Abstract
The utility model relates to a highly efficient energy-saving lamp. There are currently various energy-saving lamps on the market, but most of them have the problems involving a high electric consumption, a large heat value and a short service life. The highly efficient energy-saving lamp consists of a lamp holder and a lamp body installed on the holder. The lamp body comprises an electric capacity (1) which is connected in series with a silicon bridge rectifier (2) the output anode and the output cathode of which are respectively connected to the cathode and the anode of one group of series light-emitting diodes (3). The product is used for illumination and decoration.
Description
Technical field:
The utility model relates to a kind of energy-efficient lamp.
Background technology:
Various energy-saving lamps are arranged in the market, but all have disadvantages such as power consumption height, caloric value is big, service life is short.
Summary of the invention:
The purpose of this utility model provides a kind of energy-efficient lamp, does that step-down current limliting, silicon bridge play rectified action and the light emitting diode of connecting with a group is formed with electric capacity, and long service life, good reliability, energy-saving effect height.
Above-mentioned purpose realizes by following technical scheme:
Energy-efficient lamp, its composition comprises: lamp socket, be installed in the lamp body on the lamp socket, described lamp body comprises electric capacity, described capacitances in series silicon rectification bridge, the positive pole of described silicon rectification bridge output connects the negative pole of one group of series connection light emitting diode, and the negative pole of described silicon rectification bridge output connects the positive pole of one group of series connection light emitting diode.
The beneficial effects of the utility model:
1. not only applied range, illumination performance are strong, price is than moderate for this product, and effects of energy conservation and environmental protection is very obvious, the bulking property price ratio is higher than other electricity-saving lamps, the user is acceptant, as to export the international market also be a no small impact to external like product then, can promote performance, the price competition of domestic and international product, concerning the user, be undoubtedly an optimum development trend.
2. this product design designs fashion, and energy-saving effect is not only applicable to public places of entertainment such as each big resident family, market, hotel, hotel efficiently, also is applicable to enterprises and institutions, more is applicable to places such as highway, railway, factories and miness.Reach 80% through test, use proof LED (light emitting diode) energy-efficient lamp than incandescent Lantern Festival rate in the past, reach 60% than fluorescence Lantern Festival rate, reach 45% than spiral energy-conservation Lantern Festival rate, reach 80% than shot-light joint rate, and reach 5 to 80,000 hours service life.250 watts of illuminating effects that reach of street lamp in the past, using the LED energy-efficient lamp only to need 50 watts just can finish, if 250 watts street lamp can reach 2500 watts by use calculating in 10 hours power consumption every day, and use 50 watts of LED energy-efficient lamps only to need 500 watts of electricity consumptions, 2000 watts of using electricity wisely, press 100,000 calculating as a certain city street lamp by that analogy, use this product can economize on electricity 200,000,000 watts every day, amount to more than 100,000,000 yuan of RMB.So high energy-saving effect has not only improved the recovery of product cost greatly, but also has made major contribution for national energy savings.
Disadvantages such as 3.LED energy-efficient lamp adopts the cold light source design, greatly reduces power consumption, has prolonged service life, and power consumption height, the caloric value that has solved traditional in the past lighting existence is big, service life is short.
4. adopt the LED energy-efficient lamp to replace various lightings, it is the method for having used innovative thinking, its structure has novelty and originality, be the breakthrough and the development of the revolution of energy-efficient lamp research and discovery for many years, its structural principle belongs to domestic initiation, filled up domestic blank, it throws light on and energy-saving effect efficiently, occupies the leading domestic level of this series products.
5.LED energy-efficient lamp meets the novel energy-conservation consumption lowering product that country encourages support fully, it is science and technology item with great realistic meaning, the development and the exploitation of energy-efficient product will be promoted, energy-saving and cost-reducing field has been brought actively and deep effect, can produce good economic benefit and social benefit.
Description of drawings:
Accompanying drawing 1 is the syndeton schematic diagram that this product has 38 light emitting diodes.
Accompanying drawing 2 is series connection schematic diagrames of 52 light emitting diodes.
Accompanying drawing 3 is series connection schematic diagrames of 80 light emitting diodes.
Positive and negative electrode shown in the figure has annexation.Can fit on the light fixture of different shaping and purposes.
The specific embodiment:
Embodiment 1:
Energy-efficient lamp, its composition comprises: lamp socket, be installed in the lamp body on the lamp socket, described lamp body comprises electric capacity 1, described capacitances in series silicon rectification bridge 2, the positive pole of described silicon rectification bridge output connects the negative pole of one group of series connection light emitting diode 3, and the negative pole of described silicon rectification bridge output connects the positive pole of one group of series connection light emitting diode.
Embodiment 2:
Energy-efficient lamp, its composition comprises: lamp socket, be installed in the lamp body on the lamp socket, described lamp body comprises electric capacity 1, described capacitances in series silicon rectification bridge 2, the positive pole of described silicon rectification bridge output connects the negative pole of one group of series connection light emitting diode 3, and the negative pole of described silicon rectification bridge output connects the positive pole of one group of series connection light emitting diode.Described one group of series connection light emitting diode comprises 38 light emitting diodes.
Embodiment 3:
Energy-efficient lamp, its composition comprises: lamp socket, be installed in the lamp body on the lamp socket, described lamp body comprises electric capacity 1, described capacitances in series silicon rectification bridge 2, the positive pole of described silicon rectification bridge output connects the negative pole of one group of series connection light emitting diode 3, and the negative pole of described silicon rectification bridge output connects the positive pole of one group of series connection light emitting diode.Described one group of series connection light emitting diode comprises 52 light emitting diodes.
Embodiment 4:
Energy-efficient lamp, its composition comprises: lamp socket, be installed in the lamp body on the lamp socket, described lamp body comprises electric capacity 1, described capacitances in series silicon rectification bridge 2, the positive pole of described silicon rectification bridge output connects the negative pole of one group of series connection light emitting diode 3, and the negative pole of described silicon rectification bridge output connects the positive pole of one group of series connection light emitting diode.Described one group of series connection light emitting diode comprises 80 light emitting diodes.The LED energy-efficient lamp not only has kinds such as ornament lamp, illuminating lamp, lamp affixed to the ceiling, street lamp, shot-light, geographical lamp, but also comprise various different big or small models, as: ornament lamp 3W, 4W, illuminating lamp has 6W, 8W, lamp affixed to the ceiling has 8W, 12W, street lamp has 40W, 50W or the like, and the technology path of taking is: establish profile, design circuit (material has Lamp cup, socket, wiring board, silicon bridge, electric capacity, luminous tube, plug-in unit etc.); Set up shell, arrangement mode: dress up Luo mouth, socket ornament lamp, lamp affixed to the ceiling, street lamp, shot-light etc. by different model design teams, by the lamp designed lines plate of different model, electronic component, assembling, debugging, check to reach optimal illumination and energy-saving effect or the like.
Claims (1)
1. energy-efficient lamp, its composition comprises: lamp socket, be installed in the lamp body on the lamp socket, it is characterized in that: described lamp body comprises electric capacity, described capacitances in series silicon rectification bridge, the positive pole of described silicon rectification bridge output connects the negative pole of one group of series connection light emitting diode, and the negative pole of described silicon rectification bridge output connects the positive pole of one group of series connection light emitting diode.
