CN211512328U - Breathable gel material paper diaper convenient to wear

Info

Publication number: CN211512328U
Application number: CN201921940271.XU
Authority: CN
Inventors: 刘妙锋; 陈东飞; 赵乐; 蒲晓邨
Original assignee: Shenzhen Lemin Technology Co ltd
Current assignee: Shenzhen Lemin Technology Co ltd
Priority date: 2019-11-11
Filing date: 2019-11-11
Publication date: 2020-09-18
Anticipated expiration: 2029-11-11

Abstract

The utility model relates to a ventilative gel material panty-shape diapers of conveniently dressing, including the trousers body and the core that can absorb the urine, trousers body front end is provided with preceding ring waist, trousers body rear end is provided with the back ring waist, still include one end with preceding ring waist one end is connected, the other end with the elastic cord that back ring waist one end is connected. The utility model discloses the effect of conveniently dressing has.

Description

Breathable gel material paper diaper convenient to wear

Technical Field

The utility model relates to a field of paper diaper, in particular to a breathable gel material paper diaper convenient to wear.

Background

At present be paper diaper structure on market mainly includes the dustcoat, the absorber, the leak protection barricade, shank elasticity rubber band, the magic is detained and back waist elastic component, the dustcoat expandes to be rectangle, divide into even preceding waist district as an organic whole on the dustcoat length direction, crotch district and back waist district, the dustcoat includes outer and the water permeability inlayer of non-permeability, the absorber is in between outer and the water permeability inlayer of non-permeability to pass through glue bonding fixation along the edge of absorber, the leak protection barricade, shank elasticity rubber band and magic are detained and are all fixed on the dustcoat, the magic is detained to enclose paper diaper during the use and is worn on one's body.

However, when the baby grows to be able to walk upright, the baby is unwilling to lie down and wear the baby in a matching way, and for the standing and active baby, one hand needs to be vacated for the baby wearing the paper diaper to hold the baby to prevent the baby from moving around, so the wearing of the paper diaper is not very convenient.

SUMMERY OF THE UTILITY MODEL

The utility model aims at providing a ventilative gel material panty-shape diapers of conveniently wearing have the effect of conveniently wearing.

The above utility model discloses an above-mentioned utility model purpose can realize through following technical scheme:

the utility model provides a ventilative gel material panty-shape diapers that conveniently dress, includes the trousers body and can absorb the core of urine, trousers body front end is provided with preceding ring waist, trousers body rear end is provided with back ring waist, still include one end with preceding ring waist one end is connected, the other end with the elastic cord that back ring waist one end is connected.

By adopting the technical scheme, for a standing baby, the paper diaper is attached to the crotch of the baby, and the elastic band is stretched to the shoulder of the baby, so that the baby can be pre-worn, the paper diaper cannot be easily separated even if the baby is good, and a person wearing the paper diaper can adjust the position of the paper diaper by using two hands, and the front girth and the rear girth are folded and bonded to finish the wearing of the paper diaper; therefore, on one hand, the paper diaper can be conveniently worn by a standing or active baby due to the arrangement of the elastic bands; on the other hand, the stability after wearing can be enhanced.

The utility model discloses further set up to: the two elastic bands are arranged on the two sides of the trousers body.

By adopting the technical scheme, the two elastic bands can be simultaneously fixed on the shoulders at the two sides of the baby, so that the pre-wearing stability of the paper diaper is further enhanced, the pre-worn paper diaper is not easy to separate, and the paper diaper is convenient to wear.

The utility model discloses further set up to: and a buffer cushion is arranged in the middle of the elastic band.

Through adopting above-mentioned technical scheme, the elastic cord is dressed the back, sets up in the blotter and the contact of baby's shoulder at elastic cord middle part to promote the comfort level that the elastic cord was dressed.

The utility model discloses further set up to: the elastic cord cladding has ventilative non-woven fabrics, ventilative non-woven fabrics can be along with the elastic cord is synchronous to be stretched and contract.

By adopting the technical scheme, the breathable non-woven fabric is soft and skin-friendly, and can replace the elastic band to contact the skin of a baby after the breathable non-woven fabric is wrapped by the elastic band, so that the discomfort of the elastic band during wearing is reduced; when the elastic band is not stretched, the breathable non-woven fabric is in a folded state, and the elastic band and the breathable non-woven fabric are stretched and contracted synchronously, so that the breathable non-woven fabric is prevented from interfering the deformation of the elastic band.

The utility model discloses further set up to: the elastic cord both ends with ventilative non-woven fabrics both ends are fixed, ventilative non-woven fabrics both ends are provided with fixed the knot, preceding ring waist with the both ends of back ring waist all are provided with the confession the button hole of fixed knot lock joint.

By adopting the technical scheme, the elastic band can be detachably connected to the trousers body through the matching of the fixing buckles and the button holes, so that a user can detach and install the elastic band according to actual needs; the fixing buckle and the button hole are simply and quickly matched, and a user can conveniently disassemble and assemble the elastic band. The fixing button is arranged on the elastic band, so that after the elastic band is disassembled, the buttonholes of the front ring waist and the rear ring waist do not protrude out of the diaper body, and the attractiveness of the paper diaper is improved; after the two ends of the elastic band are fixed with the two ends of the breathable non-woven fabric, the position of the elastic band in the breathable non-woven fabric can be stabilized.

The utility model discloses further set up to: the front ring waist and the rear ring waist are provided with inserting bags for placing the elastic bands.

Through adopting above-mentioned technical scheme, the setting of slash pocket can provide one for the elastic cord and place the position, dresses the back with panty-shape diapers, can lift the elastic cord off, places in the slash pocket, makes things convenient for accomodating of elastic cord.

The utility model discloses further set up to: the two sides of the trousers body are provided with leakproof isolation edges.

By adopting the technical scheme, the leakage-proof isolation edges can increase the wrapping degree of the trousers body and prevent leakage liquid from leaking from two sides of the trousers body; in addition, the overall coating degree of the trousers body can be increased, so that the comfort of a wearer is improved.

The utility model discloses further set up to: the core body is sequentially provided with dust-free paper, breathable water-absorbing elastic gel, fluffy cloth, breathable water-absorbing elastic gel and dust-free paper from top to bottom.

By adopting the technical scheme, the dust-free paper has extremely high water absorption and good water retention performance; the breathable water-absorbing elastic gel has extremely strong water absorption performance and air permeability, and the water absorption and water absorption capacity of the core body can be greatly improved by arranging the double-layer high-molecular water-absorbing resin.

To sum up, the utility model discloses a beneficial technological effect does:

1. for a standing baby, the elastic band stretches to the shoulder of the baby after the paper diaper is attached to the crotch of the baby, so that the baby can be dressed in advance, the paper diaper cannot be easily separated even if the baby moves, and the baby can be conveniently dressed.

2. The two elastic bands can be fixed on the shoulders on the two sides of the baby at the same time, so that the pre-wearing stability of the paper diaper is further enhanced, and the paper diaper can be conveniently worn.

3. The dust-free paper has extremely high water absorption and good water retention performance; the breathable water-absorbing elastic gel has extremely strong water absorption performance and air permeability, and the water absorption and water absorption capacity of the core body can be greatly improved by arranging the double-layer high-molecular water-absorbing resin.

Drawings

FIG. 1 is a schematic view of the overall structure of the utility model, and the trousers body is connected with an elastic belt which is in a stretching state;

fig. 2 is a schematic partial cross-sectional view of the present invention, showing the structure of the elastic band and the breathable non-woven fabric, the elastic band being in a stretched state;

FIG. 3 is a schematic structural view of the pants body of the present invention;

fig. 4 is an explosion structure diagram of the core body of the present invention.

In the figure: 1. a pant body; 2. a core body; 3. elastic bands; 4. a front ring waist; 5. back ring waist; 6. a cushion pad; 7. a breathable non-woven fabric; 8. a fixing buckle; 9. a buttonhole; 10. inserting a bag; 11. a leakage-proof isolation edge; 12. dust-free paper; 13. breathable water-absorbing elastic gel; 14. fluffy cloth.

Detailed Description

The present invention will be described in further detail with reference to the accompanying drawings.

The utility model provides a ventilative gel material panty-shape diapers of convenient wearing, refers to figure 1, includes the trousers body 1, can absorb the core 2 of urine in order to be located the elastic cord 3 of two of the 1 both sides of the trousers body, and 1 front end of the trousers body is provided with preceding

ring waist

4, and 1 rear end of the trousers body is provided with back ring waist 5, and preceding ring waist 4 and back ring waist 5 paste the bonding through the magic. The elastic band 3 is preferably a jacquard polyester elastic band 3, the pH value of the jacquard polyester elastic band is between weak acidity and neutrality, the jacquard polyester elastic band is weak acidity and is relatively skin-friendly, and the situation of skin itch is reduced.

Referring to fig. 2, a buffer pad 6 is disposed in the middle of the elastic band 3, and after the elastic band 3 is worn, the buffer pad 6 contacts with the shoulders of the infant, thereby improving the comfort of wearing the elastic band 3. The breathable non-woven fabric 7 is wrapped outside the elastic band 3, the breathable non-woven fabric 7 is soft and skin-friendly, and the breathable non-woven fabric 7 can replace the elastic band 3 to contact with the skin of a baby after being wrapped on the elastic band 3, so that discomfort when the elastic band 3 is worn is reduced, and the breathable non-woven fabric 7 is in a folded state when the elastic band 3 is not stretched, so that the breathable non-woven fabric 7 can be stretched synchronously along with the elastic band 3 when the elastic band 3 is stretched.

Referring to fig. 2 and 3, two ends of the elastic band 3 are sewn and fixed with two ends of the breathable non-woven fabric 7, two ends of the breathable non-woven fabric 7 are provided with fixing buckles 8, two ends of the front ring waist 4 and the rear ring waist 5 are respectively provided with a button hole 9 for fastening the fixing buckles 8, and the elastic band 3 can be detachably connected to the trousers body 1 through the matching of the fixing buckles 8 and the button holes 9, so that a user can disassemble and assemble the elastic band 3 according to actual needs; the fixing buckle 8 and the button hole 9 are simply and quickly matched, so that a user can conveniently disassemble and assemble the elastic band 3; in addition, the length of the elastic band 3 can be changed according to the needs of the user.

The slash pocket 10 that supplies elastic cord 3 to place is all seted up to preceding ring waist 4 and back ring waist 5, can provide one for elastic cord 3 and place the position, dresses the paper diaper after, can lift elastic cord 3 off, places in slash pocket 10, makes things convenient for accomodating of elastic cord 3.

Referring to fig. 3, the two sides of the trousers body 1 are provided with the leakproof isolation edges 11, so that the wrapping degree of the trousers body 1 can be increased, and leakage liquid can be prevented from leaking from the two sides of the trousers body 1; in addition, the overall coating degree of the trousers body 1 can be increased, so that the comfort of a wearer is improved.

Referring to fig. 4, the core body 2 is sequentially provided with the dust-free paper 12, the breathable water-absorbing elastic gel 13, the fluffy cloth 14, the breathable water-absorbing elastic gel 13 and the dust-free paper 12 from top to bottom, and the dust-free paper 12 has extremely high water absorption and good water retention performance; the breathable water-absorbing elastic gel 13 has extremely strong water absorption performance and air permeability, and the water absorption and water absorption capacity of the core body 2 can be greatly improved due to the arrangement of the double-layer high-molecular water-absorbing resin.

The implementation principle of the embodiment is as follows: when a standing baby wears the trousers, the fixing buttons 8 on the breathable non-woven fabric 7 are buckled on the button holes 9 of the trousers body 1, and the two elastic bands 3 are arranged on the two sides of the trousers body 1; unfolding the trousers body 1, attaching the trousers body 1 to the crotch of the baby, further stretching the elastic band 3 to the shoulders of the baby, and adjusting the position of the elastic band 3 on the shoulders to enable the cushion 6 on the elastic band 3 to be in contact with the shoulders; further adjusting the trousers body 1, looping the front loop waist 4 and the rear loop waist 5 on the waist of the baby, and attaching the front loop waist and the rear loop waist to each other through a magic tape; further wearing and adjusting the leakproof isolation edge 11; then, the user can select to detach the elastic bands 3 or continue to use the elastic bands 3 to enhance the wearing stability of the diaper according to the actual situation of the infant, and the detached elastic bands 3 can be accommodated in the insertion pockets 10.

The embodiment of this specific implementation mode is the preferred embodiment of the present invention, not limit according to this the utility model discloses a protection scope, so: all equivalent changes made according to the structure, shape and principle of the utility model are covered within the protection scope of the utility model.

Claims

1. The utility model provides a convenient ventilative gel material panty-shape diapers of dressing, includes the trousers body (1) and can absorb core (2) of urine, the trousers body (1) front end is provided with preceding ring waist (4), the trousers body (1) rear end is provided with back ring waist (5), its characterized in that: and the elastic band (3) is connected with one end of the front ring waist (4) and the other end of the front ring waist (5).

2. The breathable gel material diaper of claim 1, wherein: two elastic bands (3) are arranged, and the two elastic bands (3) are positioned on two sides of the trousers body (1).

3. The breathable gel material diaper of claim 2, wherein: a buffer pad (6) is arranged in the middle of the elastic band (3).

4. The breathable gel material diaper of claim 3, wherein: the elastic band (3) is coated with breathable non-woven fabric (7), and the breathable non-woven fabric (7) can be stretched and contracted synchronously with the elastic band (3).

5. The breathable gel material diaper of claim 4, wherein: elastic cord (3) both ends with ventilative non-woven fabrics (7) both ends are fixed, ventilative non-woven fabrics (7) both ends are provided with fixed knot (8), preceding ring waist (4) with the both ends of back ring waist (5) all are provided with the confession button hole (9) of fixed knot (8) lock joint.

6. The breathable gel material diaper of claim 5, wherein: the front ring waist (4) and the rear ring waist (5) are provided with inserting bags (10) for placing the elastic bands (3).

7. The breathable gel material diaper of claim 6, wherein: leak-proof isolation edges (11) are arranged on two sides of the trousers body (1).

8. The breathable gel material diaper of claim 7, wherein: the core body (2) is sequentially provided with dust-free paper (12), breathable water-absorbing elastic gel (13), fluffy cloth (14), breathable water-absorbing elastic gel (13) and dust-free paper (12) from top to bottom.
