Abstract

The utility model relates to the technical field of metal silicon, and discloses a conveyor belt type silicon mud drying device, which comprises a main box, and four threaded connection plates are fixed at the bottom of the main box. The bottom is fixedly connected with a support rod. In the conveyor belt type silicon mud drying device, by setting the drive wheel inside the main box and the motor turning block outside the main box, the conveyor belt between the two drive wheels can be driven to connect the metal silicon, so as to achieve the purpose of easy operation of the device. Set the reaction box at the top of the main box to connect the lift pump and the control box, and set the telescopic outer rod at the bottom of the lift pump to slide and connect the heating box, so as to achieve the purpose of lifting the heating box. The generated heat source is not easily lost. By setting the heating box fixedly connected on the front of the main box, the operation level of the recording device is achieved, and the purpose of informing the staff through the speaker is convenient for the user to use.

Description

A conveyor belt type silicon mud drying device

technical field

The utility model relates to the technical field of metal silicon, in particular to a conveyor belt type silicon mud drying device.

Background technique

Metal silicon, also known as crystalline silicon or industrial silicon, is mainly used as an additive for non-ferrous alloys. Metal silicon is a product smelted by quartz and coke in an electric heating furnace. The content of the main component silicon is about 98%, and the rest Impurities are iron, aluminum and calcium.

With the development of science and technology and the progress of people's life, people's requirements for the convenience of industrial production are getting higher and higher. The previous metal silicon drying device was placed manually, which caused people to be unable to quickly dry the device when using it, thus affecting production. Therefore, a conveyor belt type silicon mud drying device is proposed to solve this problem.

Utility model content

(1) Technical problems solved

In view of the deficiencies of the prior art, the utility model provides a conveyor belt type silicon mud drying device, which has the advantages of being transported by a motor and can be quickly dried, and solves the problem that the device cannot be dried quickly, thereby affecting the efficiency of production. The problem.

(2) Technical solutions

In order to realize the purpose of the above-mentioned motor-driven transportation and fast drying device, the utility model provides the following technical solution: a conveyor belt type silicon mud drying device, including a main box, the bottom of the main box is fixed with a number of four. There are two threaded connection plates, the bottom of the threaded connection plate is fixedly connected with a support rod, the front of the main box is fixedly connected with an alarm box, and the interior of the main box is rotatably connected with two transmission wheels. The front side of the transmission wheel is rotatably connected with a motor turning block that runs through the main box and extends to the outside of the front side of the main box, a conveyor belt is rotatably connected between the two transmission wheels, and a reaction box is fixedly connected to the top of the main box, so the The left and right sides of the reaction box are fixedly connected with a lift control box, the bottom of the lift control box is fixedly connected with a heat shield, the top of the reaction box is fixedly connected with a lift pump, and the top of the reaction box is located in the lift The front of the pump is fixedly connected with a control box, the bottom plate of the lift pump is fixedly connected with a telescopic outer rod that penetrates through the reaction box and extends to the inside of the reaction box, the bottom of the telescopic outer rod is slidably connected with a heating box, and the heating box is slidably connected to the bottom of the heating box. A heating connecting ring is fixedly connected inside, a heating net is fixedly connected inside the heating connecting ring, and a heat-reflecting mirror is fixedly connected to the bottom wall of the inner cavity of the heating box.

Preferably, the main box is composed of a support plate at the bottom and two splints at the top, and the distance between the two splints is equal to the length of the transmission wheel, and the main box and the threaded connection plate are fixedly connected by screws.

Preferably, the support rod is composed of a top connecting rod and a bottom support seat, and the bottom of the support seat is provided with evenly distributed anti-skid grooves, and the connecting rod and the support seat are connected by welding.

Preferably, the transmission wheel is composed of a middle connecting cylinder and two sides of the clamping plate, and the distance between the two clamping plates and the connecting cylinder are connected by welding, and the front side of the right transmission wheel is fixedly connected with a transition rod.

Preferably, the reaction box is in the shape of a square box, and the top of the reaction box is provided with a circular hole with a diameter equal to the diameter of the telescopic outer rod, and the connection between the lift pump and the main box is welding.

Preferably, the heating box is composed of a square box at the bottom and a telescopic inner rod at the top, and the bottom of the square box is provided with a square groove, and the connection between the telescopic inner rod and the square box is welding.

(3) Beneficial effects

Compared with the prior art, the utility model provides a conveyor belt type silicon mud drying device, which has the following beneficial effects:

In the conveyor belt type silicon mud drying device, by setting the driving wheel inside the main box and the motor turning block outside the main box, the conveyor belt between the two driving wheels can be driven to connect the metal silicon, so as to achieve the purpose of easy operation of the device. Set the reaction box at the top of the main box to connect the lift pump and the control box, and set the telescopic outer rod at the bottom of the lift pump to slide and connect the heating box, so as to achieve the purpose of lifting the heating box. The generated heat source is not easily lost. By setting the heating box fixedly connected on the front of the main box, the operation level of the recording device is achieved, and the purpose of informing the staff through the speaker is convenient for the user to use.

Description of drawings

Fig. 1 is the structural representation of the utility model;

Fig. 2 is the side sectional view of the reaction box of the utility model;

Fig. 3 is a partial enlarged schematic view of part A in Fig. 2 of the present invention.

In the picture: 1 main box, 2 threaded connection plates, 3 support rods, 4 alarm boxes, 5 transmission wheels, 6 motor rotating blocks, 7 conveyor belts, 8 reaction boxes, 9 lift control boxes, 10 heat shields, 11 lift pumps, 12 control box, 13 telescopic outer rod, 14 heating box, 15 heating connecting ring, 16 heating net, 17 anti-heat mirror.

Detailed ways

The technical solutions in the embodiments of the present utility model will be clearly and completely described below with reference to the accompanying drawings in the embodiments of the present utility model. Obviously, the described embodiments are only a part of the embodiments of the present utility model, rather than all the implementations. example. Based on the embodiments of the present invention, all other embodiments obtained by those of ordinary skill in the art without creative work fall within the protection scope of the present invention.

Please refer to Figure 1-3, a conveyor belt type silicon mud drying device, including a main box 1, the main box 1 is composed of a support plate at the bottom and two clamping plates at the top, and the distance between the two clamping plates is the same as that of the transmission wheel. 5 are equal in length, and the main box 1 and the threaded connection plate 2 are fixedly connected by screw nails, the bottom of the main box 1 is fixed with four threaded connection plates 2, and the bottom of the threaded connection plate 2 is fixedly connected with a support rod 3, The support rod 3 consists of a connecting rod at the top and a support seat at the bottom, and the bottom of the support seat is provided with evenly distributed anti-skid grooves, and the connection between the connecting rod and the support seat is welding, and the front of the main box 1 is fixedly connected with an alarm box 4. There are two transmission wheels 5 connected in rotation inside the main box 1. The transmission wheel 5 is composed of a connecting cylinder in the middle and a splint on both sides, and the distance between the two splints and the connecting cylinder is welded. The front side of the side drive wheel 5 is fixedly connected with a transition rod, the front side of the right side drive wheel 5 is rotatably connected with a motor turning block 6 that penetrates through the main box 1 and extends to the outside of the front side of the main box 1, and the two transmission wheels 5 are rotatably connected. There is a conveyor belt 7, a reaction box 8 is fixedly connected to the top of the main box 1, the reaction box 8 is in the shape of a square box, and the top of the reaction box 8 is provided with a circular hole with a diameter equal to the diameter of the telescopic outer rod 13, and the lift pump 11 is connected to the main box. The connection mode of the box 1 is welding, the left and right sides of the reaction box 8 are fixedly connected with a lift control box 9, the bottom of the lift control box 9 is fixedly connected with a heat shield 10, and the top of the reaction box 8 is fixedly connected with a lift pump 11, A control box 12 is fixedly connected to the top of the reaction box 8 and located on the front of the lift pump 11 , and a telescopic outer rod 13 that penetrates the reaction box 8 and extends to the interior of the reaction box 8 is fixedly connected to the bottom plate of the lift pump 11 , and the bottom of the telescopic outer rod 13 is fixedly connected. A heating box 14 is slidably connected, and the heating box 14 is composed of a square box at the bottom and a telescopic inner rod at the top, and a square groove is opened at the bottom of the square box, and the connection between the telescopic inner rod and the square box is welding, and the heating box 14 A heating connection ring 15 is fixedly connected inside the heating connection ring 15, a heating net 16 is fixedly connected to the inside of the heating connection ring 15, and a heat-reflecting mirror 17 is fixedly connected to the bottom wall of the inner cavity of the heating box 14. The motor turning block 6 outside the main box 1 can drive the conveyor belt 7 between the two transmission wheels 5 to connect the metal silicon, so as to achieve the purpose of facilitating the operation of the device. By setting the reaction box 8 on the top of the main box 1, the lift pump 11 and The control box 12 is slidably connected to the heating box 14 by setting the telescopic outer rod 13 at the bottom of the lifting pump 11 to achieve the purpose of lifting and lowering the heating box 14. It is not easy to lose the effect. By setting the heating box 14 fixedly connected on the front of the main box 1, the operation level of the recording device is achieved, and the purpose of informing the staff through the speaker is convenient for the user to use.

To sum up, in this conveyor belt type silicon mud drying device, by arranging the driving wheel 5 inside the main box 1 and the motor turning block 6 outside the main box 1, the conveyor belt 7 between the two driving wheels 5 can be connected in a driving manner. Metal silicon, to achieve the purpose of facilitating the operation of the device, by setting the reaction box 8 on the top of the main box 1 to connect the lift pump 11 and the control box 12, and by setting the telescopic outer rod 13 at the bottom of the lift pump 11 to slide and connect the heating box 14, so as to achieve heat generation The purpose of lifting and lowering the box 14, by setting the heat-reflecting mirror 17 inside the heating box 14, the effect of making the heat source generated by the heating net 16 not easy to lose, by setting the heating box 14 fixedly connected on the front of the main box 1, to achieve the recording device operation level, The purpose of informing the staff through the horn facilitates the use of the user, and solves the problem that the device cannot be dried quickly, thereby affecting the production efficiency.

Although the embodiments of the present invention have been shown and described, it will be understood by those skilled in the art that various changes and modifications can be made to these embodiments without departing from the principles and spirit of the present invention , alternatives and modifications, the scope of the present invention is defined by the appended claims and their equivalents.

Claims (6)

1. A conveyor belt type silicon mud drying device, comprising a main box (1), characterized in that: the bottom of the main box (1) is fixed with four threaded connection plates (2) in number, and the thread The bottom of the connecting plate (2) is fixedly connected with a support rod (3), the front of the main box (1) is fixedly connected with an alarm box (4), and the internal rotation connection of the main box (1) is two in number. The front side of the transmission wheel (5) on the right side is rotatably connected with a motor turning block (6) that runs through the main box (1) and extends to the outside of the front of the main box (1). The two transmission wheels A conveyor belt (7) is rotatably connected between (5), a reaction box (8) is fixedly connected to the top of the main box (1), and a lift control box is fixedly connected to the left and right sides of the reaction box (8). (9), the bottom of the lift control box (9) is fixedly connected with a heat shield (10), the top of the reaction box (8) is fixedly connected with a lift pump (11), and the top of the reaction box (8) is fixedly connected with a lift pump (11). A control box (12) is fixedly connected to the top and located at the front of the lift pump (11), and the bottom plate of the lift pump (11) is fixedly connected to a telescopic outer rod that penetrates the reaction box (8) and extends to the interior of the reaction box (8). (13), a heating box (14) is slidably connected to the bottom of the telescopic outer rod (13), and a heating connecting ring (15) is fixedly connected to the inside of the heating box (14), and the heating connecting ring (15) A heating net (16) is fixedly connected to the inside of the heating box (14), and a heat-reflecting mirror (17) is fixedly connected to the bottom wall of the inner cavity of the heating box (14). 2. A conveyor belt type silicon mud drying device according to claim 1, characterized in that: the main box (1) is composed of a support plate at the bottom and a plywood with two plywoods at the top, and the two plywood The distance between them is equal to the length of the transmission wheel (5), and the main box (1) and the threaded connection plate (2) are fixedly connected by screw nails. 3. A conveyor belt type silicon mud drying device according to claim 1, characterized in that: the support rod (3) is composed of a connecting rod at the top and a support seat at the bottom, and the bottom of the support seat is provided with Evenly distributed anti-skid grooves, and the connection between the connecting rod and the support seat is welding. 4. A conveyor belt type silicon mud drying device according to claim 1, characterized in that: the drive wheel (5) is composed of a connecting cylinder in the middle and a plywood on both sides, and the distance between the two plywood is the same as the distance between the two plywood. The connection method of the connecting cylinder is welding, and a transition rod is fixedly connected to the front of the right transmission wheel (5). 5. A conveyor belt type silicon mud drying device according to claim 1, characterized in that: the reaction box (8) is in the shape of a square box, and the top of the reaction box (8) is provided with a diameter and a telescopic outer The rods (13) are round holes with the same diameter, and the connection between the lift pump (11) and the main box (1) is welding. 6. A conveyor belt type silicon mud drying device according to claim 1, characterized in that: the heating box (14) is composed of a square box at the bottom and a telescopic inner rod at the top, and the bottom of the square box is opened There is a square groove, and the connection between the telescopic inner rod and the square box is welding.
