Abstract
本实用新型公开了一种建筑用广角度外窗结构，包括窗框架、开合式窗体和闭式窗体，窗框架的中部设有中间架，窗框架上设有电动推杆，开合式窗体设置于窗框架内侧，开合式窗体对称设置于中间架的两端，对称的开合式窗体的一侧与中间架转动连接，开合式窗体远离中间架一端安装有与电动推杆相对应的限位装置，闭式窗体固定安装于窗框内且所述闭式窗体对称设置于开合式窗体的两侧，对称的闭式窗体以及对称的开合式窗体分别处于不同的平面。本实用新型相比于现有的平面式窗台视野更加广，通过设置限位装置以及电动推杆实现开合式窗体的开合，操作简单方便，对称的开合式窗体以一定的角度设置更有利于室内的空气流通，从而有效提升使用者的体验感。
The utility model discloses a wide-angle exterior window structure for building, which comprises a window frame, an opening and closing window and a closing window. An intermediate frame is arranged in the middle of the window frame, and an electric push rod is arranged on the window frame. The body is arranged on the inner side of the window frame, and the opening and closing windows are symmetrically arranged at both ends of the intermediate frame. The corresponding limiting device, the closed window is fixedly installed in the window frame, and the closed window is symmetrically arranged on both sides of the opening and closing window, and the symmetrical closed window and the symmetrical opening and closing window are respectively in different positions. plane. Compared with the existing plane window sill, the utility model has a wider field of vision, the opening and closing of the opening and closing window is realized by setting the limit device and the electric push rod, the operation is simple and convenient, and the symmetrical opening and closing window is set at a certain angle. It is conducive to indoor air circulation, thereby effectively improving the user's experience.
Description
Technical Field
The utility model relates to a building technical field, concretely relates to wide angle outer window structure for building.
Background
Modern building windows are usually glass windows to increase the lighting in the room and ensure that the room has sufficient natural light. However, the outer windows of the buildings on the market are embedded in the wall body, so that the indoor visual field range is small, and the indoor air circulation effect is poor due to the planar design; secondly, the existing window is only improved in the aspect of system technology, so that the window has the functions of theft prevention, robbery prevention, alarm and the like, but the window can be operated only manually, is troublesome to operate and inconvenient to use, and seriously influences the experience of a user. There is a need for an exterior window structure that overcomes the above-mentioned deficiencies.
SUMMERY OF THE UTILITY MODEL
The utility model aims to solve the technical problem that a wide angle outer window structure for building is provided, compare in current planar windowsill field of vision wider, easy operation is convenient, and this structure is favorable to indoor circulation of air, effectively promotes user's experience and feels.
A wide-angle outer window structure for building comprises
The middle part of the window frame is provided with a middle frame; an electric push rod is arranged on the window frame;
the opening-closing type window body is arranged on the inner side of the window frame; the opening-closing type windows are symmetrically arranged at two ends of the middle frame; one side of the symmetrical opening-closing type window body is rotationally connected with the middle frame; one end of the opening-closing type window body, which is far away from the middle frame, is provided with a limiting device corresponding to the electric push rod;
a closed window body; the closed window body is fixedly arranged in the window frame and symmetrically arranged on two sides of the opening-closing window body;
the symmetrical closed window body and the symmetrical opening and closing window body are respectively positioned on different planes.
As a preferred scheme, the limiting device comprises a toggle switch; the toggle switch is arranged at one end of the opening-closing type window body, which is far away from the middle frame.
As a preferred scheme, a controller is embedded at the side end of the opening-closing window body; the controller is electrically connected with the toggle switch; the controller is electrically connected with the electric push rod through a lead.
As a preferred scheme, the limiting device further comprises a limiting block; the limiting block is arranged at one end, far away from the middle frame, of the top of the opening-closing type window body.
As the preferred scheme, the limiting block is provided with a limiting hole corresponding to the electric push rod.
Preferably, the opening and closing window comprises a first opening and closing window sash and a second opening and closing window sash; the first opening-closing type window sash and the second opening-closing type window sash are symmetrically arranged relative to the middle frame; the width of the first opening-closing type window sash and the width of the second opening-closing type window sash are 1580-1700 mm.
Preferably, an included angle β is formed between the first opening-closing type window sash and the second opening-closing type window sash, wherein β is larger than or equal to 115 degrees and smaller than or equal to 150 degrees.
Preferably, the closed window comprises a first closed window sash and a second closed window sash; the first closed type window sash is arranged on one side, away from the second open type window sash, of the first open type window sash; the second closed type window sash is arranged on one side, away from the first open type window sash, of the second open type window sash; the width of the first closed type window sash and the width of the second closed type window sash are 1450-1550 mm.
Preferably, an included angle theta is formed between the first closed type window sash and the first open type window sash, wherein the theta is larger than or equal to 105 degrees and smaller than or equal to 140 degrees.
Preferably, an included angle alpha is formed between the second closed type window sash and the second open type window sash, wherein the alpha is more than or equal to 110 degrees and less than or equal to 145 degrees.
Has the advantages that: the utility model discloses a symmetry is equipped with open-close type window form and closed window form in window frame, wherein the closed window form of symmetry and the open-close type window form of symmetry are in different planes respectively and can enlarge the field of vision, compare in current planar windowsill field of vision wider, can promote user's experience and feel, realize opening and shutting of open-close type window form through setting up stop device and electric putter, and easy operation is convenient, compare in the totally enclosed type windowsill, the open-close type window form of symmetry more is favorable to indoor circulation of air with certain angle setting, further promote user's experience and feel.
Drawings
Fig. 1 is a front view of the present invention.
Fig. 2 is a top view of the present invention.
Fig. 3 is a partial structure diagram of the opening-closing window of the present invention.
Fig. 4 is a partial schematic view of the window frame of the present invention.
In the figure: 1-closed window body; 2-opening and closing type window body; 3-a middle frame; 4-a window frame; 5-a limiting device; 11-a first closed sash; 12-a second closed sash; 21-a first open-close type window sash; 22-a second open-close type sash; 41-electric push rod; 51-toggle switch; 52-a controller; 53-wire; 54-a limiting block; 55-limiting hole.
Detailed Description
The present invention will now be described in further detail with reference to the accompanying drawings. These drawings are simplified schematic drawings and illustrate the basic structure of the present invention only in a schematic manner, and thus show only the components related to the present invention.
In the present invention, it should be noted that the terms "upper", "lower", "inner", "outer", "middle", "far away", "close" and the like indicate the orientation or positional relationship based on the orientation or positional relationship shown in the drawings, and are only for convenience of description and simplification of description, but do not indicate or imply that the device or element referred to must have a specific orientation, be constructed in a specific orientation and be operated, and thus, should not be construed as limiting the present invention; the terms "first", "second" and "first" are used for descriptive purposes only and are not to be construed as indicating or implying relative importance; furthermore, unless expressly stated or limited otherwise, the terms "mounted," "connected," and "connected" are to be construed broadly, as they may be fixedly connected, detachably connected, or integrally connected, for example; can be mechanically or electrically connected; they may be connected directly or indirectly through intervening media, or they may be interconnected between two elements. The specific meaning of the above terms in the present invention can be understood in specific cases to those skilled in the art.
Examples
As shown in fig. 1 and 4, the utility model provides a wide angle exterior window structure for building, including window frame 4, open-close type window form 2 and closed window form 1, the middle part of window frame 4 is equipped with intermediate frame 3, be equipped with electric putter 41 on window frame 4, open-close type window form 2 sets up in window frame 4 inboard, open-close type window form 2 symmetry sets up in the both ends of intermediate frame 3, one side and the intermediate frame 3 of symmetrical open-close type window form 2 are rotated and are connected, open-close type window form 2 is kept away from intermediate frame 3 one end and is installed the stop device 5 corresponding with electric putter 41, closed window form 1 fixed mounting is in window frame 4 and closed window form 1 symmetry sets up in the both sides of open-close type window form 2, symmetrical closed window form 1 and symmetrical open-close type window form 2 are in different planes respectively; the utility model discloses a symmetry is equipped with open-close type window form 2 and closed window form 1 in window frame 4, wherein the closed window form 1 of symmetry and the open-close type window form 2 of symmetry are in different planes respectively and can enlarge the field of vision, compare in current planar windowsill field of vision wider, can promote user's experience and feel, realize opening and shutting of open-close type window form 2 through setting up stop device 5 and electric putter 41, and easy operation is convenient, compare in the totally enclosed windowsill, the open-close type window form 2 of symmetry more is favorable to indoor circulation of air with certain angle setting, further promote user's experience and feel.
Referring to fig. 3, in the specific example of the present invention, the limiting device 5 includes a toggle switch 51, the toggle switch 51 is installed at one end of the opening and closing type window body 2 far from the middle frame 3, a controller 52 is embedded at the side end of the opening and closing type window body 2, the controller 52 is electrically connected with the toggle switch 51, the controller 52 is electrically connected with the electric push rod 41 through a wire 53, the limiting device 5 further includes a limiting block 54, the limiting block 54 is installed at one end of the top of the opening and closing type window body 2 far from the middle frame 3, and a limiting hole 55 corresponding to the electric push rod 41 is provided on the limiting block; through toggle switch 51 with signal transmission to controller 52, controller 52 received signal and handles, then pass through wire 53 and open and close the action to electric putter 41 transmission, thereby realize that the push rod on electric putter 41 stretches out and the withdrawal, when the push rod stretches out, the push rod is arranged in spacing hole 55 and is carried on spacingly, open-close type window body 2 is in the state of locking this moment, open-close type window body 2 can not be opened, when the push rod withdraws, the push rod withdraws from spacing hole 55, open-close type window body 2 is in the unblock state this moment, open-close type window body 2 can not be opened, thereby realize indoor ventilation.
In the preferred example of the present invention, the opening and closing window 2 includes a first opening and closing type window sash 21 and a second opening and closing type window sash 22, the first opening and closing type window sash 21 and the second opening and closing type window sash 22 are symmetrically disposed about the middle frame 3, the widths of the first opening and closing type window sash 21 and the second opening and closing type window sash 22 are specifically 1615mm, the closed window 1 includes a first closed type window sash 11 and a second closed type window sash 12, the first closed type window sash 11 is disposed on one side of the first opening and closing type window sash 21 away from the second opening and closing type window sash 22, the second closed type window sash 12 is disposed on one side of the second opening and closing type window sash 22 away from the first opening and closing type window sash 21, and the widths of the first closed type window sash 11 and the second closed type window sash 12 are specifically 1520 mm; the width of the first opening-closing type window sash 21 is the same as that of the second opening-closing type window sash 22, and the width of the first closed type window sash 11 is the same as that of the second closed type window sash 12, so that the opening-closing type window body 2 and the closed type window body 1 are symmetrical about the middle frame 3, the attractiveness of the outer window is improved, and the experience of a user is improved.
Referring to fig. 2, in some embodiments of the present invention, in order to ensure the aesthetic property of the exterior window, an included angle β is formed between the first opening and closing type window sash 21 and the second opening and closing type window sash 22, an included angle θ is formed between the first closed type window sash 11 and the first opening and closing type window sash 21, and an included angle α is formed between the second closed type window sash 12 and the second opening and closing type window sash 22, which is equal to β = θ = α =135 °, so that the opening and closing type window body 2 and the closed type window body 1 are completely symmetrical about the middle frame 3 after the structure is adopted, and the aesthetic property is stronger.
In the description herein, references to the description of the terms "one embodiment," "certain embodiments," "an illustrative embodiment," "an example," "a specific example," or "some examples," etc., mean that a particular feature, structure, material, or characteristic described in connection with the embodiment or example is included in at least one embodiment or example of the invention. In this specification, schematic representations of the above terms do not necessarily refer to the same embodiment or example. Furthermore, the particular features, structures, materials, or characteristics described may be combined in any suitable manner in any one or more embodiments or examples.
The basic principles and the main features of the invention and the advantages of the invention have been shown and described above, it will be evident to those skilled in the art that the invention is not limited to the details of the foregoing illustrative embodiments, but that the invention may be embodied in other specific forms without departing from the spirit or essential characteristics of the invention. The present embodiments are therefore to be considered in all respects as illustrative and not restrictive, the scope of the invention being indicated by the appended claims rather than by the foregoing description, and all changes which come within the meaning and range of equivalency of the claims are therefore intended to be embraced therein. Any reference sign in a claim should not be construed as limiting the claim concerned.
Furthermore, it should be understood that although the present description refers to embodiments, not every embodiment may contain only a single embodiment, and such description is for clarity only, and those skilled in the art should integrate the description, and the embodiments may be combined as appropriate to form other embodiments understood by those skilled in the art.
Claims (10)
1. The utility model provides a wide angle exterior window structure for building which characterized in that: comprises that
The middle part of the window frame is provided with a middle frame; an electric push rod is arranged on the window frame;
the opening-closing type window body is arranged on the inner side of the window frame; the opening-closing type windows are symmetrically arranged at two ends of the middle frame; one side of the symmetrical opening-closing type window body is rotationally connected with the middle frame; one end of the opening-closing type window body, which is far away from the middle frame, is provided with a limiting device corresponding to the electric push rod;
a closed window body; the closed window body is fixedly arranged in the window frame and symmetrically arranged on two sides of the opening-closing window body; the symmetrical closed window body and the symmetrical opening and closing window body are respectively positioned on different planes.
2. A wide angle exterior window structure for buildings as claimed in claim 1, wherein the limiting means comprises a toggle switch; the toggle switch is arranged at one end of the opening-closing type window body, which is far away from the middle frame.
3. The wide-angle exterior window structure for buildings as claimed in claim 2, wherein a controller is embedded at a side end of the opening and closing type window body; the controller is electrically connected with the toggle switch; the controller is electrically connected with the electric push rod through a lead.
4. A wide angle exterior window structure for buildings as claimed in claim 3, wherein the limiting means further comprises a limiting block; the limiting block is arranged at one end, far away from the middle frame, of the top of the opening-closing type window body.
5. The wide-angle outer window structure for buildings according to claim 4, wherein the limiting block is provided with a limiting hole corresponding to the electric push rod.
6. A wide angle architectural exterior window structure according to claim 1, wherein said retractable window comprises a first retractable sash and a second retractable sash; the first opening-closing type window sash and the second opening-closing type window sash are symmetrically arranged relative to the middle frame; the width of the first opening-closing type window sash and the width of the second opening-closing type window sash are 1580-1700 mm.
7. The wide angle exterior window structure for buildings as claimed in claim 6, wherein the first and second sashes form an included angle β, wherein β is 115 ° or more and 150 ° or less.
8. The wide angle exterior window structure for buildings according to claim 7, wherein the closed window comprises a first closed sash and a second closed sash; the first closed type window sash is arranged on one side, away from the second open type window sash, of the first open type window sash; the second closed type window sash is arranged on one side, away from the first open type window sash, of the second open type window sash; the width of the first closed type window sash and the width of the second closed type window sash are 1450-1550 mm.
9. The wide angle exterior window structure for buildings as claimed in claim 8, wherein the first closed type sash and the first open type sash form an angle θ, wherein θ is 105 ° or more and 140 ° or less.
10. The wide angle exterior window structure for buildings as claimed in claim 9, wherein the second closed type sash and the second open type sash form an angle α, wherein α is 110 ° or more and 145 ° or less.
