CN213840280U - Cloud video and video conference all-in-one machine - Google Patents
Cloud video and video conference all-in-one machine Download PDFInfo
- Publication number
- CN213840280U CN213840280U CN202021883214.5U CN202021883214U CN213840280U CN 213840280 U CN213840280 U CN 213840280U CN 202021883214 U CN202021883214 U CN 202021883214U CN 213840280 U CN213840280 U CN 213840280U
- Authority
- CN
- China
- Prior art keywords
- base
- fixedly connected
- outside
- seted
- video
- Prior art date
- Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
- Active
Links
Images
Landscapes
- Two-Way Televisions, Distribution Of Moving Picture Or The Like (AREA)
Abstract
The utility model discloses a cloud video-communication video conferencing all-in-one relates to projecting apparatus technical field, specifically is a cloud video-communication video conferencing all-in-one, which comprises a base, the cylindrical hole of symmetric distribution is seted up in the outside of base, and the cylindrical hole swing joint in the base outside has the horizontal pole of symmetric distribution, the one end fixedly connected with gyro wheel of horizontal pole, the notch of relative distribution is seted up to the outside of base. This cloud video-communication video conference all-in-one through seting up the annular spout of semicircle at the top of backup pad to swing joint symmetric distribution's slider in the spout at backup pad top, simultaneously at the bottom fixed connection base of display, utilize base bottom surface fixed connection's pivot can rotate along with the removal of slider, and then guaranteed that the device can carry out diversified demonstration with the display, solved in the past the device can only carry out the problem that the single direction shows.
Description
Technical Field
The utility model relates to a projecting apparatus technical field specifically is a cloud video-communication video conferencing all-in-one.
Background
With the rapid development of social science and technology, more and more enterprise conferences are not limited to face-to-face conferences, and many enterprises often use video conferences to communicate in order to know and announce a new policy in the first time, so that a cloud video and video conference all-in-one machine is needed for high-level companies and enterprises.
At present, there are many types of conference all-in-one in the market, current conference all-in-one often all is with two display fixed connection at the top of support frame, but because the decoration and the overall arrangement of different formula meeting rooms are different, this type of device can not carry out diversified video display, and this type of device can not carry out the pertinence matching to the meeting desk of co-altitude not, some current conference all-in-one that can lift function often rise to the highest place after hardly keep balance, in addition often can need use projection instrument in the meeting room, but this type of device just does not possess the required screen of production projection, for this reason we have proposed a cloud video conference all-in-one.
SUMMERY OF THE UTILITY MODEL
Not enough to prior art, the utility model provides a cloud video-communication video conferencing all-in-one has solved the problem of proposing among the above-mentioned background art.
In order to achieve the above purpose, the utility model discloses a following technical scheme realizes: a cloud video and video conference integrated machine comprises a base, wherein cylindrical holes are symmetrically distributed on the outer side of the base, the cylindrical holes on the outer side of the base are movably connected with cross rods which are symmetrically distributed, one end of each cross rod is fixedly connected with a roller, notches which are oppositely distributed are formed in the outer portion of the base, notches which are symmetrically distributed are movably connected with diagonal rods which are symmetrically distributed, one end of each diagonal rod is fixedly connected to the top of each roller, a circular hole groove is formed in the outer portion of the base, a rocker is movably connected with the circular hole groove in the outer side of the base, a rectangular groove is formed in the inner cavity of the base, a lifting plate which is symmetrically distributed is movably connected with the rectangular groove in the inner cavity of the base, a pressing block is fixedly connected with the rectangular groove in the inner side of the lifting plate, and a supporting plate is fixedly connected with the top of the pressing block, the utility model discloses a screen support, including backup pad, the both sides fixedly connected with symmetric distribution's of backup pad bottom fixed block, the outside fixedly connected with metal cardboard of fixed block, the inside swing joint of metal cardboard has the support, the outside swing joint of support has the screen spool, semicircle annular spout has been seted up at the top of backup pad, the semicircle annular spout swing joint at backup pad top has the display, the top surface fixedly connected with battery of backup pad.
Optionally, the screw thread slotted holes are symmetrically formed in the outer portion of the base, the screw thread slotted holes in the outer portion of the base are connected with symmetrically distributed fixing nuts in a threaded mode, and the base is made of stainless steel metal.
Optionally, a cylindrical slotted hole is formed in the cross rod, the inclined rod is a solid metal inclined rod, the top of the roller is movably connected with a bearing, the bottom end of the inclined rod is fixedly connected to the top of the bearing, and the bottom of the roller is fixedly connected with the roller.
Optionally, the outside fixedly connected with symmetric distribution's of rocker gear, the sawtooth notch has been seted up to the inside of lifter plate, and one side of the inside notch of lifter plate has seted up inside sunken spout, the outside gear of rocker is arranged in the spout of the inside notch of lifter plate, and the outside gear of rocker and the inside sawtooth notch mutual adaptation of lifter plate.
Optionally, the inside fixedly connected with cement piece of briquetting, the outside fixedly connected with metal casing of briquetting, rectangular groove has been seted up to the inside of metal cardboard, rectangular notch has been seted up in the outside of metal cardboard, rectangular notch swing joint in the metal cardboard outside has spacing fixture block, the round hole has been seted up to the inside of support, and the inside round hole of support and the outside mutual adaptation of support.
Optionally, the bottom of the display is fixedly connected with a base, the base at the bottom of the display is made of an outer rubber layer and a metal inner container, the bottom of the base is movably connected with rotating shafts which are symmetrically distributed, and a sliding block at the bottom of the display is in a T shape.
The utility model provides a cloud video-communication video conferencing all-in-one possesses following beneficial effect:
1. this cloud video-communication video conference all-in-one through seting up the annular spout of semicircle at the top of backup pad to swing joint symmetric distribution's slider in the spout at backup pad top, simultaneously at the bottom fixed connection base of display, utilize base bottom surface fixed connection's pivot can rotate along with the removal of slider, and then guaranteed that the device can carry out diversified demonstration with the display, solved in the past the device can only carry out the problem that the single direction shows.
2. This cloud video-communication video conference all-in-one, through the inside swing joint lifter plate at the base, and horizontal pole and down tube at the outside swing joint symmetric distribution of base, simultaneously at the inside swing joint support of metal cardboard, can guarantee the device when rising to highest position, the horizontal pole and the gyro wheel of device bottom can keep the device top steady, and utilize the slidable support, and then guaranteed that the device can provide the required screen of projection for projection instrument, thereby solved the device in the past and riseed the back, lead to the device unstable, and do not have the problem of supplementary projection ability.
Drawings
FIG. 1 is a schematic structural view of the present invention;
fig. 2 is a schematic view of the structure of the cloud video conference all-in-one machine of the present invention;
FIG. 3 is a schematic view of a partial structure of the cloud video conference all-in-one machine of the present invention;
fig. 4 is the local dispersion structure diagram of the cloud video-based video conference all-in-one machine of the present invention.
In the figure: 1. a base; 2. a cross bar; 3. a roller; 4. a diagonal bar; 5. a rocker; 6. a lifting plate; 7. briquetting; 8. a support plate; 9. a fixed block; 10. a metal card board; 11. a support; 12. a screen reel; 13. a storage battery; 14. a display.
Detailed Description
The technical solutions in the embodiments of the present invention will be described clearly and completely with reference to the accompanying drawings in the embodiments of the present invention, and it is obvious that the described embodiments are only some embodiments of the present invention, not all embodiments.
Referring to fig. 1 to 4, the present invention provides a technical solution: a cloud video and video conference integrated machine comprises a base 1, wherein the outside of the base 1 is provided with symmetrically distributed threaded slotted holes, the threaded slotted holes on the outside of the base 1 are in threaded connection with symmetrically distributed fixing nuts, the base 1 is made of stainless steel metal, the outside of the base 1 is provided with symmetrically distributed cylindrical holes, the threaded slotted holes on the outside of the base 1 are in threaded connection with the symmetrically distributed fixing nuts in the threaded slotted holes on the outside of the base 1, the device can be ensured to adjust the fixing nuts on the outside of the base 1 so as to adjust and control the overall stability of the device, the cylindrical holes on the outside of the base 1 are movably connected with symmetrically distributed cross rods 2, one ends of the cross rods 2 are fixedly connected with idler wheels 3, the cylindrical slotted holes are arranged inside the cross rods 2, the inclined rods 4 are solid metal inclined rods, and the tops of the idler wheels 3 are movably connected with bearings, the bottom end of the diagonal rod 4 is fixedly connected to the top of the bearing, the bottom of the roller 3 is fixedly connected with the roller, notches which are distributed oppositely are formed in the outer portion of the base 1, the notches in the outer portion of the base 1 are movably connected with the diagonal rods 4 which are distributed symmetrically, one end of the diagonal rod 4 is fixedly connected to the top of the roller 3, the cross rod 2 and the diagonal rod 4 which are distributed symmetrically are movably connected to the outer portion of the base 1, the bearing is movably connected to the top of the roller 3, and the bottom end of the diagonal rod 4 is fixedly connected to the top of the bearing, so that the device can provide enough external supporting force, the problem that the device inclines or collapses is effectively solved, a circular hole groove is formed in the outer portion of the base 1, the circular hole groove in the outer side of the base 1 is movably connected with a rocker 5, a rectangular groove is formed in the inner cavity of the base 1, and the rectangular groove in the inner cavity of the base 1 is movably connected with a lifting plate 6 which is distributed symmetrically, the outer part of the rocker 5 is fixedly connected with symmetrically distributed gears, the inner part of the lifting plate 6 is provided with a sawtooth notch, one side of the inner notch of the lifting plate 6 is provided with an inward sunken chute, the gear outside the rocker 5 is positioned in the chute of the inner notch of the lifting plate 6, the gear outside the rocker 5 is mutually matched with the sawtooth notch inside the lifting plate 6, the inner part of the lifting plate 6 is provided with the sawtooth notch, one side of the inner sawtooth notch of the lifting plate 6 is provided with the chute, the gear outside the rocker 5 is mutually matched with the sawtooth notch inside the lifting plate 6, the lifting height of the device can be rapidly adjusted, the running efficiency of the device is greatly improved, the inner side of the lifting plate 6 is provided with a rectangular notch, the rectangular notch inside the lifting plate 6 is fixedly connected with a pressing block 7, the top of the pressing block 7 is fixedly connected with a supporting plate 8, two sides of the bottom of the supporting plate 8 are fixedly connected with symmetrically distributed fixing blocks 9, the outer side of the fixed block 9 is fixedly connected with a metal clamping plate 10, the inner part of the metal clamping plate 10 is movably connected with a bracket 11, the inner part of the pressing block 7 is fixedly connected with a cement block, the outer part of the pressing block 7 is fixedly connected with a metal shell, the inner part of the metal clamping plate 10 is provided with a rectangular groove, the outer side of the metal clamping plate 10 is provided with a rectangular notch, the rectangular notch on the outer side of the metal clamping plate 10 is movably connected with a limiting fixture block, the inner part of the bracket 11 is provided with a round hole, the round hole on the inner part of the bracket 11 is mutually matched with the outer part of the bracket 11, the outer part of the bracket 11 is movably connected with a screen scroll 12, the stability of the top of the device can be ensured by fixedly connecting the cement block on the inner part of the pressing block 7, meanwhile, the rectangular groove is arranged on the inner part of the metal clamping plate 10, and the rectangular notch is arranged on the outer side of the metal clamping plate 10, the bracket 11 can be ensured under the quick fixation of the limiting fixture, and then realized that support 11 drives screen spool 12 and carries out steady removal, semicircle annular chute has been seted up at the top of backup pad 8, semicircle annular chute swing joint at backup pad 8 top has display 14, top surface fixedly connected with battery 13 of backup pad 8, the bottom fixedly connected with base of display 14, the base of display 14 bottom is made by outer and metal inner bag of rubber, and the bottom swing joint symmetric distribution's of base pivot, the slider of display 14 bottom is the T font, through seting up semicircle annular chute at the top of backup pad 8, and swing joint T font slider in the spout at backup pad 8 top, can guarantee that display 14 can carry out the steady slip, and then the effectual in-process of having guaranteed the device at regulation display 14 scope, the stability at device top can be guaranteed.
In conclusion, this cloud video conference all-in-one, during the use, the user need with the fixation nut anticlockwise rotation in the base 1 outside, then take out horizontal pole 2 to the outside, simultaneously with the down tube 4 outside to the outside tensile, then the fixation nut in the fixed base 1 outside, the user need rotate rocker 5 afterwards, make lifter plate 6 rise to the highest position, then communicate the power with battery 13, and open display 14, then when needing to carry out the large-size screen projection again, the user need move support 11 forward, and launch screen reel 12, so can.
The above, only be the concrete implementation of the preferred embodiment of the present invention, but the protection scope of the present invention is not limited thereto, and any person skilled in the art is in the technical scope of the present invention, according to the technical solution of the present invention and the utility model, the concept of which is equivalent to replace or change, should be covered within the protection scope of the present invention.
Claims (6)
1. A cloud video and video conference all-in-one machine comprises a base (1), and is characterized in that: the outer side of the base (1) is provided with symmetrically distributed cylindrical holes, the cylindrical holes on the outer side of the base (1) are movably connected with symmetrically distributed cross rods (2), one end of each cross rod (2) is fixedly connected with a roller (3), the outer part of the base (1) is provided with notches which are distributed oppositely, the notches on the outer part of the base (1) are movably connected with symmetrically distributed inclined rods (4), one end of each inclined rod (4) is fixedly connected to the top of each roller (3), the outer part of the base (1) is provided with a circular hole groove, the circular hole groove on the outer side of the base (1) is movably connected with a rocker (5), the inner cavity of the base (1) is provided with a rectangular groove, the rectangular groove on the inner cavity of the base (1) is movably connected with symmetrically distributed lifting plates (6), and the inner side of each lifting plate (6) is provided with a rectangular notch, the utility model discloses a screen printing machine, including lifter plate (6), top fixedly connected with backup pad (8) of briquetting (7), fixed block (9) of the both sides fixedly connected with symmetric distribution of backup pad (8) bottom, outside fixedly connected with metal cardboard (10) of fixed block (9), the inside swing joint of metal cardboard (10) has support (11), the outside swing joint of support (11) has screen reel (12), the semicircle annular spout has been seted up at the top of backup pad (8), the semicircle annular spout swing joint at backup pad (8) top has display (14), the top surface fixedly connected with battery (13) of backup pad (8).
2. The integrated cloud video and video conference machine of claim 1, wherein: the novel stainless steel base is characterized in that thread slotted holes which are symmetrically distributed are formed in the outer portion of the base (1), the thread slotted holes in the outer portion of the base (1) are connected with fixing nuts which are symmetrically distributed in a threaded mode, and the base (1) is made of stainless steel metal.
3. The integrated cloud video and video conference machine of claim 1, wherein: the inside of horizontal pole (2) has been seted up the cylindrical slotted hole, down tube (4) are solid metal down tube, the top swing joint of gyro wheel (3) has the bearing, the bottom fixed connection of down tube (4) is at the top of bearing, the bottom fixed connection of gyro wheel (3) has the gyro wheel.
4. The integrated cloud video and video conference machine of claim 1, wherein: the outer fixed connection of rocker (5) has the gear of symmetric distribution, the sawtooth notch has been seted up to the inside of lifter plate (6), and one side of the inside notch of lifter plate (6) has seted up inside sunken spout, the gear of rocker (5) outside is arranged in the spout of the inside notch of lifter plate (6), and the mutual adaptation of rocker (5) outside gear and lifter plate (6) inside sawtooth notch.
5. The integrated cloud video and video conference machine of claim 1, wherein: the inside fixedly connected with cement piece of briquetting (7), the outside fixedly connected with metal casing of briquetting (7), the rectangle recess has been seted up to the inside of metal cardboard (10), the rectangle notch has been seted up in the outside of metal cardboard (10), the rectangle notch swing joint in the metal cardboard (10) outside has spacing fixture block, the round hole has been seted up to the inside of support (11), and the inside round hole of support (11) and the outside mutual adaptation of support (11).
6. The integrated cloud video and video conference machine of claim 1, wherein: the bottom of the display (14) is fixedly connected with a base, the base at the bottom of the display (14) is made of an outer rubber layer and a metal inner container, the bottom of the base is movably connected with rotating shafts which are symmetrically distributed, and a sliding block at the bottom of the display (14) is T-shaped.
