Abstract

The utility model belongs to the technical field of medical equipment, in particular to a single-shoulder oblique-span chest strap, comprising a chest strap front, a chest strap back, an elastic strap, and an elastic shoulder strap; The front side of the chest belt and the lower edge of the back side of the chest belt are sewed and connected, and a first elastic band is arranged, and the two ends of the front side of the chest belt and the back side of the chest belt are provided with armpit openings; The upper and lower ends of the elastic shoulder strap are provided with a hook and loop fastener, and the hook and loop fasteners are respectively attached to the front hook and loop fastener strips and the back hook and loop fastener strips. The single-shoulder oblique-span type chest belt of the utility model adopts the combination of a female tube top and a single-shoulder oblique-span belt for fixing, so as to release the breast on the healthy side from the compression of the chest belt, and adopt the double fixation of the shoulder belt and the chest belt for the breast on the affected side. It is not easy to loosen and shift; it is used for postoperative benign breast tumors to protect the surgical incision, prevent bleeding, and reduce postoperative complications.

Description

Single-shoulder inclined-striding type chest belt

Technical Field

The utility model belongs to the technical field of medical instrument, concretely relates to formula pectoral girdle is striden to one side to single shoulder.

Background

The medical instrument refers to instruments, equipment, appliances, in-vitro diagnostic reagents, calibrators, materials and other similar or related articles which are directly or indirectly used for a human body, and the nursing chest strap is used as a medical instrument which can help a patient to protect breasts and enable the patient to quickly recover health.

However, in the process of protecting the breasts of a patient, the breasts of the patient cannot be comprehensively protected, the breasts are easily extruded by an external object, discomfort is brought to the patient, the wound healing is affected, meanwhile, the water cannot be effectively prevented, and risks are brought to the wound healing of the patient.

In recent years, the incidence of breast diseases in women has been increasing due to various reasons, and surgical treatment is an effective method for treating both benign and malignant diseases. However, postoperative bleeding is a common complication, and in order to prevent the occurrence of complications such as incision bleeding, annular chest straps are used for pressure dressing, and the dressing method puts all the breasts at two sides into the chest straps, so that the breasts at healthy sides still can be subjected to the pressure of the chest straps, the comfort of a patient is reduced, and physical and mental recovery is not facilitated; the traditional postoperative uses the pectoral girdle to put the breasts at both sides in the pectoral girdle, so that the healthy breasts are also pressed by the pectoral girdle.

Therefore, there is a need to provide a breast cancer postoperative care chest band to solve the above technical problems.

SUMMERY OF THE UTILITY MODEL

To solve the problems set forth in the background art described above. The utility model provides a single-shoulder inclined-span chest strap, which combines the female tube top with the single-shoulder inclined-span strap fixation, liberates the healthy-side breast from the chest strap pressurization, adopts the double fixation of shoulder straps and chest straps for the affected-side breast, and is not easy to loosen and shift; can be used for postoperative treatment of benign tumor of breast, protecting operation incision, preventing hemorrhage, and reducing postoperative complications.

In order to achieve the above object, the utility model provides a following technical scheme: a single-shoulder inclined-striding type chest strap comprises a chest strap front side, a chest strap back side, an elastic band, a latex pad, a front side sticky buckle strip, an elastic shoulder strap, a sticky buckle and a back side sticky buckle strip; the two ends of the front side of the chest belt are mutually connected with the two ends of the back side of the chest belt, the lower edges of the front side of the chest belt and the back side of the chest belt are provided with a first elastic band in a sewing connection mode, and armpit openings are formed in the two ends of the front side of the chest belt and the back side of the chest belt; the front side and the back side of the chest belt are respectively provided with a front side adhesive buckle strip and a back side adhesive buckle strip, and the upper end and the lower end of the elastic shoulder belt are respectively provided with an adhesive buckle which is respectively adhered with the front side adhesive buckle strip and the back side adhesive buckle strip through the adhesive buckles.

Preferably, the back of the chest belt is also provided with a latex pad.

Preferably, the armpit opening is of arcuate design.

Preferably, the second elastic band is sewed and connected with the upper edge of the front surface of the chest band and the upper edge of the back surface of the chest band.

Preferably, the elastic shoulder strap has a width of 5cm and a length of 25 cm.

Preferably, the width of the first stretch band is 5 cm.

Preferably, the width of the front surface button strip and the back surface button strip is 5 cm.

Preferably, the height of the bottom end of the armpit opening and the lower edge of the front surface and the back surface of the chest belt is 15 cm.

Compared with the prior art, the beneficial effects of the utility model are that:

the single-shoulder inclined-straddle type chest strap of the utility model adopts the combination of female bra (bra without shoulder straps) and single-shoulder inclined-straddle strap fixation, liberates the healthy-side breast from the chest strap pressurization, adopts the double fixation of shoulder straps and chest straps for the affected-side breast, and is not easy to loosen and shift; the normal breasts can not be pressurized by the chest belt any more, and the armpit openings adopt arc-shaped design, so that armpit indentations or pressure sores can be effectively prevented; the single-shoulder oblique belt is only pressed on the affected side, is fixed from the back of the healthy side to the contralateral breast and has the function of pressurizing the affected side breast; the medical dressing is used after benign breast tumor operation, so that no lacuna is generated between an postoperative flap and a thoracic cavity, an operation incision is protected, bleeding is prevented, and postoperative complications are reduced.

Drawings

In order to more clearly illustrate the embodiments of the present invention or the technical solutions in the prior art, the drawings needed to be used in the description of the embodiments or the prior art will be briefly described below, it is obvious that the drawings in the following description are only some embodiments of the present invention, and for those skilled in the art, other drawings can be obtained according to the structures shown in the drawings without creative efforts.

FIG. 1 is a schematic structural view of an embodiment of a single-shoulder inclined-striding type chest belt of the present invention;

FIG. 2 is a schematic front view of the single-shoulder inclined-striding chest belt of the present invention;

FIG. 3 is a schematic view of a rear view of the single-shoulder inclined-striding chest belt of the present invention;

fig. 4 is a schematic structural view of the shoulder strap of the single-shoulder inclined-striding chest strap of the present invention.

Detailed Description

The technical solutions in the embodiments of the present invention will be described clearly and completely with reference to the accompanying drawings in the embodiments of the present invention, and it is obvious that the described embodiments are only some embodiments of the present invention, not all embodiments. Based on the embodiments in the present invention, all other embodiments obtained by a person skilled in the art without creative work belong to the protection scope of the present invention.

It should be noted that, if directional indications (such as upper, lower, left, right, front and rear … …) are involved in the embodiment of the present invention, the directional indications are only used to explain the relative position relationship between the components, the motion situation, etc. in a specific posture (as shown in the drawings), and if the specific posture is changed, the directional indications are changed accordingly.

In addition, if there is a description relating to "first", "second", etc. in the embodiments of the present invention, the description of "first", "second", etc. is for descriptive purposes only and is not to be construed as indicating or implying relative importance or implicitly indicating the number of technical features indicated. Thus, a feature defined as "first" or "second" may explicitly or implicitly include at least one such feature. In addition, the technical solutions in the embodiments may be combined with each other, but it must be based on the realization of those skilled in the art, and when the technical solutions are contradictory or cannot be realized, the combination of the technical solutions should not be considered to exist, and is not within the protection scope of the present invention.

Example 1

Referring to fig. 1-4, the present invention provides the following technical solutions: a single-shoulder inclined-striding type chest strap comprises a chest strap front 1, a chest strap back 2, elastic bands 3, latex pads 5, front sticky buckle strips 6, elastic shoulder straps 7, sticky buckles 8 and back sticky buckle strips 9; the two ends of the front 1 of the chest belt are mutually connected with the two ends of the back 2 of the chest belt, the lower edges of the front 1 of the chest belt and the back 2 of the chest belt are sewed and connected with a first elastic band 3, and armpit openings 4 are arranged at the two ends of the front 1 of the chest belt and the back 2 of the chest belt; the middle parts of the front 1 and the back 2 of the chest belt are respectively provided with a front sticky buckle strip 6 and a back sticky buckle strip 9, the upper end and the lower end of the elastic shoulder belt 7 are respectively provided with a sticky buckle 8, and the sticky buckles 8 are respectively adhered with the front sticky buckle strip 6 and the back sticky buckle strip 9.

Specifically, the back 2 of the chest belt is also provided with a latex pad 5 which is soft and has good air permeability.

Specifically, the armpit opening 4 is designed in an arc shape; the armpits of the patient are designed into arc shapes, so that the armpits of the patient are liberated, and no indentation or pressure sore is generated.

Specifically, the upper edges of the front 1 and the back 2 of the chest belt are provided with a second elastic band in a sewing connection way; the material used for the front 1 and the back 2 of the chest belt is pure cotton, and the upper and the lower edges are fixed by elastic bands, so that the chest belt is not easy to move and is comfortable to wear.

Specifically, the width of the elastic shoulder strap 7 is 5cm, and the length is 25 cm; the elastic shoulder straps 7 are independently designed, have small local pressure on the shoulders and can freely adjust the elasticity.

Specifically, the width of the first elastic band 3 is 5 cm.

Specifically, the width of the front surface button strip 6 and the back surface button strip 9 is 5 cm.

Specifically, the height between the bottom end of the armpit opening 4 and the lower edges of the front surface 1 and the back surface 2 of the chest belt is 15 cm.

The utility model discloses a theory of operation and use flow: when the utility model is used, the female bra (the bra without shoulder straps) is combined with the fixation of the single-shoulder inclined spanning belt, the breast at the healthy side is liberated from the chest belt pressurization, and the breast at the affected side is fixed by the shoulder straps and the chest belt, so that the breast is not easy to loosen and shift; after the patient wears the chest band (without shoulder straps) according to the normal wearing method, the elastic shoulder straps 7 are obliquely pressed in front of the front surface 1 of the chest band on the affected side (for example, the wound is on the right side, the elastic shoulder straps 7 are adhered to the right breast through the right shoulder from the left side of the back surface 2 of the chest band upwards, the other side is the same), so that the breasts on the healthy side are not pressed by the front surface 1 of the chest band, and only the breasts on the affected side (the operation side) are pressed by the chest band.

The middle parts of the front 1 and the back 2 of the chest belt are respectively provided with a front sticky buckle strip 6 and a back sticky buckle strip 9, the upper end and the lower end of the elastic shoulder belt 7 are respectively provided with a sticky buckle 8, and the sticky buckles 8 are respectively adhered with the front sticky buckle strip 6 and the back sticky buckle strip 9; the tightness can be adjusted according to the size of the chest after the chest is completely opened, so that the examination and the dressing change are convenient; the front surface 1 of the chest strap, the middle part of the back surface 2 of the chest strap and the upper end and the lower end of the elastic shoulder strap 7 are respectively provided with a magic tape opening, the front surface and the elastic shoulder strap 7 can be adjusted according to the body shape of a patient and the position of an operation incision, and after fat is removed, muscles and skin directly generate gaps, and the middle or transverse pressure is unstable, so that a high-molecular pressurizing pad is arranged in the elastic shoulder strap, so that safe pressurization can be realized, pressure is balanced, sweat and moisture can be discharged, and the elastic shoulder strap is comfortable to fit.

Finally, it should be noted that: although the present invention has been described in detail with reference to the foregoing embodiments, it will be apparent to those skilled in the art that modifications may be made to the embodiments described in the foregoing embodiments, or equivalents may be substituted for elements thereof. Any modification, equivalent replacement, or improvement made within the spirit and principle of the present invention should be included in the protection scope of the present invention.

Claims (8)

1. A single-shoulder oblique-strap chest strap, characterized in that: it comprises a chest strap front (1), a chest strap back (2), an elastic band (3), a latex pad (5), a front velcro strip (6), Elastic shoulder straps (7), hook and loop fasteners (8), and back hook and loop fastener strips (9); the ends of the front (1) of the chest strap are connected to the ends of the back (2) of the chest strap, and the front (1) and A first elastic band (3) is sewed and connected to the lower edge of the back of the chest strap (2), and armpit openings (4) are provided on both ends of the front of the chest strap (1) and the back of the chest strap (2); the front of the chest strap (1) ) and the middle of the back of the chest strap (2) are respectively provided with a front hook and loop fastener (6) and a back hook and loop fastener (9), and the upper and lower ends of the elastic shoulder strap (7) are provided with hook and loop fasteners (8), and The hook and loop fasteners (8) are respectively adhered to the front hook and loop fastener strips (6) and the back hook fastener strips (9). 2 . The one-shoulder oblique-span chest strap according to claim 1 , wherein a latex pad ( 5 ) is further provided on the back ( 2 ) of the chest strap. 3 . 3 . The one-shoulder oblique-strap chest strap according to claim 1 , wherein the armpit opening ( 4 ) adopts an arc-shaped design. 4 . 4 . The one-shoulder diagonal chest strap according to claim 1 , wherein the upper edges of the front (1) and the back (2) of the chest strap are sewed and connected with a second elastic band. 5 . 5 . The one-shoulder diagonal chest strap according to claim 1 , wherein the elastic shoulder strap ( 7 ) has a width of 5 cm and a length of 25 cm. 6 . 6 . The one-shoulder diagonal chest strap according to claim 1 , wherein the width of the first elastic band ( 3 ) is 5 cm. 7 . 7 . The one-shoulder diagonal chest strap according to claim 1 , wherein the width of the front hook and loop fastener strips ( 6 ) and the back surface hook and loop fastener strips ( 9 ) is 5 cm. 8 . 8. The one-shoulder oblique-strap chest strap according to claim 1, wherein the bottom end of the armpit opening (4) is connected to the lower edge of the chest strap front (1) and the chest strap back (2) Height is 15cm.
