Abstract
本实用新型公开了一种微重力条件下的跑步束缚装置，包括：肩部束缚结构和腰部束缚结构，肩部束缚结构包括对在人体背部交叉并跨越人体肩部设置的肩部束带；腰部束缚结构包括围绕人体腰部设置的腰部束带、一对第一束缚带和一对第二束缚带；第一束缚带在人体正面与通过位置可调的第一卡扣结构连接肩部束带的一端相连，第二束缚带在人体背面通过位置可调的第二卡扣结构与肩部束带的另一端相连；腰部束带的两端通过位置可调的第三卡扣结构连接。这种跑步束缚装置，可以实现不同身高、腰围、胸围人体的肩部和腰部合理的载荷分配，使人体躯干的肌肉和骨骼承载相应加载负荷，使使用者能够较舒适地利用跑步束缚装置进行微重力条件下的跑步锻炼。
The utility model discloses a running restraint device under the condition of microgravity, comprising: a shoulder restraint structure and a waist restraint structure, wherein the shoulder restraint structure comprises a shoulder belt which is crossed on the back of a human body and arranged across the shoulders of the human body; The restraint structure includes a waist belt, a pair of first restraint belts and a pair of second restraint belts arranged around the waist of the human body; the first restraint belt is connected to the shoulder belt through a position-adjustable first buckle structure on the front of the human body. One end is connected, and the second restraint belt is connected with the other end of the shoulder belt through a position-adjustable second buckle structure on the back of the human body; both ends of the waist belt are connected by a position-adjustable third buckle structure. The running restraint device can realize a reasonable load distribution between the shoulders and waist of the human body with different heights, waist circumferences and bust circumferences, so that the muscles and bones of the human trunk can bear the corresponding loading loads, so that the user can use the running restraint device to perform micro-motion more comfortably. Running workout in gravity.
Description
Technical Field
The utility model relates to a physical training equipment technical field, concretely relates to restriction device of running under microgravity condition.
Background
The heart and lung of the human body are in the microgravity environment for a long time. The function of skeletal muscles is continuously reduced, and the health and the working efficiency of the human body are seriously threatened. In order to combat the physiological effects of weight loss, physical exercise is required on-track. The current on-orbit research shows that running exercise is an effective means for carrying out ecological exercise under the microgravity condition and resisting the physiological effect of weightlessness.
Running under the microgravity condition, the key technology that needs to solve is the constraint technique, and its main function is to fix the human body relatively on the platform of running, overcomes the influence of microgravity, and furthest's assurance human body is run with ground motion custom, helps the human body adapt to the space environment of outer space as early as possible, takes exercise cardiopulmonary function and skeletal muscle system comprehensively, improves the neural muscle harmony to guarantee healthy and work efficiency.
It is now retrieved that US patent publication No. US20160008206a1 discloses an exoskeleton-based exercise and training device having a waist, a left leg, a left knee, a left foot, a right leg, a right knee, a right foot, a waist, a back, a torso, a left shoulder and a right shoulder for assistance: a. an upper frame configured to be positioned behind the back of the user; b. a brace connected with the upper frame, the brace configured to encircle the torso of the user, thereby connecting the torso to the upper frame; c. a lower frame connected to the upper frame, the lower frame having a right limit extending beyond the user's right leg and a left limit extending beyond the user's left leg; d. a right hip joint located at the right lateral end of the lower frame; e. a left hip joint located at the left lateral end of the lower frame; f. a right upper link pivotally connected to the right hip joint; g. a left upper link pivotally connected to the left hip joint; h. a right lower link pivotally connected to the right upper link by a right knee joint; i. a left lower link pivotally connected to the left upper link by a left knee joint; j. a right foot plate configured to be positioned under the user's right foot, the right foot plate pivotally connected to the right lower link by a right ankle joint; k. a left foot plate configured to be positioned under the user's left foot, the left foot plate pivotally connected to the left lower link by a left ankle joint; a right knee actuator configured to control a pivot position of the right lower link relative to the right upper link and configured to apply a desired torque between the right lower link and the right upper link; m, a left knee actuator configured to control a pivot position of the lower left link relative to the upper left link and configured to apply a desired torque between the lower left link and the upper left link. The function of the device can be realized in a microgravity environment or a normal ground environment.
However, the above-mentioned running restriction device has the problems of insufficient load distribution and adaptability design, and when a user wears the device to do exercise, the user generally feels uncomfortable, the pain feeling of the shoulder and the waist is large, and the local skin generates inflammatory reaction due to compression and friction, thereby affecting the exercise effect.
SUMMERY OF THE UTILITY MODEL
Therefore, the to-be-solved technical problem of the utility model lies in overcoming among the prior art that the adaptability between constraint device and the user is relatively poor, and the user is painful sense great of shoulder and waist when taking exercise after wearing the constraint device. Thereby affecting the exercise effect and providing a running restraint device under microgravity conditions.
In order to solve the technical problem, the technical scheme of the utility model as follows:
a running restraint device under microgravity conditions, comprising:
a shoulder restraint structure including a pair of shoulder straps configured to cross over the back of the person and to be disposed across the shoulders of the person;
a waist restraint structure including a waist belt configured to be disposed around a waist of a human body and a pair of first straps and a pair of second straps connected to the waist belt; the first strap is configured to be connected to one end of the shoulder strap on the front side of the person, and the second strap is configured to be connected to the other end of the shoulder strap on the back side of the person;
the part of the shoulder belt, which is arranged on the front face of the human body, is connected with a first buckle in a sliding way for adjusting the bound length of the shoulder belt on the front face of the human body, and the first belt is connected with a second buckle suitable for being buckled with the first buckle;
the part of the shoulder belt, which is arranged on the back of the human body, is connected with a third buckle, and the second binding belt is slidably connected with a fourth buckle which is used for adjusting the binding length of the second binding belt on the back of the human body and is suitable for being buckled with the third buckle;
one end of the waist belt is connected with a fifth buckle, and the other end of the waist belt is connected with a sixth buckle which is used for adjusting the binding length of the waist belt and is suitable for being buckled with the fifth buckle.
Further, the shoulder binding structure further comprises a V-shaped shoulder pad configured to fit the shoulder of the human body, and a pair of the shoulder straps are connected to the outer side surface of the V-shaped shoulder pad facing away from the human body.
Furthermore, two shoulder pad arms of the V-shaped shoulder pad are configured to extend from the back of the human body to the front of the human body across the shoulders of the human body, a bending part is arranged on each shoulder pad arm, and the included angle of the upper side of the bending part is configured to be matched with the shape of the neck of the human body.
Further, the V-shaped shoulder pad of the shoulder restraint structure and the pair of shoulder straps are configured to be symmetrically disposed along a line of symmetry of the human body.
Furthermore, the pair of shoulder straps are respectively connected with chest straps configured on the front chest of the human body, one of the chest straps is connected with a seventh buckle, and the other chest strap is slidably connected with an eighth buckle which is used for adjusting the bound length of the pair of chest straps on the front chest of the human body and is suitable for being buckled with the seventh buckle.
Furthermore, a sliding buckle is connected to the shoulder belt in a sliding manner, and one end of the chest belt is connected to the sliding buckle.
Further, the waist binding structure further comprises a waist pad configured to fit with the waist of the human body, the waist belt, the first binding belt and the second binding belt are all connected to the outer side of the waist pad facing away from the human body, and the waist belt is bound to the outer sides of the first binding belt and the second binding belt.
Further, the lumbar pad includes: a middle cushion area configured to fit with a human back lumbar spine area; the left cushion area is connected to the left side of the middle cushion area and is configured to be matched with the left waist side area of the human body; the right side pad area is connected to the right side of the middle pad area and is configured to be matched with the right waist side area of the human body; the left pad area, the middle pad area and the right pad area are formed by dividing the left pad area, the middle pad area and the right pad area by sewing lines.
Further, one end of the first binding belt is connected to the waist pad, the other end of the first binding belt is connected to a pull ring, and the second buckle is connected to the first binding belt in a sliding mode; the second restraining belt comprises a first connecting branch belt connected with the pull ring and a second connecting branch belt connected with the waist pad; the pull ring is further connected with a pull belt suitable for being connected with a treadmill and used for applying pulling force to the first binding belt and the second binding belt.
Further, the waist pad is made of soft materials.
The utility model discloses technical scheme has following advantage:
1. the utility model provides a running restraint device under microgravity condition, when running exercise under the microgravity condition is simulated, the fifth buckle and the sixth buckle at the two ends of waist restraint are buckled, so that the waist belt is restrained at the waist of the human body; the second buckles on the two first straps and the two first buckles on the pair of crossed shoulder straps are buckled on the front side of the human body, and the fourth buckles on the two second straps and the two third buckles on the pair of crossed shoulder straps are buckled on the back side of the human body, so that the pair of shoulder straps are connected with the waist strap and are tied on the shoulders of the human body; the shoulder and waist integrated running and restraining device can realize symmetrical longitudinal loading on two sides of a body and reasonable load body distribution thereof, so that muscle and skeleton systems of the trunk and the lower limbs of the human body bear corresponding loading loads, and the running exercise for resisting resistance is completed.
2. The utility model provides a running binding device under microgravity condition, because the fifth buckle is connected with the waist belt in a sliding way, the loading point of the fifth buckle on the waist belt can be adjusted, and then the length of the waist belt bound on the waist part of the human body can be adjusted, and the stress condition of the waist part of the human body is changed; in the same way, the first buckle is connected with the shoulder belt in a sliding manner, the fourth buckle is connected with the second binding belt in a sliding manner, the binding length of the shoulder belt and the first binding belt on the front side of the human body can be adjusted, and the binding length of the shoulder belt and the second binding belt on the back side of the human body can be adjusted, so that the stress of the shoulder of the human body can be changed, the reasonable load distribution of the shoulder and the waist of the human body can be realized, the requirements of different heights and different waist load distribution proportions of the shoulder and the waist of the human body can be met, and the comfort of the shoulder of a user can be guaranteed.
3. The utility model provides a running constraint device under microgravity condition, the setting of V type shoulder pad on the shoulder band can reduce the pressure of human shoulder, reduces the oppression sense that the shoulder band led to the fact human shoulder, neck, improves user's travelling comfort.
4. The utility model provides a constraint device of running under microgravity condition, two shoulder pad arms of V type shoulder pad are configured to stride across human shoulder from the human back and extend to the human body openly, are equipped with the kink on the shoulder pad arm, and the contained angle of kink upside is configured to the appearance looks adaptation with human neck. The arrangement of the bending part on the shoulder pad arm can increase the opening radian of the pair of shoulder pad arms, so that the shoulder pad arms are better matched with the appearance of the neck of a human body, and the oppression feeling of the shoulder bridle on the neck of the human body is reduced.
5. The utility model provides a running binding device under microgravity condition, a pair of chest bridles are buckled through a seventh buckle and an eighth buckle, and a pair of shoulder bridles can transmit force through the chest bridles, so that better load distribution consistency of shoulders on both sides of a human body is ensured; moreover, the eighth buckle is slidably connected to one of the chest straps, so that the binding length of the two chest straps on the chest of the human body can be adjusted to meet the requirements of users with different chest circumferences.
6. The utility model provides a running constraint device under microgravity condition, chest band pass through the setting of thread slipping sliding connection in shoulder band, can further improve shoulder constraint structure and the human adaptability of different physiques, make the user can utilize the running constraint device to take exercise more comfortablely.
7. The utility model provides a running constraint device under microgravity condition, the waist constraint structure goes up the setting of bustle, can increase the lifting surface area of human waist, reduces the oppression sense that the waist band caused human waist, improves user's travelling comfort.
8. The utility model provides a restriction device of running under microgravity condition, the bustle of constituteing by left side liner district, middle liner district and right side liner district makes the bustle everywhere all can with human waist appearance looks adaptation, improve the comfort after the user wears.
9. The utility model provides a restriction device of running under microgravity condition is connected the back with stretching strap and treadmill, and the stretching strap can be through drawing the knot and exert pulling force to first constraint area and second constraint area to make the shoulder band can tie at human front and the back, balanced shoulder waistband load everywhere distributes, the exercise of running under the realization microgravity condition.
10. The utility model provides a running constraint device under microgravity condition, the mode that the bustle adopted flexible material to make can alleviate waistband and human contact interface's oppression sense, prevents skin friction damage, and sweat is soaked and is stayed the sweat that causes and pollute and the peculiar smell when preventing to run, improves running constraint device and uses the comfort.
In conclusion, the user can comfortably utilize the running restraint device to perform running exercise under the microgravity condition by increasing the stress area between the running restraint device and the human body, increasing the radian of the neck and increasing the height, the chest circumference and the waistline of the user.
Drawings
In order to more clearly illustrate the embodiments of the present invention or the technical solutions in the prior art, the drawings used in the embodiments or the technical solutions in the prior art will be briefly described below, and it is obvious that the drawings in the following description are some embodiments of the present invention, and for those skilled in the art, other drawings can be obtained according to these drawings without creative efforts.
Figure 1 is a front view of a person wearing a running restraint apparatus;
figure 2 is a back view of a person wearing the running restraint apparatus;
FIG. 3 is a right side view of a person wearing the running restraint apparatus;
fig. 4 is a schematic view of the overall structure of a shoulder restraint structure in the running restraint device according to the embodiment of the present invention;
fig. 5 is a front schematic view of a waist binding structure of the running binding device according to the embodiment of the present invention;
fig. 6 is a schematic structural view of a waist pad in the running restraint device according to the embodiment of the present invention;
fig. 7 is a schematic view of a connection structure of a sixth buckle on a waist belt according to an embodiment of the present invention.
Description of reference numerals: 11. a shoulder harness; 12. a first buckle; 13. a third buckle; 14. a V-shaped shoulder pad; 141. a shoulder pad arm; 142. a bending section; 15. a chest strap; 16. a seventh buckle; 17. an eighth buckle; 18. sliding and buckling; 21. a waist belt; 22. a first restraining strap; 23. a second restraining strip; 231. a first connecting branch belt; 232. a second connecting branch belt; 24. a second buckle; 25. a fourth buckle; 26. a fifth buckle; 27. a sixth buckle; 28. a waist pad; 281. a middle pad region; 282. a left side pad area; 283. a right side pad area; 29. a pull ring; 291. and a draw tape.
Detailed Description
The technical solution of the present invention will be described clearly and completely with reference to the accompanying drawings, and obviously, the described embodiments are some, but not all embodiments of the present invention. Based on the embodiments in the present invention, all other embodiments obtained by a person skilled in the art without creative work belong to the protection scope of the present invention.
In the description of the present invention, it should be noted that the terms "center", "upper", "lower", "left", "right", "vertical", "horizontal", "inner", "outer", and the like indicate orientations or positional relationships based on the orientations or positional relationships shown in the drawings, and are only for convenience of description and simplification of description, but do not indicate or imply that the device or element referred to must have a specific orientation, be constructed and operated in a specific orientation, and thus, should not be construed as limiting the present invention. Furthermore, the terms "first," "second," and "third" are used for descriptive purposes only and are not to be construed as indicating or implying relative importance.
In the description of the present invention, it is to be noted that, unless otherwise explicitly specified or limited, the terms "mounted," "connected," and "connected" are to be construed broadly, and may be, for example, fixedly connected, detachably connected, or integrally connected; can be mechanically or electrically connected; they may be connected directly or indirectly through intervening media, or they may be interconnected between two elements. The specific meaning of the above terms in the present invention can be understood in specific cases to those skilled in the art.
Furthermore, the technical features mentioned in the different embodiments of the invention described below can be combined with each other as long as they do not conflict with each other.
A running restraint apparatus under microgravity conditions, as shown in figures 1-7, includes a shoulder restraint structure and a waist restraint structure. Wherein the shoulder restraint structure comprises a pair of shoulder straps 11 configured to cross on the back of the human body and to span the shoulders of the human body; the waist restraining structure includes a waist belt 21 configured to be disposed around the waist of a human body and a pair of first straps 22 and a pair of second straps 23 connected to the waist belt 21. The first strap 22 is configured to be connected to one end of the shoulder strap 11 at the front of the person's body, and the second strap 23 is configured to be connected to the other end of the shoulder strap 11 at the back of the person's body.
The shoulder belt 11 is slidably connected to a portion of the front surface of the human body, and a first buckle 12 for adjusting a binding length of the shoulder belt 11 on the front surface of the human body is connected to the first strap 22, and a second buckle 24 adapted to be buckled to the first buckle 12 is connected to the first strap 22. The third buckle 13 is connected to the portion of the shoulder belt 11 disposed on the back of the human body, and the fourth buckle 25 adapted to be buckled with the third buckle 13 for adjusting the bound length of the second binding belt 23 on the back of the human body is slidably connected to the second binding belt 23. One end of the waist belt 21 is connected with a fifth buckle 26, and the other end is slidably connected with a sixth buckle 27 which is used for adjusting the binding length of the waist belt 21 and is suitable for being buckled with the fifth buckle 26.
When the running restraint device simulates running exercise under the microgravity condition, the fifth buckle 26 and the sixth buckle 27 at the two ends of the waist restraint are buckled, so that the waist belt 21 is restrained at the waist of a human body; the second buckles 24 on the two first straps 22 and the two first buckles 12 on the pair of crossed shoulder straps 11 are buckled on the front side of the human body, and the fourth buckles 25 on the two second straps 23 and the two third buckles 13 on the pair of crossed shoulder straps 11 are buckled on the back side of the human body, so that the pair of shoulder straps 11 are connected with the waist strap 21 and are tied on the shoulders of the human body; the shoulder and waist integrated running and restraining device can realize symmetrical longitudinal loading on two sides of a body and reasonable load body distribution thereof, so that muscle and skeleton systems of the trunk and the lower limbs of the human body bear corresponding loading loads, and the running exercise for resisting resistance is completed.
The running binding device can also be adaptively adjusted according to different heights, waistlines and chest circumferences of different human bodies. Specifically, as the fifth buckle 26 is slidably connected to the waist belt 21, the loading point of the fifth buckle 26 on the waist belt can be adjusted, so as to adjust the length of the waist belt 21 bound on the waist portion of the human body, and change the stress condition of the waist portion of the human body; similarly, the first buckle 12 is slidably connected to the shoulder strap 11, so as to adjust the binding length of the shoulder strap 11 and the first strap 22 on the front side of the human body; the fourth buckle 25 is slidably connected to the second binding belt 23, and can also adjust the binding length of the shoulder binding belt 11 and the second binding belt 23 on the back of the human body; the loading sites of the buckles are adjusted, so that the stress condition of the shoulders of a human body can be changed, reasonable load distribution of the shoulders and the waist of the human body is realized, the requirements of load distribution proportions of the shoulders and the waist of the human body with different heights and different waistlines are met, and the comfort of the shoulders of users is ensured.
For example, when adjusting the height, the fifth buckle 26 and the sixth buckle 27 at the two ends of the waist belt 21 are buckled, and the loading points of the first buckle 12 and the fourth buckle 25 are adjusted to extend or shorten the length of the shoulder belt 11 tied on the human body, so as to adapt to the requirements of users with different heights. When the waist circumference is adjusted, the loading point of the fifth buckle 26 on the waist belt 21 is adjusted, so that the length of the waist belt 21 bound on the waist part of the human body can be adjusted, and the requirements of users with different waist circumferences are met. In addition, the load distribution of the shoulders and the waist of the human body can be adjusted by adjusting the loading points of the first buckle 12, the fourth buckle 25 and the fifth buckle 26. For example, when it is desired to increase the force applied to the shoulder and decrease the force applied to the waist, the loading point of the fifth buckle 26 on the waist belt 21 is adjusted to loosen the waist belt 21 based on the constant total external force applied to the running restraint device, and the force applied to the waist is decreased while the force applied to the shoulder is increased. When the shoulder stress needs to be reduced and the waist stress needs to be increased, the loading point of the fifth buckle 26 on the waist belt 21 is adjusted to tighten the waist belt 21, so that the waist stress is increased and the shoulder stress is reduced.
In this embodiment, the shoulder restraint structure further includes a V-shaped shoulder pad 14 configured to fit the shoulder of the human body, and a pair of shoulder straps 11 are connected to the outer side of the V-shaped shoulder pad 14 facing away from the human body. The V-shaped shoulder pad 14 on the shoulder belt 11 can reduce the pressure of the shoulders of the human body, reduce the oppressive feeling of the shoulder belt 11 to the shoulders and the neck of the human body, and improve the comfort of the user. Specifically, the whole pad of the V-shaped shoulder pad 14 is filled with a breathable and sweat-resistant high-strength material, and the whole soft material edge covering design is performed, so that the comfort of the shoulder and the neck of a user is ensured.
In the present embodiment, the two shoulder pad arms 141 of the V-shaped shoulder pad 14 are configured to extend from the back of the human body to the front of the human body across the shoulders of the human body, the shoulder pad arms 141 are provided with the bending part 142, and the included angle of the upper side of the bending part 142 is configured to fit the shape of the neck of the human body. The V-shaped shoulder pad 14 and the pair of shoulder straps 11 of the shoulder binding structure are symmetrically arranged along the symmetry line of the human body. Preferably, the angle between the pair of shoulder straps 11 is 80 degrees, and the bending angle of the bending part 142 of the V-shaped shoulder pad 14 is 150 degrees. The arrangement of the bending part 142 on the shoulder pad arm 141 can increase the opening radian of the pair of shoulder pad arms 141, so that the shoulder pad arms 141 can be better matched with the shape of the neck of a human body, and the oppression feeling of the shoulder strap 11 on the neck of the human body is reduced.
In the present embodiment, the pair of shoulder straps 11 are respectively connected with chest straps 15 disposed on the front chest of the human body, one of the chest straps 15 is connected with a seventh buckle 16, and the other chest strap 15 is slidably connected with an eighth buckle 17 for adjusting the bound length of the pair of chest straps 15 on the front chest of the human body and adapted to be buckled with the seventh buckle 16. The pair of chest bridles 15 are buckled through a seventh buckle 16 and an eighth buckle 17, and the action of force can be transmitted between the pair of shoulder bridles 11 through the chest bridles 15, so that the better load distribution consistency of the shoulders on the two sides of the human body is ensured; moreover, the eighth buckle 17 is slidably connected to one of the chest belts 15, so that the binding length of the two chest belts 15 on the chest of the human body can be adjusted to meet the requirements of users with different chest circumferences.
Further, a slide fastener 18 is slidably connected to the shoulder belt 11, and one end of the chest belt 15 is connected to the slide fastener 18. And the extension direction of the chest strap 15 is perpendicular to the extension direction of the shoulder straps 11 and is extended toward a space between the pair of shoulder straps 11. The design of the chest strap 15 slidably connected to the shoulder strap 11 through the slide fastener 18 can further improve the adaptability of the shoulder binding structure to different body sizes, so that the user can exercise more comfortably with the running binding device.
In this embodiment, the waist restraining structure further comprises a waist pad 28 configured to fit the waist of the human body, and the waist belt 21, the first and second straps 22 and 23 are connected to the outer side of the waist pad 28 facing away from the human body. And the waist belt 21 is bound to the outside of the first and second straps 22 and 23 for pressing the first and second straps 22 and 23 against the lumbar pad 28. The waist pad 28 can increase the stress area between the waist binding structure and the waist of the human body, reduce the oppression feeling of the waist belt 21 to the waist of the human body, and improve the comfort of the user.
Specifically, the lumbar pad 28 includes a middle pad region 281 and left and right pad regions 282 and 283 symmetrically disposed on opposite sides of the middle pad region 281. Wherein the middle pad region 281 is configured to fit the human back lumbar spinal region; the left side pad area 282 is configured to fit the left lumbar region of the human body; the right side pad region 283 is configured to fit the right waist region of the human body; the left pad area 282, the middle pad area 281, and the right pad area 283 are formed by dividing with sewing thread. The waist pad 28 consisting of the left pad area 282, the middle pad area 281 and the right pad area 283 ensures that all parts of the waist pad 28 can be matched with the shape of the waist of a human body, thereby improving the comfort of a user after wearing.
In this embodiment, bustle 28 adopts soft material to make, bustle 28 is the same with V type shoulder pad 14, whole liner adopts ventilative, anti-sweat high strength's material as the packing, and whole soft material design of borduring has been carried out, the surface fabric adopts and has waterproof, antifouling and wear-resisting high strength PVC PU surface fabric, can alleviate the oppression sense of waistband and human contact interface, prevent skin friction damage, sweat pollution and peculiar smell that sweat ingression and storage caused when preventing to run use the comfort, improve the binding device of running and use the comfort.
In this embodiment, one end of the first strap 22 is fixedly connected to the lumbar pad 28, the other end is connected to the pull ring 29, and the second buckle 24 is slidably connected to the first strap 22. The second restraining band 23 includes a first connecting brace 231 connected with the pull ring 29 and a second connecting brace 232 fixedly connected with the lumbar pad 28. Preferably, the first binding band 22 and the first connecting branch band 231 are formed by winding the same binding band on the pull ring 29, and the second connecting branch band 232 and the first connecting branch band 231 are also formed by folding the same binding band around a rotating shaft at a certain angle. Also attached to the pull ring 29 is a pull strap 291 adapted for attachment to a treadmill for applying a pulling force to the first and second straps 22, 23. After the pull belt 291 is connected with the treadmill, the pull belt 291 can apply pulling force to the first and second straps 22 and 23 through a pull buckle, so that the shoulder straps 11 can be bound on the front and back of the human body, the load distribution at each position of the shoulder belt is balanced, and the running exercise under the microgravity condition is realized.
In summary, the running restraint device under microgravity condition provided by the embodiment of the invention can make the user comfortably utilize the running restraint device to perform running exercise under microgravity condition by increasing the stress area between the running restraint device and the human body, increasing the neck radian and increasing the adjustment measures of height, chest circumference and waist circumference.
It should be understood that the above examples are only for clarity of illustration and are not intended to limit the embodiments. Other variations and modifications will be apparent to persons skilled in the art in light of the above description. And are neither required nor exhaustive of all embodiments. And obvious variations or modifications can be made without departing from the scope of the invention.
