Abstract

In a MIMO/MISO system, either: WiMAX, UMTS/WCDMA/EDGE. GSM/GPRS/EDGE, or the like, the CSI (Channel State Information) is quantized dynamically by the receiver and sent back to a transmitter which performs spatial multiplexing or beamforming. The receiver at discrete time t + 1 is controlled to:
- estimate a codeword F _t+1 according to any suitable optimization method;
- index the codeword F _t+1 into a reduced codebook Δ(F _t ) belonging to a larger codebook Φ ;
- transmit on the backward channel the state information corresponding to the index of F _t+1 spanning the reduced codebook Δ(F _t );
- calculate a reduced codebook Δ(F _t+1) including 2^bδ orthogonal codewords of Φ according to the following expression: $$\mathrm{\Delta }\left({\mathbf{F}}_{t+1}\right)=\left\{{\mathbf{F}}_i\right\}\in \mathrm{\Phi }:\underset{{\mathbf{F}}_i\in \mathrm{\Delta }\left({\mathbf{F}}_{t+1}\right)}{\max }\left(d\left({\mathbf{F}}_i,{\mathbf{F}}_{t+1}\right)\right)<\underset{{\mathbf{F}}_j\in \mathrm{\Delta }\left({\mathbf{F}}_{i+1}\right)}{\min }\left(d\left({\mathbf{F}}_j,{\mathbf{F}}_{t+1}\right)\right),$$

where i, j are generic index spanning the elements of codebook Φ, and d (□) is the chordal distance from F _t+1:
and the transmitter at discrete time t + 1 is controlled to:
- receive on the backward channel said index of F _t+1 and use it for retrieving F _t+1 from the reduced codebook Δ(F _t ) calculated by the transmitter at discrete time t ;
- multiply the actual sample of the baseband transmission signal by the codeword F _t+1 and transmit the product on the forward channel;
- calculate a reduced codebook Δ(F _t+1) according to the same expression used by the receiver (fig.2).

Description

FIELD OF THE INVENTION
• The present invention relates to the field of wireless communication networks, and in particular to a reduced feedback dynamic codebook transmission method for multi-antenna systems. (Used acronyms description and bibliographic references are given at the end of the description).
  The invention can be used indifferently in standard and non-standard cellular networks, but some advantages are obviously derived from its possible use in wireless networks conforming with different standards, for example:
• 3GPP GSM and related GPRS, EDGE.
• 3GPP UMTS: WCDMA, FDD/TDD-CDMA, HSDPA, HSUPA, LTE.
• CDMA2000, PCS, UMB, Ambient Networks (AN).
• IEEE std 802.16-2004: "IEEE Computer Society and IEEE Microwave Theory and Techniques Society, "IEEE Standard for Local and Metropolitan Area Networks Part 16: Air Interface for Fixed Broadband Wireless Access Systems", IEEE Std 802.16-2004 (Revision of IEEE Std 802.16-2001), 1 October 2004",
as amended by :
• IEEE 802.16e-2005: "IEEE Computer Society and IEEE Microwave Theory and Techniques Society, "IEEE Standard for Local and Metropolitan Area Networks Part 16: Air Interface for Fixed Broadband Wireless Access Systems", Amendment 2: Physical and Medium Access Control Layers for Combined Fixed and Mobile Operation in Licensed Bands and Corrigendum 1; 28 February 2006"; (see entries: 8.4.8.3.6 and 8.4.5.4.10.1 to 8.4.5.4.10.15).
• IEEE std 802.16-2004/Cor2/2/D4 - Ref.[9]: "Draft standard for local and metropolitan area networks. Part 16 : Air Interface for Fixed and Mobile Broadband Wireless access Systems Corrigendum 2", May 2007. (see Ref.[9]).
• Another useful text for WiMAX is: "WiMAX Forum^™ Mobile System Profile - Release 1.0 Approved Specification - (Revision 1.4.0: 2007-05-02)"; (see Tables 69 and 70).
BACKGROUND ART
• Closed loop schemes are regarded as an appealing technique for MIMO wireless systems, as they improve the reliability and throughput performance by adapting the spatial precoder according to channel conditions (informed transmitter) in bibliographic Reference [1].
  Fig.1 shows the general diagram of a discrete-time transmit beamforming MISO system with limited feedback by the receiver RX to the transmitter TX, as disclosed in Ref.[7]. The depicted structure is very general and is compliant with a lot of spatial multiplexing algorithms. This structure can also be extended to a MIMO system. With reference to fig.1 , a Base Station (BS) 1 transmits, with N = 2 antennas, N = 2 signals relevant to the same user at a discrete time interval n corresponding to the symbol time T_s of a sample of the continuous signal. Each baseband signal is weighted (precoded) by an its own complex weight w_n (precode) calculated by a processor block 2 (Beamforming Vector Generator) of BS 1. The complex weights w _n is a vector that spans a codebook H stored in both TX and RX.
  The N = 2 streams are transmitted on the radio channel downlink to a Mobile Station 3, which receives both streams with a single antenna. The Mobile 3 evaluates the downlink channel h _n (a vector that collects all samples of the MISO pulse response) convoluted with the weight vector w _n , which constitutes the Channel State Information (CSI), by any suitable optimization algorithm (e.g. ML) aimed to improve the quality of the reception at the Mobile 3 upon the knowledge of pilot tones. The CSI is forwarded to a Quantizer 4, which compresses it according to a quantization algorithm (briefly discussed soon) assuming that Mobile 3 has perfect knowledge of the forward channel (DL), and slow-rate feedback channel is considered as free of errors and delays. The CSI Quantizer 4 maps the normalized channel vector u _n = h _n /∥h _n ∥ (named the channel shape) onto a member of the codebook H and outputs its index J_n (the CSI) to the input of a cascaded block 5. The latter, according to an aperiodic feedback scheme, initiates a feedback of the index whenever the CSI changes (J_n ≠ J _n-1). The quantized index J_n is fed back with lesser band consuming constraint than in absence of compression. At the transmission side the Beamforming Vector Generator 2 receives the quantized index J_n from the feedback channel and uses it to address a new set of weights {w _n+1} at time n + 1 of the codebook H seen as a look-up table.
  In Ref.[7] presently described, similarly to Ref.[5], Ref.[6], and Ref.[8] some temporal correlations in fading channel have been exploited for feedback reduction. In Ref.[5] a tracking procedure for the channel subspace based on binary feedback has been considered. In Ref.[6], Ref.[7] and Ref.[8] the time-varying quantized channel is modelled as a Markov process and feedback reduction is achieved by dropping low probability transitions. The probability of each transition is obtained by statistical training of the Markov process. Turning the attention to Ref.[7], the CSI Quantizer 4 maps the states of the channel-state Markov chain one-to-one to the members of the codebook H. This mapping also exists between the codebook members and the quantized values of the channel shape u _n . The codebook H is designed by partitioning the channel shape space (unit hyper sphere) into N regions, called Voronoi cells in the specialized literature. Compared with the case of no feedback compression, the feedback compression method based on dropping low probability transitions incurs the additional costs of storing additional tables defining the ε-neighbourhood of the Markov state i as: $${\mathrm{N}}_{\epsilon }\left(i\right)=\left\{1\le j\le N|P_{i,j}\ge \epsilon \right\},i=1,\cdots ,N$$




  where ε> 0 is a small positive number.
• A lot of other techniques for an efficient design of the feedback channel have been proposed in the literature in case of, e.g., beamforming Ref.[2], and spatial multiplexing Ref.[3], and Ref.[4]. However, most of these schemes are pessimistic as they assume block fading channels and thus neglect temporal channel correlation in the feedback protocol design.
OBJECT OF THE INVENTION
• In view of the state of the art described, it is an object of the present invention to provide a CSI reporting technique with reduced-bitrate which exploits the temporal correlation of the fading channel without any training of the channel model and any storage for additional tables are requested, in order to be more prone to practical implementation in wireless systems.
SUMMARY AND ADVANTAGES OF THE INVENTION
• The invention achieves said object by providing a method for quantizing dynamically the state information of a forward transmission channel sent back by a receiver to a transmitter equipped with n_t antennas for transmitting n_s streams on the forward channel according to a spatial multiplexing or beamforming scheme, the method including the following steps executed by the receiver at discrete time t+1:
• estimating a codeword F _t+1 according to any suitable optimization method;
• indexing the codeword F _t+1 into a reduced codebook Δ(F _t ) belonging to a larger codebook Φ;
• transmitting on the backward channel the state information corresponding to the index of F _t+1 spanning the reduced codebook Δ(F _t );
• calculating a reduced codebook Δ(F _t+1) including 2 ^bδ orthogonal codewords of Φ according to the following expression:
• $$\mathrm{\Delta }\left({\mathbf{F}}_{t+1}\right)=\left\{{\mathbf{F}}_i\right\}\in \mathrm{\Phi }:\underset{{\mathbf{F}}_i\in \mathrm{\Delta }\left({\mathbf{F}}_{t+1}\right)}{\max }\left(d\left({\mathbf{F}}_i{\mathbf{F}}_{t+1}\right)\right)<\underset{{\mathbf{F}}_j\notin \mathrm{\Delta }\left({\mathbf{F}}_{t+1}\right)}{\min }\left(d\left({\mathbf{F}}_j{\mathbf{F}}_{t+1}\right)\right),$$

where i, j are generic index spanning the elements of codebook Φ, and d(□) is the chordal distance from F _t+1:
and the following steps executed by the transmitter at discrete time t+1:
• receiving on the backward channel said index of F _t+1 and using it for retrieving F _t+1 from the reduced codebook Δ(F _t ) calculated by the transmitter at discrete time t ;
• multiplying the actual sample of the baseband transmission signal by the codeword F _t+1 and transmitting the product on the forward channel;
• calculating a reduced codebook Δ(F _t+1) according to the same expression used by the receiver, as disclosed in claim 1.
• The step of indexing the codeword F _t+1 spanning Δ(F _t ) at the receiver is driven by one-to-one associations between the 2 ^bd configurations of b _δ bits and the 2 ^bd codewords of Δ(F _t ), said associations map the reduced address space of Δ(F _t ) onto the larger address space of codebook Φ seen as a look-up table. The same one-to-one associations are assumed at the transmitter for de-indexing or demapping.
• The method of above is valid for MIMO and MISO systems, indifferently.
• Additional features of the present invention which are believed to be novel are set forth with particularity in the dependent claims.
• We remark that:
• The codeword F _t ∈□ ^{n_t ×n_s} is a n_t × n_s precoding matrix (or a n_t vector in case of beamforming), where □ ^{n_t ×n_s} is a complex vector space.
• The codebook Φ includes n_w = n_t × n_s codewords (also termed precoders).
• The reduced codebook Δ(F _t ) contains n _δ ≤ n_w codewords that can be indexed with b_δ = ┌log₂ n_δ ┐⁺ ≤ b bits, where ┌ ┐⁺ indicates the approximation to the nearest higher integer.
• The chordal distance $d\left({\mathbf{F}}_i{\mathbf{F}}_t\right)\equiv \sin \left({\vartheta }_{\mathit{ij}}\right)=\frac{1}{\sqrt{2}}{\Vert {\mathbf{F}}_i{{\mathbf{F}}_t}^H-{\mathbf{F}}_t{{\mathbf{F}}_t}^H\Vert }_F$

  tunes the ability of the system to track fast channel fluctuations and in the meanwhile allows feedback load reduction.
In conclusion, the main idea of the invention is that for highly correlated channels the precoder F _t+1 at time t+1 lies in a neighbourhood of precoder F _t at time t. Therefore, quantization of F _t+1 can be efficiently narrowed to the neighbourhood of F _t .
• Especially for MISO systems, the reduced codebook Δ(F _t ) can be modelled as a ball of radius δ centred around F _t and the chordal distance is the radius δ itself. In such a case the step of estimating the radius δ is performed by solving the following expression:



  where:
•
  (F _t ,δ) is the aforementioned n_t -dimensional ball centred on F _t ,
• G _i is an n_t ×n_s unitary matrix belonging to an Ω(n_t ,n_s ) vector space encompassing all n_t × n_s unitary matrices definable on the codebook Φ,
• V(G _i ) is a quantization (Voronoi) region associated to the i_th codeword G _i ∈Φ. Partition of a Codebook into adjacent Voronoi regions is a known concept.
  In the next description the radius δ will be calculated in closed form; alternatively, an upper bound will be provided.
  Profitably:
• The method of the invention is independent of the role that a transmitting/receiving entity plays in the network, since either the Base Station (BS) or the Mobile Station (MS) could play the role of transmitting entity on the forward channel, with the only constraint that the MS be able to transmit with n_t antennas.
• The method of the invention is independent of the number of transmitting antennas, and either a single or multiple antenna is possible at the receiver which estimates the CSI.
• The method of the invention is independent of the type of adopted spatial multiplexing scheme; for example, according to a beamforming scheme with n_s =1, only one stream is transmitted by every antenna.
• Differently from literature, the method does not require any training of the channel model and is therefore more prone to practical implementation in wireless systems.
• Furthermore, no specific assumptions about channel statistics and codebook properties have been taken.
• With correlated time-varying channels the method allows a reduction of the feedback load with negligible loss of performance.
• According to a variant of the invention, the number b_δ of bits used to express the cardinality of Δ(F _t ) (or the value of radius δ), instead of being evaluated at each time slot, is assumed in suboptimal way as being lower than, or equal to, the bitrate currently available on the backward channel multiplied by the symbol time of the modulated transmission signal. The available bitrate can be communicated by the transmitting entity to the receiving entity each time it is changed, but this event happens at very slow time-interval in respect of symbol-time, so that the traffic of payload on the forward channel is not affected by these types of dedicated messages, significantly. The variant prevents the estimation of radius δ analytically but it is less reliable in the fast tracking of channel fading.
BRIEF DESCRIPTION OF THE DRAWINGS
• The features of the present invention which are considered to be novel are set forth with particularity in the appended claims. The invention and its advantages may be understood with reference to the following detailed description of an embodiment thereof taken in conjunction with the accompanying drawings given for purely non-limiting explanatory purposes and wherein:
• fig.1 shows the general diagram of a beamforming system with limited feedback operating according to a method of the known art;
• fig.2 shows the general diagram of a beamforming system with limited feedback operating according to the method of the present invention;
• figg.3 and 4 show some vectorial representations referred to the quantization regions and correlated channel useful to understand the method of the invention;
• fig.5 shows a double family of comparative curves between simulated CCDF and an approximate closed form expression use in the calculation, encompassing different normalized Doppler frequency values taken as a variable parameter;
• figg.6, 7 and 8 show different sets of curves reporting the numerical results of some comparative simulations between the quantization of the CSI according to known method and the method of the invention.
DETAILED DESCRIPTION OF SOME EMBODIMENTS OF THE INVENTION
• In fig.1 we see a closed loop MIMO wireless system consisting of a transmitter 6 equipped with n_t transmit antennas and a receiver 7 equipped with n_r receive antennas on the forward link. The forward channel H _t at time slot t is modelled as a Rayleigh distributed n_r × n_t matrix having i.i.d. entries:



  and is arbitrarily correlated among different time slots. The receiver 7 is connected to the transmitter 6 through a reverse channel for user traffic (not shown) and through an additional low-rate (in-band) feedback channel. Without losing of generality, the feedback channel is supposed zero-delay and ideal. The transmitter 6 has n_t inputs for a vector s _t ∈□ ^{n_s ×1} that contains the modulated symbols for each independent data stream such that $E\left[{\mathbf{s}}_t{\mathbf{s}}_t^H\right]={\mathbf{I}}_{n_s}\mathrm{.}$


• The transmitter 6 multiplexes n_s ≤ min{n_r , n_t } streams during every time slot t of the wireless channel by spatial multiplexing, see Ref.[1] or even IEEE 802.16e-2005, entry 8.4.8.3.6 (MIMO precoding matrix W). This includes beamforming by trivially setting n_s = 1. The system transfer function at time slot t on the forward link is modelled as: $${\mathbf{y}}_t={\mathbf{H}}_t{\mathbf{F}}_t{\mathbf{s}}_t+{\mathbf{n}}_t\mathrm{.}$$


• Here y _t ∈□ ^{n_r ×1} is the received signal, n _t ∼CN(0 _{nr ×1},σ² I _nr ) is the Gaussian i.i.d. additive noise and F _t ∈□ ^{n_t ×n_s} is the precoding matrix (or vector in case of beamforming). According to current assumptions in wireless standard Ref.[9], the energy is equally split among the n_s orthogonal streams (F _t ^H F _t = I _ns ) such that F _t spans n_s dimensions over the n_t dimensional space.
• The precoder F _t is dynamically adapted to channel conditions at time t+1 according to quantized CSI conveyed by the receiver 7 to transmitter 6 on the feedback channel (supposed ideal with zero-delay). In detail, at each time slot t+1 the following operations are executed:
1. 1. the receiver 7, according to any suitable optimization criterion known in the art, e.g. ML, chooses the optimal precoder F _t+1 from a subset Δ(F _t ) of a pre-defined codebook Φ including n_w codewords (precoders);
2. 2. the receiver feeds back on the low-rate channel the index of precoder F _t+1 spanning the reduced codebook Δ(F _t );
3. 3. the receiver calculates a reduced codebook Δ(F _t+1) including 2 ^bδ orthogonal codewords of Φ, according to the following expression: $$\mathrm{\Delta }\left({\mathbf{F}}_{t+1}\right)=\left\{{\mathbf{F}}_i\right\}\in \mathrm{\Phi }:\underset{{\mathbf{F}}_i\in \mathrm{\Delta }\left({\mathbf{F}}_{t+1}\right)}{\max }\left(d\left({\mathbf{F}}_i{\mathbf{F}}_{t+1}\right)\right)<\underset{{\mathbf{F}}_j\notin \mathrm{\Delta }\left({\mathbf{F}}_{t+1}\right)}{\min }\left(d\left({\mathbf{F}}_j{\mathbf{F}}_{t+1}\right)\right),$$


   where i, j are generic index spanning the elements of codebook Φ, and d(F _i , F _t+1) is the chordal distance from F _t+1;
4. 4. the transmitter receives the quantized index and uses it to retrieve the precoder F _t+1 from subset Δ(F _t ) in correspondence of that index;
5. 5. the transmitter multiply the actual baseband sample by precoder F _t+1 and transmit the product;
6. 6. The transmitter calculate a reduced codebook Δ(F _t+1) as done in the receiver.
• Some definitions are introduced here to give support to the reduced codebook determination:
• Let Ω(n_t,n_s ) be the set of all n_t ×n_s unitary matrices. The chordal distance between two subspaces generating unitary matrices G _i ∈Ω(n_t ,n_s ) and G _j ∈Ω(n_t ,n_s ) (i.e., matrices whose columns spaces span n_s dimensions over the available n_t dimensions) is defined as: $$d\left({\mathbf{G}}_i{\mathbf{G}}_j\right)\equiv \sin \left({\vartheta }_{\mathit{ij}}\right)=\frac{1}{2}{\Vert {\mathbf{G}}_i{{\mathbf{G}\begin{array}{c}\mathit{H}\\ \mathit{i}\end{array}-{\mathbf{G}}_j\mathbf{G}\begin{array}{c}\mathit{H}\\ \mathit{i}\end{array}{\Vert }_{\mathit{F}},}_{}}^{}}_{}$$


  where ϑ _i,j ∈[0,π/2] is the angle between G _i and G _j , and ∥□∥ _F is the Frobenius norm.
• The quantization (Voronoi) region associated to the i_th codeword G _¡ ∈Φ is defined as $$V\left({\mathbf{G}}_i\right)=\left\{\left\{\mathbf{X}\right\}\in \mathrm{\Omega }\left(n_t{n}_s\right):d\left({\mathbf{G}}_i\mathbf{X}\right)<d\left({\mathbf{G}}_j\mathbf{X}\right)\forall j\ne i\right\},$$

• A ball B(G _i ,δ) of radius δ centred on G _¡ ∈Ω(n_t ,n_s ) is defined as the subset of all matrices belonging to Ω(n_t ,n_s ) within a given distance δ from G _j , Ref.[2]:

  It is now better understandable the analytic expression:

  given before for the reduced codebook with spherical constraint.
Mathematical evaluation of CSI quantization
• In the successive description the nearly-optimal feedback load is evaluated for the closed loop system based on a feedback reduction procedure as said above. A nearly optimal value for distance δ to be used in (6) is evaluated according to the temporal channel correlation. A closed-form upper bound on the corresponding feedback load is obtained by estimating the average cardinality of Δ(F _t ,δ).
• For simplicity, in the following a MISO system employing Maximum Ratio Transmission (MRT) is considered such that the unquantized (n_t ×1) precoder at time t is ${\bar{\mathbf{h}}}_t={{\mathbf{h}\begin{array}{c}\mathit{H}\\ \mathit{t}\end{array}/\Vert {\mathbf{h}}_t\Vert \mathrm{.}}_{}}^{}$



  . It is assumed that h _t is mapped on F _t ∈Φ as: $${\mathbf{F}}_t=\left\{{\mathbf{G}}_i\in \mathrm{\Phi }:d\left({\mathbf{G}}_i{\bar{\mathbf{h}}}_t\right)<d\left({\mathbf{G}}_j{\bar{\mathbf{h}}}_t\right)\forall {\mathbf{G}}_j\in \mathrm{\Phi },j\ne i\right\}$$


• The optimal reduced codebook Δ(F _t ) is defined as:



  such that: $$\mathrm{Pr}\left({\mathbf{F}}_{t+1}\notin \mathrm{\Delta }\left({\mathbf{F}}_{\mathrm{<figure-callout\; id="0"\; label="t\; \; \delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">t</figure-callout>}}{\delta }_{}{}_0\right)\right)=\epsilon$$




  where ε is an arbitrary threshold (0 ≤ ε ≤ 1). According to (8), δ ₀ is the minimum distance such that the probability that the precoder F _t+1 at time t+1 lies outside a ball of radius δ ₀ centered on F _t is ε. Condition (9) can be equivalently expressed as: $$\mathrm{Pr}\left(d\left({\mathbf{F}}_t,{\bar{\mathbf{h}}}_{t+1}\right)\ge {\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0\right)=\epsilon \mathrm{.}$$


• The analytical solution of (10) is not practical as it is based on specific assumptions on the shape of the Voronoi region V(F _t ). Therefore, in the following a general upper bound on δ₀ is derived by avoiding any assumption on the Voronoi region shape. With reference to fig.3 , it can be shown that: $$d\left({\mathbf{F}}_t{\bar{\mathbf{h}}}_{t+1}\right)\le d\left({\mathbf{F}}_t{\bar{\mathbf{h}}}_t\right)+d\left({\bar{\mathbf{h}}}_t{\bar{\mathbf{h}}}_{t+1}\right)\le d_m+d\left({\bar{\mathbf{h}}}_t{\bar{\mathbf{h}}}_{t+1}\right)$$



  where d _m is the maximum quantization error distance for any Voronoi region of codebook Φ: $$d_m=\left\{\min \left(\mathit{\lambda }\right):\mathit{\lambda }\ge d\left({\mathbf{G}}_j\mathbf{x}\right),\forall \mathbf{x}\in V\left({\mathbf{G}}_j\right),\forall {\mathbf{G}}_j\in \mathrm{\Phi }\right\}\mathrm{.}$$


• The maximum quantization error length d _m is a specific property of the codebook and has to be evaluated numerically. However, in case Φ is the optimal codebook based on Grassmannian manifold Ref.[10], a simple tight bound on d _m is given by the following Rankin bound given in Ref.[11]: $$d_{\mathrm{m}}\le \sqrt{\frac{\left(n_t-1\right)n_w}{n_t\left(n_w-1\right)}}$$



  According to (11) and (10), the following relationship holds for any ${\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0^{ʹ}\ge d_m:$



  $$\mathrm{Pr}\left(d\left({\bar{\mathbf{h}}}_t,{\bar{\mathbf{h}}}_{t+1}\right)\ge {\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0^{ʹ}-d_m\right)=\mathrm{Pr}\left(d\left({\bar{\mathbf{h}}}_t,{\bar{\mathbf{h}}}_{t+1}\right)+d_m\ge {\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0^{ʹ}\right)$$



  $$\to \mathrm{Pr}\left(d\left({\mathbf{F}}_t,{\bar{\mathbf{h}}}_{t+1}\right)\ge {\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0^{ʹ}\right)\le \epsilon$$



  Eq. (15) shows that an upper bound ${\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0^{ʹ}\ge {\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0$



  to be used for the optimization of (6) is obtained by solving the (14) for ${\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0^{ʹ}:$



  $${\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0^{ʹ}=\left\{\mathit{\lambda }:\mathrm{Pr}\left(d\left({\bar{\mathbf{h}}}_t,{\bar{\mathbf{h}}}_{t+1}\right)\ge \mathit{\lambda }-d_m\right)=\epsilon \right\}={\bar{F}}_{d\left({\bar{\mathbf{h}}}_t,{\bar{\mathbf{h}}}_{t+1}\right)}^{-1}\left(\epsilon \right),$$



  where ${\bar{F}}_{d\left({\bar{\mathbf{h}}}_t,{\bar{\mathbf{h}}}_{t+1}\right)}^{-1}\left(\begin{array}{|c|}\hline \\ \hline\end{array}\right)$



  is the inverse of the CCDF (Complementary CDF) of d ( h _t , h _t+1). The following is the analytical expression of a closed form for F _{d( h t, h t+1)}(□) to be used in (16), that will be derived later in the description: $${\bar{F}}_{d\left({\bar{\mathbf{h}}}_t,{\bar{\mathbf{h}}}_{t+1}\right)}\left(\delta \right)\equiv \mathrm{Pr}\left(d\left({\bar{\mathbf{h}}}_t,{\bar{\mathbf{h}}}_{t+1}\right)>\delta \right)=\frac{\left(2n_t-2\right)!}{\mathrm{\Gamma }\left(n_t\right)\mathrm{\Gamma }\left(n_t-1\right)}{\displaystyle \sum _{k=0}^{n_t-2}}{\left(-1\right)}^k\left(\begin{array}{c}{n}_t-2\\ k\end{array}\right)\frac{{\left(\frac{{\tan }^2\delta }{1-{\left|\mathrm{<figure-callout\; id="2"\; label="\rho "\; filenames="imgf0001.png"\; state="\{\{state\}\}">\rho </figure-callout>}\right|}^2}+1\right)}^{-n_t-k}}{n_t+k}$$


• A closed-form upper bound on the reduced codebook $\mathrm{\Delta }\left({\mathbf{F}}_{\mathrm{<figure-callout\; id="0"\; label="t\; \; \delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">t</figure-callout>}}{\delta }_{}^{}{}_0^{ʹ}\right)$



  size is derived in the following according to the optimal reduced codebook (8) and the approximate quantization ball radius ${\delta }_{}^{}$ ${}_0^{ʹ}$



  given by (16). By recalling that d(F _i , h ¡)≤d_m it holds (see fig.3 for visual reference): $$d\left({\mathbf{F}}_t{\mathbf{F}}_{t+1}\right)\le d\left({\mathbf{F}}_t{\bar{\mathbf{h}}}_t\right)+d\left({\bar{\mathbf{h}}}_t{\bar{\mathbf{h}}}_{t+1}\right)+d\left({\bar{\mathbf{h}}}_{t+1}{\mathbf{F}}_{t+1}\right)$$



  $$d\left({\mathbf{F}}_t{\mathbf{F}}_{t+1}\right)\le 2d_m+d\left({\bar{\mathbf{h}}}_t{\bar{\mathbf{h}}}_{t+1}\right)={\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0^{ʹ}+d_m,$$




  where (11) has been plugged into (18) in the last passage.
• Let A(F _i ,δ) be the surface on the n_t -dimensional unit sphere that is included in ball of radius δ centered in F _i . It is shown in Ref.[2] that the ratio between A(F _i ,δ) and the total surface of the unit sphere is: $$\frac{A\left({\mathbf{F}}_i\delta \right)}{A_{\mathit{tot}}}={\mathrm{<figure-callout\; id="2"\; label="\delta "\; filenames="imgf0001.png"\; state="\{\{state\}\}">\delta </figure-callout>}}^{2\left(n_t-1\right)}\mathrm{.}$$


• Assuming that the codewords are uniformly distributed on the unit sphere, the average number of codewords covered by A(F _i ,δ) is: $$\left|\mathrm{\Delta }\left({\mathbf{F}}_i\delta \right)\right|={\mathrm{<figure-callout\; id="2"\; label="\delta "\; filenames="imgf0001.png"\; state="\{\{state\}\}">\delta </figure-callout>}}^{2\left(n_t-1\right)}{n}_w,$$




  where |Δ(F _t ,δ)| is the cardinality of the reduced codebook. Therefore, an upper bound on the codebook (8) size is: $$\left|\mathrm{\Delta }\left({\mathbf{F}}_i\delta \right)\right|\le {\left({\delta }_0^{ʹ}+2{\mathrm{<figure-callout\; id="2"\; label="d\; m"\; filenames="imgf0001.png"\; state="\{\{state\}\}">d</figure-callout>}}_m\right)}^{2\left(n_t-1\right)}{n}_w,$$




  where ${\mathrm{<figure-callout\; id="0"\; label="\delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">\delta </figure-callout>}}_0^{ʹ}$



  is the upper bound on δ₀ in (8) given by (16). As a general rule bounds (16) and (21) are tight for d_m → 0 , i.e., when the granularity of quantization regions is low. On the other hand, bound (22) may be loose for moderately dense codebooks and a tighter approximation is given by: $$\left|\mathrm{\Delta }\left({\mathbf{F}}_i\delta \right)\right|\le {\left({\delta }_0^{ʹ}+2\bar{\delta }\right)}^{2\left(n_t-1\right)}{n}_w,$$




  where δ is the average quantization error length.
• Here a closed form expression for Pr(d( h _t , h _t+1)>δ)≡ F _{d( h t, h t+1)}(δ) to be numerically inverted and plugged into (16) is derived. The time-varying MISO channel is modeled as an autoregressive AR(1) process commonly accepted as wireless channel model: $${\mathbf{h}}_{t+1}=\rho {\mathbf{h}}_t+{\mathbf{w}}_{t+1},$$




  where



  is the Gaussian innovation and ρ ∈



  is the correlation factor (0 ≤ ρ≤1). Assuming Clarke's channel model, ρ is related to the normalized channel Doppler frequency as: $$\rho ={\mathrm{<figure-callout\; id="0"\; label="J"\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">J</figure-callout>}}_0\left(2\mathit{\pi \psi }\right),$$



  where J ₀ is the even Bessel function of zero order.
• With reference to fig.4 , let ${\mathbf{w}}_{t+1}^{|\Vert }$



  be the projection of w _t+1 on h _t and let ${\mathbf{w}}_{t+1}^{\perp }$



  be the projection of w _t+1 on the null space of h _t : $${\mathbf{w}}_{t+1}^{\left|\right|}=\left({\mathbf{h}}_t^H{\mathbf{h}}_t/{\mathbf{h}}_t{\mathbf{h}}_t^H\right){\mathbf{w}}_{t+1}$$



  $${\mathbf{w}}_{t+1}^{\perp }=\left(\mathbf{I}-{\mathbf{h}}_t^H{\mathbf{h}}_t/{\mathbf{h}}_t{\mathbf{h}}_t^H\right){\mathbf{w}}_{t+1}\mathrm{.}$$



  In the considered setting, according to Ref.[2], the Eq. (3) reduces to: $$d\left({\bar{\mathbf{h}}}_i{\bar{\mathbf{h}}}_{t+1}\right)\equiv \sin \left({\mathit{\vartheta }}_{\mathit{t}\mathit{,}\mathit{t}\mathit{+}1}\right)={\tan }^{-1}\left(\Vert {\mathbf{w}}_{t+1}^{\perp }\Vert /\Vert {\mathbf{h}}_t+{\mathbf{w}}_{t+1}^{\left|\right|}\Vert \right)\mathrm{.}$$


• The distribution of d( h _t , h _t+1) is obtained directly from (27), however its expression is not suitable for practical usage in real-time systems. Therefore, in the following an approximate expression for F _{d( h t, h t+1)}(δ) that is tight for highly correlated channels (ρ→1) is derived.
• It is first observed that for $\rho \to 1\Vert {\mathbf{h}}_t+{\mathbf{w}}_{t+1}^{\left|\right|}\Vert \to \Vert {\mathbf{h}}_t\Vert$



  with high probability. Therefore, Eq. (27) is approximate as: $$d\left({\bar{\mathbf{h}}}_{\mathit{t}}{\bar{\mathbf{h}}}_{t+1}\right)\cong {\tan }^{-1}\left(\Vert {\mathbf{w}}_{t+1}^{\perp }\Vert /\Vert {\mathbf{h}}_t\Vert \right)={\tan }^{-1}\sqrt{{\Vert {\mathbf{w}}_{t+1}^{\perp }\Vert }^2/{\Vert {\mathbf{h}}_t\Vert }^2}\mathrm{.}$$



  Since h _t is a Gaussian vector of i.i.d. elements, ∥h _t ∥² is a scaled χ-squared random variable with 2n_t degrees of freedom and average value n_t , $${\mathrm{Pr}}_{{\Vert {\mathbf{h}}_t\Vert }^2}\left(x\right)=\frac{{\left(2x\right)}^{N-1}\exp \left(-x\right)}{\mathrm{\Gamma }\left(n_t\right)2^{n_t-1}}$$




  in which Γ(n_t ) is any algebraic function.
  On the other hand, it can be shown that $\Vert {\mathbf{w}}_{t+1}^{\perp }{\Vert }^2$



  is distributed as a χ-squared random variable with 2n_t - 2 degrees of freedom scaled by λ=1-ρ²: $${\mathrm{Pr}}_{\Vert {\mathbf{w}}_{t+1}^{\perp }{\Vert }^2}\left(y\right)=\frac{{\left(\frac{2}{\mathit{\lambda }}y\right)}^{N-2}\exp \left(-y/\mathit{\lambda }\right)}{\mathit{\lambda }\mathrm{\Gamma }\left(n_t-1\right)2^{n_t-2}}$$



  The p.d.f. of $z=\Vert {\mathbf{w}}_{t+1}^{\perp }{\Vert }^2/{\Vert {\mathbf{h}}_t\Vert }^2$



  is derived from (29) and (30): $${\mathrm{Pr}}_z\left(\mathit{\gamma }\right)=\frac{\left(2n_t-2\right)!}{\mathrm{\Gamma }\left(n_t\right)\mathrm{\Gamma }\left(n_t-1\right){\mathit{\lambda }}^{n_t-1}}{\mathit{\gamma }}^{n_t-2}{\left(\mathit{\gamma }/\mathit{\lambda }+1\right)}^{-2n_t+1}$$



  The CCDF F _{d( h t, h t+1)}(δ) of d( h _t , h _t+1) is finally obtained by integrating (31) and substituting z = tan² δ.
• Fig.5 shows the comparison between the (17) and the numerical CCDF of d ( h _t , h _t+1) in (27) for n_t = 4 and for various values of ρ expressed as in Eq. (25). As expected, the (17) is tight for ρ→1, which is the setting of most practical interest for the feedback compression technique previously discussed.
• Now with reference to the remaining figg.6, 7, and 8, the proposed feedback reduction algorithm is evaluated in terms of average rate performance for various codebook design criteria and system parameters. The channel at generic time slot t is distributed according to (1) and channel correlation is modeled by the AR(1) model (24). The average rate is evaluated according to Shannon's capacity: $$\bar{R}=E\left[R_t\right]=E\left[{\log }_2\det \left(\mathbf{I}+{\mathbf{H}}_t{\mathbf{F}}_t{{\mathbf{F}}_t}^H{{\mathbf{H}}_t}^H/{\mathrm{<figure-callout\; id="2"\; label="\sigma "\; filenames="imgf0001.png"\; state="\{\{state\}\}">\sigma </figure-callout>}}^2\right)\right]$$



  as a function of the normalized Doppler frequency ψ in (24). The feedback channel is assumed as error-free and zero-delay.
• The following feedback schemes are evaluated:
• Analog feedback (solid line): the optimal unquantized precoder ${\bar{\mathbf{h}}}_t={{\mathbf{h}\begin{array}{c}\mathit{H}\\ \mathit{t}\end{array}/\Vert {\mathbf{h}}_t\Vert }_{}}^{}$

  is used at each time-slot t.
• Conventional quantized feedback ("x" marker): an independent feedback of b = ┌log₂ n_w ┐⁺ = 6 bits is sent on a time-slot basis.
• Reduced quantized feedback (dashed lines): the reduced feedback technique of the method of the invention is assumed and the reduced codebook includes the 2 ^b' nearest neighbors of F _t . The feedback load is independent on Doppler frequency.
• Reduced quantized feedback ("o" marker): the reduced feedback technique of the method of the invention is assumed, and the feedback load is dynamically adjusted to channel normalized Doppler frequency. The actual feedback load is function of channel correlation according to (16).
• Fig.6 shows the performance for a MISO system with n_t = 4 transmit antennas and average SNR=1/σ²=20dB. Codebook Φ is taken from the Grassmannian manifold



  (4,1,64), see Ref.[2]. The proposed feedback load estimation criterion (16) proves to be able to efficiently tune the feedback load according to channel correlation.
• Fig.7 shows the average rate for a MISO system with n_t = 8 transmit antennas and SNR=20dB. A random codebook Φ with 1024 codewords leading to an uncompressed feedback load of b = ┌log₂ n_w ┐⁺ = 10 bit/time-slot is assumed. The efficiency of the feedback load estimator (16) is confirmed in this case, too.
• Fig.8 shows the normalized feedback load f: i.e. the ratio between the reduced feedback load (8) and the uncompressed feedback load: $$f={\lceil {\log }_2\left|\mathrm{\Delta }\left({\mathbf{F}}_{\mathrm{<figure-callout\; id="0"\; label="t\; \; \delta "\; filenames="imgf0004.png,imgf0007.png"\; state="\{\{state\}\}">t</figure-callout>}}{\delta }_{}^{}{}_0^{ʹ}\right)\right|\rceil }^{+}/{\lceil {\log }_2{n}_w\rceil }^{+}$$


• The simulation shows that significant feedback reduction can be achieved for highly correlated channels and that the margin for feedback reduction increases with the density of the codebook.
• Although the invention has been described with particular reference to a preferred embodiment, it will be evident to those skilled in the art, that the present invention is not limited thereto, but further variations and modifications may be applied without departing from the scope of the invention as defined by the annexed claims.
