CN212354712U

CN212354712U - Split wine box

Info

Publication number: CN212354712U
Application number: CN202020880080.5U
Authority: CN
Inventors: 秦文恒; 卢明
Original assignee: Shandong Variety Lian Packaging Ltd By Share Ltd
Current assignee: Shandong Variety Lian Packaging Ltd By Share Ltd
Priority date: 2020-05-23
Filing date: 2020-05-23
Publication date: 2021-01-15
Anticipated expiration: 2030-05-23

Abstract

The utility model relates to a to open wine box, the rectangle frame is established to beverage bottle lower part cover, and rectangle frame lower part cover is established the casing, places at the bottom of the bottle on the beverage bottle the casing bottom, bottom plate A is established to the piece of falling U A inside wall left end, and bottom plate A lower extreme is articulated with casing left side wall upper end, and the piece of falling U B lateral wall left part is fixed with the piece of falling U A inside wall right part, and backup pad A left end is fixed with bottom plate A right side wall upper portion, and convex recess A is seted up to backup pad A right part, and bottom plate B is established to the piece of falling U C inside wall right-hand member, and bottom plate B lower extreme is articulated with casing right side wall upper end, and backup pad B right-hand member is fixed with bottom plate B left side wall upper portion, and convex recess B is seted up to backup pad B left part. The utility model has the advantages that: the wine box satisfies people's hunting psychology and can achieve the purpose of enlarging the liquor sales.

Description

Split wine box

Technical Field

The utility model relates to a wine box especially relates to a to open wine box.

Background

The main components of the white spirit are glycol and water, people endow the white spirit with cultural and emotional values, the white spirit is divided into three, six and nine parts, and the like, a good wine bottle can improve the price of the white spirit, the wine bottle needs to be put into a wine box in order to prevent the wine bottle from being broken in the process of carrying the white spirit, and the existing wine box cannot meet the hunting psychology of people and cannot enlarge the sales volume of the white spirit.

SUMMERY OF THE UTILITY MODEL

The utility model discloses the technical problem that will solve is: the utility model provides a to open wine box, has solved current wine box and can not satisfy people's the thoughts psychology of hunting, can not enlarge the problem of white spirit sales volume.

The utility model discloses a solve the technical scheme that the problem that the aforesaid provided adopted and be:

a split wine box comprises a shell 1, a rectangular frame 2, a connecting assembly A3, an inverted U-shaped piece B4, a supporting plate A5, an arc-shaped groove A501, a rope A6, a connecting assembly B7, a supporting plate B8, an arc-shaped groove B801, a wine bottle 9, a bottle bottom 901, a bottle neck 902 and a rope B10, wherein the rectangular frame 2 is sleeved on the lower portion of the wine bottle 9, the shell 1 is sleeved on the lower portion of the rectangular frame 2, the bottle bottom 901 on the wine bottle 9 is placed at the bottom of the shell 1, the connecting assembly A3 is hinged on the upper portion of the shell 1, the connecting assembly A3 comprises an inverted U-shaped piece A301 and a bottom plate A302, the bottom plate A302 is fixedly arranged on the left end of the inner side wall of the inverted U-shaped piece A301, the lower end of the bottom plate A302 is hinged to the upper end of the left side wall of the shell 1, the inverted U-shaped piece A301 is in clearance fit with the adjacent left side wall of the upper portion of the rectangular frame 2, the supporting plate A5 is in clearance fit with the inverted U-shaped piece B4, the right part of the supporting plate A5 is provided with an arc-shaped groove A501, the upper part of the shell 1 is hinged with a connecting component B7, the connecting component B7 comprises an inverted U-shaped piece C701 and a bottom plate B702, the bottom plate B702 is fixedly arranged at the right end of the inner side wall of the inverted U-shaped piece C701, the lower end of the bottom plate B702 is hinged with the upper end of the right side wall of the shell 1, the inverted U-shaped piece C701 is in clearance fit with the adjacent right side of the upper part of the rectangular frame 2, the right part of the outer side wall of the inverted U-shaped piece B4 is in clearance fit with the left part of the inner side wall of the inverted U-shaped piece C701, the right end of the supporting plate B8 is fixedly connected with the upper part of the left side wall of the bottom plate B702, the supporting plate B8 is in clearance fit with the adjacent inverted U-shaped piece B4, the left part of the supporting plate B8 is provided with an arc-shaped groove B801, and the bottle neck 902 is in clearance fit with the adjacent arc-shaped groove A501 on the supporting plate A5 and the adjacent arc-shaped groove B801 on the supporting plate B8.

The lower part of the inner side of the rectangular frame 2 is provided with a connecting component C11, the connecting component C11 comprises an annular plate 1101 and a supporting plate C1102, the annular plate 1101 is sleeved outside the bottle bottom 901, the bottle bottom 901 is in clearance fit with the annular plate 1101, the supporting plate C1102 is respectively fixedly arranged on the left part and the right part of the lower surface of the annular plate 1101, the supporting plate C1102 is positioned at the bottom of the shell 1, and the connecting component C11 prevents the bottle bottom 901 from shaking.

The left side of the upper part of the inverted U-shaped piece C701 is provided with a plug 12, the plug 12 sequentially penetrates through the adjacent inverted U-shaped piece C701 and the inverted U-shaped piece B4, the plug 12 is in sliding connection with the inverted U-shaped piece C701 and the inverted U-shaped piece B4, and the plug 12 fixes a connecting assembly A3 and a connecting assembly B7.

The upper end of the plug 12 is fixedly provided with a string C13 for facilitating the extraction of the plug 12 through the string C13.

The utility model discloses a theory of operation: the casing is established to rectangle frame lower part cover, coupling assembling C is put in the inside casing bottom of downside of rectangle frame, the beverage bottle is placed in the casing bottom, the outside cover is established at the bottom of the bottle at the annular slab, clockwise rotation coupling assembling A, anticlockwise rotation coupling assembling B, convex recess A in the backup pad A, it is spacing to the bottleneck with convex recess B in the backup pad B, the U-shaped piece C left part is inserted to the U-shaped piece B right part that falls, insert adjacent U-shaped piece C to the stopper, U-shaped piece B falls, the mode of opening is, hand gripping rope C, rope C drives the stopper and keeps away from U-shaped piece C, U-shaped piece B falls, anticlockwise rotation coupling assembling A, the distance that rope A restriction coupling assembling A opened, clockwise rotation coupling assembling B, the distance that rope B restriction coupling assembling B opened.

The beneficial effects of the utility model reside in that: 1. the wine box satisfies people's hunting psychology and can achieve the purpose of enlarging the liquor sales. 2. Place coupling assembling C in the inboard lower part of rectangle frame, coupling assembling C includes annular slab, backup pad C, and the annular slab is established to the outside cover at the bottom of the bottle, just at the bottom of the bottle with annular slab clearance fit, the annular slab lower surface left and right parts do not fixedly set up backup pad C, just backup pad C is located casing bottom, coupling assembling C prevent at the bottom of the bottle from shaking. 3. The left side of the upper portion of the inverted U-shaped piece C is provided with a plug, the plug sequentially penetrates through the inverted U-shaped piece C and the inverted U-shaped piece B, the plug is connected with the inverted U-shaped piece C and the inverted U-shaped piece B in a sliding mode, and the plug is fixedly connected with the connecting assembly A and the connecting assembly B. 4. The upper end of the plug is fixedly provided with a rope C, so that the plug can be conveniently drawn out through the rope C.

Drawings

Fig. 1 is a schematic structural diagram of the present invention;

fig. 2 is a schematic structural diagram of the housing of the present invention;

fig. 3 is a top view of the housing of the present invention;

FIG. 4 is a schematic structural diagram of a rectangular frame of the present invention;

fig. 5 is a top view of the rectangular frame of the present invention;

fig. 6 is a schematic structural view of the connection assembly a of the present invention;

fig. 7 is a side view of the connection assembly a of the present invention;

fig. 8 is a schematic structural view of the connection assembly B of the present invention;

fig. 9 is a side view of the connection assembly B of the present invention;

fig. 10 is a schematic structural view of the connection assembly a and the connection assembly B of the present invention after being opened;

fig. 11 is a schematic structural view of the connecting assembly C of the present invention being placed in the housing;

fig. 12 is a schematic structural view of the connection assembly C of the present invention;

fig. 13 is a schematic structural diagram of the stopper of the present invention.

The device comprises a shell 1, a rectangular frame 2, a connecting assembly A3, an inverted U-shaped piece A301, a bottom plate A302, an inverted U-shaped piece B4, a support plate A5, an arc-shaped groove A501, a rope A6, an connecting assembly B7, an inverted U-shaped piece C701, a bottom plate B702, a support plate B8, an arc-shaped groove B801, a wine bottle 9, a bottle bottom 901, a bottle neck 902, a rope B10, a connecting assembly C11, an annular plate 1101, a support plate C1102, a stopper 12 and a rope C13.

Detailed Description

The embodiments of the present invention will be further explained with reference to the drawings.

Referring to fig. 1-13, a split wine box according to this embodiment includes a case 1, a rectangular frame 2, a connecting assembly A3, an inverted U-shaped member B4, a supporting plate A5, an arc-shaped groove a501, a string A6, a connecting assembly B7, a supporting plate B8, an arc-shaped groove B801, a wine bottle 9, a bottle bottom 901, a bottle neck 902, and a string B10, the rectangular frame 2 is sleeved on a lower portion of the wine bottle 9, the bottle bottom 901 of the wine bottle 9 is placed on a bottom of the case 1, the connecting assembly A3 is hinged on an upper portion of the case 1, the connecting assembly A3 includes an inverted U-shaped member a301 and a bottom plate a302, a bottom plate a302 is fixed to a left end of an inner side wall of the inverted U-shaped member a301, a lower end of the bottom plate a302 is hinged to an upper end of a left side wall of the case 1, the inverted U-shaped member a301 is in clearance fit with an adjacent upper portion of the rectangular frame 2, a 36, backup pad A5 left end with bottom plate A302 right side wall upper portion fixed connection, just backup pad A5 with fall U-shaped spare B4 clearance fit, arc recess A501 is seted up to backup pad A5 right part, and articulated coupling assembling B7 in casing 1 upper portion, coupling assembling B7 is including falling U-shaped spare C701, bottom plate B702, and fall U-shaped spare C701 inside wall right-hand member fixed set up bottom plate B702, bottom plate B702 lower extreme with casing 1 right side wall upper end is articulated, fall U-shaped spare C701 and adjacent rectangle frame 2 upper portion right side clearance fit, fall U-shaped spare B4 outside wall right part with fall U-shaped spare C701 inside wall left part clearance fit, backup pad B8 right-hand member with bottom plate B702 left side wall upper portion fixed connection, just backup pad B8 with adjacent fall U-shaped spare B4 clearance fit, backup pad B8 left part sets up arc recess B801, bottleneck 902 and adjacent arc recess A501 on backup pad A5, The circular arc-shaped groove B801 on the support plate B8 is in clearance fit.

The working principle of the specific embodiment is as follows: the casing is established to rectangle frame lower part cover, coupling assembling C is put in the inside casing bottom of downside of rectangle frame, the beverage bottle is placed in the casing bottom, the outside cover is established at the bottom of the bottle at the annular slab, clockwise rotation coupling assembling A, anticlockwise rotation coupling assembling B, convex recess A in the backup pad A, it is spacing to the bottleneck with convex recess B in the backup pad B, the U-shaped piece C left part is inserted to the U-shaped piece B right part that falls, insert adjacent U-shaped piece C to the stopper, U-shaped piece B falls, the mode of opening is, hand gripping rope C, rope C drives the stopper and keeps away from U-shaped piece C, U-shaped piece B falls, anticlockwise rotation coupling assembling A, the distance that rope A restriction coupling assembling A opened, clockwise rotation coupling assembling B, the distance that rope B restriction coupling assembling B opened.

The utility model discloses a concrete embodiment does not constitute the pair the utility model discloses a restriction, all adopt the utility model discloses a similar structure and change are all in the utility model discloses a within the protection scope.

Claims

1. The utility model provides a to open wine box which characterized in that: comprises a shell (1), a rectangular frame (2), a connecting assembly A (3), an inverted U-shaped piece B (4), a support plate A (5), an arc-shaped groove A (501), a rope A (6), a connecting assembly B (7), a support plate B (8), an arc-shaped groove B (801), a wine bottle (9), a bottle bottom (901), a bottle neck (902) and a rope B (10), wherein the rectangular frame (2) is sleeved on the lower part of the wine bottle (9), the shell (1) is sleeved on the lower part of the rectangular frame (2), the bottle bottom (901) on the wine bottle (9) is placed at the bottom of the shell (1), the upper part of the shell (1) is hinged with the connecting assembly A (3), the connecting assembly A (3) comprises an inverted U-shaped piece A (301) and a bottom plate A (302), the left end of the inner side wall of the inverted U-shaped piece A (301) is fixedly provided with the bottom plate, the inverted U-shaped part A (301) is in clearance fit with the upper left side of the adjacent rectangular frame (2), the outer side wall left part of the inverted U-shaped part B (4) is fixedly connected with the inner side wall right part of the inverted U-shaped part A (301), the left end of the support plate A (5) is fixedly connected with the upper part of the right side wall of the bottom plate A (302), the support plate A (5) is in clearance fit with the inverted U-shaped part B (4), the right part of the support plate A (5) is provided with an arc-shaped groove A (501), the upper part of the shell (1) is hinged with a connecting component B (7), the connecting component B (7) comprises an inverted U-shaped part C (701) and a bottom plate B (702), the right end of the inner side wall of the inverted U-shaped part C (701) is fixedly provided with the bottom plate B (702), the lower end of the bottom plate B (702) is hinged with the upper end of the right side wall of the shell, inverted U-shaped piece B (4) lateral wall right part with inverted U-shaped piece C (701) inside wall left part clearance fit, backup pad B (8) right-hand member with bottom plate B (702) left side wall upper portion fixed connection, just backup pad B (8) and adjacent inverted U-shaped piece B (4) clearance fit, convex recess B (801) are seted up to backup pad B (8) left part, bottleneck (902) and adjacent convex recess A (501) on backup pad A (5), convex recess B (801) clearance fit on backup pad B (8).

2. The split wine box of claim 1, wherein: rectangular frame (2) inboard lower part place coupling assembling C (11), coupling assembling C (11) include annular plate (1101), backup pad C (1102), and annular plate (1101) is established to bottle end (901) outside cover, just bottle end (901) with annular plate (1101) clearance fit, the left and right part of annular plate (1101) lower surface is fixed backup pad C (1102) that sets up respectively, just backup pad C (1102) are located casing (1) bottom.

3. The split wine box of claim 1, wherein: the left side of the upper portion of the inverted U-shaped piece C (701) is provided with a plug (12), the plug (12) penetrates through the inverted U-shaped piece C (701) and the inverted U-shaped piece B (4) in sequence, and the plug (12) is connected with the inverted U-shaped piece C (701) and the inverted U-shaped piece B (4) in a sliding mode.

4. The split wine box of claim 3, wherein: the upper end of the plug (12) is fixedly provided with a rope C (13).
