Abstract
本实用新型公开了一种新型畜禽饲料搅拌机，包括料桶、绞龙、桶盖、提手、散热风机、出料斗、支架、滚轮、转轴、电机、底板，所述料桶为圆柱空心状，所述绞龙安装在料桶内部，所述桶盖安装在料桶顶部，所述提手安装在桶盖顶部两侧，所述散热风机安装在料桶前端，所述出料斗安装在料桶右侧，所述支架安装在料桶底部四角，所述滚轮安装在支架底部，所述转轴安装在料桶底部，所述电机安装在转轴底部。本实用新型的畜禽饲料搅拌机设有散热风机，能够在搅拌过程中及时给搅拌机散热，降低了搅拌能耗，提高了搅拌机的使用寿命，桶盖方便查看料桶内部状况，滚轮使其移动起来十分方便，同时在移动后能够被放置的更加的稳定。
The utility model discloses a novel livestock and poultry feed mixer, which comprises a material bucket, an auger, a bucket cover, a handle, a cooling fan, a discharge hopper, a bracket, a roller, a rotating shaft, a motor and a bottom plate. The material bucket is a cylindrical hollow shape. , the auger is installed inside the bucket, the bucket cover is installed on the top of the bucket, the handles are installed on both sides of the top of the bucket cover, the cooling fan is installed at the front of the bucket, and the discharge hopper is installed on the top of the bucket. On the right side of the bucket, the brackets are installed at the four corners of the bottom of the bucket, the rollers are installed at the bottom of the bracket, the rotating shaft is installed at the bottom of the bucket, and the motor is installed at the bottom of the rotating shaft. The livestock and poultry feed mixer of the utility model is provided with a cooling fan, which can dissipate heat to the mixer in time during the mixing process, reduce the energy consumption of mixing, and improve the service life of the mixer. It is very convenient and can be placed more stably after moving.
Description
Technical Field
The utility model relates to a mixer especially relates to a novel beasts and birds fodder mixing machine.
Background
With the gradual expansion of the livestock industry, the fodder mixing machine has become an indispensable machine for the livestock industry. The existing livestock and poultry feed stirring machine can not dissipate heat in the stirring process, so that the stirring energy consumption of the stirring machine is increased, the stirring energy consumption is increased, the heat production quantity is increased, the service life of the stirring machine is greatly influenced, and the feed stirring machine is heavy in size and not easy to move.
SUMMERY OF THE UTILITY MODEL
An object of the utility model is to provide a novel beasts and birds fodder mixing machine to solve above-mentioned technical problem.
In order to realize the purpose, the utility model adopts the following technical scheme:
the utility model provides a novel livestock and poultry feed mixer, includes storage bucket, auger, bung, handle, cooling fan, goes out hopper, support, gyro wheel, pivot, motor, bottom plate, the storage bucket is the hollow form of cylinder, the auger is installed inside the storage bucket, the bung is installed at the storage bucket top, the handle is installed in bung top both sides, cooling fan installs at the storage bucket front end, it installs on the storage bucket right side to go out the hopper, the support mounting is in storage bucket bottom four corners, the gyro wheel is installed in the support bottom, the pivot is installed in the storage bucket bottom, the motor is installed in the pivot bottom, the bottom plate is installed in the motor bottom, and bottom plate and support welding.
On the basis of the technical scheme, the barrel cover comprises a left cover, a right cover and a hinge, and the left cover is hinged with the right cover through the hinge.
On the basis of the technical scheme, the roller comprises a round shaft, a brake groove, a brake pedal, a connecting shaft and an installation block, the brake groove is formed in the surface of the round shaft, the brake pedal is installed in the brake groove, the round shaft is welded with the installation block through the connecting shaft, and the installation block is welded with the bottom of the support.
On the basis of the technical scheme, the charging bucket, the bucket cover, the lifting handle, the bracket and the bottom plate are all made of 304 stainless steel materials.
Compared with the prior art, the utility model has the advantages of it is following: the utility model discloses beasts and birds fodder mixing machine is equipped with cooling fan, can in time give the mixer heat dissipation at the stirring in-process, has reduced the stirring energy consumption, has improved the life of mixer, and the bung conveniently looks over the inside situation of storage bucket, and the gyro wheel makes it remove very convenient, can place more stable after removing simultaneously.
Drawings
Fig. 1 is a schematic view of the appearance structure of the present invention.
Fig. 2 is a schematic view of the barrel cover of the present invention.
Fig. 3 is a schematic view of the roller of the present invention.
In the figure: 1. the device comprises a charging basket, 2, an auger, 3, a barrel cover, 4, a lifting handle, 5, a heat dissipation fan, 6, a discharge hopper, 7, a support, 8, a roller, 9, a rotating shaft, 10, a motor, 11, a bottom plate, 12, a left cover, 13, a right cover, 14, a hinge, 15, a circular shaft, 16, a braking groove, 17, a braking pedal, 18, a connecting shaft, 19 and an installation block.
Detailed Description
The invention is explained in further detail below with reference to the figures and the embodiments.
As shown in fig. 1-3, a novel livestock and poultry feed mixer, including storage bucket 1, auger 2, bung 3, handle 4, cooling fan 5, play hopper 6, support 7, gyro wheel 8, pivot 9, motor 10, bottom plate 11, storage bucket 1 is the cylinder heart form, auger 2 installs inside storage bucket 1, bung 3 installs at storage bucket 1 top, handle 4 installs in 3 top both sides of bung, cooling fan 5 installs at 1 front end of storage bucket, it installs on 1 right side of storage bucket to go out hopper 6, support 7 installs in 1 bottom four corners of storage bucket, gyro wheel 8 installs in support 7 bottom, pivot 9 is installed in 1 bottom of storage bucket, motor 10 installs in pivot 9 bottom, bottom plate 11 installs in motor 10 bottom, and bottom plate 11 welds with support 7.
The barrel cover 3 comprises a left cover 12, a right cover 13 and a hinge 14, wherein the left cover 12 is hinged with the right cover 13 through the hinge 14.
The roller 8 comprises a round shaft 15, a brake groove 16, a brake pedal 17, a connecting shaft 18 and a mounting block 19, the brake groove 16 is formed in the surface of the round shaft 15, the brake pedal 17 is mounted in the brake groove 16, the round shaft 15 is welded with the mounting block 19 through the connecting shaft 18, and the mounting block 19 is welded with the bottom of the support 7.
The charging basket 1, the barrel cover 3, the lifting handle 4, the support 7 and the bottom plate 11 are all made of 304 stainless steel materials.
The utility model discloses a theory of operation: can in time give the mixer heat dissipation through cooling fan at the stirring in-process, improve the life of mixer, the inside situation of storage bucket is conveniently looked over to the bung, and the gyro wheel makes it remove very conveniently, can place more stable after removing simultaneously.
The foregoing is a preferred embodiment of the present invention, and for those skilled in the art to understand the teaching of the present invention, the changes, modifications, replacements and variations to the embodiments will still fall within the protection scope of the present invention without departing from the principle and spirit of the present invention.
Claims (4)
1. The utility model provides a novel beasts and birds fodder mixing machine, includes storage bucket (1), auger (2), bung (3), handle (4), cooling fan (5), goes out hopper (6), support (7), gyro wheel (8), pivot (9), motor (10), bottom plate (11), its characterized in that: the utility model discloses a storage battery, including storage bucket (1), packing auger (2), storage bucket (1), bucket (1) are hollow, install inside storage bucket (1) auger (2), install at storage bucket (1) top bung (3), install in bung (3) top both sides handle (4), heat dissipation fan (5) are installed at storage bucket (1) front end, go out hopper (6) and install on storage bucket (1) right side, install in storage bucket (1) bottom four corners support (7), install in support (7) bottom gyro wheel (8), install in storage bucket (1) bottom pivot (9), motor (10) are installed in pivot (9) bottom, install in motor (10) bottom plate (11), and bottom plate (11) and support (7) welding.
2. The novel livestock and poultry feed mixer according to claim 1, characterized in that: the barrel cover (3) comprises a left cover (12), a right cover (13) and a hinge (14), and the left cover (12) is hinged to the right cover (13) through the hinge (14).
3. The novel livestock and poultry feed mixer according to claim 1, characterized in that: the roller (8) comprises a round shaft (15), a brake groove (16), a brake pedal (17), a connecting shaft (18) and a mounting block (19), the brake groove (16) is formed in the surface of the round shaft (15), the brake pedal (17) is mounted in the brake groove (16), the round shaft (15) is welded with the mounting block (19) through the connecting shaft (18), and the mounting block (19) is welded with the bottom of the support (7).
4. The novel livestock and poultry feed mixer according to claim 1, characterized in that: the charging bucket (1), the bucket cover (3), the lifting handle (4), the support (7) and the bottom plate (11) are all made of 304 stainless steel.
