Cleaning and sterilizing device for horn coil production and processing

Technical Field

The utility model relates to a horn coil field particularly, relates to a horn coil cleaning and sterilizing device for production and processing.

Background

With the arrival of the information era, the society develops continuously, the science progresses continuously, equipment in various fields is improved and updated continuously, in the technical field of electroacoustic products, various loudspeaker cone voice coils appear, the most important loudspeaker coil is the loudspeaker coil, and the loudspeaker coil can produce a large amount of metal impurities on the surface after the production and processing process, so that the loudspeaker coil can not be disinfected and cleaned.

Traditional horn coil disinfection belt cleaning device function is comparatively single, can't carry after the disinfection washs, still can't dry, and the impurity of wasing out in addition can't effectively be retrieved, still can pollute the water source, and it is still very inconvenient to remove even, can't satisfy people's demand gradually.

An effective solution to the problems in the related art has not been proposed yet.

SUMMERY OF THE UTILITY MODEL

An object of the utility model is to provide a loudspeaker coil cleaning and sterilizing device for production and processing to solve the problem that proposes among the above-mentioned background art.

In order to achieve the above object, the utility model provides a following technical scheme: including carrying platform, funnel, disinfection frame, wash rack, stoving frame and truckle, carry the platform to include catch basin, outlet and spout, the catch basin is located carry the inside of platform, the outlet is located one side of catch basin, the spout is located carry the inboard of platform, the spout is equipped with the filter, the top of filter is equipped with gear motor, one side of gear motor is equipped with a plurality of gear antiskid section of thick bamboo, the funnel is located carry the top of platform, the disinfection frame is located one side of funnel, the wash rack is located one side of disinfection frame, the stoving frame is located one side of wash rack, the inside ventilation groove that is equipped with of stoving frame, the top of ventilation groove is equipped with the protection network, the inside of ventilation groove is equipped with the air exhauster, the bottom of air exhauster is equipped with the heating pipe.

Further, the filter plate is sleeved with the sliding groove.

Furthermore, the gear motor is fixedly connected with the conveying platform through bolts, the gear anti-slip cylinder is fixedly connected with the conveying platform through bearings, the gear anti-slip cylinder is further connected with the gear motor in a meshed mode, and the funnel is fixedly connected with the conveying platform through bolts.

Further, the disinfection frame is fixedly connected with the conveying table through bolts, a liquid inlet pipe is arranged on one side of the disinfection frame, a liquid discharge pipe is fixedly arranged at the bottom of the disinfection frame, and the liquid inlet pipe is fixedly connected with a liquid discharge pipe pipeline.

Furthermore, the wash rack with carry platform bolt fixed connection, one side of wash rack is equipped with the inlet tube, the fixed drain pipe that is equipped with in bottom of wash rack, inlet tube and drain pipe pipeline fixed connection.

Further, the drying rack is fixedly connected with the conveying table through bolts, the protective net is fixedly connected with the drying rack through bolts, the exhaust fan is fixedly connected with the drying rack through bolts, and the heating pipe is fixedly connected with the drying rack through bolts.

Further, the portable caster wheel is located at the bottom end of the conveying table and fixedly connected with the conveying table through bolts.

Compared with the prior art, the utility model discloses following beneficial effect has:

1. the utility model relates to a loudspeaker coil production and processing is with cleaning and disinfecting device in, has set up and has carried platform, gear motor, a gear antiskid section of thick bamboo, disinfection frame and wash rack, drives a gear antiskid section of thick bamboo through gear motor and rotates, realizes removing the coil, through the fluid-discharge tube of disinfection frame and the drain pipe of wash rack, can play and be convenient for process abluent effect to the coil.

2. The utility model relates to a loudspeaker coil production and processing is with cleaning and disinfecting device in, has set up catch basin, spout and filter, through the impurity on the filter coil, can play the effect of being convenient for filter metallic impurity.

3. The utility model relates to a horn coil production and processing is with cleaning and disinfecting device in, has set up stoving frame, ventilation groove, protection network, air exhauster and heating pipe, blows off the steam of heating pipe through the air exhauster, can play the effect of the fast drying of being convenient for.

4. The utility model relates to a during horn coil production and processing used cleaning and sterilizing device, set up portable truckle, can play the effect of being convenient for remove.

Drawings

In order to more clearly illustrate the embodiments of the present invention or the technical solutions in the prior art, the drawings required to be used in the embodiments will be briefly described below, and it is obvious that the drawings in the following description are only some embodiments of the present invention, and for those skilled in the art, other drawings can be obtained according to these drawings without creative efforts.

FIG. 1 is a schematic structural view of a cleaning and disinfecting device for horn coil production according to the present invention;

FIG. 2 is a schematic structural view of the interior of a conveying table of a cleaning and disinfecting device for horn coil production and processing according to the present invention;

fig. 3 is a schematic view of the connection structure inside the drying rack of the cleaning and disinfecting device for horn coil production and processing according to the utility model.

Reference numerals:

1. a conveying table; 101. a water storage tank; 102. a water outlet; 103. a chute; 2. a filter plate; 3. a gear motor; 4. a gear anti-slip cylinder; 5. a funnel; 6. a disinfecting rack; 601. a liquid inlet pipe; 602. a liquid discharge pipe; 7. a cleaning frame; 701. a water inlet pipe; 702. a drain pipe; 8. a drying rack; 801. a ventilation slot; 802. a protective net; 803. an exhaust fan; 804. heating a tube; 9. a caster is portable.

Detailed Description

The technical solution in the embodiments of the present invention will be clearly and completely described below with reference to the drawings in the embodiments of the present invention, and it is obvious that the described embodiments are only some embodiments of the present invention, rather than all embodiments, and all other embodiments obtained by a person of ordinary skill in the art without creative work belong to the protection scope of the present invention based on the embodiments of the present invention.

In the description of the present invention, it should be noted that the terms "top", "bottom", "one side", "the other side", "front", "back", "middle part", "inside", "top", "bottom", etc. indicate the orientation or positional relationship based on the orientation or positional relationship shown in the drawings, which is only for the convenience of description and simplification of the description, but does not indicate or imply that the device or element referred to must have a specific orientation, be constructed in a specific orientation, and be operated, and thus, should not be construed as limiting the present invention; the terms "first," "second," and "third" are used for descriptive purposes only and are not to be construed as indicating or implying relative importance; furthermore, unless expressly stated or limited otherwise, the terms "mounted," "connected," and "connected" are to be construed broadly, as they may be fixedly connected, detachably connected, or integrally connected, for example; can be mechanically or electrically connected; they may be connected directly or indirectly through intervening media, or they may be interconnected between two elements. The specific meaning of the above terms in the present invention can be understood in specific cases to those skilled in the art.

Referring to fig. 1-3, a cleaning and disinfecting device for horn coil production according to an embodiment of the present invention includes a conveying table 1, a funnel 5, a disinfecting frame 6, a cleaning frame 7, a drying frame 8 and portable casters 9, the conveying table 1 includes a water storage tank 101, a water outlet 102 and a sliding chute 103, the water storage tank 101 is located inside the conveying table 1, the water outlet 102 is located on one side of the water storage tank 101, the sliding chute 103 is located inside the conveying table 1, the sliding chute 103 is provided with a filter plate 2, a gear motor 3 is arranged on the top end of the filter plate 2, one side of the gear motor 3 is provided with a plurality of gear anti-sliding cylinders 4, the funnel 5 is located on the top end of the conveying table 1, the disinfecting frame 6 is located on one side of the funnel 5, the cleaning frame 7 is located on one side of the disinfecting frame 6, the drying frame 8 is located on one side of the cleaning frame 7, the drying frame 8 is internally provided with a ventilation slot 801, the top end of the ventilation slot 801 is provided with a protective net 802, the inside of ventilation groove 801 is equipped with air exhauster 803, and the bottom of air exhauster 803 is equipped with heating pipe 804, the utility model discloses not only have the effect of being convenient for carry and cleaning and disinfecting, but also have the effect of being convenient for fast drying and filtering.

According to the above scheme of this embodiment, filter 2 cup joints with spout 103, can play the effect of filtering metallic impurity.

According to the above scheme of this embodiment, gear motor 3 and carry platform 1 bolt fixed connection, gear antiskid section of thick bamboo 4 and carry platform 1 bearing fixed connection, gear antiskid section of thick bamboo 4 still is connected with gear motor 3 meshing, funnel 5 and carry platform 1 bolt fixed connection, can play the effect of carrying.

According to the above scheme of this embodiment, disinfection frame 6 and transport platform 1 bolt fixed connection, one side of disinfection frame 6 is equipped with feed liquor pipe 601, and the fixed fluid-discharge tube 602 that is equipped with in bottom of disinfection frame 6, feed liquor pipe 601 and fluid-discharge tube 602 pipeline fixed connection can play the effect of being convenient for spray the antiseptic solution.

According to the above scheme of this embodiment, wash rack 7 and delivery platform 1 bolt fixed connection, one side of wash rack 7 is equipped with inlet tube 701, and the fixed drain pipe 702 that is equipped with in bottom of wash rack 7, inlet tube 701 and drain pipe 702 pipeline fixed connection can play the effect of being convenient for water spray cleaning.

According to the above scheme of this embodiment, stoving frame 8 and conveying platform 1 bolt fixed connection, protection network 802 and the 8 bolt fixed connection of stoving frame, air exhauster 803 and the 8 bolt fixed connection of stoving frame, heating pipe 804 and the 8 bolt fixed connection of stoving frame can play the effect of the fast drying of being convenient for.

According to the above-mentioned scheme of this embodiment, the caster 9 is located at the bottom end of the conveying platform 1, and the caster 9 is fixedly connected with the conveying platform 1 by bolts, so that the effect of moving conveniently can be achieved.

Principle of operation

When specifically using, pour into the coil of rigid production through funnel 5, gear motor 3 starts to drive gear antiskid section of thick bamboo 4 and rotates simultaneously, carry the coil, when disinfecting frame 6, the antiseptic solution is got into by feed liquor pipe 601, spout through fluid-discharge tube 602, disinfect the coil, when wasing frame 7, the water source is got into by inlet tube 701, spout through drain pipe 702, wash the coil, when drying frame 8, the wind that air exhauster 803 took out dries the coil after heating pipe 804 heats, be convenient for directly accomodate, water source after the washing falls into in filter 2 filters back catch basin 101, discharge through outlet 102, filter 2 filters behind the metallic impurity and takes out through spout 103 and clear up.

Finally, it should be noted that: although the present invention has been described in detail with reference to the foregoing embodiments, it will be apparent to those skilled in the art that modifications may be made to the embodiments described in the foregoing embodiments, or equivalents may be substituted for elements thereof. Any modification, equivalent replacement, or improvement made within the spirit and principle of the present invention should be included in the protection scope of the present invention.

Claims

1. A cleaning and disinfecting device for horn coil production and processing comprises a conveying table (1), a funnel (5), a disinfecting frame (6), a cleaning frame (7), a drying frame (8) and portable casters (9), and is characterized in that the conveying table (1) comprises a water storage tank (101), a water outlet (102) and a sliding groove (103), the water storage tank (101) is positioned inside the conveying table (1), the water outlet (102) is positioned on one side of the water storage tank (101), the sliding groove (103) is positioned on the inner side of the conveying table (1), the sliding groove (103) is provided with a filter plate (2), the top end of the filter plate (2) is provided with a gear motor (3), one side of the gear motor (3) is provided with a plurality of gear anti-sliding cylinders (4), the funnel (5) is positioned on the top end of the conveying table (1), and the disinfecting frame (6) is positioned on one side of the funnel (5), wash rack (7) are located one side of disinfection frame (6), stoving frame (8) are located one side of wash rack (7), the inside ventilation groove (801) that is equipped with of stoving frame (8), the top of ventilation groove (801) is equipped with protection network (802), the inside in ventilation groove (801) is equipped with air exhauster (803), the bottom of air exhauster (803) is equipped with heating pipe (804).

2. A cleaning and disinfecting device for the production and processing of a horn coil as claimed in claim 1, characterized in that said filter plate (2) is sleeved with said chute (103).

3. The cleaning and disinfecting device for the production and processing of the horn coil as claimed in claim 1, wherein the gear motor (3) is fixedly connected with the conveying table (1) by bolts, the gear anti-slip cylinder (4) is fixedly connected with the conveying table (1) by bearings, the gear anti-slip cylinder (4) is further connected with the gear motor (3) in a meshed manner, and the funnel (5) is fixedly connected with the conveying table (1) by bolts.

4. The cleaning and disinfecting device for horn coil production and processing according to claim 1, wherein the disinfecting frame (6) is fixedly connected with the conveying table (1) through bolts, a liquid inlet pipe (601) is arranged on one side of the disinfecting frame (6), a liquid outlet pipe (602) is fixedly arranged at the bottom of the disinfecting frame (6), and the liquid inlet pipe (601) is fixedly connected with the liquid outlet pipe (602) in a pipeline manner.

5. The cleaning and disinfecting device for horn coil production and processing according to claim 1, characterized in that the cleaning rack (7) is fixedly connected with the conveying table (1) by bolts, a water inlet pipe (701) is arranged at one side of the cleaning rack (7), a water outlet pipe (702) is fixedly arranged at the bottom of the cleaning rack (7), and the water inlet pipe (701) is fixedly connected with the water outlet pipe (702) by a pipeline.

6. The cleaning and disinfecting device for horn coil production and processing according to claim 1, characterized in that said drying rack (8) is bolted and fixedly connected to said conveying table (1), said protective screen (802) is bolted and fixedly connected to said drying rack (8), said exhaust fan (803) is bolted and fixedly connected to said drying rack (8), and said heating pipe (804) is bolted and fixedly connected to said drying rack (8).

7. A cleaning and disinfecting device for the production and processing of a horn coil as recited in claim 1, characterized in that said casters (9) are located at the bottom end of said conveyor table (1), said casters (9) being bolted to said conveyor table (1).
