CN213009917U

CN213009917U - Garbage disposal is with having filtration classified recovery garbage bin

Info

Publication number: CN213009917U
Application number: CN202021353905.4U
Authority: CN
Inventors: 卢国全
Original assignee: Hunan Zhongzhou Energy Saving Technology Co ltd
Current assignee: Zhongzhou Energy Conservation Technology Co ltd
Priority date: 2020-07-11
Filing date: 2020-07-11
Publication date: 2021-04-20
Anticipated expiration: 2030-07-11

Abstract

The utility model discloses a refuse treatment is with having filtration classification of retrieving garbage bin, including bucket bottom plate and gomphosis board, the upper end of bucket bottom plate is equipped with the ladle body, and is equipped with the draw-in groove around the upper end of ladle body and encloses the edge, the draw-in groove encloses and is equipped with the gomphosis board around the upper end on edge, the draw-in groove encloses one side on edge and is equipped with the hinge, and is connecting the bung on the hinge, the upper end both sides of bung are equipped with the handle, lower extreme one side of ladle body is equipped with the wheel rim, and the lower extreme opposite side of ladle body is equipped with the supporting leg, the inside lower extreme of. This be provided with the main effect of collecting the box and lie in collecting the liquid that filter upper end rubbish oozed to reduce the liquid in the garbage bin and be smelly because of long-term airtight fermentation that leads to, collect the box simultaneously and still can place the deodorization ball in order to prevent liquid natural fermentation, the fixture block mainly plays in addition and carries out spacing fixed the preventing slippage to collecting the box, and the handle mainly plays in addition and lifts the effect of taking out and collecting the box.

Description

Garbage disposal is with having filtration classified recovery garbage bin

Technical Field

The utility model relates to a garbage bin filters and categorised recovery technical field specifically is a garbage treatment is with having filtration categorised recovery garbage bin.

Background

Along with the increasing living standard of people, the consumption of energy and various living goods is larger and larger, so that various garbage wastes are generated, the garbage can for recycling the garbage is generated under the condition, and the living convenience of people is greatly improved due to the application of the garbage can.

The existing garbage cans on the market are basically similar, and are mostly composed of the garbage can, a can cover, a rim and the like, but have some defects, such as lack of solid-liquid separation on the garbage, and the problem that the garbage is easy to smell in a closed state for a long time cannot be solved. Therefore, the classified recycling garbage can with the filtering structure for garbage disposal is provided.

SUMMERY OF THE UTILITY MODEL

An object of the utility model is to provide a refuse treatment is with having categorised garbage bin of retrieving of filtration to solve the garbage bin on the existing market that proposes in the above-mentioned background art basically all more similar, mostly by garbage bin itself to and constitute such as bung and wheel rim, but also have some weak points simultaneously, for example lack the solid-liquid separation to rubbish, simultaneously because of the long-term problem that can not solve in this aspect of smelly easily under the encapsulated situation to rubbish.

In order to achieve the above object, the utility model provides a following technical scheme: the garbage can comprises a can bottom plate and an embedded plate, wherein a can body is arranged at the upper end of the can bottom plate, a clamping groove enclosing edge is arranged on the periphery of the upper end of the can body, the embedded plate is arranged on the periphery of the upper end of the clamping groove enclosing edge, a hinge is arranged on one side of the clamping groove enclosing edge, a can cover is connected to the hinge, handles are arranged on two sides of the upper end of the can cover, a wheel rim is arranged on one side of the lower end of the can body, supporting legs are arranged on the other side of the lower end of the can body, a filter plate is arranged at the lower end of the interior of the can body, filter holes are formed in the surface of the filter plate, a collecting box is arranged below the filter plate, a handle is arranged on one side of the collecting box, a cover plate is arranged on the outer side of the can body.

Preferably, the collecting box is horizontally placed at the upper end of the barrel bottom plate, the collecting box and the clamping block on one side of the upper end of the barrel bottom plate are in embedded distribution, and the handle on one side of the collecting box is in embedded distribution.

Preferably, the barrel cover forms a rotating structure through a hinge, the handles are symmetrically distributed along the center line of the barrel cover, and the barrel cover and the embedding plate are in embedded distribution.

Preferably, the border of filter is laminated each other with the inner wall of ladle body, and the filtration pore of crossing on the filter is hole form evenly distributed, and the apron in the ladle body outside is the fan-shaped form distribution that opens and shuts simultaneously.

Preferably, the barrel bottom plate and the barrel body are distributed in a semi-closed manner, and the surrounding edge of the clamping groove at the upper end of the barrel body is distributed in a protruding surrounding manner.

Preferably, the rim and the supporting legs are symmetrically distributed along the central axis of the barrel bottom plate, and the rim and the supporting legs are respectively positioned at the rear and the front of the barrel body.

Compared with the prior art, the beneficial effects of the utility model are that: this refuse treatment is with having filtration categorised recovery garbage bin is provided with the liquid that collects the box that the main function lies in can collecting the filter upper end rubbish ooze to reduce the liquid in the garbage bin and lead to the fermentation stink because of airtight for a long time, collect the box simultaneously and still can place the deodorization ball in order to prevent liquid natural fermentation, the fixture block mainly plays in addition and carries out spacing fixed the preventing slippage to collecting the box, the handle mainly plays in addition and lifts and takes out the effect collecting the box.

The main effect of bung lies in closing the ladle body to make the inside rubbish peculiar smell of ladle body can not give off and float, and the hinge mainly plays the fixed connection bung, thereby makes the bung can rotate to open and shut, and the main effect of handle lies in making things convenient for the operator to open and close the bung in addition.

The main effect of filter lies in bearing rubbish to make rubbish can not drop to collecting the box in, and the main effect of filtration pore lies in can filtering the liquid that oozes in the rubbish, thereby makes the liquid of filter upper end can flow naturally and fall to collecting in the box, and the apron mainly plays in addition and covers to collecting the gap that the box is located ladle body one side and close, thereby makes the liquid peculiar smell in collecting the box can not fly away.

Drawings

Fig. 1 is a schematic front view of the external structure of the present invention;

FIG. 2 is a schematic side view of the internal structure of the present invention;

FIG. 3 is a schematic view of the enlarged structure of the part A of the present invention;

fig. 4 is a schematic view of the structure of the collecting box of the present invention.

In the figure: 1. a tub bottom plate; 2. a barrel body; 3. the clamping groove is surrounded; 4. a tabling plate; 5. a barrel cover; 6. a hinge; 7. a handle; 8. a rim; 9. supporting legs; 10. a filter plate; 11. a filtration pore; 12. a collection box; 13. a handle; 14. a cover plate; 15. and (7) clamping blocks.

Detailed Description

The technical solutions in the embodiments of the present invention will be described clearly and completely with reference to the accompanying drawings in the embodiments of the present invention, and it is obvious that the described embodiments are only some embodiments of the present invention, not all embodiments. Based on the embodiments in the present invention, all other embodiments obtained by a person skilled in the art without creative work belong to the protection scope of the present invention.

Referring to fig. 1-4, the present invention provides a technical solution: a garbage can with a filtering structure for classified recovery for garbage disposal comprises a can bottom plate 1, a can body 2, a clamping groove surrounding edge 3, an embedded plate 4, a can cover 5, a hinge 6, a handle 7, a rim 8, supporting legs 9, a filtering plate 10, a filtering hole 11, a collecting box 12, a handle 13, a cover plate 14 and a clamping block 15, wherein the can body 2 is arranged at the upper end of the can bottom plate 1, the clamping groove surrounding edge 3 is arranged around the upper end of the can body 2, the embedded plate 4 is arranged around the upper end of the clamping groove surrounding edge 3, the hinge 6 is arranged on one side of the clamping groove surrounding edge 3, the can cover 5 is connected onto the hinge 6, the handle 7 is arranged on two sides of the upper end of the can cover 5, the rim 8 is arranged on one side of the lower end of the can body 2, the supporting legs 9 are arranged on the other side of the lower end of the can body 2, the filtering plate 10 is arranged on the lower end of the interior of the, a cover plate 14 is arranged above the handle 13 and outside the barrel body 2, and a clamping block 15 is arranged at one side of the upper end of the barrel bottom plate 1 and at the lower end of the collecting box 12.

The collecting box 12 is horizontally placed at the upper end of the barrel bottom plate 1, the collecting box 12 and the clamping block 15 at one side of the upper end of the barrel bottom plate 1 are in embedded distribution, meanwhile, the handle 13 at one side of the collecting box 12 is in embedded distribution, the collecting box 12 has the main function of collecting liquid seeped from the garbage at the upper end of the filter plate 10 so as to reduce fermentation and stink of the liquid in the garbage barrel caused by long-term sealing, meanwhile, the collecting box 12 can also be used for placing a deodorizing ball to prevent the liquid from being naturally fermented, in addition, the clamping block 15 mainly plays a role in limiting, fixing and preventing the collecting box 12 from slipping, and in addition, the handle 13 mainly plays a role in lifting and pulling out the collecting box 12;

the barrel cover 5 forms a rotating structure through the hinge 6, the handles 7 are symmetrically distributed along the central line of the barrel cover 5, meanwhile, the barrel cover 5 and the embedded plate 4 are in embedded distribution, the barrel cover 5 mainly has the main function of closing the barrel body 2, so that the peculiar smell of garbage in the barrel body 2 cannot be emitted and float out, the hinge 6 mainly plays a role of fixedly connecting the barrel cover 5, so that the barrel cover 5 can be opened and closed in a rotating manner, and in addition, the handles 7 mainly have the function of facilitating an operator to open and close the barrel cover 5;

the edge of the filter plate 10 is attached to the inner wall of the barrel body 2, the filter holes 11 in the filter plate 10 are uniformly distributed in a hole shape, meanwhile, the cover plate 14 on the outer side of the barrel body 2 is distributed in a fan-shaped opening and closing shape, the filter plate 10 is mainly used for bearing garbage, so that the garbage cannot fall into the collection box 12, the filter holes 11 are mainly used for filtering liquid seeped from the garbage, so that the liquid at the upper end of the filter plate 10 can naturally flow into the collection box 12, in addition, the cover plate 14 mainly covers a gap of the collection box 12 on one side of the barrel body 2, and therefore the peculiar smell of the liquid in the collection box 12 cannot float out;

the garbage collection vehicle comprises a barrel bottom plate 1, a barrel body 2, a clamping groove surrounding edge 3 and a collecting box 12, wherein the barrel bottom plate 1 and the barrel body 2 are distributed in a semi-closed manner, the clamping groove surrounding edge 3 at the upper end of the barrel body 2 is distributed in a protruding surrounding manner, the barrel body 2 has the main function of containing garbage, the barrel bottom plate 1 mainly plays the roles of fixing a rim 8 and a supporting leg 9, meanwhile, the barrel bottom plate 1 also plays the role of placing and bearing the collecting box 12, and the clamping groove surrounding edge 3 mainly plays the roles of facilitating the garbage collection vehicle to fork and put;

rim 8 and supporting leg 9 are along the axis symmetric distribution of barrel head board 1, and rim 8 and supporting leg 9 are located the rear and the place ahead of ladle body 2 respectively, and rim 8's main effect lies in can carrying out vertical support to ladle body 2 to make ladle body 2 can not incline unstably, and rim 8's main effect lies in can making the garbage bin can slide the removal, thereby has saved the trouble you of carrying the garbage bin.

The working principle is as follows: for the classified recycling garbage can with the filtering structure for garbage disposal, firstly, the can body 2 is communicated with the can bottom plate 1 and pushed to a designated position through the rim 8, then the can cover 5 is opened through the handle 7, then the garbage is thrown into the can body 2, finally the can cover 5 is closed through the handle 7 and the hinge 6, then when the garbage drops onto the filter plate 10, liquid seeped from the garbage bag can flow into the collecting box 12 through the filtering hole 11, attention is paid to the fact that the cover plate 14 can be lifted, the collecting box 12 is drawn out by pulling the handle 13, then a deodorant is placed into the collecting box 12, then the collecting box 12 is pushed into the can body 2 and fixed through the clamping block 15, and the clamping groove surrounding edge 3 is mainly used for facilitating the garbage recycling vehicle to fork and put down the can body 2.

Although embodiments of the present invention have been shown and described, it will be appreciated by those skilled in the art that changes, modifications, substitutions and alterations can be made in these embodiments without departing from the principles and spirit of the invention, the scope of which is defined in the appended claims and their equivalents.

Claims

1. The utility model provides a refuse treatment is with having categorised garbage bin of retrieving of filtration, includes bucket bottom plate (1) and gomphosis board (4), its characterized in that: the upper end of the barrel bottom plate (1) is provided with a barrel body (2), a clamping groove surrounding edge (3) is arranged on the periphery of the upper end of the barrel body (2), an embedded plate (4) is arranged on the periphery of the upper end of the clamping groove surrounding edge (3), one side of the clamping groove surrounding edge (3) is provided with a hinge (6), a barrel cover (5) is connected onto the hinge (6), handles (7) are arranged on two sides of the upper end of the barrel cover (5), one side of the lower end of the barrel body (2) is provided with a rim (8), the other side of the lower end of the barrel body (2) is provided with a supporting leg (9), a filter plate (10) is arranged at the lower end of the interior of the barrel body (2), a filter hole (11) is formed in the plate surface of the filter plate (10), a collecting box (12) is arranged below the filter plate (10), one side of the collecting box (12) is provided with a handle (13), a clamping block (15) is arranged at one side of the upper end of the barrel bottom plate (1) and is positioned at the lower end of the collecting box (12).

2. The garbage can with filtering structure for sorting and recycling of garbage according to claim 1, wherein: the collecting box (12) is horizontally placed at the upper end of the barrel bottom plate (1), the collecting box (12) and a clamping block (15) on one side of the upper end of the barrel bottom plate (1) are distributed in an embedded mode, and meanwhile the handle (13) on one side of the collecting box (12) is distributed in an embedded mode.

3. The garbage can with filtering structure for sorting and recycling of garbage according to claim 1, wherein: the barrel cover (5) forms a rotating structure through the hinge (6), the handles (7) are symmetrically distributed along the central line of the barrel cover (5), and the barrel cover (5) and the embedded plate (4) are distributed in an embedded manner.

4. The garbage can with filtering structure for sorting and recycling of garbage according to claim 1, wherein: the border of filter (10) and the inner wall of ladle body (2) laminate each other, and filter hole (11) on filter (10) are the pore form evenly distributed, and apron (14) in ladle body (2) outside are the fan-shaped form distribution that opens and shuts simultaneously.

5. The garbage can with filtering structure for sorting and recycling of garbage according to claim 1, wherein: the barrel bottom plate (1) and the barrel body (2) are distributed in a semi-closed manner, and the clamping groove surrounding edge (3) at the upper end of the barrel body (2) is distributed in a protruding surrounding manner.

6. The garbage can with filtering structure for sorting and recycling of garbage according to claim 1, wherein: the rim (8) and the supporting legs (9) are symmetrically distributed along the central axis of the barrel bottom plate (1), and the rim (8) and the supporting legs (9) are respectively positioned behind and in front of the barrel body (2).
