WO2025019482A1 - Methods, reagents, and kits for tuning an immunoassay signal - Google Patents
Methods, reagents, and kits for tuning an immunoassay signal Download PDFInfo
- Publication number
- WO2025019482A1 WO2025019482A1 PCT/US2024/038174 US2024038174W WO2025019482A1 WO 2025019482 A1 WO2025019482 A1 WO 2025019482A1 US 2024038174 W US2024038174 W US 2024038174W WO 2025019482 A1 WO2025019482 A1 WO 2025019482A1
- Authority
- WO
- WIPO (PCT)
- Prior art keywords
- probnp
- sample
- antibody
- kit
- reagent
- Prior art date
- Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
- Ceased
Links
Classifications
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K16/00—Immunoglobulins [IG], e.g. monoclonal or polyclonal antibodies
- C07K16/18—Immunoglobulins [IG], e.g. monoclonal or polyclonal antibodies against material from animals or humans
- C07K16/26—Immunoglobulins [IG], e.g. monoclonal or polyclonal antibodies against material from animals or humans against hormones ; against hormone releasing or inhibiting factors
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K14/00—Peptides having more than 20 amino acids; Gastrins; Somatostatins; Melanotropins; Derivatives thereof
- C07K14/435—Peptides having more than 20 amino acids; Gastrins; Somatostatins; Melanotropins; Derivatives thereof from animals; from humans
- C07K14/575—Hormones
- C07K14/58—Atrial natriuretic factor complex; Atriopeptin; Atrial natriuretic peptide [ANP]; Cardionatrin; Cardiodilatin
-
- G—PHYSICS
- G01—MEASURING; TESTING
- G01N—INVESTIGATING OR ANALYSING MATERIALS BY DETERMINING THEIR CHEMICAL OR PHYSICAL PROPERTIES
- G01N33/00—Investigating or analysing materials by specific methods not covered by groups G01N1/00 - G01N31/00
- G01N33/48—Biological material, e.g. blood, urine; Haemocytometers
- G01N33/50—Chemical analysis of biological material, e.g. blood, urine; Testing involving biospecific ligand binding methods; Immunological testing
- G01N33/53—Immunoassay; Biospecific binding assay; Materials therefor
- G01N33/543—Immunoassay; Biospecific binding assay; Materials therefor with an insoluble carrier for immobilising immunochemicals
- G01N33/54313—Immunoassay; Biospecific binding assay; Materials therefor with an insoluble carrier for immobilising immunochemicals the carrier being characterised by its particulate form
- G01N33/54326—Magnetic particles
-
- G—PHYSICS
- G01—MEASURING; TESTING
- G01N—INVESTIGATING OR ANALYSING MATERIALS BY DETERMINING THEIR CHEMICAL OR PHYSICAL PROPERTIES
- G01N33/00—Investigating or analysing materials by specific methods not covered by groups G01N1/00 - G01N31/00
- G01N33/48—Biological material, e.g. blood, urine; Haemocytometers
- G01N33/50—Chemical analysis of biological material, e.g. blood, urine; Testing involving biospecific ligand binding methods; Immunological testing
- G01N33/74—Chemical analysis of biological material, e.g. blood, urine; Testing involving biospecific ligand binding methods; Immunological testing involving hormones or other non-cytokine intercellular protein regulatory factors such as growth factors, including receptors to hormones and growth factors
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K2317/00—Immunoglobulins specific features
- C07K2317/30—Immunoglobulins specific features characterized by aspects of specificity or valency
- C07K2317/33—Crossreactivity, e.g. for species or epitope, or lack of said crossreactivity
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K2317/00—Immunoglobulins specific features
- C07K2317/50—Immunoglobulins specific features characterized by immunoglobulin fragments
- C07K2317/54—F(ab')2
-
- G—PHYSICS
- G01—MEASURING; TESTING
- G01N—INVESTIGATING OR ANALYSING MATERIALS BY DETERMINING THEIR CHEMICAL OR PHYSICAL PROPERTIES
- G01N2333/00—Assays involving biological materials from specific organisms or of a specific nature
- G01N2333/435—Assays involving biological materials from specific organisms or of a specific nature from animals; from humans
- G01N2333/575—Hormones
- G01N2333/58—Atrial natriuretic factor complex; Atriopeptin; Atrial natriuretic peptide [ANP]; Brain natriuretic peptide [BNP, proBNP]; Cardionatrin; Cardiodilatin
-
- G—PHYSICS
- G01—MEASURING; TESTING
- G01N—INVESTIGATING OR ANALYSING MATERIALS BY DETERMINING THEIR CHEMICAL OR PHYSICAL PROPERTIES
- G01N2800/00—Detection or diagnosis of diseases
- G01N2800/32—Cardiovascular disorders
- G01N2800/325—Heart failure or cardiac arrest, e.g. cardiomyopathy, congestive heart failure
Definitions
- the present disclosure tunes the signal to noise ratio of an NT ⁇ proBNP sandwich immunoassay suitable for use in a high ⁇ throughput analyzer.
- BACKGROUND [0003]
- Left ventricular dysfunction can occur as part of coronary heart disease, arterial hypertension, valvular disease, and primary myocardial disease. If the left ventricular dysfunction remains untreated and is progressive, the potential for mortality is high, for example, due to sudden cardiac death.
- Chronic cardiac insufficiency is a clinical syndrome caused by impairment of the cardiac pumping function. Based on the symptoms, the presence and severity of cardiac insufficiency may be classified in stages I–IV such as by the New York Heart Association (NYHA). Clinical tests and imaging procedures are used to diagnose left ventricular dysfunction.
- Natriuretic peptides reported in the literature include atrial natriuretic peptide (ANP), brain natriuretic peptide (BNP), and C-type natriuretic peptide (CNP). The significance of natriuretic peptides in the control of cardiovascular system function has been established. Brain natriuretic peptide biomarkers are commonly used to aid in diagnosis and assess severity in patients with heart failure (HF). [0005] ANP and BNP have natriuretic and diuretic properties. As antagonists of the renin-angiotensin-aldosterone system, ANP and BNP influence the electrolyte and fluid balance in the body.
- ProBNP includes 108 amino acids. It is secreted mainly by the left ventricle of the heart and, in this process, is cleaved into physiologically active BNP (Amino Acid 77–108), and the N-terminal fragment NT-proBNP (Amino Acid 1–76) (See e.g., Nadar SK, Shaikh MM. Biomarkers in Routine Heart Failure Clinical Care. Card Fail Rev. 2019;5(1):50 ⁇ 56. doi: 10.15420/cfr.2018.27.2).
- Biomarkers such as NT-proBNP act as surrogates for clinically meaningful outcomes and may or may not reflect the pathogenesis underlying a disease. Examples of clinical utility include diagnosis, the prediction of disease progression or regression, and prognostication of mortality.
- a biomarker should be easily acquired, reliably measured, and available for serial monitoring. Ideally, it would also provide an advantage of currently used clinical measures in ease, timeframe, and/or expense.
- Certain substances in a biological sample problematically interfere with an assay format for measuring a biomarker.
- biotin present in a biological sample may bias assay results and/or interfere with an assay, for example, in assays where biotinylated antibody is a separate reagent from a solid phase that includes a biotin binding molecule, such as (but not limited to) unconjugated streptavidin ⁇ coated particles.
- the assay format problematically allows time for any biotin naturally present in a biological sample to complex with the streptavidin ⁇ coated particles, resulting in interference in which the biotinylated antibody is blocked from binding to the streptavidin ⁇ coated particles.
- FIG. 1 depicts a prior art immunoassay format for NT ⁇ proBNP.
- the prior art immunoassay utilizes three reagents: a streptavidin ⁇ coated particle (Reagent 1), a biotinylated antibody (Reagent 2), and an acridinium ester ⁇ labeled antibody (Reagent 3).
- the two antibodies bind to non ⁇ overlapping epitopes of NT ⁇ proBNP so that a sandwich complex can be formed (Product 1).
- FIG. 2 depicts the effects of biotin interference on the prior art immunoassay of FIG. 1.
- FIG. 3 depicts one non ⁇ limiting embodiment of an NT ⁇ proBNP immunoassay constructed in accordance with the present disclosure.
- FIG. 4 depicts an exemplary block diagram of a computer system 1100 suitable for executing the methods of the present disclosure on a chemical analyzer.
- FIG. 5 graphically illustrates a receiver operating characteristic (ROC) curve demonstrating the clinical sensitivity and specificity of the immunoassay constructed in accordance with the present disclosure.
- ROC receiver operating characteristic
- compositions, devices, kits, and/or methods have been described in terms of particular embodiments, it will be apparent to those of skill in the art that variations may be applied to the compositions, devices, kits, and/or methods and in the steps or in the sequence of steps of the methods described herein without departing from the concept, spirit, and scope of the present disclosure. All such similar substitutions and modifications apparent to those skilled in the art are deemed to be within the spirit, scope, and concept of the present disclosure as defined by the appended claims.
- the term “plurality” refers to “two or more.” [0023]
- the use of the term “at least one” will be understood to include one as well as any quantity more than one, including but not limited to, 2, 3, 4, 5, 10, 15, 20, 30, 40, 50, 100, etc.
- the term “at least one” may extend up to 100 or 1000 or more, depending on the term to which it is attached; in addition, the quantities of 100/1000 are not to be considered limiting, as higher limits may also produce satisfactory results.
- the use of the term “at least one of X, Y, and Z” will be understood to include X alone, Y alone, and Z alone, as well as any combination of X, Y, and Z.
- any reference to “one embodiment,” “an embodiment,” “some embodiments,” “one example,” “for example,” or “an example” means that a particular element, feature, structure, or characteristic described in connection with the embodiment is included in at least one embodiment.
- the appearance of the phrase “in some embodiments” or “one example” in various places in the specification is not necessarily all referring to the same embodiment, for example. Further, all references to one or more embodiments or examples are to be construed as non ⁇ limiting to the claims.
- the term “about” is used to indicate that a value includes the inherent variation of error for a composition/apparatus/ device, the method being employed to determine the value, or the variation that exists among the study subjects.
- the designated value may vary by plus or minus twenty percent, or fifteen percent, or twelve percent, or eleven percent, or ten percent, or nine percent, or eight percent, or seven percent, or six percent, or five percent, or four percent, or three percent, or two percent, or one percent from the specified value, as such variations are appropriate to perform the disclosed methods and as understood by persons having ordinary skill in the art.
- antibody is used herein in the broadest sense and refers to, for example, intact monoclonal antibodies and polyclonal antibodies, multi ⁇ specific antibodies (e.g., bispecific antibodies), antibody fragments and conjugates thereof that exhibit the desired biological activity of analyte binding (such as, but not limited to, Fab, Fab', F(ab')2, Fv, scFv, Fd, diabodies, single ⁇ chain antibodies, and other antibody fragments and conjugates thereof that retain at least a portion of the variable region of an intact antibody), antibody substitute proteins or peptides (i.e., engineered binding proteins/peptides), and combinations or derivatives thereof.
- analyte binding such as, but not limited to, Fab, Fab', F(ab')2, Fv, scFv, Fd, diabodies, single ⁇ chain antibodies, and other antibody fragments and conjugates thereof that retain at least a portion of the variable region of an intact antibody
- antibody substitute proteins or peptides i.e.
- the antibody can be of any type or class (e.g., IgG, IgE, IgM, IgD, and IgA) or sub ⁇ class (e.g., IgG1, IgG2, IgG3, IgG4, IgA1, and IgA2).
- biomarker or “biological marker” is used herein, consistent with its use in the art, to refer to an entity whose presence, level, or form correlates with a particular biological event or state of interest, so that it is considered to be a “marker” of that event or state.
- a biomarker may be or include a marker for a particular disease state, or for likelihood that a particular disease, disorder, or condition may develop, occur, or reoccur.
- a biomarker may be or include a marker for a particular disease or therapeutic outcome or likelihood thereof.
- a biomarker is predictive of the relevant biological event or state of interest; in some non ⁇ limiting embodiments, a biomarker is prognostic of the relevant biological event or state of interest; and in some non ⁇ limiting embodiments, a biomarker is diagnostic of the relevant biological event or state of interest.
- a biomarker is a possible biomarker of the relevant biological event or state of interest.
- a biomarker may be an entity of any chemical class.
- a biomarker may be or include a nucleic acid, a polypeptide, a small molecule, or a combination thereof.
- a biomarker is a cell surface marker.
- a biomarker is intracellular.
- a biomarker is found in a particular tissue (e.g., lung tissue).
- a biomarker is found outside of cells (e.g., is secreted or is otherwise generated or present outside of cells, e.g., in a body fluid such as blood, urine, tears, saliva, cerebrospinal fluid, etc.).
- a biomarker is an NT ⁇ proBNP Biomarker.
- An “NT ⁇ proBNP Biomarker” as used herein refers to a biological marker for Heart Failure (HF).
- one or more NT ⁇ proBNP Biomarkers include the N-terminal fragment NT-proBNP (Amino Acid 1–76) of proBNP.
- characteristic fragment refers to a fragment of a biomarker (e.g., NT-proBNP Biomarker) that is sufficient to identify the biomarker from which the fragment was derived.
- a “characteristic fragment” of a biomarker is one that contains an amino acid sequence, or a collection of amino acid sequences, that together allow for the biomarker from which the fragment was derived to be distinguished from other possible biomarkers, proteins, or polypeptides.
- a characteristic fragment includes at least 10, at least 20, at least 30, at least 40, or at least 50 amino acids.
- a characteristic fragment refers to a fragment of a biomarker that has at least 90%, at least 95%, at least 99% sequence identity to the biomarker from which the characteristic fragment was derived.
- hybridization refers to the physical property of single ⁇ stranded nucleic acid molecules (e.g., DNA or RNA) to anneal to complementary nucleic acid molecules.
- Hybridization can typically be assessed in a variety of contexts – including where interacting nucleic acid molecules are studied in isolation or in the context of more complex systems (e.g., while covalently or otherwise associated with a carrier entity and/or in a biological system or cell).
- hybridization can be detected by a hybridization technique, such as a technique selected from the group consisting of in situ hybridization (ISH), microarray, Northern blot, Southern blot, and the like.
- ISH in situ hybridization
- hybridization refers to 100% annealing between the single ⁇ stranded nucleic acid molecules and the complementary nucleic acid molecule.
- annealing is less than 100% (e.g., at least 95%, at least 90%, at least 85%, at least 80%, at least 75%, at least 70% of a single ⁇ stranded nucleic acid molecule anneals to a complementary nucleic acid molecule).
- Hybridization techniques, and methods for evaluating hybridization are well known in the art. See, e.g., Sambrook, et al., 1989, Molecular Cloning: A Laboratory Manual, Second Edition, Cold Spring Harbor Press, Plainview, N.Y.
- hybridization conditions such that sequences having at least a desired level of complementarity will stably hybridize, while those having lower complementarity will not.
- hybridization conditions and parameters see, e.g., Sambrook, et al., 1989, Molecular Cloning: A Laboratory Manual, Second Edition, Cold Spring Harbor Press, Plainview, N.Y.; Ausubel, F. M. et al. 1994, Current Protocols in Molecular Biology. John Wiley & Sons, Secaucus, N.J.
- detection agent refers to any element, molecule, functional group, compound, fragment, or moiety that is detectable.
- a detection agent is provided or utilized alone. In some non ⁇ limiting embodiments, a detection agent is provided and/or utilized in association with (e.g., joined to) another agent.
- detection agents include, but are not limited to: various ligands, radionuclides (e.g., 3 H, 14 C, 18 F, 19 F, 32 P, 35 S, 135 I, 125 I, 123 I, 64 Cu, 187 Re, 111 In, 90 Y, 99m Tc, 177 Lu, 89 Zr etc.), fluorescent dyes, chemiluminescent agents (such as, for example, acridinum esters, stabilized dioxetanes, and the like), bioluminescent agents, spectrally resolvable inorganic fluorescent semiconductors, nanocrystals (i.e., quantum dots), metal nanoparticles (e.g., gold, silver, copper, platinum, etc.), nanoclusters, paramagnetic metal ions, enzymes, color
- diagnosis test refers to a step or series of steps that is or has been performed to attain information that is useful in determining whether a patient has a disease, disorder, or condition and/or in classifying a disease, disorder, or condition into a phenotypic category or any category having significance with regard to prognosis of a disease, disorder, or condition, or likely response to treatment (either treatment in general or any particular treatment) of a disease, disorder, or condition.
- diagnosis refers to providing any type of diagnostic information, including, but not limited to, whether a subject is likely to have or develop a disease, disorder, or condition; state, staging, or characteristic of a disease, disorder, or condition as manifested in the subject; information related to the nature or classification of a condition such as a tumor or a heart condition; information related to prognosis; and/or information useful in selecting an appropriate treatment or additional diagnostic testing.
- Selection of treatment may include the choice of a particular therapeutic agent or other treatment modality such as surgery, radiation, etc., a choice about whether to withhold or deliver therapy, a choice relating to dosing regimen (e.g., frequency or level of one or more doses of a particular therapeutic agent or combination of therapeutic agents), etc.
- Selection of additional diagnostic testing may include more specific testing for a given disease, disorder, or condition.
- the words “comprising” (and any form of comprising, such as “comprise” and “comprises”), “having” (and any form of having, such as “have” and “has”), “including” (and any form of including, such as “includes” and “include”), or “containing” (and any form of containing, such as “contains” and “contain”) are inclusive or open ⁇ ended and do not exclude additional, unrecited elements or method steps.
- a process, method, article, or apparatus that comprises a list of elements is not necessarily limited to only those elements but may include other elements not expressly listed or inherently present therein.
- the term “or combinations thereof” as used herein refers to all permutations and combinations of the listed items preceding the term.
- “A, B, C, or combinations thereof” is intended to include at least one of: A, B, C, AB, AC, BC, or ABC, and if order is important in a particular context, also BA, CA, CB, CBA, BCA, ACB, BAC, or CAB.
- the term “substantially” means that the subsequently described event or circumstance occurs at least 80% of the time, or at least 85% of the time, or at least 90% of the time, or at least 95% of the time.
- the term “substantially adjacent” may mean that two items are 100% adjacent to one another, or that the two items are within close proximity to one another but not 100% adjacent to one another, or that a portion of one of the two items is not 100% adjacent to the other item but is within close proximity to the other item.
- the phrase “associated with” includes both direct association of two moieties to one another as well as indirect association of two moieties to one another.
- Non ⁇ limiting examples of associations include covalent binding of one moiety to another moiety either by a direct bond or through a spacer group, non ⁇ covalent binding of one moiety to another moiety either directly or by means of specific binding pair members bound to the moieties, incorporation of one moiety into another moiety such as by dissolving one moiety in another moiety or by synthesis, and coating one moiety on another moiety.
- biological fluid sample as used herein will be understood to include any liquid test sample that may be obtained from a patient and utilized in accordance with the present disclosure.
- volume as it relates to the liquid test samples utilized in accordance with the present disclosure typically refers to a volume of liquid test sample in a range of from about 0.1 ⁇ l to about 100 ⁇ l, or a range of from about 1 ⁇ l to about 75 ⁇ l, or a range of from about 2 ⁇ l to about 60 ⁇ l, or a value less than or equal to about 50 ⁇ l, or the like.
- patient as utilized herein includes human and veterinary subjects.
- a patient is a mammal. In certain other non ⁇ limiting embodiments, the patient is a human.
- the term “mammal” for purposes of diagnosis/treatment refers to any animal classified as a mammal, including human, domestic and farm animals, nonhuman primates, and zoo, sports, or pet animals, such as dogs, horses, cats, cows, etc.
- a “health care provider” or “health care decision maker” includes any individual authorized to diagnose or treat a patient, or to assist in the diagnosis or treatment of a patient.
- a health care provider can be an individual who is not authorized to diagnose or treat a patient, or to assist in the diagnosis or treatment of a patient.
- “Point of care testing” refers to real time diagnostic testing that can be done in a rapid time frame so that the resulting test is performed faster than comparable tests that do not employ this system. Point of care testing can be performed rapidly and on site, such as in a doctor's office, at a bedside, in a stat laboratory, emergency room, or other such locales, particularly where rapid and accurate results are required. The patient can be present, but such presence is not required.
- Point of care includes, but is not limited to: emergency rooms, operating rooms, hospital laboratories and other clinical laboratories, doctor's offices, in the field, or in any situation in which a rapid and accurate result is desired.
- specific binding partner as used in particular (but not by way of limitation) herein in the terms “target analyte ⁇ specific binding partner” or “biotin ⁇ specific binding partner,” will be understood to refer to any molecule capable of specifically associating with the target analyte.
- the binding partner may be an antibody, a receptor, a ligand, aptamers, molecular imprinted polymers (i.e., inorganic matrices), combinations or derivatives thereof, as well as any other molecules capable of specific binding to the target analyte.
- immunoassay refers to an assay to determine the presence of a diagnostic biomarker in a biological sample by reacting the sample with an antibody (or fragment thereof) that specifically binds to the diagnostic biomarker or characteristic fragment thereof, wherein the reaction is carried out for a time and under conditions that allow for the formation of an immunocomplex between the antibody (or fragment thereof) and the diagnostic biomarker.
- sample refers to a biological sample obtained or derived from a human subject, as described herein.
- a biological sample includes biological tissue or fluid.
- a biological sample may include blood; blood cells; tissue or fine needle biopsy samples; cell ⁇ containing body fluids; free floating nucleic acids; cerebrospinal fluid; lymph; tissue biopsy specimens; surgical specimens; other body fluids, secretions, and/or excretions; and/or cells therefrom.
- a biological sample includes cells obtained from an individual, e.g., from a human or animal subject.
- obtained cells are or include cells from an individual from whom the sample is obtained.
- a sample is a “primary sample” obtained directly from a source of interest by any appropriate means.
- a primary biological sample is obtained by methods selected from the group consisting of biopsy (e.g., fine needle aspiration or tissue biopsy), surgery, collection of body fluid (e.g., blood).
- a sample is cardiac tissue obtained from the subject.
- sample refers to a preparation that is obtained by processing (e.g., by removing one or more components of and/or by adding one or more agents to) a primary sample.
- sample processing may be a plasma sample that is treated with an anticoagulant selected from the group consisting of EDTA, heparin, and citrate.
- sample processing the sample may be processed to isolate one or more proteins (e.g., by capturing proteins with one or more antibodies).
- a “processed sample” may include, for example, nucleic acids or polypeptides extracted from a sample or obtained by subjecting a primary sample to techniques such as amplification or reverse transcription of mRNA, isolation and/or purification of certain components.
- Subject refers to an organism, for example, a mammal (e.g., a human).
- a human subject is an adult, adolescent, or pediatric subject.
- a subject is at least 50, at least 55, at least 60, at least 65, at least 70, at least 75, or at least 80 years of age.
- a subject is suffering from a disease, disorder or condition, e.g., a disease, disorder or condition that can be treated as provided herein.
- a subject is susceptible to a disease, disorder, or condition; in some embodiments, a susceptible subject is predisposed to and/or shows an increased risk (as compared to the average risk observed in a reference subject or population) of developing the disease, disorder or condition.
- a subject displays one or more symptoms of a disease, disorder or condition.
- a subject does not display a particular symptom (e.g., clinical manifestation of disease) or characteristic of a disease, disorder, or condition.
- a subject does not display any symptom or characteristic of a disease, disorder, or condition such as heart failure.
- a subject is a patient.
- a subject is an individual to whom diagnosis and/or therapy is and/or has been administered.
- Threshold value refers to a value (or values) that are used as a reference to attain information on and/or classify the results of a measurement, for example, the results of a measurement attained in an assay.
- a threshold value can be determined based on one or more control samples.
- a threshold value can be determined prior to, concurrently with, or after the measurement of interest is taken.
- a threshold value can be a range of values.
- a threshold value can be a value (or range of values) reported in the relevant field (e.g., a value found in a standard table).
- the term “stratification” refers to the division of potential patient groups or patient groups into subgroups such as strata or blocks. In embodiments, “strata” refers to a particular section of a patient population. [0050] Turning now to various non ⁇ limiting embodiments of the present disclosure, improved biomarker assay formats, as well as compositions/reagents/kits containing reagents for measuring a biomarker, along with methods of using same, are described herein.
- the present disclosure provides improved assays, such as (but not limited to) improved NT-proBNP assays, having improved performance where problematic free or natural biotin is or may be present in a biological sample and can cause interference in existing assay formats.
- biomarker assay formats are formulated to tune signal from a signal moiety.
- the assay format includes one or more streptavidin ⁇ coated solid supports (such as but not limited to one or more bead substrates or particles) that have been pre ⁇ incubated with one or more biotinylated antibodies (or binding fragments thereof) to form one or more solid phase reagents suitable for use in an immunoassay while eliminating or substantially eliminating interference of free biotin in a biological sample.
- the present disclosure tunes the signal to noise ratio of an NT ⁇ proBNP sandwich immunoassay suitable for use in a high ⁇ throughput analyzer.
- non ⁇ limiting embodiments because the solid phase reagent is presented with the biotinylated antibody in a pre ⁇ complexed form, there are substantially no opportunities for free or natural biotin from the sample to interfere in the assay.
- “no interference to biotin” is defined as a percent bias of ⁇ 10%.
- the present disclosure allows the NT ⁇ proBNP assay to claim no interference up to 3510 ng/mL biotin.
- the present immunoassay may be run on a high ⁇ throughput chemical analyzer capable of running more than 20, 30, 40, 50, 75, 100, or more tests per hour.
- the present disclosure also includes non ⁇ transient computer readable media suitable for executing the methods of the present disclosure on a chemical analyzer.
- the immunoassays may detect a complex between a serum marker or characteristic fragment thereof and a serum marker ⁇ binding antibody using a second antibody that is labeled and also binds to the serum marker or fragment thereof.
- sandwich immunoassays are used where a serum marker ⁇ binding antibody can be a capture antibody attached to an insoluble material (such as, but not limited to, a magnetic bead), and the second antibody can be a labeling antibody.
- sandwich immunoassay procedures can be used with the antibodies described hereinafter.
- embodiments of the present disclosure include an assay format suitable for detecting individual biomarkers such as NT ⁇ proBNP or a characteristic fragment thereof, as well as compositions/devices/kits containing same, methods of producing and using same, kits, and diagnostic tests related thereto.
- Certain non ⁇ limiting embodiments of the present disclosure include a preselected assay format for detecting NT ⁇ proBNP in serum. Certain non ⁇ limiting embodiments of the present disclosure advantageously reduce, eliminate, or substantially eliminate biotin interference in a reaction. In certain non ⁇ limiting embodiments, a preselected assay format advantageously limits biotin from being associated with reagents of the assay. [0055] Certain non ⁇ limiting embodiments of the present disclosure are directed to a method of determining the presence, severity, and/or predisposition of heart failure in an individual using a single biomarker.
- the present disclosure includes a method having a process sequence including: (a) forming a solid phase immunoassay reagent by contacting one or more streptavidin ⁇ coated particles with one or more biotinylated antibodies to form a complex; and (b) separating the solid phase immunoassay reagent from an immunoassay lite reagent and storing or packaging the solid phase reagent separate from the lite reagent.
- a solid phase reagent is presented with the biotinylated antibody in a pre ⁇ complexed form, there are substantially no opportunities for biotin from the biological fluid sample to interfere in the assay.
- no interference to biotin is defined as a percent bias of ⁇ 10%.
- no biotin interference includes no interference up to a concentration of 3510 ng/mL biotin.
- Embodiments of the present disclosure are suitable for use in an outpatient setting, such as where a patient in need thereof provides a biological sample from , or utilizes one or more embodiments of the present disclosure as part of an ambulatory care strategy, such as where medical service embodiments of the present disclosure do not require hospitalization, or wherein patients are free to leave a medical facility once a service or procedure of the present disclosure is complete.
- outpatient care include home health services, annual check ⁇ ups at a physician’s office or non ⁇ admitting clinic settings such as medical offices, clinics, ambulatory surgery centers, hospital outpatient departments and other non ⁇ hospital centers.
- embodiment of the present disclosure are suitable for use by a user in home ambulatory care to promote patient independence, permit a transition from hospital to home care, or as part of a home monitoring strategy e.g., cardiac monitoring.
- the assays of the present disclosure can be applied in a single occurrence in an outpatient care setting such as an outpatient facility where the patient does not need to be present for more than 1 ⁇ 24 hours, 24 hours, or 12 hours.
- a patient in need thereof will provide a biological sample such as blood or serum from an outpatient setting.
- the biological sample may be shared with a facility suitable for performing one or more assays or embodiments of the present disclosure in order to analyze the patient health information such as cardiac information.
- kits including one or more anti ⁇ HF Biomarker agents and instructions for use (e.g., treatment, prophylactic, or diagnostic use).
- the kit is used for an in vitro diagnostic assay to diagnose HF.
- the one or more anti ⁇ HF Biomarker agents include antibody agents.
- one or more of the antibody agents are labeled with a detectable moiety.
- the kit further includes a detection agent (e.g., one or more acridinium ester molecules).
- a detection agent e.g., one or more acridinium ester molecules.
- one or more of the antibody agents are labeled with one or more of the acridinium ester molecules.
- the kit further includes one or more secondary antibody agents that specifically bind to one or more of the anti ⁇ HF Biomarker antibody agents. Additional kit embodiments are described in the Examples below.
- the instructions for use provide a method for use suitable for an ATELLICA® CI Analyzer (Siemens Healthineers USA, Malvern, PA), e.g., 1900 model.
- the kit further includes one or more control samples.
- the control samples include one or more HF Biomarker standards.
- a kit can include other ingredients, such as (but not limited to) a solvent or buffer, a stabilizer or a preservative, and/or an agent for treating a condition or disorder described herein.
- other ingredients can be included in a kit, but in different compositions or containers than the anti ⁇ HF Biomarker agents.
- a kit can include instructions for admixing the anti ⁇ HF Biomarker agents and the other ingredients, or for using the anti ⁇ HF Biomarker together with the other ingredients.
- kits for use in accordance with the present disclosure may include a reference or control sample(s), instructions for processing samples, instructions for performing tests on samples, and/or instructions for interpreting the results, as well as buffers and/or other reagents necessary for performing tests.
- Methods and kits provided herein detect NT ⁇ proBNP in a sample with a sensitivity and a specificity that renders the outcome of the test reliable enough to be medically actionable.
- Methods and kits described herein for detection and/or diagnosis of HF in a subject detects NT ⁇ proBNP with a sensitivity greater than 75%, greater than 80%, greater than 85%, greater than 90%, greater than 95%, greater than 96%, greater than 97%, greater than 98%, greater than 99%, or about 100%.
- methods and kits provided herein can detect NT ⁇ proBNP with a sensitivity that is between about 70% ⁇ 100%, between about 80% ⁇ 100%, or between about 90 ⁇ 100%.
- compositions can detect NT ⁇ proBNP with a sensitivity and a specificity that is between about 50% ⁇ 100%, between about 60% ⁇ 100%, between about 70% ⁇ 100%, between about 80% ⁇ 100%, or between about 90 ⁇ 100%.
- a composition includes one or more biotinylated antibodies associated with one or more streptavidin ⁇ coated solid supports (such as, but not limited to, streptavidin ⁇ coated beads or particles).
- the assay format includes one or more streptavidin ⁇ coated particles such as one or more bead substrates having been pre ⁇ incubated with one or more biotinylated antibodies to form one or more solid phase reagents suitable for use in eliminating or substantially eliminating interference of free biotin in a biological fluid sample.
- the present disclosure tunes the signal to noise ratio of an NT ⁇ proBNP sandwich immunoassay suitable for use in a high ⁇ throughput analyzer.
- non ⁇ limiting embodiments because the solid phase reagent is presented with the biotinylated antibody in a pre ⁇ complexed form, there are substantially no opportunities for free or natural biotin from the sample to interfere in the assay when the reagents are mixed with sample.
- “no interference to biotin” is defined as a percent bias of ⁇ 10%.
- the present disclosure allows the NT ⁇ proBNP assay to claim no interference up to 3510 ng/mL biotin.
- the present immunoassay may be run on a high ⁇ throughput chemical analyzer capable of running more than 20, 30, 40, 50, 75, or 100 tests per hour. In certain non ⁇ limiting embodiments, the present immunoassay may be run, for example, on an ATELLICA® CI Analyzer (Siemens Healthineers USA, Malvern, PA), e.g., 1900 model.
- an immunoassay one or more specific binding species are used. Typical examples are the sandwich immunoassay, where two specific binding species (antibody or antigen) bind to non ⁇ overlapping epitopes of the analyte of interest.
- the other specific binding species is frequently associated with a solid or suspendable substrate (“the solid phase”) covalently or through adsorption. Alternatively, it may be linked to a first member of a second binding pair (e.g., biotin), while the second member of the second binding pair (e.g., streptavidin) is attached to the solid phase.
- a solid or suspendable substrate e.g., biotin
- Solid phases may be macroscopic solid phases, such as (but not limited to) microtiter well, tube and ball in tube devices, or suspendable solid phases, such as (but not limited to) beads, latex beads, magnetic latex beads, and the like, as well as other paramagnetic materials.
- a secondary binding species is commonly labeled through the use of a tag. The interaction between the tag and the solid phase allows for detection and quantification of the analyte of interest through a variety of detection methods corresponding to the label utilized.
- Reagent 1 is a streptavidin ⁇ coated particle (such as, but not limited to, a streptavidin ⁇ coated magnetic bead);
- Reagent 2 is a biotinylated first antibody; and
- Reagent 3 is an acridinium ⁇ labeled second antibody.
- the two antibodies of Reagents 2 and 3 bind to non ⁇ overlapping epitopes of NT ⁇ proBNP so that both antibodies can bind to a single molecule of NP ⁇ proBNP.
- the three reagents are mixed with a biological sample suspected of containing NT ⁇ proBNP (such as, but not limited to, plasma or serum), the two antibodies bind to NP ⁇ proBNP, and the biotinylated antibody binds to the streptavidin of the particles to form Reaction Product 1, in which the acridinium ester is indirectly associated with the solid phase particle via the binding of the two antibodies to NT ⁇ proBNP.
- the Reaction Product 1 can be detected via the signal generated by the acridinium ester associated with the solid phase.
- the free biotin competes with the biotinylated antibody for binding to the streptavidin ⁇ coated particles.
- Reagent 1 is the streptavidin ⁇ coated particle having the biotinylated first antibody pre ⁇ bound thereto
- Reagent 2 is the acridinium ⁇ labeled second antibody.
- the use of streptavidin ⁇ coated magnetic beads provides a fast magnetic response time and is suitable for use in high throughput and multiplexed assays.
- the streptavidin coating is contacted with one or more biotinylated antibodies under conditions suitable to associate the streptavidin coating and biotinylated antibodies. Therefore, the immunoassay of the present disclosure can be a fully automated 2-site sandwich immunoassay using direct chemiluminescent technology, which uses constant or substantially constant amounts of two monoclonal antibodies.
- the Solid Phase contains a bound biotinylated monoclonal sheep anti-human antibody specific to NT-proBNP and conjugated to streptavidin magnetic particles.
- the Lite Reagent contains an acridinium-ester-labeled monoclonal sheep anti-human NT-proBNP F(ab')2 fragment specific to NT-proBNP.
- a direct relationship exists between the amount of NT-proBNP present in the patient sample and the amount of relative light units (RLUs) detected by the system.
- RLUs relative light units
- a computer program may include instructions for the system to select appropriate next steps, including additional medication, a treatment, and/or additional testing for a subject.
- the computer program may be configured such that the computer system can identify a subject for further testing (e.g., heart tests), identify a subject as being at risk of having or having HF, and/or identify a subject to receive medication based on received data (e.g., an NT ⁇ proBNP Biomarker profile) and use the data to calculate an NT ⁇ proBNP Biomarker score.
- FIG. 4 is a block diagram of a computer system 1100 that can be used in the operations described above, according to one non ⁇ limiting embodiment.
- the system 1100 includes a processor 1110, a memory 1120, a storage device 1130, and an input/output device 1140. Each of the components 1110, 1120, 1130, and 1140 are interconnected using a system bus 1150.
- the system may optionally further include analyzing equipment 1160 for determining a level of one or more biomarkers of the present disclosure in a sample.
- the processor 1110 is capable of processing instructions for execution within the system 1100.
- the processor 1110 is a single ⁇ threaded processor.
- the processor 1110 is a multi ⁇ threaded processor.
- the processor 1110 is capable of processing instructions stored in the memory 1120 or on the storage device 1130, including for receiving or sending information through the input/output device 1140.
- the memory 1120 stores information within the system 1100.
- the memory 1120 is a computer ⁇ readable medium.
- the memory 1120 is a volatile memory unit.
- the memory 1120 is a non ⁇ volatile memory unit.
- the storage device 1130 is capable of providing mass storage for the system 1100.
- the storage device 1130 is a computer ⁇ readable medium.
- the input/output device 1140 provides input/output operations for the system 1100.
- the input/output device 1140 includes a keyboard and/or pointing device. In one non ⁇ limiting embodiment, the input/output device 1140 includes a display unit for displaying graphical user interfaces.
- the system 1100 can be used to build a database. In certain non ⁇ limiting embodiments, a method of the present disclosure is performed in the system 1100 disposed within a chemical analyzer. For example, a computer program product can include instructions that cause the processor 1110 to perform the steps of any of the methods disclosed or otherwise contemplated herein. [0081] Additionally, non ⁇ transitory computer readable media containing executable instructions that when executed cause a processor to perform operations including a method as provided herein are provided.
- a non ⁇ transitory computer readable medium containing executable instructions that when executed cause a processor to perform operations including any of the methods disclosed or otherwise contemplated herein.
- a non ⁇ transitory computer readable medium includes a hard drive, external hard drive, discs, CDs, DVDs, and/or the like that stores data.
- software disposed within a physical medium is suitable for use herein.
- a non ⁇ transitory computer readable media contains executable instructions that when executed cause a processor to perform operations including a method of determining the presence, severity, and/or predisposition of heart failure (HF) in an individual, wherein the method includes the steps of: incubating the assay components of the present disclosure with a biological sample, and determining the amount of NT ⁇ proBNP in a sample.
- HF heart failure
- Example 1 The present disclosure includes in a non ⁇ limiting embodiment an NT-proBNP assay suitable for in vitro diagnostic use in the quantitative determination of N-terminal pro-brain natriuretic peptide (NT-proBNP) in human serum and plasma (EDTA and lithium heparin) using a chemical analyzer, such as (but not limited to) the ADVIA Centaur® XP system.
- a chemical analyzer such as (but not limited to) the ADVIA Centaur® XP system.
- ED Emergency Department
- OP Outpatient
- the Materials present in the kit include: ⁇ Lite reagent (7.5 ml/reagent pack) containing monoclonal sheep anti ⁇ human NT ⁇ proBNP F(ab’)2 fragment antibody ( ⁇ 0.36 ⁇ g/ml) labeled with acridinium ester in buffer; bovine serum albumin (BSA); bovine gamma globulin; and preservatives.
- ⁇ Lite reagent 7.5 ml/reagent pack
- monoclonal sheep anti ⁇ human NT ⁇ proBNP F(ab’)2 fragment antibody ⁇ 0.36 ⁇ g/ml
- BSA bovine serum albumin
- bovine gamma globulin bovine gamma globulin
- Solid Phase reagent (20.0 ml/reagent pack) containing monoclonal sheep anti ⁇ human NT ⁇ proBNP antibody ( ⁇ 2 ⁇ g/ml) labeled with biotin bound to streptavidin magnetic particles ( ⁇ 220 mg/L) in buffer; BSA; bovine gamma globulin; sheep gamma globulin; and preservatives.
- BSA monoclonal sheep anti ⁇ human NT ⁇ proBNP antibody
- streptavidin magnetic particles ⁇ 220 mg/L
- the assay of the present disclosure is a fully automated 2-site sandwich immunoassay using direct chemiluminescent technology, which uses constant amounts of 2 monoclonal antibodies.
- the Solid Phase contains a bound biotinylated monoclonal sheep anti-human antibody specific to NT-proBNP and conjugated to streptavidin magnetic particles.
- the Lite Reagent contains an acridinium-ester-labeled monoclonal sheep anti-human NT-proBNP F(ab')2 fragment specific to NT-proBNP.
- RLUs relative light units
- Non ⁇ limiting procedures for collecting the specimen or sample may involve one or more of the following optional steps: observe universal precautions when collecting specimens; handle all specimens as if they are capable of transmitting disease; follow recommended procedures for collection of diagnostic blood specimens by venipuncture; follow the instructions provided with your specimen collection device for use and processing; allow blood specimens to clot completely before centrifugation; and/or keep tubes capped at all times.
- Non ⁇ limiting procedures for storing the specimen or sample may involve one or more of the following optional steps: after centrifugation, serum specimens stored on the clot are stable for up to 24 hours at 2–8°C; separated samples are stable for up to 3 days at room temperature, and for up to 4 days at 2–8°C; separated samples are stable at ⁇ ⁇ 20°C for up to 12 months; avoid more than 1 freeze-thaw cycle; do not store in a frost ⁇ free freezer; and/or thoroughly mix thawed samples and centrifuge them before using.
- Non ⁇ limiting assay procedures may involve one or more of the following optional steps.
- the system (including a high throughput chemical analyzer) automatically performs the following steps: dispenses 20 ⁇ L of sample into a cuvette; dispenses 200 ⁇ L of Solid Phase and 75 ⁇ L of Ancillary Well Reagent, then incubates for 3 minutes at 37°C; dispenses 75 ⁇ L of Lite Reagent, then incubates for 6 minutes at 37°C; performs a wash sequence using a wash reagent (such as, but not limited to, ADVIA Centaur Wash 1); dispenses 300 ⁇ L each of acid and base reagent (such as, but not limited to, ADVIA Centaur Acid Reagent and ADVIA Centaur Base Reagent) into initiate the chemiluminescent reaction; and/or reports results.
- a wash reagent such as, but not limited to, ADVIA Centaur Wash 1
- dispenses 300 ⁇ L each of acid and base reagent such as, but not limited to, ADVIA Centaur Acid Re
- Non ⁇ limiting instructions for preparing the reagents for use on an automated system include: all reagents are liquid and ready to use. Before loading the packs onto the system, reagents require mixing. For information about mixing the reagents, refer to the system online help.
- Non ⁇ limiting instructions for preparing the automated system to perform the assays of the present disclosure include: ensure that sufficient materials are loaded on the system. Refer to Materials Provided and Materials Required but Not Provided for guidance about required reagents.
- Non ⁇ limiting instructions for setting Master Curve Definition include: before initiating calibration on each new lot of reagent, enter the assay master curve values by scanning the master curve card.
- Non ⁇ limiting instructions for performing calibration include: For calibration of one certain non ⁇ limiting embodiments of the assay, use the calibrators provided with each kit. Calibrators provided in an assay kit must only be used with the reagent lot provided in the same kit.
- Non ⁇ limiting instructions for Calibration Frequency include: Perform a calibration if one or more of the following conditions exist: At the end of the 36-day calibration interval; When changing lot numbers of primary reagent packs; When indicated by quality control results; and after major maintenance or service, if indicated by quality control results.
- Perform government regulations or accreditation requirements for calibration frequency Individual laboratory quality control programs and procedures may require more frequent calibration.
- Non ⁇ limiting instructions for preparing the calibrators include one or more of the following optional steps: add 2.0 mL of reagent water into each vial. Replace cap. Let the vials stand for 30 minutes at room temperature to allow the lyophilized material to dissolve. Gently mix and invert the vials to ensure homogeneity of the material. For extended storage, aliquot and seal tightly. Store reconstituted material according to stability limits specified in Reagents. Do not store in a frost ⁇ free freezer. Before using frozen calibrators, allow the material to thaw completely. Gently mix and invert the vials to ensure homogeneity of the material. Use calibrators within the stability limits specified in Reagents and discard any remaining material.
- Non ⁇ limiting instructions for performing the calibration procedure include: ensuring that the appropriate master curve and calibrator assigned values are entered on the system. For information about defining the master curve and entering calibrator values, refer to the system online help. Load the required reagents for the assay. Schedule the calibrators. Label two sample containers with barcode labels: one container for the low calibrator and one container for the high calibrator. Place the barcode labels on the sample containers with the readable characters oriented vertically. Barcode labels are lot ⁇ specific. Do not use barcode labels from one lot of calibrators with any other lot of calibrators. Gently mix the product and dispense a sufficient volume of each calibrator into the appropriate sample containers. Avoid bubbles. The required sample volume for testing depends on several factors.
- Non ⁇ limiting instructions for performing quality xontrol include: for quality control of certain non ⁇ limiting embodiments of the assays of the present disclosure, use an appropriate quality control material of known analyte concentration with a minimum of two levels (low and high) at least once during each day that samples are analyzed. Use the quality control material in accordance with the quality control instructions for use. Additional quality control material can be used at the discretion of the laboratory. Use the quality control material in accordance with the quality control instructions for use.
- Non ⁇ limiting instructions for Taking Corrective Action include: If the quality control results do not fall within the expected control interval, do not report results.
- NT-proBNP levels > 35,000 pg/mL (4130 pmol/L) to obtain accurate results.
- For automated dilutions perform the following activities: Load a multi ⁇ diluent (such as, but not limited to, ADVIA Centaur Multi-Diluent 1). Ensure that sufficient sample volume is available. Refer to the table below. Select the appropriate dilution factor. For automatic dilutions enter a Dilution Point ⁇ 35,000 pg/mL (4130 pmol/L).
- Results from assays of the present disclosure should be interpreted with the appropriate clinical guidelines and in conjunction with the patient’s medical history, clinical presentation, and other findings. Guidelines recommend using natriuretic peptides in both Emergency Department (ED) and Outpatient (OP) settings for diagnosis or exclusion of heart failure. The performance of the assays of the present disclosure was evaluated separately in each of these settings using published age ⁇ independent and age ⁇ dependent cut ⁇ off values.
- Emergency Department (ED) Population [0106] For patients presenting to ED settings with clinical suspicion of HF, the NT ⁇ proBNP assay results should be interpreted as indicated in Table 2.
- Elevated or depressed natriuretic peptides values can be caused by conditions which may confound the diagnosis of heart failure.
- conditions such as chronic heart failure, acute coronary syndrome, atrial fibrillation, pulmonary embolism, valvular heart disease, myocarditis, pulmonary hypertension, renal deficiency, stroke, and sepsis can elevate NT ⁇ proBNP levels in the absence of acute heart failure.
- obesity, flash pulmonary edema, pericarditis, and cardiac tamponade are associated with reduced NT ⁇ proBNP levels.
- the optimal use of natriuretic peptide assays excludes the HF diagnosis.
- NT ⁇ proBNP values are summarized in Tables 5 ⁇ 6 for subjects with acute HF by subgroups based on age group (Table 5) and NYHA Functional Class (Table 6).
- the males with Acute HF are summarized in Table 7, while the females with acute HF are summarized in Table 8.
- TABLE 5 ED Population – All Subjects with Acute HF T TABLE 8 [0116] ED Population ⁇ all subjects with Acute HF (e.g, such as NYHA Functional Class).
- the NYHA classifications for the ED population with acute HF are provided in Table 9.
- Outpatient (OP) Population [0118] A total of 1033 subjects who presented to the OP setting with signs and symptoms of HF were enrolled. Of these, 185 subjects (102 females and 83 males) were diagnosed with new onset HF and included in the disease study group. NT ⁇ proBNP values are summarized for subjects with new onset HF based on age group (Tables 13 ⁇ 15) and NYHA Functional Class (Tables 16 ⁇ 18). Table 13 summarizes OP population – all subjects with new onset HF.
- the area under the ROC curve for the NT ⁇ proBNP assay is 0.839 with a 95% confidence interval of 0.804 to 0.868.
- Performance Characteristics [0123] Measuring Interval: 35 – 35,000 pg/mL (4.13 – 4130 pmol/L). The lower limit of the measuring interval is defined by the limit of quantitation (LoQ). Report results below the measuring interval as ⁇ 35 pg/ml (4.13 pmol/L).
- LoB Limit of Blank
- LoD Limit of Detection
- LoQ Limit of Quantitation
- LoB and LoD values are representative data.
- the LoB corresponds to the highest measurement result likely to be observed for a blank sample with a probability of 95%.
- the LoD corresponds to the lowest concentration of NT ⁇ proBNP that can be detected with a probability of 95%.
- the LoQ corresponds to the lowest amount of NT ⁇ proBNP in a sample at which the within laboratory CV is 20%.
- Detection capability was determined in accordance with CLSI Document EP17 ⁇ A2.
- Clinical Performance A total of 3128 subjects with signs and symptoms of acute HF who presented to the ED, were prospectively enrolled in a multi ⁇ site clinical evaluation of one non ⁇ limiting embodiment of the NT ⁇ proBNP assay of the present disclosure. Diagnosis and severity of HF were determined by an independent central adjudication panel of expert clinicians (cardiologists). 1148 subjects were adjudicated as acute HF, and 1980 subjects were adjudicated as without HF. [0126] The descriptive statistics for the NT ⁇ proBNP test results (pg/ml) were determined for the ED Population at enrollment. [0127] Table 19 summarizes the baseline characteristics for all of the ED population, while Table 20 summarizes the baseline characteristics of the ED population by age group. TABLE 19 TABLE 20
- a likelihood ratio of 3.53 indicates a person with acute HF is 3.5 times more likely to have a positive test result than a person with no acute HF.
- Subjects with an indeterminate result had a reduction in post ⁇ test risk of HF to 24.3% and were nearly half (LR 0.55) as likely to be in the HF population than in the negative diagnosis population.
- a likelihood ratio of 0.07 indicates a person with acute HF is 0.07 (less than 1/10 th ) times likely to have a negative test than a person with no acute HF.
- Table 21 summarizes the results for all sex and age groups combined;
- Table 22 summarizes the results by age group;
- Table 23 summarizes the male subjects by age group;
- Table 24 summarizes the female subjects by age group. Analyses were also performed for relevant ED population clinical subgroups as shown in Tables 25 ⁇ 32.
- TABLE 21 TABLE 22
- TABLE 23 TABLE 24
- Clinical sensitivity and specificity were determined for the OP population and relevant OP clinical subgroups by comparing the performance of the non ⁇ limiting embodiment of the NT ⁇ proBNP assay of the present disclosure to the adjudicated diagnosis. Using a single cut ⁇ off of 126 pg/mL, relative to the adjudicated diagnosis of new onset HF, the analysis consisted of calculations of clinical sensitivity, clinical specificity, Positive Predictive Value (PPV), and Negative Predictive Value (NPV). The results are summarized in Tables 34 ⁇ 38. [0140] Clinical sensitivity and specificity were determined in accordance with CLSI Document EP12 ⁇ A2.
- Bias due to these substances does not exceed 10% at NT ⁇ proBNP concentrations of 116 – 163 pg/mL (13.7 – 19.2 pmol/L) and 1478 ⁇ 2225 pg/mL (174 ⁇ 263 pmol/L).
- Cross ⁇ Reactivity was determined in accordance with CLSI Document EP07 ⁇ ed3. Cross ⁇ reactants listed in Table 44 were tested at NT ⁇ proBNP concentrations of 0 pg/mL (0 pmol/L) and 126 – 158 pg/mL (14.9 – 18.6 pmol/L). TABLE 44 [0155] Linearity [0156] Linearity testing was performed in accordance with CLSI Document EP06 ⁇ ed2. The assay is linear for the measuring interval of 35 – 35,000 pg/mL (4.13 – 4130 pmol/L).
- the lite reagent, solid phase reagent, ancillary well reagent, calibrator, multi ⁇ diluent, and/or wash reagent can be stored unopened at 2 ⁇ 8°C.
- the lite reagent, solid phase reagent, and/or ancillary well reagent are substantially stable for at least 36 days once onboard.
- Example 3 contains a comparison of the biotin interference observed between the prior art 3 ⁇ reagent NT ⁇ proBNP assay and one non ⁇ limiting embodiment of the 2 ⁇ reagent NT ⁇ proBNP assay of the present disclosure.
- the acceptable percent bias observed for the assay of the present concentration occurs at a biotin concentration that is at least about 50x higher than the biotin concentration at which an acceptable percent bias was observed in the prior art assay.
- kits for use in determining an amount of NT ⁇ proBNP in a biological sample comprising: (a) a solid phase reagent comprising a solid support having a first anti ⁇ NT ⁇ proBNP antibody or binding fragment thereof directly or indirectly attached thereto; and (b) a lite reagent comprising a second anti ⁇ NT ⁇ proBNP antibody or binding fragment thereof labeled with an acridinium ester; and wherein the first and second anti ⁇ NT ⁇ proBNP antibodies or binding fragments thereof bind to non ⁇ overlapping epitopes of NT ⁇ proBNP and thereby form an immunocomplex comprising (a), (b), and NT ⁇ proBNP.
- Illustrative embodiment 2 Illustrative embodiment 2.
- Illustrative embodiment 3 The kit of Illustrative embodiment 2, wherein the biotin ⁇ specific binding molecule is selected from the group consisting of streptavidin, traptavidin, and avidin.
- Illustrative embodiment 4 The kit of Illustrative embodiment 3, wherein the biotin ⁇ specific binding molecule is streptavidin.
- Illustrative embodiment 6. The kit of any of Illustrative embodiments 1 ⁇ 5, wherein the solid phase reagent of (a) comprises a biotinylated monoclonal sheep anti-human antibody specific to NT-proBNP conjugated to a magnetic particles having streptavidin coated on at least a portion of a surface thereof.
- Illustrative embodiment 8A The kit of any of illustrative embodiments 1 ⁇ 8, wherein the kit is configured for use in an emergency department setting.
- Illustrative embodiment 8B The kit of any of illustrative embodiments 1 ⁇ 8A, wherein the kit is configured for use in an outpatient setting.
- Illustrative embodiment 8C The kit of any of illustrative embodiments 1 ⁇ 8B, wherein the kit is configured for use in an emergency department and/or outpatient setting.
- Illustrative embodiment 9 A method of determining the presence, severity, and/or predisposition of Heart Failure (HF) in an individual, the method including the steps of: (a) combining, either simultaneously or wholly or partially sequentially, to form a reaction mixture: (i) a biological fluid sample; (ii) a solid phase reagent comprising a solid support having a first anti ⁇ NT ⁇ proBNP antibody or binding fragment thereof attached thereto; and (iii) a lite reagent comprising a second anti ⁇ NT ⁇ proBNP antibody or binding fragment thereof labeled with an acridinium ester, wherein the first and second anti ⁇ NT ⁇ proBNP antibodies or binding fragments thereof bind to non ⁇ overlapping epitopes of NT ⁇ proBNP; (b) incubating the reaction mixture under conditions that allow for
- Illustrative embodiment 10 The method of Illustrative embodiment 9, further comprising the step of: (d) using a mathematical algorithm to obtain an HF score based on the measured value of NT ⁇ proBNP in the sample.
- Illustrative embodiment 11 The method of Illustrative embodiment 9 or 10, wherein the biological fluid sample is selected from the group consisting of blood, serum, plasma, and combinations thereof.
- Illustrative embodiment 13 The method of any of Illustrative embodiments 9 ⁇ 11, wherein the first anti ⁇ NT ⁇ proBNP antibody or binding fragment thereof is biotinylated, and wherein at least a portion of a surface of the solid support is coated with a biotin ⁇ specific binding molecule, whereby the first anti ⁇ NT ⁇ proBNP antibody or binding fragment thereof is indirectly attached to the solid support.
- Illustrative embodiment 13 The method of Illustrative embodiment 12, wherein the biotin ⁇ specific binding molecule is selected from the group consisting of streptavidin, traptavidin, and avidin.
- Illustrative embodiment 13A The method of illustrative embodiment 13, wherein the biotin ⁇ specific binding molecule is streptavidin.
- Illustrative embodiment 14 The method of any of Illustrative embodiments 9 ⁇ 13A, wherein the solid support comprises magnetic and/or latex particles.
- Illustrative embodiment 15 The method of any of Illustrative embodiments 9 ⁇ 14, wherein the solid phase reagent of (ii) comprises a biotinylated monoclonal sheep anti-human antibody specific to NT-proBNP conjugated to a magnetic particles having streptavidin coated on at least a portion of a surface thereof.
- Illustrative embodiment 17 The method of any of Illustrative embodiments 9 ⁇ 15, wherein the lite reagent of (iii) comprises an acridinium-ester-labeled monoclonal sheep anti-human NT-proBNP F(ab')2 fragment specific to NT-proBNP.
- Illustrative embodiment 17A The method of any of Illustrative embodiments 9 ⁇ 16, wherein substantially no interference from biotin present in the biological fluid sample is observed.
- Illustrative embodiment 17A The method of Illustrative embodiment 17, wherein substantially no biotin interference is defined as a percent bias of ⁇ 10%.
- Illustrative embodiment 17B The method of any of Illustrative embodiment 17B.
- Illustrative embodiment 17 or 17A wherein substantially no biotin interference is observed at a biotin concentration in the biological fluid sample of up to about 3510 ng/ml biotin
- Illustrative embodiment 18 The method of any of Illustrative embodiments 9 ⁇ 17, wherein at least one of steps (b), (c), and (d) is performed on an automated analyzer.
- step (c) is further defined as measuring an amount of relative light units (RLUs), wherein the amount of RLUs is directly proportional to an amount of NT ⁇ proBNP in the sample.
- RLUs relative light units
- Illustrative embodiment 19B The method of any of Illustrative embodiments 9 ⁇ 19A, wherein the method or a potion thereof is performed in an outpatient setting.
- a sample may be obtained in the out ⁇ patient setting or from an out ⁇ patient strata and shared with a facility suitable for performing the methods of the present disclosure or using kits of the present disclosure.
- the sharing may be done by sending sample to the facility under conditions suitable for shipping biological materials.
- Illustrative embodiment 19C Illustrative embodiment 19C.
- Illustrative embodiment 20 A non ⁇ transitory computer readable medium containing executable instructions that when executed cause a processor to perform operations including the method of any of Illustrative embodiments 9 ⁇ 19C.
- Illustrative embodiment 21 A non ⁇ transitory computer readable medium containing executable instructions that when executed cause a processor to perform operations including the method of any of Illustrative embodiments 9 ⁇ 19C.
- kits for use in determining an amount of NT ⁇ proBNP in a biological sample comprising: (a) a solid phase reagent comprising a biotinylated monoclonal sheep anti-human antibody specific to NT-proBNP conjugated to a magnetic particle having streptavidin coated on at least a portion of a surface thereof; (b) a lite reagent comprising acridinium-ester-labeled monoclonal sheep anti-human NT-proBNP F(ab')2 fragment specific to NT-proBNP; and wherein the antibody of (a) and F(ab’)2 fragment of (b) bind to non ⁇ overlapping epitopes of NT ⁇ proBNP and thereby form an immunocomplex comprising (a), (b), and NT ⁇ proBNP.
- Illustrative embodiment 22 The kit of Illustrative embodiment 21, wherein (a) is packaged separately from (b).
- Illustrative embodiment 22A The kit of illustrative embodiment 21 or 22, wherein the kit is configured for use in an emergency department setting.
- Illustrative embodiment 22B The kit of any of illustrative embodiments 21 ⁇ 22A, wherein the kit is configured for use in an outpatient setting.
- Illustrative embodiment 23 The kit of any of illustrative embodiments 21 ⁇ 22A, wherein the kit is configured for use in an outpatient setting.
- a method of determining the presence, severity, and/or predisposition of Heart Failure (HF) in an individual including the steps of: (a) combining, either simultaneously or wholly or partially sequentially, to form a reaction mixture: (i) a biological fluid sample; (ii) a solid phase reagent comprising a biotinylated monoclonal sheep anti-human antibody specific to NT-proBNP conjugated to a magnetic particle having streptavidin coated on at least a portion of a surface thereof; (iii) a lite reagent comprising acridinium-ester-labeled monoclonal sheep anti-human NT-proBNP F(ab')2 fragment specific to NT-proBNP, wherein the antibody of (ii) and F(ab’)2 fragment of (iii) bind to non ⁇ overlapping epitopes of NT ⁇ proBNP; and (b) incubating the reaction mixture under conditions that allow for binding of (ii) and (iii)
- Illustrative embodiment 24 The method of Illustrative embodiment 23, further comprising the step of: (d) using a mathematical algorithm to obtain an HF score based on the measured value of NT ⁇ proBNP in the sample.
- Illustrative embodiment 25 The method of Illustrative embodiment 23 or 24, wherein the biological fluid sample is selected from the group consisting of blood, serum, plasma, and combinations thereof.
- Illustrative embodiment 26 The method of any of Illustrative embodiments 23 ⁇ 25, wherein substantially no interference from biotin present in the biological fluid sample is observed.
- Illustrative embodiment 26A The method of Illustrative embodiment 26, wherein substantially no biotin interference is defined as a percent bias of ⁇ 10%.
- Illustrative embodiment 26B The method of Illustrative embodiment 26 or 26A, wherein substantially no biotin interference is observed at a biotin concentration in the biological fluid sample of up to about 3510 ng/ml biotin.
- Illustrative embodiment 27 The method of any of Illustrative embodiments 23 ⁇ 26, wherein at least one of steps (b), (c), and (d) is performed on an automated analyzer.
- Illustrative embodiment 28 The method of Illustrative embodiment 27, wherein step (c) is further defined as measuring an amount of relative light units (RLUs), wherein the amount of RLUs is directly proportional to an amount of NT ⁇ proBNP in the sample.
- RLUs relative light units
- Illustrative embodiment 28A The method of any of Illustrative embodiments 23 ⁇ 28, wherein the method is performed in an emergency department setting.
- Illustrative embodiment 28B The method of any of Illustrative embodiments 23 ⁇ 28A, wherein the method is performed in an outpatient setting.
- Illustrative embodiment 28C The method of any of Illustrative embodiments 23 ⁇ 28, wherein the method is performed in an emergency department and/or or outpatient setting.
- Illustrative embodiment 29 A non ⁇ transitory computer readable medium containing executable instructions that when executed cause a processor to perform operations including the method of any of Illustrative embodiments 23 ⁇ 28C.
- Illustrative embodiment 30 A non ⁇ transitory computer readable medium containing executable instructions that when executed cause a processor to perform operations including the method of any of Illustrative embodiments 23 ⁇ 28C.
- a method of determining the presence, severity, and/or predisposition of Heart Failure (HF) in an individual including the steps of: (a) combining, either simultaneously or wholly or partially sequentially, to form a reaction mixture: (i) a biological fluid sample; (ii) a solid phase reagent comprising a solid support having a first anti ⁇ NT ⁇ proBNP antibody or binding fragment thereof attached thereto; and (iii) a lite reagent comprising a second anti ⁇ NT ⁇ proBNP antibody or binding fragment thereof labeled with an acridinium ester, wherein the first and second anti ⁇ NT ⁇ proBNP antibodies or binding fragments thereof bind to non ⁇ overlapping epitopes of NT ⁇ proBNP; (b) incubating the reaction mixture under conditions that allow for binding of (ii) and (iii) to NT ⁇ proBNP present in the biological fluid sample to form an immunocomplex; and (c) measuring an amount of immunocomplex formed to obtain a measured value for NT ⁇ proBNP in
- Illustrative embodiment 31 Embodiment 30 including wherein the method is performed in an emergency department, point ⁇ of ⁇ care and/or outpatient setting.
- Illustrative embodiment 32 Embodiment 30 ⁇ 31, wherein the biological fluid sample is obtained in the outpatient setting, and subsequently provided to the reaction mixture.
- Illustrative embodiment 33 Embodiment 30 ⁇ 32, wherein the individual is characterized as from an out ⁇ patient strata.
- Illustrative embodiment 34 Embodiment 30 ⁇ 33, wherein the first anti ⁇ NT ⁇ proBNP antibody or binding fragment thereof is biotinylated, and wherein at least a portion of a surface of the solid support is coated with streptavidin, whereby the first anti ⁇ NT ⁇ proBNP antibody or binding fragment thereof is indirectly attached to the solid support, wherein the solid support comprises magnetic and/or latex particles, wherein: the solid phase reagent of (ii) comprises a biotinylated monoclonal sheep anti-human antibody specific to NT-proBNP conjugated to a magnetic particles having streptavidin coated on at least a portion of a surface thereof; and the lite reagent of (iii) comprises an acridinium-ester-labeled monoclonal sheep anti-human NT-proBNP F(ab')2 fragment specific to NT-proBNP, wherein no biotin interference is observed at a biotin concentration in the biological fluid sample of up to about 3510
Landscapes
- Health & Medical Sciences (AREA)
- Life Sciences & Earth Sciences (AREA)
- Chemical & Material Sciences (AREA)
- Molecular Biology (AREA)
- Immunology (AREA)
- Engineering & Computer Science (AREA)
- Biomedical Technology (AREA)
- Organic Chemistry (AREA)
- Hematology (AREA)
- General Health & Medical Sciences (AREA)
- Medicinal Chemistry (AREA)
- Urology & Nephrology (AREA)
- Biochemistry (AREA)
- Endocrinology (AREA)
- Genetics & Genomics (AREA)
- Biophysics (AREA)
- Food Science & Technology (AREA)
- Microbiology (AREA)
- General Physics & Mathematics (AREA)
- Pathology (AREA)
- Analytical Chemistry (AREA)
- Biotechnology (AREA)
- Proteomics, Peptides & Aminoacids (AREA)
- Cell Biology (AREA)
- Physics & Mathematics (AREA)
- Zoology (AREA)
- Gastroenterology & Hepatology (AREA)
- Toxicology (AREA)
- Cardiology (AREA)
- Investigating Or Analysing Biological Materials (AREA)
Abstract
Description
Claims
Priority Applications (2)
| Application Number | Priority Date | Filing Date | Title |
|---|---|---|---|
| AU2024292177A AU2024292177A1 (en) | 2023-07-17 | 2024-07-16 | Methods, reagents, and kits for tuning an immunoassay signal |
| CN202480047400.XA CN121532655A (en) | 2023-07-17 | 2024-07-16 | Methods, reagents, and kits for modulating immunoassay signals |
Applications Claiming Priority (2)
| Application Number | Priority Date | Filing Date | Title |
|---|---|---|---|
| US202363514108P | 2023-07-17 | 2023-07-17 | |
| US63/514,108 | 2023-07-17 |
Publications (1)
| Publication Number | Publication Date |
|---|---|
| WO2025019482A1 true WO2025019482A1 (en) | 2025-01-23 |
Family
ID=94282544
Family Applications (1)
| Application Number | Title | Priority Date | Filing Date |
|---|---|---|---|
| PCT/US2024/038174 Ceased WO2025019482A1 (en) | 2023-07-17 | 2024-07-16 | Methods, reagents, and kits for tuning an immunoassay signal |
Country Status (3)
| Country | Link |
|---|---|
| CN (1) | CN121532655A (en) |
| AU (1) | AU2024292177A1 (en) |
| WO (1) | WO2025019482A1 (en) |
Citations (4)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| US20050239138A1 (en) * | 2004-03-15 | 2005-10-27 | Georg Hess | Use of cardiac hormones to assess risk of cardiovascular complication from volume overload |
| US20170269100A1 (en) * | 2009-11-21 | 2017-09-21 | Abbott Laboratories | Assays for human nt-pro b-type natriuretic peptide, human pro b-type natriuretic peptide and human b-type natriuretic peptide |
| CN109678958B (en) * | 2019-01-31 | 2022-03-18 | 重庆探生科技有限公司 | Human NT-proBNP specific recombinant goat monoclonal antibody, and preparation method and application thereof |
| WO2022126055A1 (en) * | 2020-12-07 | 2022-06-16 | Siemens Healthcare Diagnostics Inc. | Labels comprising dibromopyridazinediones for immunoassays and methods of production and use thereof |
-
2024
- 2024-07-16 CN CN202480047400.XA patent/CN121532655A/en active Pending
- 2024-07-16 WO PCT/US2024/038174 patent/WO2025019482A1/en not_active Ceased
- 2024-07-16 AU AU2024292177A patent/AU2024292177A1/en active Pending
Patent Citations (4)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| US20050239138A1 (en) * | 2004-03-15 | 2005-10-27 | Georg Hess | Use of cardiac hormones to assess risk of cardiovascular complication from volume overload |
| US20170269100A1 (en) * | 2009-11-21 | 2017-09-21 | Abbott Laboratories | Assays for human nt-pro b-type natriuretic peptide, human pro b-type natriuretic peptide and human b-type natriuretic peptide |
| CN109678958B (en) * | 2019-01-31 | 2022-03-18 | 重庆探生科技有限公司 | Human NT-proBNP specific recombinant goat monoclonal antibody, and preparation method and application thereof |
| WO2022126055A1 (en) * | 2020-12-07 | 2022-06-16 | Siemens Healthcare Diagnostics Inc. | Labels comprising dibromopyridazinediones for immunoassays and methods of production and use thereof |
Non-Patent Citations (1)
| Title |
|---|
| LEE, J.H. ; CHOI, H.K. ; CHANG, J.H.: "Optimization of biotin labeling of antibodies using mouse IgG and goat anti-mouse IgG-conjugated fluorescent beads and their application as capture probes on protein chip", JOURNAL OF IMMUNOLOGICAL METHODS, ELSEVIER SCIENCE PUBLISHERS B.V.,AMSTERDAM., NL, vol. 362, no. 1-2, 31 October 2010 (2010-10-31), NL , pages 38 - 42, XP027509588, ISSN: 0022-1759, DOI: 10.1016/j.jim.2010.08.006 * |
Also Published As
| Publication number | Publication date |
|---|---|
| CN121532655A (en) | 2026-02-13 |
| AU2024292177A1 (en) | 2025-12-18 |
Similar Documents
| Publication | Publication Date | Title |
|---|---|---|
| CN104303061B (en) | The prognosis of adverse events in patient with doubtful chronic heart failure | |
| EP1739430B1 (en) | Assay method for cardiovascular disease | |
| JP2011523051A (en) | GDF-15 as a biomarker in type 1 diabetes | |
| TW201643429A (en) | Prostate antigen standard and its use | |
| JP2011509403A (en) | Means and method for assessing the risk of a patient visiting an emergency room based on GDF-15 | |
| CN105308455B (en) | Methods and compositions for diagnosing preeclampsia | |
| CN101144811A (en) | Biochemical markers for acute pulmonary embolism | |
| US20080255766A1 (en) | Methods and kits for the diagnosis of sickle cell | |
| CN105102984B (en) | Use of sCD14 or its fragments or derivatives for risk stratification, diagnosis and prognosis | |
| WO2017197028A1 (en) | Compositions and methods for identifying subjects at risk for traumatic brain injury | |
| JP4927825B2 (en) | Apparatus and method for diagnosing or predicting early stage cardiac dysfunction | |
| WO2013049509A1 (en) | Assay panel for non-alcoholic steatohepatitis | |
| EP1722226A1 (en) | Method of distinguishing type a and type b acute aortic dissection and acute myocardial infarction and kit for distinguishment | |
| CN116547536A (en) | GDF-15 for predicting disease severity in patients with COVID-19 | |
| CN115308423B (en) | Biomarkers, kits and methods for preeclampsia risk prediction, assessment or diagnosis | |
| CN121532655A (en) | Methods, reagents, and kits for modulating immunoassay signals | |
| US11112414B2 (en) | Biomarker of rehospitalization after heart failure | |
| US20240361336A1 (en) | Newborn screening for congenital heart defect using cardiovascular biomarkers in dried blood samples | |
| EP3438669A1 (en) | Method for determining susceptibility to diabetes | |
| JP2015078842A (en) | Ischemic heart disease evaluation method, evaluation kit, and evaluation device | |
| WO2025036431A1 (en) | Myocardial damage assessment method, apparatus, sample analysis system and use thereof | |
| JP2007093312A (en) | Method for distinguishing acute aortic dissection with H-FABP and D-dimer and kit for differentiation | |
| Chien et al. | Comparison of the analytical performance for measurement of cardiac troponin I | |
| HK40106382A (en) | Highly sensitive immunoassay reagent and measurement method | |
| HK1119771B (en) | Devices and methods for diagnosing or predicting early stage cardiac dysfunctions |
Legal Events
| Date | Code | Title | Description |
|---|---|---|---|
| 121 | Ep: the epo has been informed by wipo that ep was designated in this application |
Ref document number: 24843850 Country of ref document: EP Kind code of ref document: A1 |
|
| WWE | Wipo information: entry into national phase |
Ref document number: AU2024292177 Country of ref document: AU |
|
| ENP | Entry into the national phase |
Ref document number: 2024292177 Country of ref document: AU Date of ref document: 20240716 Kind code of ref document: A |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 2024843850 Country of ref document: EP |
|
| NENP | Non-entry into the national phase |
Ref country code: DE |
