CN2710875Y - Machine for forming plastic tube materials - Google Patents
Machine for forming plastic tube materials Download PDFInfo
- Publication number
- CN2710875Y CN2710875Y CNU2004200480621U CN200420048062U CN2710875Y CN 2710875 Y CN2710875 Y CN 2710875Y CN U2004200480621 U CNU2004200480621 U CN U2004200480621U CN 200420048062 U CN200420048062 U CN 200420048062U CN 2710875 Y CN2710875 Y CN 2710875Y
- Authority
- CN
- China
- Prior art keywords
- machine
- discharging screw
- tube materials
- plastic tube
- discharging
- Prior art date
- Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
- Expired - Fee Related
Links
Images
Landscapes
- Processing And Handling Of Plastics And Other Materials For Molding In General (AREA)
Abstract
The utility model discloses a machine for forming plastic tube materials, comprising a machine body. A transmission device, a heating device and a discharging device are arranged in the machine body. The discharging device is composed of discharging screw bolts and a material barrel. The discharging screw bolts are connected with the transmission device, and the heating device is arranged on the material barrel. The machine for forming plastic tube materials is characterized in that two discharging screw bolts are arranged in the material barrel, and the two discharging screw bolts are meshed with each other. The discharging screw bolts are in cone form. Adopting a structure with two conical discharging screw bolts, the machine for forming plastic tube materials can carry out the process of the plastic powder material and the plastic particle material directly. The machine for forming plastic tube materials can also carry out the process in which the plastic powder material and the plastic particle material are blended together. The utility model not only discharges fast, but saves the process with a good temperature retention and a high pressure intensity. The machine for forming plastic tube materials which is designed according to the utility model can bring a positive using effect to the plastic manufacture industry.
Description
Technical field: what the utility model was related is a kind of invention of plastic pipe make-up machine, and what be specifically related to is a kind of improvement invention of plastic pipe make-up machine drawing mechanism, particularly be the improvement invention of discharging screw rod in the drawing mechanism.
Background technology: in the prior art, plastic pipe make-up machine drawing mechanism all adopts single screw rod discharging, and the same end to end footpath of screw rod, the plastic pipe make-up machine of this kind structure is all wanted earlier the plastics powder to be made into plastic pellet earlier, plastic pellet is poured in the charging aperture of plastic pipe make-up machine again, so the plastic pipe make-up machine of this kind structure is produced, and tubing efficient is low, the operation trouble.
Summary of the invention: in view of the problem that known technology exists, the purpose of this utility model aims to provide a kind of simple in structure, reasonable in design, raise the efficiency, and applicable plastics powder becomes the plastic pipe make-up machine of tubing with plastic particle processing.In order to achieve the above object, the utility model is finished by following mode: this kind plastic pipe make-up machine, comprise body, be provided with transmission device, heater, drawing mechanism in described body, described drawing mechanism is made up of discharging screw rod and barrel, and described discharging screw rod is connected with transmission device, described heater is located on the barrel, it is characterized in that being provided with two discharging screw rods in the described barrel, and two screw rods are meshing with each other, described discharging screw rod is tapered.Described screw rod is the nitrated steel material.This kind plastic pipe make-up machine owing to adopt the conical double-screw structure, can directly carry out the processing of plastics powder, also can directly carry out plastic particle processing, plastics powder and plastic pellet can also be blended together to process.The utility model not only discharging is fast, and saves operation, good heat preservation performance, intensity of pressure height, according to the plastic pipe make-up machine of the utility model design motif made, brings positive result of use will for the plastics manufacturing.
Description of drawings: the utility model has following accompanying drawing:
Fig. 1 is a screw-rod structure schematic diagram of the present utility model.
The specific embodiment: accompanying drawing has been represented structure of the present utility model and embodiment, further describes the relevant details and the operation principle of embodiment below more in conjunction with the accompanying drawings.The concrete structure prior art of this kind plastic pipe make-up machine is existing, and present embodiment no longer encyclopaedizes.This kind plastic pipe make-up machine, comprise body, in described body, be provided with transmission device, heater, drawing mechanism, described drawing mechanism is made up of discharging nitrated steel material screw rod 1 and barrel, described discharging screw rod is connected with transmission device, and described thermic devices is located on the barrel, is provided with two discharging screw rods in the described barrel, and two screw rods are meshing with each other, and described discharging screw rod is tapered.
As long as the utility model will be used to make the charging aperture that the powder of plastic pipe or plastic pellet or powder and plastic pellet blending are poured body into together, powder or plastic pellet can be along the lines on the discharging screw rod 12 displacements forward, on the throne moving past in the journey, heater on the barrel can be fused into powder or plastic pellet the fluid displacement that goes ahead, up to entering into subsequent processing from discharging opening.The utility model is reasonable in design, and is simple in structure, raises the efficiency, and can directly carry out plastics powder processing, also can directly carry out plastic particle processing, plastics powder and plastic pellet can also be blended together to process.According to the plastic pipe make-up machine of the utility model design motif made, bring positive result of use will for the plastics manufacturing.
Claims (2)
1, a kind of plastic pipe make-up machine, comprise body, in described body, be provided with transmission device, heater, drawing mechanism, described drawing mechanism is made up of discharging screw rod and barrel, described discharging screw rod is connected with transmission device, and described heater is located on the barrel, it is characterized in that being provided with in the described barrel two discharging screw rods, and two screw rods are meshing with each other, and described discharging screw rod (1) is tapered.
2, a kind of plastic pipe make-up machine as claimed in claim 1 is characterized in that described discharging screw rod (1) is the nitrated steel material.
Priority Applications (1)
| Application Number | Priority Date | Filing Date | Title |
|---|---|---|---|
| CNU2004200480621U CN2710875Y (en) | 2004-04-09 | 2004-04-09 | Machine for forming plastic tube materials |
Applications Claiming Priority (1)
| Application Number | Priority Date | Filing Date | Title |
|---|---|---|---|
| CNU2004200480621U CN2710875Y (en) | 2004-04-09 | 2004-04-09 | Machine for forming plastic tube materials |
Publications (1)
| Publication Number | Publication Date |
|---|---|
| CN2710875Y true CN2710875Y (en) | 2005-07-20 |
Family
ID=34872394
Family Applications (1)
| Application Number | Title | Priority Date | Filing Date |
|---|---|---|---|
| CNU2004200480621U Expired - Fee Related CN2710875Y (en) | 2004-04-09 | 2004-04-09 | Machine for forming plastic tube materials |
