CN102303490B - Automobile tire burst prevention controller on basis of electrical power steering - Google Patents
Automobile tire burst prevention controller on basis of electrical power steering Download PDFInfo
- Publication number
- CN102303490B CN102303490B CN 201110177244 CN201110177244A CN102303490B CN 102303490 B CN102303490 B CN 102303490B CN 201110177244 CN201110177244 CN 201110177244 CN 201110177244 A CN201110177244 A CN 201110177244A CN 102303490 B CN102303490 B CN 102303490B
- Authority
- CN
- China
- Prior art keywords
- steering
- circuit
- blowing out
- control
- signal
- Prior art date
- Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
- Expired - Fee Related
Links
Images
Abstract
The invention discloses an automobile tire burst prevention controller on the basis of the electrical power steering and relates to an automobile safety control device. The automobile tire burst prevention controller on the basis of the electrical power steering comprises an ECU (Electrical Conversion Unit) processor, a data acquisition part, a data processing part, a tire burst display part, a tire burst alarm part, a motor steering control part, a power supply circuit, an upper communication circuit and a fault diagnosis circuit. In the case of tire burst, the tire burst alarm part is started and tire burst information is displayed by the tire burst display part; a steering wheel is detected whether to steer and a steering direction and a steering angle of the steering wheel are detected by the data acquisition part; if the steering wheel does not steer, a steering system of a vehicle is directly controlled to carry out tire burst prevention control by the motor steering control part; if the steering wheel steers, the steering direction, the steering angle and turning velocity information of the steering wheel need to be detected so as to provide parameters for correcting a steering declination angle, then the steering system of the vehicle is controlled by the motor steering control part, and by controlling the steering system of the vehicle, the vehicle is kept moving in the original driving direction after the tire is burst so that the vehicle is avoided being out of control and being deflected when the tire is burst.
Description
Technical field
The present invention relates to safety control device for automobile, particularly a kind of automobile tire burst prevention controller.
Background technology
The easy sideslip out of control of direction caused casualties and the property damage accident when motor tire was blown out suddenly, industry is done deep research to the automobile tire burst prevention control technology for this reason, mainly contain at present following several automobile tire burst prevention control technology: (1) super flat tire technology, the core of this technology is the height of reduce motor tire, strengthen the support rigidity on motor tire sidewall, thereby after the wheel Somatic Embryogenesis is blown out, the height of wheel is not significantly descended, in order to the basic rideability of relative low speed is provided for tire, the original intention of this technology is to remove stepney, be not that preventing car is blown out, and this technology after blowing out, also do not report to the police in advance early warning and relief effect, because the ratio of rigidity of this kind tire is larger, will cause like this automobile adhesive ability in the process of moving to descend, want to improve the adhesive ability that travels and just must realize by the width that increases tire, and the tire height descended and can make relatively difficulty of tire dismantling, so the application prospect of this technology is still waiting demonstration; (2) direction is from lock technology, the core concept of this technology is to adopt tyre pressure sensor to detect the tire pressure of motor tire, take turns and just bearing circle is carried out unidirectional self-lock after Somatic Embryogenesis is blown out when detecting certain, this moment, chaufeur can free steer direction dish, can alleviate tyre explosion direction skew afterwards after the bearing circle self-locking, but this technology mainly rests on the presentation, also be in test session, up to the present also there is not place in operation, and after blowing out, also do not report to the police in advance early warning and relief effect; (3) coaxial wheels air pressure interworking technology, the core concept of this technology is that the air chamber of the left and right wheels of the coaxial tire of automobile is communicated, like this after the wheel Somatic Embryogenesis of a coaxial side is blown out, the gas of opposite side tire can pass to the tire of blowing out by fast speed, automobile just can not be because of a side wheel the tire excessive and direction of the rear rolling resistance skew of blowing out like this, thereby reduces the possibility that causes the accident of blowing out; Also have company to propose the another kind of method of similar this technology, namely detecting after a side wheel Somatic Embryogenesis blows out, ignite fast the tire of opposite side, quite similar with this technology mechanism, the reliability of this method is also in further checking; (4) blow out the monitoring and safety control system, the core of this technology is to utilize high-precision Intelligence sensor to detect the pressure information of motor tire, if detecting certain takes turns Somatic Embryogenesis and blows out, then at once signal of tyre burst is transferred to central processing unit, central processing unit can be controlled automatic brake mechanism and carry out braking deceleration and brake, but the side direction adhesion value of automobile is with variation in braking procedure, and namely road holding is bad, so excessive braking deceleration.
Current runflat control technology or cost is too high as can be known by above analysis, or is exactly that poor reliability or technology are not mature enough, and what apply in market also is not too many.
Summary of the invention
The objective of the invention is for overcome and solve existing automobile since do not have perfect blow out anti-deflection device and when motor tire occurs blowing out suddenly easy sideslip out of control cause casualties, shortcoming and the problem of property damage accident, a kind of automobile tire burst prevention controller based on electric powered steering is provided, when automobile travels with middle and high speed and occurs blowing out suddenly, can reliably, effectively prevent Vehicle Driving Wandering, automatically keep automobile on original travel direction, guarantee ride safety of automobile, prevent that personal casualty and property damage accident from occuring.
The technical solution used in the present invention is to achieve the above object of the invention: a kind of automobile tire burst prevention controller based on electric powered steering, the hardware of this automobile tire burst prevention controller comprises ECU treater (the ATmega128 micro controller system that automobile tire burst prevention controller uses is called " ECU treater " here), part of data acquisition, data processing section, the display part of blowing out, the warning part of blowing out, the motor steering control part, power circuit, upper communicating circuit and fault diagnosis circuit, part of data acquisition comprises the tierod displacement number of delivering a letter acceptor circuit, the steering wheel angle signal receiving circuit, the vehicle speed signal acceptor circuit, the pressure detecting signal acceptor circuit of blowing out, data processing section comprises tierod displacement signal treatment circuit, the steering wheel angle signal processing circuit, the vehicle speed signal treatment circuit, the pressure detecting signal treatment circuit of blowing out, tierod displacement signal acceptor circuit is connected with tierod displacement signal treatment circuit, the steering wheel angle signal receiving circuit is connected with the steering wheel angle signal processing circuit, the vehicle speed signal acceptor circuit is connected with the vehicle speed signal treatment circuit, the pressure detecting signal acceptor circuit of blowing out is connected with the pressure detecting signal treatment circuit of blowing out, the display part of blowing out comprises blow out display circuit and the read-out of blowing out that is connected with the display circuit of blowing out, blowing out reports to the police partly comprises the alarm buzzer of blowing out the warning driving circuit and being connected with the warning driving circuit of blowing out, the motor steering control part comprise the motor steering driving circuit and be connected with the motor steering driving circuit turn to control motor, tierod displacement transducer signal treatment circuit, the steering wheel angle signal processing circuit, the vehicle speed signal treatment circuit, the pressure detecting signal treatment circuit of blowing out, the display circuit of blowing out, the warning driving circuit of blowing out, the motor steering driving circuit, power circuit, upper communicating circuit and fault diagnosis circuit are connected with the ECU treater respectively.
Further technical scheme of the present invention is: be provided be used to the control program of controlling above-mentioned automobile tire burst prevention controller work in the described ECU treater, the control process of this control program control automobile tire burst prevention controller work may further comprise the steps: 1) detect tire pressure signal by the pressure detecting signal sensor of blowing out, have or not the generation of blowing out by the pressure signal judgement, occur to determine again if blow out which or which take turns Somatic Embryogenesis and blow out, preserve the information of blowing out and provide parameter for follow-up runflat control; 2) the ECU treater just starts tire burst alarming device and shows the information of blowing out by the read out instrument of blowing out after detecting signal of tyre burst, and when starting tire burst alarming device, ECU treater control stoplight stop lamp or rear taillight are lighted automatically; 3) detect automobile driving speed by the vehicle speed signal sensor, judge whether the speed of a motor vehicle is higher than safe speed, if namely withdraw from control less than safe speed, if greater than safe speed then by the automobile operation kinetic model calculating target steering angle of blowing out; 4) detecting bearing circle by the steering wheel angle signal transducer has or not and turns to and wheel steering direction and angle, enter runflat control if without direction information then directly turned to by the steering swivel system of motor steering control setup control automobile, if bearing circle turns to, the steering direction, deflection angle size and the turning velocity information that then detect bearing circle provide corrected parameter for correction turns to the drift angle, and the steering swivel system by motor steering control setup control automobile turns to again; 5) carry out closed loop control by the information that gathers the tierod displacement signal sensor.
Further technical scheme of the present invention is: in step 4) in when bearing circle has the input redirect signal, take the turn sign of chaufeur input as high priority, export to control the travel direction of automobile according to the control of the turn sign correction steering control system of bearing circle input.
The automobile tire burst prevention controller that employing the present invention is based on electric powered steering has following beneficial effect:
1. the automobile tire burst prevention controller that the present invention is based on electric powered steering adopts initiatively runflat technology, when blowing out, start immediately tire burst alarming device and show the information of blowing out by the read out instrument of blowing out, ECU treater control motor steering control setup by automobile tire burst prevention controller, the steering swivel system of motor steering control setup control automobile makes to remain on the former travel direction behind the automobile flat tire and moves, because automobile tire burst prevention controller is so that the electronic control reaction time is short, occur to the automobile steering system execution from burst tyre and turn to about about 0.1 second, (it is reported run at high speed automobile flat tire from the accident time that begins to blow out be 2 ~ 3 seconds), sideslip out of control caused casualties and property damage when the present invention can effectively avoid motor tire to occur blowing out suddenly.
2. the electronic component that the present invention is based on the automobile tire burst prevention controller of electric powered steering is selected chip and the control circuit of special quality industrial grade, can effectively guarantee the service life of controller, and reliability is high, is not easy normally to use because of failure effect.
3. the automobile tire burst prevention controller volume that the present invention is based on electric powered steering is little, simple in structure, easy to install, cost is low, easily applies.
Below in conjunction with drawings and Examples the automobile tire burst prevention controller that the present invention is based on electric powered steering is further described.
Description of drawings
Fig. 1 is the structural representation block scheme that the present invention is based on the automobile tire burst prevention controller of electric powered steering.
Fig. 2 is the control flow chart that the present invention is based on the automobile tire burst prevention controller of electric powered steering.
Fig. 3-1 the present invention is based on the control principle drawing of the automobile tire burst prevention controller of electric powered steering to Fig. 3-the 12nd:
Fig. 3-the 1st, the upper machine communication schematic circuit diagram;
Fig. 3-the 2nd, the simulated measurement input circuit schematic diagrams such as steering wheel angle;
Fig. 3-the 3rd, JTAG debug i/f circuit schematic diagram;
Fig. 3-the 4th, the digital signal input circuit schematic diagram;
Fig. 3-the 5th, vehicle speed pulse amount input circuit schematic diagram;
Fig. 3-the 6th, power circuit principle figure;
Fig. 3-the 7th, the auxiliary circuit schematic diagram;
Fig. 3-the 8th, treater pin catenation principle figure;
Fig. 3-the 9th, blowing out shows and warning driving circuit principle figure;
Fig. 3-the 10th, the motor turning motor-drive circuit schematic diagram of blowing out;
Fig. 3-the 11st, each interface connection circuit schematic diagram;
Fig. 3-the 12nd, analog-to-digital conversion canonical reference voltage and indicator light circuit schematic diagram.
The specific embodiment
Shown in Fig. 1 to Fig. 3-12, the present invention is based on the automobile tire burst prevention controller (following abbreviation " automobile tire burst prevention controller ") of electric powered steering, the hardware of this automobile tire burst prevention controller comprises ECU treater, part of data acquisition, data processing section, the display part of blowing out, part, motor steering control part, power circuit, upper communicating circuit and the fault diagnosis circuit of reporting to the police of blowing out.
The function of part of data acquisition is to gather the tierod displacement signal, the steering wheel angle signal, gather vehicle speed signal, the pressure detecting signal of blowing out, part of data acquisition comprises the tierod displacement number of delivering a letter acceptor circuit, the steering wheel angle signal receiving circuit, the vehicle speed signal acceptor circuit, the pressure detecting signal acceptor circuit of blowing out, the tierod displacement number of delivering a letter acceptor circuit is used for gathering the signal of tierod displacement pickup, the steering wheel angle signal receiving circuit is used for gathering the signal of steering wheel angle sensor, the vehicle speed signal acceptor circuit is used for gathering the signal of car speed sensor, and the pressure detecting signal acceptor circuit of blowing out is used for gathering the signal of the pressure sensor of blowing out.Data processing section comprises tierod displacement signal treatment circuit, steering wheel angle signal processing circuit, vehicle speed signal treatment circuit, the pressure detecting signal treatment circuit of blowing out, tierod displacement signal acceptor circuit is connected with tierod displacement signal treatment circuit, the steering wheel angle signal receiving circuit is connected with the steering wheel angle signal processing circuit, the vehicle speed signal acceptor circuit is connected with the vehicle speed signal treatment circuit, and the pressure detecting signal acceptor circuit of blowing out is connected with the pressure detecting signal treatment circuit of blowing out.
The display part of blowing out comprises blow out display circuit and the read-out of blowing out that is connected with the display circuit of blowing out, the blowing out part of reporting to the police comprises the alarm buzzer of blowing out the warning driving circuit and being connected with the warning driving circuit of blowing out, the motor steering control part comprise the motor steering driving circuit reach be connected with the motor steering driving circuit turn to the control motor.
Tierod displacement signal treatment circuit, steering wheel angle signal processing circuit, vehicle speed signal treatment circuit, the pressure detecting signal treatment circuit of blowing out, the display circuit of blowing out, the warning driving circuit of blowing out, motor steering driving circuit, power circuit, upper communicating circuit and fault diagnosis circuit are connected with the ECU treater respectively.
The ECU treater of automobile tire burst prevention controller is the ATmega128 micro controller system, the AD module that carries in the ATmega128 micro controller system can be processed respectively the electric signal of tierod displacement signal sensor and the input of steering wheel angle signal transducer, because the signal of tierod displacement pickup collection is analog signal, the signal quality that gathers and reliability can directly affect the accuracy of the direction control after the automobile unstability of blowing out, therefore need to analog signal be gathered with the A/D module that the ATmega128 micro controller system carries, and then the ATmega128 micro controller system just can carry out follow-up filtering and control algorithm, the signal of steering wheel angle signal transducer collection comprises the deflection angle size, steering direction and turning velocity information, the signal of steering wheel angle signal transducer is digital input signals, and digital signal also needs filtering that the accuracy of result of a measurement is improved.The analog input circuit of the A/D module that the ATmega128 micro controller system carries comprises the A/D converter of 10 precision and the analog selection switch of 8 passages, the transfer time of the mould of A/D module, the highest sampling frequency is 15kHz, and operating voltage range, can satisfy the requirement of tierod displacement signal sensor and steering wheel angle signal transducer acquisition of signal.
The voltage chip of power circuit is selected the LM2575T-5.0V power supply chip, the battery supply that general automobile uses is the 24V direct supply, because the tierod displacement pickup of ECU treater treater and this use, steering wheel angle sensor, car speed sensor, four sensors of press detection sensor of blowing out need the 5V DC power supply, the LM2575T-5.0V power supply chip just can be converted into 5V voltage to the voltage of 24V, and power satisfies operating needs assurance power supply voltage stabilization, can not cause the signal of sensor and automobile tire burst prevention controller output that very large deviation is arranged, and guarantee the precision of control.
The control motor that turns to that the present invention selects belongs to low powered DC motor, but the ATmega128 micro controller system still can not directly drive this DC motor, turn to the driving of control motor to adopt the full-bridge type chopper circuit, the working process of full-bridge type chopper circuit is: 4 field effect transistor D1, D4 is one group, D2, D3 is that a composition is to passing through pulse width modulation controlled, and D1, D4 or D2, simultaneously conducting of D3 or shutoff belong to complementary mode of operation, D1 namely, D2 during the D4 conducting, D3 turn-offs, D2, D1 during the D3 conducting, D4 turn-offs, D1, D4 and D2, D3 alternate conduction and shutoff, D1, D4 conducting D2, D3 turn-offs then electric current from left to right by turning to the control motor, turn to so the control motor with forward, work as D3, D2 conducting D1, D4 turn-offs then electric current from right to left by turning to the control motor, turn to so the control motor to reverse, therefore adopt the full-bridge type chopper circuit to make and turn to the control motor to realize rotating and reverse.
The ATmega128 micro controller system has two USART serial interfaces.The present invention adopts the USART1 serial ports to use it for serial communication, this serial ports comprises the RXD1 port of inputting receive data and exports the TXD1 port that sends data, because the USART1 serial ports of ATmega128 micro controller system uses voltage to be the TTL logic level, communication distance is limited, the words signal attenuation of long haul is serious, therefore select the RS232 logic level to improve the long haul ability, the level conversion of TTL logic level and RS232 logic level, special level transferring chip is arranged, at this MAX232 chip of selecting MAXIM company the Transistor-Transistor Logic level of ATmega128 micro controller system USART1 serial ports is converted to the RS232 logic level that adapts to long haul, the mode of connection of serial port circuit is to link to each other with the RXD1 port of the receive data of ATmega128 micro controller system with the 5 pin ground connection of serial port J1 and with the transmission data terminal of upper computer and the receive data end of upper computer is linked to each other with the TXD1 port of the transmission data of ATmega128 micro controller system.
In order to prevent that automobile tire burst prevention controller inefficacy the present invention from increasing fault diagnosis circuit, fault diagnosis circuit mainly is can show after breaking down with the storage failure data and when carrying out trouble tracing fault data to be sent out the reference for the testing staff by interface, saves the malfunction elimination time.
Be provided be used to the control program of controlling above-mentioned automobile tire burst prevention controller work in the ECU treater of described automobile tire burst prevention controller, this control program comprises with lower module: the program design of described automobile tire burst prevention controller mainly comprises five modules: signal acquisition module, module, serial communication module, angular deviation computing module, steer motor control module that timer is interrupted arranging.
Signal acquisition module, be used for the signal of tierod displacement signal sensor and the pressure detecting signal sensor collection of blowing out is processed, signal acquisition module control Atmega128 micro controller system carries out analogue to digital conversion and filtering processing to the signal of tierod displacement signal sensor and the pressure detecting signal sensor collection of blowing out.
The module that timer is interrupted arranging, be used for determining that automobile tire burst prevention controller gathers the frequency of various sensor signals, the signal of pressure sensor of blowing out adopts the external interrupt pattern, after the generation of blowing out, timer interrupts arranging modular program initialization Atmega128 micro controller system and interrupts determining that with timer T1 automobile tire burst prevention controller gathers the frequency of tierod displacement pickup and steering wheel angle sensor signal, setting just produces every 10ms timer T1 to be interrupted, to the collection of tierod displacement pickup and steering wheel angle sensor signal, also start the collection of vehicle speed signal simultaneously.
Serial communication module is used for finishing the serial ports initialization, serial ports sends and the serial ports receiving function, adopts the interrupt mode receive data between automobile tire burst prevention controller and the upper computer and adopts inquiry mode to send data.
The angular deviation computing module, being converted into the steering angle size according to the incoming signal of tierod displacement pickup calculates the target diversion angle and calculates at last the needed control voltage of steer motor, in the process of automobile tire burst prevention controller control, angular deviation computing module control Atmega128 micro controller system is calculated the deviation between the tierod position that turns to angle on target and feedback of input according to the incoming signal of tierod displacement signal sensor and the level angle conversion relation between them.
The steer motor control module turns to the steering swivel system of controlling motor and then controlling automobile to reach the high function of maintenance stability of automobile for automatically controlling when blowing out generation.The ATmega128 micro controller system has 2 road PWM passages, control 4 field effect transistor of full-bridge type chopper circuit, adopt bipolar system full-bridge copped wave control, recently make by the PWM duty of regulating DC machine to turn to the control DC machine to realize rotating and velocity magnitude control.
The work of described control program control automobile tire burst prevention controller may further comprise the steps: 1) detect tire pressure signal by the pressure detecting signal sensor of blowing out, have or not the generation of blowing out by the pressure signal judgement, occur to determine again if blow out which or which take turns Somatic Embryogenesis and blow out, preserve the information of blowing out and provide parameter for follow-up runflat control; 2) the ECU treater just starts tire burst alarming device and shows the information of blowing out by the read out instrument of blowing out after detecting signal of tyre burst, the ECU treater is controlled the warning driving circuit driving alarm buzzer of blowing out and is sent chimes of doom, simultaneously, the ECU treater control display circuit of blowing out drives the read-out of blowing out and shows the information of blowing out, the a certain Somatic Embryogenesis of taking turns of prompting chaufeur is blown out, when starting tire burst alarming device, automobile tire burst prevention controller control stoplight stop lamp or rear taillight are lighted automatically, and caution back vehicle driver takes the emergency safety measure to prevent rear-end collision; 3) detect automobile driving speed by the vehicle speed signal sensor, judge whether the speed of a motor vehicle is higher than safe speed, if namely withdraw from control less than safe speed, if greater than safe speed then calculate target steering angle by the automobile operation kinetic model of blowing out, the automobile operation kinetic model of blowing out wherein is:
Two formula of this model comprise automobile side angle speed V
YAnd yaw velocity
Two target control amounts,
Be the deflection angle that causes because blowing out,
Be the automobile speed of advance, all the other comprise quality radius of wheel R for the self structure parameter of automobile, blow out rear wheel theoretical running radius of tire r, vehicle mass m, front axle to barycenter apart from a, rear axle between the distance b of barycenter, the wheel apart from B, car load height of gravitational center h, tire cornering stiffness K
C, suspension rigidity be K, yaw rotor inertia I because the automobile operation kinetic model of blowing out is a known models, be not described in detail its reasoning process at this; 4) by the steering wheel angle signal transducer detect bearing circle have or not turn to and wheel steering direction (the steering direction here refers to or turns right) and steering angle big or small, enter runflat control if without direction information then directly turned to by the steering swivel system of motor steering control setup control automobile, if bearing circle turns to, then detect the steering direction of bearing circle, deflection angle size and turning velocity information provide corrected parameter for correction turns to the drift angle, steering swivel system by motor steering control setup control automobile turns to again, when bearing circle has the input redirect signal, take the turn sign of chaufeur input as high priority, the steering swivel system of forcing automobile turns to according to the steering swivel system of the turn sign control automobile of the input of bearing circle; 5) carry out closed loop control by the information that gathers the tierod displacement signal sensor.
After finishing control, chaufeur by by be arranged on that button cancellation in the automobile is reported to the police or the automobile stagnation of movement after the ATmega128 micro controller system no longer conducting turn to the power-transfer clutch of control motor, make to turn to control motor cancellation runflat to turn to control, and the work of cancellation tire burst alarming device and the read out instrument of blowing out.
Above-described embodiment only is preferred forms of the present invention, and the present invention is not limited to the form of above-described embodiment, as long as the conversion of doing within the scope of the present invention all belongs to category of the present invention.
Claims (2)
1. automobile tire burst prevention controller based on electric powered steering, it is characterized in that, the hardware of this automobile tire burst prevention controller comprises the ECU treater, part of data acquisition, data processing section, the display part of blowing out, the warning part of blowing out, the motor steering control part, power circuit, upper communicating circuit and fault diagnosis circuit, part of data acquisition comprises tierod displacement signal acceptor circuit, the steering wheel angle signal receiving circuit, the vehicle speed signal acceptor circuit, the pressure detecting signal acceptor circuit of blowing out, data processing section comprises tierod displacement signal treatment circuit, the steering wheel angle signal processing circuit, the vehicle speed signal treatment circuit, the pressure detecting signal treatment circuit of blowing out, tierod displacement signal acceptor circuit is connected with tierod displacement signal treatment circuit, the steering wheel angle signal receiving circuit is connected with the steering wheel angle signal processing circuit, the vehicle speed signal acceptor circuit is connected with the vehicle speed signal treatment circuit, the pressure detecting signal acceptor circuit of blowing out is connected with the pressure detecting signal treatment circuit of blowing out, the display part of blowing out comprises blow out display circuit and the read-out of blowing out that is connected with the display circuit of blowing out, blowing out reports to the police partly comprises the alarm buzzer of blowing out the warning driving circuit and being connected with the warning driving circuit of blowing out, the motor steering control part comprise the motor steering driving circuit and be connected with the motor steering driving circuit turn to control motor, tierod displacement transducer signal treatment circuit, the steering wheel angle signal processing circuit, the vehicle speed signal treatment circuit, the pressure detecting signal treatment circuit of blowing out, the display circuit of blowing out, the warning driving circuit of blowing out, the motor steering driving circuit, power circuit, upper communicating circuit and fault diagnosis circuit are connected with the ECU treater respectively; Be provided be used to the control program of controlling above-mentioned automobile tire burst prevention controller work in the described ECU treater, the control process of this control program control automobile tire burst prevention controller work may further comprise the steps: 1) detect tire pressure signal by the pressure detecting signal sensor of blowing out, have or not the generation of blowing out by the pressure signal judgement, occur to determine again if blow out which or which take turns Somatic Embryogenesis and blow out, preserve the information of blowing out and provide parameter for follow-up runflat control; 2) the ECU treater just starts tire burst alarming device and shows the information of blowing out by the read out instrument of blowing out after detecting signal of tyre burst, and when starting tire burst alarming device, ECU treater control stoplight stop lamp or rear taillight are lighted automatically; 3) detect automobile driving speed by the vehicle speed signal sensor, judge whether the speed of a motor vehicle is higher than safe speed, if namely withdraw from control less than safe speed, if greater than safe speed then by the automobile operation kinetic model calculating target steering angle of blowing out; 4) detecting bearing circle by the steering wheel angle signal transducer has or not and turns to and wheel steering direction and angle, enter runflat control if without direction information then directly turned to by the steering swivel system of motor steering control setup control automobile, if bearing circle turns to, the steering direction, deflection angle size and the turning velocity information that then detect bearing circle provide corrected parameter for correction turns to the drift angle, and the steering swivel system by motor steering control setup control automobile turns to again; 5) carry out closed loop control by the information that gathers the tierod displacement signal sensor.
2. the automobile tire burst prevention controller based on electric powered steering as claimed in claim 1, it is characterized in that, in step 4) in when bearing circle has the input redirect signal, take the turn sign of chaufeur input as high priority, export to control the travel direction of automobile according to the control of the turn sign correction steering control system of bearing circle input.
