CN201713699U - Novel laundry drying rack - Google Patents
Novel laundry drying rack Download PDFInfo
- Publication number
- CN201713699U CN201713699U CN2010202455028U CN201020245502U CN201713699U CN 201713699 U CN201713699 U CN 201713699U CN 2010202455028 U CN2010202455028 U CN 2010202455028U CN 201020245502 U CN201020245502 U CN 201020245502U CN 201713699 U CN201713699 U CN 201713699U
- Authority
- CN
- China
- Prior art keywords
- support
- bars
- drying rack
- clothes hanger
- laundry drying
- Prior art date
- Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
- Expired - Fee Related
Links
Images
Abstract
The utility model discloses a novel laundry drying rack which comprises a support arranged at the top end, wherein four telescopic support bars with identical lengths are hinged on the support, and the support bars are unfolded to form a pyramid taking the support as the top; and three support brackets are uniformly distributed in the horizontal direction on the novel laundry drying rack, each support bracket comprises four telescopic cross bars, and the cross bars are arranged between two adjacent support bars. The utility model adopts the telescopic bars to make the pyramidal laundry drying rack. In particular, the support is arranged at the top end of the laundry drying rack and the support bars are hinged on the support, so that when the support bars are unfolded, the stability of the laundry drying rack is enhanced and the occupied space for sun-drying the laundry is reduced. Furthermore, when not in use, the user can fold up the support bars and the cross bars and store the laundry drying rack on the ground or in other space; and when in use, the user can unfold the laundry drying rack, thereby saving the occupied space.
Description
Technical field
The utility model relates to a kind of instrument that hangs out, and relates in particular to a kind of novel clothes hanger.
Background technology
At present, clothes hanger is that people shine the main tool that hangs out, and clothes hanger generally can only shine the dress that dries in the air, and when the part clothes is dried in the air in solarization, can take bigger space.Especially for living in incity, city resident, the space is limited in the house, has increased the user and has shone the pressure that dries in the air.
Clothes hanger of the prior art generally adopts the mode that a hook is set on hanger, clothes is hung on the hanger, and then will link up with on iron pipe or rope, has increased user's use cost.When especially on iron pipe or rope, overworking clothes, take bigger area, bring inconvenience to the user.And when wind was bigger, hook came off easily, made clothes drop to the clothes of making dirty on the ground.
This shows that prior art needs further improvement and develops.
The utility model content
The utility model provides a kind of novel clothes hanger for solving above-mentioned defective of the prior art, solves the user and shines the technical problem that takies when hanging out than large space, occupation space when hanging out to reduce user's solarization.
For solving the problems of the technologies described above, the utility model scheme comprises:
A kind of novel clothes hanger, its top is provided with a carrier base, wherein, is hinged with four retractable support bars on this carrier base, and the support bar identical length is same, and the support bar of stretching, extension is that the top forms a pyramid with the carrier base; Evenly be provided with three support brackets of arranging along horizontal plane on the novel clothes hanger, each support bracket comprises four retractable cross bars, and cross bar is arranged between the adjacent supports bar.
Described novel clothes hanger, wherein, the support bar of above-mentioned stretching, extension is that the top forms an orthopyramid with the carrier base, support bracket is a rectangle.
Described novel clothes hanger, wherein, above-mentioned retractable cross bar is provided with gear.
A kind of novel clothes hanger that the utility model provides adopts expansion link to make a pyramid-type clothes hanger, especially on its top one carrier base is set, and support bar is hinged on this carrier base, when support bar is in extended configuration, has strengthened the steadiness of clothes hanger; And be provided with retractable cross bar between the support bar, the user can directly ride over clothes to shine on the cross bar and dry in the air, and also clothes can be hung on the hanger, hanger is hung over shine on the cross bar again and dries in the air, expanded its application space, reduced the user and shone occupation space when hanging out; Especially the utility model not using is, the user support bar and cross bar can be shunk be placed on the ground or other spaces in, again novel clothes hanger is strutted during use, saved user's usage space.
Description of drawings
Fig. 1 is the structure diagram of novel clothes hanger in the utility model.
The specific embodiment
The utility model provides a kind of novel clothes hanger, and is clearer, clear and definite in order to make the purpose of this utility model, technical scheme and advantage, below with reference to accompanying drawing and embodiment, the utility model further described.
The utility model provides a kind of novel clothes hanger, adopt retractable support bar and cross bar to make a clothes hanger, clothes hanger can be opened when the user uses, clothes hanger can be shunk when not using and place, reduce the user and shone occupation space when hanging out, saved user's usage space.As shown in Figure 1, the top of novel clothes hanger is provided with a carrier base 1, is hinged with four retractable support bars 2 on this carrier base 1, and the identical length of support bar 2 is same, and the support bar 2 of stretching, extension is that the top forms a pyramid with carrier base 1; Evenly be provided with three support brackets of arranging along horizontal plane 3 on the novel clothes hanger, each support bracket 3 comprises four retractable cross bars 4, and cross bar 4 is arranged between the adjacent supports bar 2.This shows, by stretching of support bar 2 and cross bar 4, can realize opening or shrinking of clothes hanger, and support bracket 3 is divided into three solarizations space of drying in the air with whole clothes hanger, having made things convenient for the user to shine hangs out, only take at certain area and just can shine the three layers of clothes that dry in the air, reduced the user and shone occupation space when hanging out; The user also can shrink the back with clothes hanger and place, and saved user's usage space, and the utility model making is simple, has reduced user's use cost.The utility model has also carried out corresponding improvement, and as shown in Figure 1, the support bar 2 of stretching, extension is that the top forms an orthopyramid with carrier base 1, and support bracket 3 is a rectangle, has improved the stability of clothes hanger.Especially retractable cross bar 4 is provided with gear, the user can determine the length of cross bar 4 as required, has expanded its application space, and under vertical connection status of cross bar 4, wind-force make clothes hanger more firm, even can not blow over it or blow down more greatly.
Should be understood that; above-mentioned description at preferred embodiment is comparatively detailed; can not therefore think restriction to the utility model scope of patent protection; those of ordinary skill in the art is under enlightenment of the present utility model; do not breaking away under the scope situation that the utility model claim protected; can also make various deformation such as replacement, simple combination, these all fall within the protection domain of the present utility model, and the scope of asking for protection of the present utility model should be as the criterion with claims.
Claims (3)
1. novel clothes hanger, its top is provided with a carrier base, it is characterized in that: be hinged with four retractable support bars on this carrier base, the support bar identical length with, the support bar of stretching, extension is that the top forms a pyramid with the carrier base; Evenly be provided with three support brackets of arranging along horizontal plane on the novel clothes hanger, each support bracket comprises four retractable cross bars, and cross bar is arranged between the adjacent supports bar.
2. novel clothes hanger according to claim 1 is characterized in that: the support bar of above-mentioned stretching, extension is that the top forms an orthopyramid with the carrier base, and support bracket is a rectangle.
3. novel clothes hanger according to claim 1 and 2 is characterized in that: above-mentioned retractable cross bar is provided with gear.
