The utility model provides a ceiling structure provided with an assembled inverted V-shaped keel, and belongs to the technical field of ceiling installation. This assembled few font fossil fragments furred ceiling structure includes furred ceiling board, few font subassembly, dead lever, pendant, connecting piece. According to the utility model, the connecting piece is fixed on the ceiling board, the bottom of the first inverted-V-shaped keel is connected to the connecting piece, the fixed rod is connected to the second inverted-V-shaped keel, the bottom end of the pendant is connected to the fixed rod, and the top end of the pendant is connected to the wall top, so that the situation that a plurality of connecting pieces are installed on the ceiling board can be avoided, the first inverted-V-shaped keel is not required to be connected to the connecting piece after the first inverted-V-shaped keel is connected to the fixed rod, the connecting piece only needs to be matched with the first inverted-V-shaped keel, the design difficulty of the connecting piece is reduced, the installation efficiency of the connecting piece is improved, the installation efficiency of the whole ceiling structure is further improved, the whole installation mode is safer and more reliable, and a large amount of manpower and material resources are saved.
Description
Technical Field
The utility model relates to the technical field of suspended ceiling installation, in particular to an assembled inverted V-shaped keel suspended ceiling structure.
Background
To the too high condition of former building floor height, adopt the furred ceiling to reduce the floor height usually to make whole house top surface have more characteristic, promoted whole house ornamentation style. The current furred ceiling installation need be connected the pendant bottom in a few font fossil fragments bottom one end, then with a few font fossil fragments bottom other end joint in base, then the thickness of base need connect in a few font fossil fragments behind the pendant according to a few font fossil fragments bottom highly definite apart from between the decorative board, simultaneously owing to set up a plurality of bases at the decorative board, then need adjust a plurality of bases to the alignment, increased the manufacturing degree of difficulty, reduced production efficiency, reduced the installation effectiveness.
Chinese patent CN112814255A, published Japanese 2021-05-18 disclose a ceiling structure suitable for square steel keel and a mounting method thereof, belonging to the technical field of ceiling mounting. The suspended ceiling structure suitable for the square steel keels and the installation method thereof comprise a plurality of decorative panels, a plurality of bases, the keels, hanging pieces and telescopic hanging pieces. In this prior art will stretch out and draw back flying piece joint in the first draw-in groove that is formed by first joint structure, with fossil fragments bottom other end joint in the second draw-in groove that is formed by second joint structure, thereby realize respectively with flexible flying piece and fossil fragments fastening connection through the suspender member, the commonality improves greatly, splice a plurality of decorative panels, connect fossil fragments bottom one end respectively in the base on a plurality of decorative panels simultaneously, thereby with decorative panel fastening connection in the suspender member bottom, adjust the length of flexible flying piece, whole lifting decorative panel, accomplish the installation of whole furred ceiling, it is simple to dismantle, be convenient for adjust and change, the cost is dismantled in the reduction. The pendant bottom is connected in a few font fossil fragments bottom one end in above-mentioned patent, then with a few font fossil fragments bottom other end joint in the base, then the thickness of base need connect in a few font fossil fragments behind the pendant according to a few font fossil fragments bottom highly definite between apart from the decorative board, simultaneously owing to set up a plurality of bases at the decorative board, then need adjust a plurality of bases to the alignment, increased the manufacturing degree of difficulty, reduced production efficiency, reduced the installation effectiveness.
SUMMERY OF THE UTILITY MODEL
The utility model aims to provide an assembled inverted T-shaped keel ceiling structure aiming at the defects of the prior art.
The utility model provides an assembled inverted U-shaped keel suspended ceiling structure which comprises a suspended ceiling plate, an inverted U-shaped assembly, a fixed rod, a hanging piece and a connecting piece fixed on the suspended ceiling plate, wherein the inverted U-shaped assembly comprises a first inverted U-shaped keel and a second inverted U-shaped keel arranged at the upper end of the first inverted U-shaped keel, the bottom of the first inverted U-shaped keel is connected with the connecting piece, the fixed rod is connected with the second inverted U-shaped keel, the bottom end of the hanging piece is connected with the fixed rod, and the top end of the hanging piece is connected with a wall top.
Furthermore, the dead lever is the aluminum alloy dead lever, the style of calligraphy of several words subassembly is the aluminum alloy style of calligraphy subassembly, the connecting piece is the aluminum alloy connecting piece.
Furthermore, the connecting piece comprises a first base plate connected to the ceiling board, a first enclosing baffle arranged at one end of the top of the first base plate, a second enclosing baffle arranged at the other end of the top of the first base plate, and a first fixing through hole arranged between the first enclosing baffle and the second enclosing baffle, wherein the first enclosing baffle and the first base plate enclose a first clamping groove, the first inverted V-shaped keel comprises a first connecting part connected to one end of the bottom of the second inverted V-shaped keel, a first clamping plate connected to one end of the bottom of the first connecting part, and a second connecting part connected to the other end of the bottom of the second inverted V-shaped keel, the second connecting part abuts against the second enclosing baffle when the second connecting part is inserted into the first fixing through hole, and the first clamping plate is clamped in the first clamping groove when the second connecting part abuts against the second enclosing baffle.
Furthermore, the second baffle plate and the first substrate enclose a second clamping groove, the first inverted U-shaped keel further comprises a second clamping plate connected to the other end of the second connecting portion, the first connecting portion abuts against the first baffle plate when the first connecting portion is connected to the first fixing through hole in an inserting mode, and the second clamping plate is connected to the second clamping groove when the first connecting portion abuts against the first baffle plate.
Furthermore, the hanging piece comprises a hanging plate and a fastening structure, wherein the hanging plate is clamped on the fixing rod and protrudes out of the outer side of the second inverted-V-shaped keel, and the fastening structure is used for fixing the hanging plate on the wall top.
Further, first nearly font fossil fragments still include the third connecting portion that both ends are connected respectively in first connecting portion and second connecting portion, second nearly font fossil fragments are connected respectively in the sixth connecting portion of fourth connecting portion and fifth connecting portion including connecting in the fourth connecting portion on first connecting portion top, connecting in the fifth connecting portion on second connecting portion top, both ends, third connecting portion, fourth connecting portion, sixth connecting portion, fifth connecting portion enclose into the second fixed through hole that is used for supplying the dead lever to cup joint.
Further, the n-shaped components are arranged on the connecting piece in an equidistant mode, and one fixing rod is sleeved on the second n-shaped keels respectively.
Furthermore, the hanging pieces are connected to the parts, located between the two adjacent inverted U-shaped assemblies, of the fixing rod, and the distances between the hanging pieces and the two adjacent inverted U-shaped assemblies are equal.
Furthermore, the second inverted-V-shaped keel also comprises a first reinforcing plate connected to one side end of the fourth connecting part and a second reinforcing plate connected to the other side end of the fifth connecting part.
Further, the hanging plate is a C-shaped hanging plate, and the fastening structure is an expansion bolt.
The assembled inverted U-shaped keel ceiling structure has the following beneficial effects:
the connecting piece is fixed on the ceiling board, the bottom of the first inverted-V-shaped keel is connected with the connecting piece, the fixed rod is connected with the second inverted-V-shaped keel, the bottom end of the hanging piece is connected with the fixed rod, the top end of the hanging piece is connected with the wall top, the installation of a plurality of connecting pieces on the ceiling board can be avoided, the first inverted-V-shaped keel is not required to be connected with the connecting piece after the first inverted-V-shaped keel is connected with the fixed rod, the connecting piece is only required to be matched with the first inverted-V-shaped keel, the design difficulty of the connecting piece is reduced, in addition, an inverted-V-shaped component is connected with one connecting piece in the application, the ceiling board is provided with the connecting piece, so that a plurality of connecting pieces are not required to be arranged on the ceiling board for connecting the inverted V-shaped components, the mounting efficiency of the connecting pieces is improved, and then improved whole furred ceiling structure's installation effectiveness, whole mounting means safe and reliable more and saved a large amount of manpower and material resources.
Drawings
The accompanying drawings, which are incorporated in and constitute a part of the specification, illustrate embodiments of the utility model and together with the description, serve to explain the principles of the utility model. In the drawings, like reference numerals are used to indicate like elements. The drawings in the following description are directed to some, but not all embodiments of the utility model. For a person skilled in the art, other figures can be derived from these figures without inventive effort.
Fig. 1 is a schematic structural view of a fabricated inverted-v-shaped keel ceiling structure according to an embodiment of the utility model;
figure 2 is a side view of a fabricated inverted-v-shaped keel ceiling structure according to an embodiment of the utility model;
fig. 3 is a schematic structural view of a fixing rod in an assembled type inverted-v-shaped keel ceiling structure according to an embodiment of the utility model;
fig. 4 is a schematic structural view of a n-shaped component of a fabricated n-shaped keel ceiling structure according to an embodiment of the utility model;
fig. 5 is a schematic view of an assembly of a sectional type inverted-v-shaped keel ceiling structure according to an embodiment of the utility model, wherein the first connecting portion is connected to the second connecting portion;
figure 6 is a side view of an inverted t-shaped member of an assembled inverted t-shaped keel ceiling structure according to an embodiment of the utility model, with a first connection portion connected to a second connection portion;
fig. 7 is a schematic structural view of a connector in a fabricated inverted-v-shaped keel ceiling structure according to an embodiment of the utility model;
figure 8 is a side view of a connector in a fabricated furred ceiling construction with inverted v-shaped runners according to an embodiment of the present invention;
fig. 9 is a schematic structural view of a hanging plate in an assembled inverted-v-shaped keel ceiling structure according to an embodiment of the utility model;
figure 10 is a side view of a hitch plate in a fabricated furred ceiling construction having an inverted v-shaped keel in accordance with an embodiment of the present invention.
In the figure: 1-ceiling board, 2-connecting piece, 21-first base board, 22-first enclosing baffle, 23-second enclosing baffle, 24-first fixing through hole, 25-first clamping groove, 26-second clamping groove, 3-inverted V-shaped component, 31-first inverted V-shaped keel, 311-first connecting part, 312-first clamping plate, 313-second clamping plate, 314-second connecting part, 315-third connecting part, 32-second inverted V-shaped keel, 321-fourth connecting part, 322-first reinforcing plate, 323-second reinforcing plate, 324-second fixing through hole, 325-fifth connecting part, 326-sixth connecting part, 4-fixing rod, 51-hanging plate and 52-fastening structure.
Detailed Description
In order to make the objects, technical solutions and advantages of the embodiments of the present invention clearer, the technical solutions in the embodiments of the present invention will be clearly and completely described below with reference to the drawings in the embodiments of the present invention, and it is obvious that the described embodiments are some, but not all, embodiments of the present invention. All other embodiments, which can be derived by a person skilled in the art from the embodiments given herein without making any creative effort, shall fall within the protection scope of the present invention. It should be noted that the embodiments and features of the embodiments in the present application may be arbitrarily combined with each other without conflict.
Please refer to fig. 1 to 10. The assembled inverted U-shaped keel suspended ceiling structure comprises a suspended ceiling plate 1, an inverted U-shaped component 3, a fixing rod 4, a hanging piece and a connecting piece 2 fixed on the suspended ceiling plate 1, wherein the inverted U-shaped component 3 comprises a first inverted U-shaped keel 31 and a second inverted U-shaped keel 32 arranged at the upper end of the first inverted U-shaped keel 31, the bottom of the first inverted U-shaped keel 31 is connected to the connecting piece 2, the fixing rod 4 is connected to the second inverted U-shaped keel 32, the bottom end of the hanging piece is connected to the fixing rod 4, and the top end of the hanging piece is connected to the top of a wall.
Here, the connecting member 2 is fixed on the ceiling board 1, the bottom of the first inverted-V-shaped keel 31 is connected to the connecting member 2, the fixing rod 4 is connected to the second inverted-V-shaped keel 32, the bottom end of the hanger is connected to the fixing rod 4, and the top end of the hanger is connected to the wall top, so that the mounting of a plurality of connecting members 2 on the ceiling board 1 can be avoided, the first inverted-V-shaped keel 31 is not required to be connected to the connecting member 2 after the first inverted-V-shaped keel 31 is connected to the fixing rod 4, the connecting member 2 only needs to be matched with the first inverted-V-shaped keel 31, the design difficulty of the connecting member 2 is reduced, and in the present application, one inverted-V-shaped assembly 3 is connected to one connecting member 2, and one connecting member 2 is mounted on the ceiling board 1, so that a plurality of connecting members 2 are not required to be mounted on the ceiling board 1 for connecting to the inverted-V-shaped assemblies 3, the mounting efficiency of the connecting members 2 is improved, and the mounting efficiency of the overall ceiling structure is further improved, the whole installation mode is safer and more reliable and saves a large amount of manpower and material resources.
The fixed rod 4 can be an aluminum alloy fixed rod, the n-shaped component 3 is an aluminum alloy n-shaped component, and the connecting piece 2 is an aluminum alloy connecting piece. For example connect furred ceiling board 1 through the wood joist mutually, use aluminum alloy ex-trusions to extrude square pipe, a few font subassemblies 3, connecting piece 2 respectively in this application, carry out erection joint through dead lever 4, a few font subassemblies 3, connecting piece 2 to furred ceiling board 1, waterproof performance is better, and the security performance is higher.
The connecting member 2 may include a first base plate 21 connected to the ceiling plate 1, a first surrounding baffle 22 disposed at one end of the top of the first base plate 21, a second surrounding baffle 23 disposed at the other end of the top of the first base plate 21, and a first fixing through hole 24 disposed between the first surrounding baffle 22 and the second surrounding baffle 23, the first surrounding baffle 22 and the first base plate 21 form a first engaging groove 25, the first inverted-letter-shaped keel 31 includes a first connecting portion 311 connected to one end of the bottom of the second inverted-letter-shaped keel 32, a first engaging plate 312 connected to one end of the bottom of the first connecting portion 311, and a second connecting portion 314 connected to the other end of the bottom of the second inverted-letter-shaped keel 32, the second connecting portion 314 abuts against the second surrounding baffle 23 when the second connecting portion 314 is inserted into the first fixing through hole 24, and the first engaging plate 312 engages with the first engaging groove 25 when the second connecting portion 314 abuts against the second surrounding baffle 23. The width between the first connection portion 311 and the second connection portion 314 is equal to the width of the first fixing through hole 24. The length of the first clamping plate 312 is equal to the length of the first clamping slot 25, and when the first clamping plate 312 is clamped in the first clamping slot 25, one side end of the first clamping plate 312 abuts against one side end of the first clamping slot 25.
The second retaining plate 23 and the first base plate 21 can be enclosed to form a second retaining groove 26, the first inverted-V-shaped keel 31 further includes a second retaining plate 313 connected to the other end of the second connecting portion 314, the first connecting portion 311 abuts against the first retaining plate 22 when the first connecting portion 311 is inserted into the first fixing through hole 24, and the second retaining plate 313 abuts against the second retaining groove 26 when the first connecting portion 311 abuts against the first retaining plate 22. The length of the second fastening plate 313 is equal to the length of the second card slot 26, and when the second fastening plate 313 is fastened to the second card slot 26, one side end of the second fastening plate 313 abuts against one side end of the second card slot 26. The first substrate 21 may be a rectangular substrate, the first enclosure plate 22 and the second enclosure plate 23 may both be L-shaped enclosure plates, the first fixing through holes 24 may be rectangular fixing through holes, the first connecting portions 311 and the second connecting portions 314 are arranged in parallel, and the first connecting portions 311 and the second connecting portions 314 are perpendicular to the first substrate 21. The first enclosing baffle 22 and the second enclosing baffle 23 are symmetrically arranged about a straight line where the center line of the first substrate 21 is located, the first clamping groove 25 and the second clamping groove 26 are symmetrically arranged about a straight line where the center line of the first substrate 21 is located, the first clamping connection plate 312 and the second clamping connection plate 313 are symmetrically arranged about a center line of the first connection portion 311, and the first clamping connection plate 312 and the second clamping connection plate 313 are perpendicular to the first connection portion 311.
The length of the first base plate 21 may be equal to the length of the ceiling board 1, and the center line of the first base plate 21 may be equal to the first center line of the ceiling board 1, so that the center line of the zigzag-shaped element 3 coincides with the first center line of the ceiling board 1 when the zigzag-shaped element 3 is connected to the connecting member 2, so that the hanger can uniformly apply a lifting force on the ceiling board 1 when the zigzag-shaped element 3 is lifted, and the stability of the whole system is improved.
The hanging member may include a hanging plate 51 caught to a portion of the fixing lever 4 protruding outside the second cross runner 32, and a fastening structure 52 for fixing the hanging plate 51 to the top of the wall. After the fixing rod 4 is connected to the second inverted-V-shaped keel 32, the hanging plate 51 is connected to the portion, protruding out of the outer side of the second inverted-V-shaped keel 32, of the fixing plate in a clamped mode, the fastening structure 52 fixes the hanging plate 51 to the top of the wall, and installation is convenient and fast.
The first inverted-V-shaped keel 31 may further include a third connection portion 315 having two ends respectively connected to the first connection portion 311 and the second connection portion 314, the second inverted-V-shaped keel 32 includes a fourth connection portion 321 connected to the top end of the first connection portion 311, a fifth connection portion 325 connected to the top end of the second connection portion 314, and a sixth connection portion 326 having two ends respectively connected to the fourth connection portion 321 and the fifth connection portion 325, and the third connection portion 315, the fourth connection portion 321, the sixth connection portion 326, and the fifth connection portion 325 form a second fixing through hole 324 for the fixing rod 4 to be sleeved. The joint has first a few font fossil fragments 31 in the connecting piece 2, connects reliably and simple installation easy operation, and the joint of hitch plate 51 and dead lever 4 makes the overall installation mode safe and reliable more and has saved a large amount of manpowers and material resources. Third connecting portion 315, sixth connecting portion 326 parallel arrangement, fourth connecting portion 321, the equal perpendicular to third connecting portion 315 of fifth connecting portion 325, make second fixed through hole 324 be the cuboid through-hole, make things convenient for square pipe joint in second fixed through hole 324, sixth connecting portion 326 can carry out the backstop for a few font fossil fragments 32 of second when square pipe lifts by crane a few font fossil fragments 32 of second, fourth connecting portion 321 can carry out the backstop to one side of square pipe, fifth connecting portion 325 can carry out the backstop to the opposite side of square pipe, third connecting portion 315 support column side pipe when square pipe cup joints in second fixed through hole 324. First few font fossil fragments 31, second few font fossil fragments 32 share a third connecting portion 315, save material, improve production efficiency, and third connecting portion 315 both can carry on spacingly to first connecting portion 311, second connecting portion 314 for the distance between first connecting portion 311, the second connecting portion 314 keeps fixed, can support the dead lever 4 of joint in second fixed through-hole 324 again. The first fixing through-hole 24 may be a rectangular through-hole, and the fixing rod 4 may be a square tube. The first fixing through-hole 24 may be a circular through-hole, and the fixing lever 4 may be a circular tube.
The n-shaped components 3 can be arranged on the connecting piece 2 at equal intervals, and one fixing rod 4 is respectively sleeved on the second n-shaped keels 32. The length of the third connection part 315 is less than that of the first substrate 21, and the length of the fixing rod 4 is equal to that of the first substrate 21. A plurality of zigzag-shaped members 3 may be symmetrically arranged about the second center line of the ceiling tile 1. At least two n-shaped assemblies 3 are arranged on the connecting piece 2, and two end parts of the connecting piece 2 are respectively provided with one n-shaped assembly 3, so that the hoisting force can be conveniently and uniformly applied to the ceiling plate 1, and the stability of the whole system is improved.
The pendant can be connected in the dead lever 4 and lie in the part between two adjacent nearly font subassemblies 3, and the pendant equals with two adjacent nearly font subassemblies 3's distance respectively, improves the stability that the pendant hung dead lever 4. The hangers may be symmetrically disposed about the second center line of the ceiling panel 1.
The second zigzag keel 32 may further include a first reinforcing plate 322 connected to one side end of the fourth connecting portion 321, and a second reinforcing plate 323 connected to the other side end of the fifth connecting portion 325. The first reinforcing plate 322 may be connected to a side end of the fourth connecting portion 321, the second reinforcing plate 323 may be connected to a side end of the fifth connecting portion 325, the first reinforcing plate 322 may increase strength of the fourth connecting portion 321, and the second reinforcing plate 323 may increase strength of the fifth connecting portion 325, so as to improve stability of the fixing rod 4 fastened to the second fixing through hole 324. The first reinforcing plate 322 may protect the fourth connecting portion 321 from being hit by a foreign object when the foreign object moves in a direction of one side end of the fourth connecting portion 321, and the second reinforcing plate 323 may protect the fifth connecting portion 325 from being hit by a foreign object when the foreign object moves in a direction of one side end of the fifth connecting portion 325. When the height of the first card slot 25 and the height of the second card slot 26 are both preset heights, the first reinforcing plate 322 and the first card connecting plate 312 can be connected to the first card slot 25 in a clamped mode, the second reinforcing plate 323 and the second card connecting plate 313 can be connected to the second card slot 26 in a clamped mode, and the n-shaped keels can be connected with the connecting pieces 2 of different specifications. After the first inverted-V-shaped keel 31 is connected to the connecting part 2, the first inverted-V-shaped keel 31 can be connected to different positions on the connecting part 2 by pushing the first reinforcing plate 322 and the second reinforcing plate 323 respectively, and therefore the installation efficiency is improved.
Referring to fig. 1 to 10, a method of installing an assembled type inverted-letter-shaped keel ceiling structure,
s1: fixing the connecting piece 2 on the ceiling board 1;
s2: the bottom of a first inverted-V-shaped keel 31 on the inverted-V-shaped component 3 is connected to the connecting piece 2, the fixing rod 4 is connected to a second inverted-V-shaped keel 32 on the inverted-V-shaped component 3, and the second inverted-V-shaped keel 32 is arranged at the upper end of the first inverted-V-shaped keel 31;
s3: the bottom end of the hanging piece is connected with the fixed rod 4, and the top end of the hanging piece is connected with the top of the wall.
The connecting piece 2 is fixed on the ceiling board 1, only one connecting piece 2 needs to be arranged on the ceiling board 1, the connecting pieces 2 do not need to be arranged on the ceiling board 1 after the connecting pieces 2 are aligned, the bottom of the first inverted-V-shaped keel 31 is connected to the connecting piece 2, the installation efficiency is improved, the fixed rod 4 is connected to the second inverted-V-shaped keel 32, the bottom end of the pendant is connected to the fixed rod 4, the top end of the pendant is connected to the wall top, the first inverted-V-shaped keel 31 is not needed to be connected to the connecting piece 2 after the first inverted-V-shaped keel 31 is connected to the fixed rod 4, the connecting piece 2 only needs to be matched with the first inverted-V-shaped keel 31, the design difficulty of the connecting piece 2 is reduced, and then improved whole suspended ceiling structure's installation effectiveness, dead lever 4 is connected and is not influenced first a few font fossil fragments 31 and connect in connecting piece 2 in a few font fossil fragments 32 of second, and a large amount of manpower and material resources have just been saved to more safe and reliable of whole mounting means.
The above-described aspects may be implemented individually or in various combinations, and such variations are within the scope of the present invention.
It should be noted that, in the description of the present application, it should be noted that the terms "upper end", "lower end" and "bottom end" indicating the orientation or positional relationship are based on the orientation or positional relationship shown in the drawings or the orientation or positional relationship which the product of the application is usually placed in when the product of the application is used, and are only for convenience of describing the present application and simplifying the description, but do not indicate or imply that the device referred to must have a specific orientation, be constructed in a specific orientation and be operated, and thus, should not be construed as limiting the present application. Also, the terms "comprises," "comprising," or any other variation thereof, are intended to cover a non-exclusive inclusion, such that a process, method, article, or apparatus that comprises a list of elements does not include only those elements but may include other elements not expressly listed or inherent to such process, method, article, or apparatus. Without further limitation, an element defined by the phrase "comprising an …" does not exclude the presence of other identical elements in a process, method, article, or apparatus that comprises the element.
Finally, it should be noted that: the above examples are only for illustrating the technical solutions of the present invention, and are not limited thereto. Although the present invention has been described in detail with reference to the foregoing embodiments, it will be understood by those of ordinary skill in the art that: the technical solutions described in the foregoing embodiments may still be modified, or some technical features may be equivalently replaced; and such modifications or substitutions do not depart from the spirit and scope of the corresponding technical solutions of the embodiments of the present invention.
Claims (10)
1. The utility model provides an assembled several font fossil fragments furred ceiling structure which characterized in that: including furred ceiling board (1), a few font subassemblies (3), dead lever (4), pendant, be fixed in connecting piece (2) on furred ceiling board (1), a few font subassemblies (3) include first a few font fossil fragments (31), set up in a few font fossil fragments (32) of second of first a few font fossil fragments (31) upper end, first a few font fossil fragments (31) bottom is connected in connecting piece (2), dead lever (4) are connected in a few font fossil fragments (32) of second, the pendant bottom is connected in dead lever (4), top and is connected in the wall crown.
2. The fabricated inverted-F-shaped keel ceiling structure of claim 1, wherein: the fixing rod (4) is an aluminum alloy fixing rod (4), the n-shaped component (3) is an aluminum alloy n-shaped component (3), and the connecting piece (2) is an aluminum alloy connecting piece (2).
3. A fabricated inverted-F-shaped keel ceiling structure as claimed in claim 1 or 2, wherein: the connecting piece (2) comprises a first base plate (21) connected to the ceiling plate (1), a first enclosing baffle plate (22) arranged at one end of the top of the first base plate (21), a second enclosing baffle plate (23) arranged at the other end of the top of the first base plate (21), and a first fixing through hole (24) arranged between the first enclosing baffle plate (22) and the second enclosing baffle plate (23), wherein the first enclosing baffle plate (22) and the first base plate (21) enclose a first clamping groove (25), the first inverted-V-shaped keel (31) comprises a first connecting part (311) connected to one end of the bottom of the second inverted-V-shaped keel (32), a first clamping plate (312) connected to one end of the bottom of the first connecting part (311), and a second connecting part (314) connected to the other end of the bottom of the second inverted-V-shaped keel (32), and the second connecting part (314) is abutted to the second enclosing baffle plate (23) when the second connecting part (314) is plugged to the first fixing through hole (24), the first clamping plate (312) is clamped in the first clamping groove (25) when the second connecting portion (314) abuts against the second baffle plate (23).
4. A fabricated inverted-F-shaped keel ceiling structure as claimed in claim 3, wherein: the second baffle plate (23) and the first substrate (21) are enclosed to form a second clamping groove (26), the first U-shaped keel (31) further comprises a second clamping plate (313) connected to the other end of the second connecting portion (314), the first connecting portion (311) abuts against the first baffle plate (22) when the first connecting portion (311) is inserted into the first fixing through hole (24), and the second clamping plate (313) abuts against the second clamping groove (26) when the first connecting portion (311) abuts against the first baffle plate (22).
5. The fabricated inverted-F-shaped keel ceiling structure of claim 4, wherein: the hanging piece comprises a hanging plate (51) which is clamped on the part, protruding out of the outer side of the second inverted-V-shaped keel (32), of the fixing rod (4) and a fastening structure (52) used for fixing the hanging plate (51) on the wall top.
6. A fabricated inverted-F-shaped keel ceiling structure as claimed in claim 3, wherein: the first inverted-V-shaped keel (31) further comprises a third connecting portion (315) with two ends respectively connected to the first connecting portion (311) and the second connecting portion (314), the second inverted-V-shaped keel (32) comprises a fourth connecting portion (321) connected to the top end of the first connecting portion (311), a fifth connecting portion (325) connected to the top end of the second connecting portion (314), and a sixth connecting portion (326) with two ends respectively connected to the fourth connecting portion (321) and the fifth connecting portion (325), and the third connecting portion (315), the fourth connecting portion (321), the sixth connecting portion (326) and the fifth connecting portion (325) are surrounded to form a second fixing through hole (324) for the fixing rod (4) to be sleeved with.
7. The fabricated inverted-F-shaped keel ceiling structure of claim 6, wherein: the n-shaped components (3) are arranged on the connecting piece (2) in an equidistance mode, and one of the n-shaped components is a plurality of fixing rods (4) which are respectively sleeved on a plurality of second n-shaped keels (32).
8. The fabricated inverted-F-shaped keel ceiling structure of claim 7, wherein: the pendant is connected to the part of the fixed rod (4) between two adjacent n-shaped components (3), and the distance between the pendant and each two adjacent n-shaped components (3) is equal.
9. The fabricated inverted-F-shaped keel ceiling structure of claim 6, wherein: the second inverted-V-shaped keel (32) further comprises a first reinforcing plate (322) connected to one side end of the fourth connecting part (321) and a second reinforcing plate (323) connected to the other side end of the fifth connecting part (325).
10. The fabricated inverted-F-shaped keel ceiling structure of claim 5, wherein: the hanging plate (51) is a C-shaped hanging plate, and the fastening structure (52) is an expansion bolt.
