † Cited by third party
Publication number Priority date Publication date Assignee Title
WO2016123172A1 (en) * 2015-01-30 2016-08-04 Corning Incorporated Coke sourced carbon anode for lithium ion capacitor

Also Published As

Publication number Publication date
US7582902B2 (en) 2009-09-01
CN101124646B (en) 2010-05-12
US20080144255A1 (en) 2008-06-19
JP2006179697A (en) 2006-07-06
EP1830373A4 (en) 2011-01-26
KR20070087047A (en) 2007-08-27
WO2006068173A1 (en) 2006-06-29
CN101124646A (en) 2008-02-13
EP1830373B1 (en) 2014-04-02

Similar Documents

Publication Publication Date Title
EP1830373B1 (en) Raw material coal composition for carbon material for electrode in electric double layer capacitor
EP1176617B1 (en) Activated carbon, process for producing the same, polarizable electrode, and electric double layer capacitor
EP1786008B1 (en) Raw material carbon composition for carbon material for electrode of electric double layer capacitor
JP5473282B2 (en) Carbon material for electric double layer capacitor and manufacturing method thereof
EP2172422B1 (en) Process for producing activated carbon for electric double layer capacitor electrode
EP2418664A1 (en) Carbon material for electric double layer capacitor electrode and method for producing same
JP5242090B2 (en) Method for producing activated carbon for electric double layer capacitor electrode
EP1982956A1 (en) Raw coal for making carbonaceous material for electricity storage or needle coke
JP4092344B2 (en) Raw material composition of carbon material for electric double layer capacitor electrode
EP1529755B1 (en) Process for production of activated carbon for electrode for electric double layer capacitor and carbon material thereof
JP2006059923A (en) Raw carbon composition of carbon material for electrode of electric double layer capacitor
JP2004247433A (en) Raw carbon composition of carbon material for electrode of electric double layer capacitor
JP4066506B2 (en) A method for producing a carbonaceous material.
JP5242216B2 (en) Carbon material for electric double layer capacitor electrode and manufacturing method thereof
JP4233508B2 (en) Raw carbon composition of carbon material for electrode of electric double layer capacitor
JP2008050258A (en) Carbonaceous material and electric double layer capacitor using the same
WO2006018871A1 (en) Material carbon composition for carbon material for electrode of electric double layer capacitor

Legal Events

Date Code Title Description
PUAI Public reference made under article 153(3) epc to a published international application that has entered the european phase

Free format text: ORIGINAL CODE: 0009012

17P Request for examination filed

Effective date: 20070712

AK Designated contracting states

Kind code of ref document: A1

Designated state(s): AT BE BG CH CY CZ DE DK EE ES FI FR GB GR HU IE IS IT LI LT LU LV MC NL PL PT RO SE SI SK TR

DAX Request for extension of the european patent (deleted)
A4 Supplementary search report drawn up and despatched

Effective date: 20101229

17Q First examination report despatched

Effective date: 20120621

REG Reference to a national code

Ref country code: DE

Ref legal event code: R079

Ref document number: 602005043183

Country of ref document: DE

Free format text: PREVIOUS MAIN CLASS: H01G0009058000

Ipc: H01G0011340000

RIC1 Information provided on ipc code assigned before grant

Ipc: H01G 11/34 20130101AFI20130111BHEP

Ipc: H01G 11/44 20130101ALI20130111BHEP

Ipc: C01B 31/08 20060101ALI20130111BHEP

GRAP Despatch of communication of intention to grant a patent

Free format text: ORIGINAL CODE: EPIDOSNIGR1

GRAP Despatch of communication of intention to grant a patent

Free format text: ORIGINAL CODE: EPIDOSNIGR1

INTG Intention to grant announced

Effective date: 20131029

GRAS Grant fee paid

Free format text: ORIGINAL CODE: EPIDOSNIGR3

GRAA (expected) grant

Free format text: ORIGINAL CODE: 0009210

AK Designated contracting states

Kind code of ref document: B1

Designated state(s): AT BE BG CH CY CZ DE DK EE ES FI FR GB GR HU IE IS IT LI LT LU LV MC NL PL PT RO SE SI SK TR

REG Reference to a national code

Ref country code: GB

Ref legal event code: FG4D

REG Reference to a national code

Ref country code: AT

Ref legal event code: REF

Ref document number: 660557

Country of ref document: AT

Kind code of ref document: T

Effective date: 20140415

Ref country code: CH

Ref legal event code: EP

REG Reference to a national code

Ref country code: IE

Ref legal event code: FG4D

REG Reference to a national code

Ref country code: DE

Ref legal event code: R096

Ref document number: 602005043183

Country of ref document: DE

Effective date: 20140515

REG Reference to a national code

Ref country code: AT

Ref legal event code: MK05

Ref document number: 660557

Country of ref document: AT

Kind code of ref document: T

Effective date: 20140402

REG Reference to a national code

Ref country code: NL

Ref legal event code: VDEP

Effective date: 20140402

REG Reference to a national code

Ref country code: LT

Ref legal event code: MG4D

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: LT

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: NL

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: GR

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140703

Ref country code: FI

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: CY

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: IS

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140802

Ref country code: CZ

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: BG

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140702

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: PL

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: SE

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: AT

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: ES

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: LV

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: PT

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140804

REG Reference to a national code

Ref country code: DE

Ref legal event code: R097

Ref document number: 602005043183

Country of ref document: DE

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: SK

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: DK

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: BE

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: EE

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: RO

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

PLBE No opposition filed within time limit

Free format text: ORIGINAL CODE: 0009261

STAA Information on the status of an ep patent application or granted ep patent

Free format text: STATUS: NO OPPOSITION FILED WITHIN TIME LIMIT

26N No opposition filed

Effective date: 20150106

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: IT

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

REG Reference to a national code

Ref country code: DE

Ref legal event code: R097

Ref document number: 602005043183

Country of ref document: DE

Effective date: 20150106

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: SI

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: LU

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20141221

REG Reference to a national code

Ref country code: CH

Ref legal event code: PL

REG Reference to a national code

Ref country code: IE

Ref legal event code: MM4A

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: IE

Free format text: LAPSE BECAUSE OF NON-PAYMENT OF DUE FEES

Effective date: 20141221

Ref country code: CH

Free format text: LAPSE BECAUSE OF NON-PAYMENT OF DUE FEES

Effective date: 20141231

Ref country code: LI

Free format text: LAPSE BECAUSE OF NON-PAYMENT OF DUE FEES

Effective date: 20141231

REG Reference to a national code

Ref country code: FR

Ref legal event code: PLFP

Year of fee payment: 11

PGFP Annual fee paid to national office [announced via postgrant information from national office to epo]

Ref country code: GB

Payment date: 20151102

Year of fee payment: 11

PGFP Annual fee paid to national office [announced via postgrant information from national office to epo]

Ref country code: FR

Payment date: 20151127

Year of fee payment: 11

PGFP Annual fee paid to national office [announced via postgrant information from national office to epo]

Ref country code: DE

Payment date: 20151221

Year of fee payment: 11

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: MC

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: TR

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT

Effective date: 20140402

Ref country code: HU

Free format text: LAPSE BECAUSE OF FAILURE TO SUBMIT A TRANSLATION OF THE DESCRIPTION OR TO PAY THE FEE WITHIN THE PRESCRIBED TIME-LIMIT; INVALID AB INITIO

Effective date: 20051221

REG Reference to a national code

Ref country code: DE

Ref legal event code: R119

Ref document number: 602005043183

Country of ref document: DE

GBPC Gb: european patent ceased through non-payment of renewal fee

Effective date: 20161221

REG Reference to a national code

Ref country code: FR

Ref legal event code: ST

Effective date: 20170831

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: FR

Free format text: LAPSE BECAUSE OF NON-PAYMENT OF DUE FEES

Effective date: 20170102

PG25 Lapsed in a contracting state [announced via postgrant information from national office to epo]

Ref country code: DE

Free format text: LAPSE BECAUSE OF NON-PAYMENT OF DUE FEES

Effective date: 20170701

Ref country code: GB

Free format text: LAPSE BECAUSE OF NON-PAYMENT OF DUE FEES

Effective date: 20161221
