AN ENERGY-EFFICIENT FLIPDAC SWITCHING TECHNIQUE FOR

CAPACITIVE DAC IN SAR ADCs

TECHNICAL FIELD

Embodiments of the present disclosure relate to analog to digital converters (ADC). More particularly, the embodiments relate to switching of digital to analog converters (DAC) used in ADCs to reduce the power consumption. BACKGROUND

Presently, there has been a lot of interest in energy efficient digital to analog converters (DAC) switching techniques for capacitive DAC. It has been shown that the digitization of the input voltages involving more number of DOWN transitions than UP transitions are energy in-efficient. The power consumed or energy drawn from the reference voltage is more.

In one prior art, stepwise charging technique uses adiabatic charging of the capacitors by reducing effective voltage drop across the switch. It trade-offs conversion time with energy which can hamper the speed of the operation of the SAR analog to digital converters (ADC).

In another prior art, Vcm based switching is currently the most energy-efficient DAC switching scheme which is implemented on Silicon. But the DOWN transitions are still energy inefficient due to the large MSB capacitors connected to the reference. The change in the direction of the polarization of the capacitors adds to the energy inefficiency.

Also, known in the art is that ADCs are reconfigured resolution by switching out larger capacitors with the reduction in resolution. This saves power exponentially with the resolution, as power consumption was dominated by the CD AC, but increases layout- cum-logic complexity.

Hence, there is a need of a solution which can reduce the number of DOWN transitions and thereby reducing the power consumption of ADCs. Further, the solution needs to be energy efficient, simple and minimal hardware usage. SUMMARY

The shortcomings of the prior art are overcome and additional advantages are provided through the provision of methods and systems of the present disclosure.

The present disclosure solves limitations of existing techniques by providing energy efficient DAC switching technique which consumes less power. Additional features and advantages are realized through various techniques provided in the present disclosure. Other embodiments and aspects of the disclosure are described in detail herein and are considered as part of the claimed disclosure.

In one embodiment, the disclosure provides a system to optimise energy consumption in an analog to digital converter (ADC). The system comprises a reference buffer to provide predefined clean voltages to capacitor digital to analog convertor (CDAC). Also, the system comprises a capacitive digital to analog convertor (CDAC) to convert digital feedback data into analog to compare with the input and implement binary search technique. The CDAC includes plurality of capacitors arranged in a predetermined fashion. Further, the system comprises a comparator to compare the magnitude of CDAC voltage with a predefined input voltage and generate a decision. The system also includes successive approximation register (SAR) block to control capacitors of the capacitive DAC based on the comparator output, to flip DAC input voltages of the comparator based on the output magnitude of the comparator during second MSB (most-significant-bit) decision, thereby reducing the energy consumption of the ADC.

In another embodiment, the disclosure provides a method of optimising energy consumption in an analog to digital converter (ADC). The method comprising sampling input data signals using a sampling block for providing input to capacitor digital to analog convertor (CDAC). An analog data output is generated by the CDAC. Next, estimating magnitude of the output of the CDAC is performed using a comparator. The method also includes performing flip operation on the CDAC to interchange input voltages to comparator for reducing number of down transitions in the CDAC, thereby reducing the power consumption in the ADC. The foregoing summary is illustrative only and is not intended to be in any way limiting. In addition to the illustrative aspects, embodiments, and features described above, further aspects, embodiments, and features will become apparent by reference to the drawings and the following detailed description.

BRIEF DESCRIPTION OF THE ACCOMPANYING DRAWINGS

The novel features and characteristic of the disclosure are set forth in the appended claims. The embodiments of the disclosure itself, however, as well as a preferred mode of use, further objectives and advantages thereof, will best be understood by reference to the following detailed description of an illustrative embodiment when read in conjunction with the accompanying drawings. One or more embodiments are now described, by way of example only, with reference to the accompanying drawings wherein like reference numerals represent like elements and in which:

Fig. 1 shows a block diagram of the SAR ADC, in accordance with an embodiment; Fig. 2a shows a CDAC switching in a 3 bit ADC for conventional technique;

Fig. 2b shows a CDAC switching in a 3 bit ADC for FlipDac switching technique, , in accordance with an embodiment;

Fig. 3 illustrates FlipDac switching technique for a 4-bit SAR ADC and energy cost comparison for each step in the binary search tree, in accordance with an embodiment of the present disclosure;

Fig. 4 illustrates a timing diagram for FlipDac switching technique, in accordance with an embodiment;

Fig. 5 shows a comparison of CDAC switching energy for a 10 bit SAR ADC;

Fig. 6a shows sampling in SAR ADC for a traditional method or Traditional sampling;

Fig. 6b shows sampling in SAR ADC for ping-pong input sampling;

Fig. 7 shows architecture of ping-pong input sampling technique;

Fig. 8a shows an effective activity factor for a spike approximated as a triangular waveform;

Fig. 8b shows an effective activity factor for an important spike features that should be preserved; Fig. 9 shows schematic diagram of the preamplifier switch states 1 and 2 which are determined by Flip input to the preamplifier, in accordance with an embodiment;

Fig. 10 shows the Flip Logic by switching rails implementation, in accordance with an embodiment;

Fig. 11 shows an asynchronous logic Variable resolution is implemented using the MUX setting controlled by N2 - NO;

Fig. 12 shows timing diagram of depicting asynchronous operation;

Fig. 13 shows architecture of 8 bit CD AC with separate sub-DACs;

Fig. 14 shows architecture of VGA for even or odd numbered channel;

Fig. 15 shows OTA sharing between even and odd numbered channel;

Fig. 16 (a) shows measured SNDR Vs Fi_n for -1 dBFS input at 1 MS/s speed.;

Fig. 16 (b) shows 16384 point FFT of the ADC output for -1 dBFS input at F_in = 62.439

KHz;

Fig. 17 shows measured digital output of the activity dependent ADC, the X-axis and Y- axis represent the time in μβεΰ and the output code respectively; and

Figs. 18a and 18b show relative reduction in power consumption and ODR respectively.

The figures depict embodiments of the disclosure for purposes of illustration only. One skilled in the art will readily recognize from the following description that alternative embodiments of the structures and methods illustrated herein may be employed without departing from the principles of the disclosure described herein.

DETAILED DESCRIPTION The foregoing has broadly outlined the features and technical advantages of the present disclosure in order that the detailed description of the disclosure that follows may be better understood. Additional features and advantages of the disclosure will be described hereinafter which form the subject of the claims of the disclosure. It should be appreciated by those skilled in the art that the conception and specific embodiment disclosed may be readily utilized as a basis for modifying or designing other structures for carrying out the same purposes of the present disclosure. It should also be realized by those skilled in the art that such equivalent constructions do not depart from the spirit and scope of the disclosure as set forth in the appended claims. The novel features which are believed to be characteristic of the disclosure, both as to its organization and method of operation, together with further objects and advantages will be better understood from the following description when considered in connection with the accompanying figures. It is to be expressly understood, however, that each of the figures is provided for the purpose of illustration and description only and is not intended as a definition of the limits of the present disclosure.

Exemplary embodiments of the present disclosure provide system and method to optimize energy consumption in an analog to digital converter (ADC) One embodiment of the present disclosure is a system to optimise energy consumption in an analog to digital converter (ADC). The system comprises a reference buffer to provide predefined clean voltages to capacitor digital to analog convertor (CDAC). Also, the system comprises a capacitive digital to analog convertor (CDAC) to convert digital feedback data into analog to compare with the input and implement binary search technique. The CDAC includes plurality of capacitors arranged in a predetermined fashion. Further, the system comprises a comparator to compare the magnitude of CDAC voltage with a predefined input voltage and generate a decision. The system also includes successive approximation register (SAR) block to control capacitors of the capacitive DAC based on the comparator output, to flip DAC input voltages of the comparator based on the output magnitude of the comparator during second MSB (most-significant-bit) decision, thereby reducing the energy consumption of the ADC.

Another embodiment of the present disclosure is a method of optimising energy consumption in an analog to digital converter (ADC). The method comprising sampling input data signals using a sampling block for providing input to capacitor digital to analog convertor (CDAC). An analog data output is generated by the CDAC. Next, estimating magnitude of the output of the CDAC is performed using a comparator. The method also includes performing flip operation on the CDAC to interchange input voltages to comparator for reducing number of down transitions in the CDAC, thereby reducing the power consumption in the ADC.

Fig. 1 shows a block diagram of successive approximation register (SAR) ADC, in accordance with an embodiment of the present disclosure. Fully differential input and reference voltages are used. The reference DAC and sampling capacitors are segregated to gain advantages. An on-chip reference buffer is implemented to provide clean and stable voltage reference to the ADC. The V_cm rail is not buffered as ideally no charge is required from this rail owing to the symmetric switching scheme. A master clock of only half the sampling speed is used, saving power in clock buffers by 2X and reducing total system power. Spike threshold S_TH is calculated based on the background noise and is stored in registers. The dynamic range (DR) decides the resolution setting (N2-N0) of the ADC. An energy efficient switching technique FlipDac is used to make DAC power consumption very small.

FlipDac switching is an energy efficient DAC switching techniques for CDAC. The digitization of the input voltages involving more number of DOWN transitions than UP transitions is energy in-efficient. The extra work done by the reference in discharging the CDAC during DOWN transitions dominates the energy consumption. The energy drawn from the reference can be reduced if it is possible to resolve an input through fewer DOWN transitions. Even if the number of DOWN transitions is not smaller than that of UP transitions, the energy consumption can be reduced by pushing their occurrences towards the LSBs. Fig. 2a shows the switching technique for a 3-bit SAR ADC for Vip > Vin, in accordance with an embodiment of the present disclosure. The DOWN transition draws more energy from the reference compared to the UP transition. Fig. 2b presents the switching technique proposed by us for a 3 bit ADC. For the DOWN transition step, the energy drawn from the reference is 5X smaller than that in Fig. 2a. This is achieved by discouraging the reduction of individual CDAC voltage inputs to the comparator during the DOWN transition. The inputs Vip and Vin, are interchanged to preserve the comparator logic. The scheme is also overall 33 % more energy efficient than Fig. 2a.

Fig. 3 illustrates the switching scheme for a 4-bit ADC for Vip > Vin, in accordance with an embodiment. The second MSB capacitor (2C) is the replica of the remaining two LSB capacitors. First DOWN transition as shown in Fig. 3 illustrates FlipDac switching technique. The FlipDac step does not take any extra clock cycle and hence speed is not compromised. Fig. 4 shows the timing diagram for the FlipDac switching technique, in accordance with an embodiment. If b2 is detected as logic HIGH, VC2-VC3 as shown in Fig. 3, tracks Vip-Vin in the conventional way. However, if b2 is detected as logic LOW, Flip goes high and, VC2 and VC3 interchange their roles. The residual tracking of the input Vip-Vin is then carried out by VC3-VC2 which helps in reducing the number of times CDAC is discharged, especially during the MSBs. As shown in Fig. 4, output 1001 is resolved indirectly by tracking 1 1 10 by the CDAC. This results in fewer discharging steps than in the case when CDAC resolves 1001 directly.

In one embodiment, the flipping of the CDAC is performed only for the first DOWN transition by making use of the symmetric structure of the CDAC, for both UP and DOWN transitions, from this node. The splitting of (MSB-l)¹¹¹ capacitor helps in implementing binary search, after flipping, without incurring extra time and switching. The energy consumption during various steps for a 4-bit ADC is also compared with in Fig. 3. The number in the circle represents the total number of unit capacitors connected to Vref. The relative energy costs are shown on the arrows. The energy drawn from the reference for each UP (AVDAC > 0) and DOWN (AVDAC < 0) transitions may be calculated as:

EUP ⁼ (C_sw.(V_ref-V_cm)-(C_ref+C_sw).( AVDAc))-V_ref

EDOWN = ((C_ref - C_sw) · (AVoAcD- ref

where C_sw is the capacitance switched, C_ref is the total capacitance connected to

V_ref before this step, AV_DAC is the change in CDAC reference voltage in that step.

Fig. 5 illustrates a comparison of the energy drawn from the reference for each code in a 10 bit SAR ADC and FlipDac switching technique. The switching technique achieves minima at output code 51 1 and 512 compared to maxima in, which happens because code 51 1 and code 512 are resolved by tracking code 0 and code 1023 respectively, by the CDAC, which have no DOWN transitions. Table-I compares the FlipDac switching technique with the recent CDAC switching techniques or schemes for a 10 bit ADC which shows the savings achieved over them. This scheme necessitates the use of separate sampling capacitors which upon investigation is found favourable in reducing the power consumption.

Table-I DAC switching energy comparison for 10 bit SAR ADC Spec, [IB] [13] Hi is scheme

Energy (C.V «.) 142 255.5 1.70 106

Savin '1'7 £L is/

^■s 25,3 % 58.6 % .:·¾ -

One embodiment of the present disclosure is Ping-Pong input sampling Fig. 6a shows the timing diagram of a conventional 8 bit SAR ADC. Typically 2-3 clock cycles or equivalent delay (T_vga) is dedicated to the tracking of the input on the CD AC (C_DAC)- It is then followed by 8 bit-cycles for the digitization of the sample. It demands large bandwidth or current in the input buffer (VGA). The power consumption in the VGA may be reduced by giving more time for the input tracking but it contradicts with the design of the reference buffer in the sampling approach. In this ADC, ping-pong sampling technique is employed which relaxes the design of both VGA and the reference buffer.

In one embodiment, Figs. 7b and 8 illustrate the sampling technique used or employed in the ADC. In this technique, inputs are sampled on capacitors Ci_n0 and Cmi rather than C_DAC- There are two sets of sampling capacitors of which when one is tracking the input, the other is used in the digitization of the previous sample, which enables the use of the complete sample period TS as shown in the Fig. 6b, for the input tracking which relaxes the bandwidth requirement of the VGA stage. This also reduces the power consumption in the reference buffer as comparatively more time is available for bit cycling. The Ping-pong sampling in the ADC enables the use of two half rate clocks for even and odd-numbered channels. Also, the ping-pong sampling alleviates the clock requirement by 2X over asynchronous schemes employing clocks equal to that of the sampling rate which saves power in the clock buffers. One embodiment of the present disclosure is about power saving in VGA.

Considering, if T_vga = a_vga- TS, the N bit settling error may be given by the following equation,

Assuming output resistance R_eq = β/Ι₀ where β is a constant dependent on the architecture of the driver and I_D is the current consumed in the driver, _j i¥ - ln(2) . ^.:?,,;.» - Cp _A

Now for ping-pong input sampling a_vga = 1 ,

iV^■ ln{2) . /¾ - C_nA

Ts

The percentage power saving may be calculated as,

TV

Another embodiment of the present disclosure is power saving in reference buffer: Let T_ref = a_ref · Ts, the N bit settling error due to the reference buffer may be given as,

where C_eq is the equivalent capacitance seen by the reference buffer and 50 % of each bit cycle (T_ref /N) is given for CDAC settlin .

For ping-pong input sampling a_ref = 1 ,

The percentage power saving can be calculated as,

= ( 1 ^{^} <: ) 100% (8)

Therefore, an 8 bit ADC with 2 cycles given for sampling in the conventional approach, a_vga = 0.2 and a_ref = 0.8. Hence 80 % power can be saved in the VGA and 20% power can be saved in the reference buffer by using ping pong sampling technique. Actually, the power saving in the VGA is more as the sampling capacitors are much smaller than CDAC as shown in the Fig. 7. The drawback of this architecture is the use of extra sampling capacitors. But as the sizes of capacitors are determined by thermal noise and not matching the area penalty is not significant for moderate resolution ADCs. The architecture also requires good matching between two sampling paths for a single channel application and may need calibration. But no such requirement is imposed for multichannel input, as in NRS, where each channel either even or odd, traverses a fixed path every time. Also, this alleviates the concern of duty cycle distortion due to the half- rate clocking as even and odd numbered channels are sampled by two different non overlapping clocks.

One embodiment of the present disclosure is Activity dependent ADC. There is a great need to reduce the amount of data to be transmitted to enable chronic recording from a number of channels. The information in neural Extracellular Action Potential (EAP) is essentially encoded in the spike time-stamps but the amplitude information in the EAPs is also important for spike sorting purpose. Simple thresholding is found to be equally effective as other complex spike detection algorithms. However, representing a spike as a point event causes loss of information required for spike sorting as shown in Fig. 8b. For this reason, an activity dependent ADC technique or method or scheme is employed to obviate the processing of the background noise. The digitization process is only enabled when the input is found larger than the spike detection threshold S_TH which is shown in Fig. 2. The spike detection threshold S_TH is decided based on the magnitude of the background noise (σ_η), S_TH = k. σ_η where k = 3-4, so that the probability of the false detection of the noise as a spike is very small. The ADC is programmable to operate either in this mode or free running mode to transmit raw data.

Fig. 8a illustrates the activity dependent ADC technique. The spike is approximated as a triangular waveform with maximum amplitude A_max and spike duration T_spiu. The slope the spike as shown in the Fig. 8a is calculated as,

2.A»_R<._¾R k.o »

m — = 0)

Hence. x———— ^:

In one embodiment, if the total number of spikes in time T_exp is a— S_R- T_exp where S_R is the spike rate in spikes/sec, the effective time (T_eff ) for which the N bit ADC operates is given by,

The second term in the equation 10 indicates that the ADC operates only for one cycle for spike detection and is idle for remaining N bit cycles if the spike is not detected. The effective activity factor (EAF) of as N bit ADC working on activity based A/D scheme can be given by,

The equation 11 represents the effective time for which an activity dependent ADC may be working when compared to a free running ADC. Also, the equation represents the reduction in power consumption of the ADC and output data rate (ODR) of the system. As an example, the typical values of is 1msec and SR is 100 spikes/sec. Assuming Sx_H/A_max = 0.2, EAF for an 8 bit ADC can be calculated from Eqn. 11 as approximately 0.18 which saves 82 % energy and ODR over a free running ADC. The logic is in-built in the ADC and CDAC is reused for this purpose which obviates the use of separate DAC for each channel. The spike detection threshold (S_TH) can be increased to reduce EAF and to provide more immunity against the background noise but may cause loss of information. Hence the value of STH should be decided based spike sorter's requirement in addition to the background noise.

In one embodiment, the ADC is designed with reconfigurable resolution to mitigate unnecessary processing in case of smaller dynamic range. The previous state-of-the-art ADCs reconfigured resolution by switching out larger capacitors with the reduction in resolution which saves power exponentially with the resolution. As the power consumption was dominated by the CDAC, but increases layout-cum-logic complexity. However, the CDAC power consumption is very small compared to the digital switching power by using the FlipDac switching technique. Hence, the resolution is reduced by simply halting the binary search algorithm in-between based on the resolution requirement. It enables the resolution reconfiguration from 8 bit to 1 bit at 1 bit step. Thus, the technique of variable resolution saves power linearly with the resolution and is limited by the static power consumption in the ADC. In an embodiment a preamplifier is used before the clocked latch and the use of a preamplifier is preferred for offset and kickback noise mitigation. Kickback noise is an important concern due to the use of small sampling capacitors. The preamplifier in SAR ADC is subjected to step input only and needs to amplify the error just enough for the detection of the sign by the clocked latch, which relaxes the settling requirement in the preamplifier. If A_v(s) = A_v0/ (1 + s/p), for an input V_ln. u(t) and initial condition at output as Vo(O-), the output v₀ is, u (t } = A i i A?in ( I ----- e,xp{—u?pt}} ÷ ¥₀ (0 ----- } .rp{— _ρί) ( 1.2)

The second term in equation 12 may be eliminated by resetting output before enabling CDAC output. The output of the preamp, after a delay Tj from CDAC output is calculated and effective amplification A_v,_eff is given by,

= A_V&{1 ----- e p(--w_fi¾) (13)

Fig. 10 shows a schematic diagram of preamplifier. The input transistors for REFP and REFM inputs are interchangeable to implement the Flip logic. A partial positive feedback is used to reduce the effective output conductance. The load transistors are sized, such that W2 < Wl, to prevent the effective output conductance from becoming negative, even in the presence of any mismatch. If W2 = n.Wl, the dc voltage gain A_v0 and the bandwidth co_p, for a load capacitance C_L, may be calculated as:

By increasing η towards unity, more voltage gain may be achieved but it makes the preamplifier more sluggish. As an example, let η = 0.8 as a trade -off between voltage gain, speed and stability. The obtained results or values are A_v0 = 14 and ω_ρ = 8 MHz. One embodiment of the present disclosure is FlipDac switching technique. During the first DOWN transition, flipping of the C_DAC is done to save energy. However, it may lead to the interchanging of V_DAC_p and V_DAG_I inputs to the preamplifier, which is compensated internally in the preamplifier which is as shown in Fig. 10. For implementing the flip logic, reference rails in the CDAC are also interchanged as illustrated in the Fig. 10. Rails V and G are shorted together to V_cm input and V_cmi, V_cm2 rails is shorted to REFP or REFM based on the sign of the input. Fig. 11 illustrates asynchronous technique employed in CD AC. The timing diagram for the same is illustrated in Fig. 12. The individual bit cycling phases are generated once a decision is made by the comparator after STB and is detected by a NAND gate. A shift register of depth equal to 11 is used to progress a pulse, after each decision, to enable the extraction of the next bit, where the first flip-flop is asynchronously preset by SOC to start. Programmable delay line (PDL) is used to generate STB RST and STB PST signals to respectively reset and preset STB by introducing delays Dl and D2. The input HS controls PDL to modulate delays for operating at higher speed. Once the pulse reaches the final flip-flop the conversion halts until the next SOC. The position of the final flip- flop is decided based on the resolution requirement (N2 - NO) through a digital MUX. It implements variable resolution, without complicating the layout and logic, and prevents unnecessary conversion steps to happen. Two extra flip-flops are used to include the logic for STH which can be bypassed for the free running mode.

Fig. 13 shows the architecture of the 8 bit CDAC used in the ADC, as one embodiment. Separate sub-DACs for DOWN and UP transitions are used. As the linearity of a CDAC is determined by total capacitance switched, indifferent of its position, this structure does not compromise the linearity performance of the CDAC.

One embodiment is VGA and Reference Buffer of the VGA. The architecture of the VGA is shown in Fig. 14. VGA comprises of two stages VGAl and VGA2 in which VGAl may be put in sleep mode if detectable signal amplitude is large. Switch SI and S2 are selected based on the total gain requirement to fully traverse the ADC dynamic range. The architecture of the VGA block is illustrated in Fig. 15. The OTA is shared between the two sets of capacitors for employing ping-pong input sampling. The OTA is a two-stage trans-conductance amplifier which consumes about 3 μΑ driving 1 MS/s 8- bit SAR ADC. Any noise on the reference voltage will directly appear at the output of the ADC and will deteriorate its dynamic performance, especially in a SOC environment. Hence, an on-chip reference buffer is used. The OTA designed for the reference buffer is a two-stage trans-conductance amplifier consuming 4 μΑ and is load compensated.

Figs. 16a and 16b illustrate measured SNDR for different input frequencies. The ADC achieves a SNDR of about 48.1 dB for a near Nyquist input of 499.939 KHz which translates to ENOB of 7.7. The ADC consumes total power of 8.8 μW with VDD = 1 V. Based on parasitic extracted simulations, CDAC consumes only 0.4 μW and preamp consumes 1.5 μW which is approximately 5% and 17% of the total power consumption respectively. The power consumption is dominated by the digital switching approximately 78 %. As the power consumption is dominated by the digital switching, it reduces linearly with the decrease in the resolution.

Fig. 17 illustrates activity dependent A/D represents the measured output of the ADC working under activity dependent ADC method at 1 MS/s speed. The values of S_TH and EAF are shown in Fig. 17, where the first bit S is the sign bit. The ADC takes two extra cycles for the spike detection and purging of the CDAC. If S_TH is set as 0, the ADC behaves as a free running ADC and consumes 10.7 μW. Figs. 18(a) and 18(b) show the relative reduction in power consumption and ODR as a function of S_TH under different noise conditions. An experiment is conducted with the spike input to the ADC is approximated by a triangular waveform with noise. Based on the value of input noise σ_η, a proper value of S_TH may be found which reduces power consumption and ODR but preserves three important spike features of Fig. 8(b), i.e. A_max the maximum positive spike amplitude, A_mj_n the minimum negative spike amplitude and T_pp the time between A_max and A_m;_n.

In one embodiment, VGA can only be characterized at low frequencies of approximately 1 KHz, as it is not designed to drive large capacitance i.e. approximately 5pF at higher frequencies. The low frequency voltage gain matches the expected 8-35 dB. Table II shows the comparison of the VGA with two previous state-of-the-art NRSs and shows the advantage gained due to the bandwidth relaxation by the ping pong input sampling.

Table II Shows VGA comparison.

One embodiment of the present disclosure is a 8-to-l bit, 1 MS/s SAR ADC in UMC 0.13 μιη CMOS technology. Energy efficient DAC switching technique is used which consumes lowest power compared to the conventional techniques, without using extra capacitors or clock cycles. The DAC switching technique consumes about 37 % less energy than the present state-of-the-art techniques. For multichannel input, use of ping- pong input sampling is emphasized to save power in VGA and reference buffer. Also, the S AR ADC consumes lower power in clock buffers as we employ clock of half of the sampling speed. The resolution of the ADC can be varied based on the dynamic range required to avoid unnecessary processing and save power.

The FlipDac switching techniques makes energy consumption in the DAC which is approximately 5 %, that is negligible compared to digital switching energy which is approximately 78 %. The DAC switching technique will be more beneficial in higher resolution and higher speed SAR ADCs where the DAC switching energy is more comparable to the digital switching energy. The present disclosure is not to be limited in terms of the particular embodiments described in this application, which are intended as illustrations of various aspects. Many modifications and variations can be made without departing from its spirit and scope, as will be apparent to those skilled in the art. Functionally equivalent methods and apparatuses within the scope of the disclosure, in addition to those enumerated herein, will be apparent to those skilled in the art from the foregoing descriptions. Such modifications and variations are intended to fall within the scope of the appended claims. The present disclosure is to be limited only by the terms of the appended claims, along with the full scope of equivalents to which such claims are entitled. It is also to be understood that the terminology used herein is for the purpose of describing particular embodiments only, and is not intended to be limiting.

With respect to the use of substantially any plural and/or singular terms herein, those having skill in the art can translate from the plural to the singular and/or from the singular to the plural as is appropriate to the context and/or application. The various singular/plural permutations may be expressly set forth herein for sake of clarity.

In addition, where features or aspects of the disclosure are described in terms of Markush groups, those skilled in the art will recognize that the disclosure is also thereby described in terms of any individual member or subgroup of members of the Markush group.

While various aspects and embodiments have been disclosed herein, other aspects and embodiments will be apparent to those skilled in the art. The various aspects and embodiments disclosed herein are for purposes of illustration and are not intended to be limiting, with the true scope and spirit being indicated by the following claims.

Claims

We claim:

1. A system to optimise energy consumption in an analog to digital converter (ADC) comprising: reference buffer to provide predefined clean voltages to capacitor digital to analog converter (CDAC);

capacitive digital to analog converter (CDAC) to convert digital feedback data into analog to compare with the input and implement binary search technique, said CDAC comprises capacitors arranged in a predetermined fashion;

comparator to compare the magnitude of CDAC voltage with a predefined input voltage and generate a decision;

successive approximation register (SAR) block to control capacitors of the capacitive DAC based on the comparator output, to flip DAC input voltages of the comparator based on the output magnitude of the comparator during 2^nd (most- significant-bit) MSB decision, thereby reducing the energy consumption of the ADC.

2. The system as claimed in claim 1, wherein the SAR block flips the DAC input voltages of the comparator if the output magnitude is negative value during the 2^nd MSB.

3. The system as claimed in claim 1, wherein the CDAC comprises capacitors arranged in a symmetric structure to generate differential values as input to the comparator.

4. The system as claimed in claim 1, wherein the SAR block decreases number of down transitions of the CDAC to reduce power consumption of the ADC.

5. The system as claimed in claim 1, wherein the comparator is connected to a latch to store the output data of the comparator.

6. The system as claimed in claim 1, wherein a master clock is used in the ADC to trigger all blocks with half the sampling frequency to reduce power consumption.

7. A method of optimising energy consumption in an analog to digital converter (ADC) comprising: sampling inputs data signal using a sampling block for providing input to capacitor digital to analog converter (CDAC), wherein analog data output is generated by the CDAC;

estimating magnitude of the output of the CDAC using a comparator;

performing flip operation on the CDAC to interchange input voltages to comparator to reduce number of down transitions in the CDAC, thereby reducing the power consumption in the ADC.

8. The method as claimed in claim 7, wherein the flipping operation in CDAC is performed using successive approximation register (SAR) logic block.

9. The method as claimed in claim 7, wherein a master clock is used in the ADC to trigger all blocks with half the sampling frequency to reduce power consumption.

10. The method as claimed in claim 7 or 8, wherein SAR block decreases down transition of the CDAC to reduce power consumption of the ADC.
