Abstract
The utility model provides a multifunctional desk for a computer, which comprises a desk plate, a rotatable bookshelf structure, a pen cup, a notebook heat dissipation mesh plate structure, a desk plate inner groove, an adjustable auxiliary desk plate structure, a rear support plate, a rear base, an inverted L-shaped fixed plate, a front base, a host placing box cover, a hinge, a front support plate, an L-shaped slider, a sliding groove, a drawer and a case fan, wherein the screw is connected to the upper parts of the front support plate and the rear support plate; the rotatable bookshelf structure screw is connected to the upper left side of the desk plate; the inner groove of the table plate is formed in the right side of the table plate; the adjustable auxiliary table plate structure is connected to the right side of the groove in the table plate through bolts. The utility model discloses in supplementary table, internal thread hole, adjusting bolt, the setting of auxiliary stay board and auxiliary base is favorable to carrying out the extension of desktop down when needing, increases area of use's effect.
Description
Technical Field
The utility model relates to a computer correlation equipment field, in particular to multi-functional table for computer.
Background
With the continuous acceleration of the modernization process of the society, computers become an indispensable part of people's work and life, and when the computer is used, the computer is generally applied to computer desks.
But the current desk desktop is not convenient for adjust, and the computer heat dissipation is not convenient, and the bookshelf uses inconvenient problem.
Therefore, it is necessary to invent a multifunctional table for a computer.
SUMMERY OF THE UTILITY MODEL
In order to solve the technical problem, the utility model provides a multifunctional desk for computer, current desk desktop is not convenient for adjust, and the computer heat dissipation is not convenient, and the bookshelf uses inconvenient problem. A multifunctional desk for a computer comprises a desk plate, a rotatable bookshelf structure, a pen cup, a notebook computer heat dissipation mesh plate structure, a desk plate inner groove, an adjustable auxiliary desk plate structure, a rear support plate, a rear base, an inverted L-shaped fixing plate, a front base, a host computer placing box cover, hinges, a front support plate, an L-shaped sliding block, a sliding groove, a drawer and a case fan, wherein the desk plate is connected to the upper parts of the front support plate and the rear support plate through screws; the rotatable bookshelf structure screw is connected to the upper left side of the desk plate; the notebook heat dissipation mesh plate structure is connected to the right side of the upper part of the desk plate through screws; the pen cup is placed inside the right side of the rotatable bookshelf structure; the inner groove of the table plate is formed in the right side of the table plate; the adjustable auxiliary table plate structure is connected to the right side of the inner groove of the table plate through bolts; the rear base is glued to the lower part of the rear support plate; the left side of the inverted L-shaped fixing plate is connected to the right side of the lower part of the front supporting plate through a bolt, and the upper end of the inverted L-shaped fixing plate is connected to the left side of the bottom of the host placing box through a bolt; the front base is glued to the lower part of the front support plate; the host placing box is connected to the right side of the lower part of the front supporting plate through an inverted L-shaped fixing plate bolt; the host placing box cover is arranged on the upper part of the host placing box through a hinge; two L-shaped sliding blocks are provided, one upper end screw is connected to the middle position of the lower part of the table plate, the lower part of the L-shaped sliding block is arranged in the sliding groove, the other upper end screw is connected to the right side of the lower part of the table plate, and the lower end of the L-shaped sliding block is arranged in the sliding groove; the sliding chutes are arranged on the left side and the right side of the upper part of the drawer; the drawer is connected to the right side of the lower part of the desk plate through the sliding groove and the L-shaped sliding block; the fan screw of the case is arranged in the middle of the front of the host placing case; the adjustable auxiliary table plate structure comprises an auxiliary table plate, an internal threaded hole, an adjusting bolt, an auxiliary supporting plate and an auxiliary base, wherein the auxiliary table plate is connected to the lower part of the right side of the inner groove of the table plate through the adjusting bolt; the inner threaded hole is formed in the lower portion of the left side of the auxiliary table plate; the adjusting bolt is connected to the lower part of the left side of the auxiliary table plate; the auxiliary supporting plate is connected to the lower part of the right side of the auxiliary table plate through screws; the auxiliary base is glued to the lower part of the auxiliary supporting plate.
Preferably, the rotatable bookshelf structure comprises a cylindrical bookshelf and bookshelf fastening strips; the bookshelf comprises a limiting plate, a limiting bolt, a storage box partition plate, a storage box and a rotating seat, wherein the rotating seat is embedded at the lower part of the cylindrical bookshelf; the bookshelf fastening strips are connected around the lower part of the cylindrical bookshelf in a surrounding manner; the limiting plates are respectively glued to the left side of the upper part of the storage box and the right side of the upper part of the storage box; the limiting bolt is in threaded connection with the right side of the limiting plate; the storage box clapboard is glued at the middle position in the storage box; the storage box is connected to the upper left portion of the table plate through screws. The lower part of the rotating seat is embedded in the upper part of the middle position of the storage box.
Preferably, the notebook computer heat dissipation mesh plate structure comprises a ventilation mesh plate, a front fan, a rear fan, a heat dissipation box, a fan battery and a fan switch, wherein the ventilation mesh plate is glued on the upper part of the heat dissipation box; the front fan is glued at the lower part of the left side of the ventilation screen plate; the rear fan is glued to the lower part of the right side of the ventilation screen plate; the heat dissipation box is connected to the upper part of the right side of the desk plate through screws; the fan battery is glued inside the left side of the heat dissipation box; the fan switch is arranged on the left lower side of the heat dissipation box.
Preferably, the upper part of the box cover is embedded with a round or square stainless steel net.
Preferably, the right side and the lower side of the host placing box are inlaid with stainless steel mesh pore plates.
Preferably, the fan battery is a lithium battery with a rated voltage of 6V.
Preferably, the periphery of the table plate is glued with anti-knocking rubber strips.
Preferably, a plurality of rectangular partition plates are arranged inside the cylindrical bookshelf.
Preferably, the ventilation screen plate is a stainless steel mesh-shaped pore plate, and the heat dissipation box is a rectangular box with an opening at the lower part.
Preferably, the case fan is a G12308HA2SL type direct current fan.
Preferably, the front fan adopts a G12308HA2SL type direct current fan; the rear fan adopts a G12308HA2SL type direct current fan.
Preferably, the lower part of the right side of the table plate is provided with an internal thread hole matched with the internal thread hole.
Compared with the prior art, the beneficial effects of the utility model are that:
1. the utility model discloses in, supplementary table, internal thread hole, adjusting bolt, the extension of desktop is carried out to the setting of auxiliary stay board and auxiliary base when being favorable to down needing, realizes increasing usable floor area's effect.
2. The utility model discloses in, cylindrical bookshelf, the storage tank, the setting of roating seat is favorable to strengthening the practicality and the convenience of bookshelf, strengthens the multifunctionality of desk.
3. The utility model discloses in, bookshelf fastening strip, limiting plate, spacing bolt the setting, be favorable to when using rotatory bookshelf book can not be thrown away because of the rotation, also can play fixed position's effect.
4. The utility model discloses in, ventilation otter board, leading fan, rearmounted fan, the setting of heat dissipation box is favorable to playing radiating effect to the notebook when using the notebook, dispels the heat effectively.
5. The utility model discloses in, the table all around the rubber joint have prevent the setting of the rubber strip that knocks, be favorable to preventing that the staff from being knocked by table limit or table corner, protection staff's safety.
6. The utility model discloses in, cylindrical bookshelf carry out the divided setting by the rectangle baffle, be favorable to depositing alone of books, can not cause to obscure and increase the searching degree of difficulty, do benefit to the staff and look for.
Drawings
Fig. 1 is a schematic structural diagram of the present invention.
Fig. 2 is a schematic structural view of the adjustable auxiliary table structure of the present invention.
Fig. 3 is a schematic structural view of the rotatable bookshelf structure of the present invention.
Fig. 4 is a schematic structural diagram of the notebook heat sink mesh plate structure of the present invention.
In the figure:
1. a table plate; 2. a rotatable bookshelf structure; 21. a cylindrical bookshelf; 22. a bookshelf fastening strip; 23. a limiting plate; 24. a limit bolt; 25. a storage compartment divider; 26. a storage box; 27. a rotating base; 3. a pen cup; 4. A notebook heat dissipation mesh plate structure; 41. a ventilation screen plate; 42. a front-mounted fan; 43. a rear fan; 44. a heat dissipation box; 45. a fan battery; 46. a fan switch; 5. a table plate inner groove; 6. an adjustable auxiliary table structure; 61. an auxiliary table plate; 62. an internally threaded bore; 63. adjusting the bolt; 64. an auxiliary support plate; 65. an auxiliary base; 7. a rear support plate; 8. a rear base; 9. an inverted L-shaped fixing plate; 10. a front-mounted base; 11. A host placement box; 12. a case cover is placed on the host; 13. a hinge; 14. a front support plate; 15. an L-shaped slider; 16. a chute; 17. a drawer; 18. a case fan.
Detailed Description
The invention is further described below with reference to the accompanying drawings:
example (b):
as shown in figures 1 to 4
The utility model provides a multifunctional desk for computer, which comprises a desk plate 1, a rotatable bookshelf structure 2, a pen cup 3, a notebook heat dissipation mesh plate structure 4, a desk plate internal groove 5, an adjustable auxiliary desk plate structure 6, a rear support plate 7, a rear base 8, an inverted L-shaped fixed plate 9, a front base 10, a host placing box 11, a host placing box cover 12, a hinge 13, a front support plate 14, an L-shaped slider 15, a chute 16, a drawer 17 and a case fan 18, wherein the desk plate 1 is connected with the upper parts of the front support plate 14 and the rear support plate 7 through screws; the rotatable bookshelf structure 2 is connected to the left upper side of the desk plate 1 through screws; the notebook heat dissipation mesh plate structure 4 is connected to the right side of the upper part of the desk plate 1 through screws; the pen cup 3 is arranged inside the right side of the rotatable bookshelf structure 2; the table plate inner groove 5 is formed in the right side of the table plate 1; the adjustable auxiliary table plate structure 6 is connected to the right side of the inner groove 5 of the table plate through bolts; the rear base 8 is glued at the lower part of the rear support plate 7; the left side of the inverted L-shaped fixing plate 9 is bolted on the right side of the lower part of the front supporting plate 14, and the upper end of the inverted L-shaped fixing plate 9 is bolted on the left side of the bottom of the host placing box 11; the front base 10 is glued on the lower part of the front support plate 14; the host placing box 11 is connected to the right side of the lower part of the front supporting plate 14 through an inverted L-shaped fixing plate 9 by bolts; the host placing box cover 12 is arranged on the upper part of the host placing box 11 through a hinge 13; two L-shaped sliding blocks 15 are provided, one upper end is connected with the middle position of the lower part of the table plate 1 through a screw, the lower part is arranged in the sliding groove 16, the other upper end is connected with the right side of the lower part of the table plate 1 through a screw, and the lower end is arranged in the sliding groove 16; the sliding grooves 16 are formed in the left side and the right side of the upper part of the drawer 17; the drawer 17 is connected to the right side of the lower part of the table plate 1 through a sliding chute 16 and an L-shaped sliding block 15; the case blower 18 is arranged in the middle of the front of the host placing case 11 through screws; the adjustable auxiliary table structure 6 comprises an auxiliary table 61, an internal threaded hole 62, an adjusting bolt 63, an auxiliary support plate 64 and an auxiliary base 65, wherein the auxiliary table 61 is connected to the lower part of the right side of the table inner groove 5 through the adjusting bolt 63; the internal thread hole 62 is formed in the lower left part of the auxiliary table board 61; the adjusting bolt 63 is connected to the lower part of the left side of the auxiliary table plate 61; the auxiliary supporting plate 64 is connected to the lower part of the right side of the auxiliary table plate 61 through screws; the auxiliary base 65 is glued to the lower portion of the auxiliary support plate 64.
In the above embodiment, specifically, the rotatable bookshelf structure 2 includes a cylindrical bookshelf 21, a bookshelf fastening strip 22; the bookshelf comprises a limiting plate 23, a limiting bolt 24, a storage box clapboard 25, a storage box 26 and a rotating seat 27, wherein the rotating seat 27 is embedded at the lower part of the cylindrical bookshelf 21; the bookshelf fastening strips 22 are encircled around the lower part of the cylindrical bookshelf 21; the limiting plate 23 is respectively glued to the left side of the upper part of the storage box 26 and the right side of the upper part of the storage box 26; the limiting bolt 24 is in threaded connection with the right side of the limiting plate 23; the storage box clapboard 25 is glued at the middle position in the storage box 26; the storage box 26 is connected to the upper left part of the table board 1 through screws. The lower part of the rotary seat 27 is embedded in the upper part of the middle position of the storage box 26.
In the above embodiment, specifically, the notebook heat dissipation mesh plate structure 4 includes a ventilation mesh plate 41, a front fan 42, a rear fan 43, a heat dissipation box 44, a fan battery 45 and a fan switch 46, where the ventilation mesh plate 41 is glued on the upper portion of the heat dissipation box 44; the front fan 42 is glued to the lower part of the left side of the ventilation screen plate 41; the rear fan 43 is glued at the lower part of the right side of the ventilation screen plate 41; the heat dissipation box 44 is connected to the upper part of the right side of the table board 1 through screws; the fan battery 45 is glued inside the left side of the heat dissipation box 44; the fan switch 46 is disposed at the lower left side of the heat dissipation case 44.
In the above embodiment, specifically, the upper portion of the box cover 12 is inlaid with a circular or square stainless steel net.
In the above embodiment, specifically, the right side and the lower side of the host placing box 11 are inlaid with mesh-shaped hole plates made of stainless steel.
In the above embodiment, specifically, the fan battery is a lithium battery with a rated voltage of 6V.
In the above embodiment, specifically, the periphery of the table board 1 is glued with the anti-knocking rubber strips.
In the above embodiment, specifically, a plurality of rectangular partition plates are disposed inside the cylindrical bookshelf 21.
In the above embodiment, specifically, the ventilation mesh plate 41 is a stainless steel mesh plate, and the heat dissipation box 44 is a rectangular box with an open lower portion.
In the above embodiment, specifically, the chassis fan adopts a G12308HA2SL type dc fan.
In the above embodiment, specifically, the front fan 42 adopts a G12308HA2SL type dc fan; the rear fan 43 adopts a G12308HA2SL type direct current fan.
In the above embodiment, specifically, the lower portion of the right side of the table board 1 is provided with an internal threaded hole matching with the internal threaded hole 62.
Principle of operation
The utility model discloses in the course of the work, when carrying out the work, can place the computer on ventilation otter board 41 when using the notebook, open fan switch 46, inside leading fan 42 this moment, rearmounted fan 43 is rotatory, dispel the heat to the notebook, take supplementary table 61 out from table inside groove 5 when needing to carry out the extension of table 1, then fix with adjusting bolt 63, accomplish the extension of table 1, can unscrew adjusting bolt 63 when not using and will assist in table 61 indentation table inside groove 5, supplementary backup pad 64 is neat with rearmounted backup pad 7, when using rotatable bookshelf structure 2, place the little interlayer in cylindrical bookshelf 21 with books, when looking for books, stir cylindrical bookshelf 21 can, need fix and make it not rotate, it can to screw roating seat 27.
Utilize technical scheme, or technical personnel in the field are in the utility model discloses under technical scheme's the inspiration, design similar technical scheme, and reach above-mentioned technological effect, all fall into the utility model discloses a protection scope.
Claims (8)
1. The multifunctional table for the computer is characterized by comprising a table plate (1), a rotatable bookshelf structure (2), a pen cup (3), a notebook heat-radiating mesh plate structure (4), a table plate inner groove (5), an adjustable auxiliary table plate structure (6), a rear supporting plate (7), a rear base (8), an inverted L-shaped fixing plate (9), a front base (10), a host placing box (11), a host placing box cover (12), a hinge (13), a front supporting plate (14), an L-shaped sliding block (15), a sliding groove (16), a drawer (17) and a case fan (18), wherein the table plate (1) is connected to the upper parts of the front supporting plate (14) and the rear supporting plate (7) through screws; the rotatable bookshelf structure (2) is connected to the left upper side of the desk plate (1) through screws; the notebook heat dissipation mesh plate structure (4) is connected to the right side of the upper part of the desk plate (1) through screws; the pen cup (3) is placed inside the right side of the rotatable bookshelf structure (2); the table plate inner groove (5) is formed in the right side of the table plate (1); the adjustable auxiliary table plate structure (6) is connected to the right side of the inner groove (5) of the table plate through bolts; the rear base (8) is glued at the lower part of the rear support plate (7); the left side of the inverted L-shaped fixing plate (9) is connected to the right side of the lower part of the front supporting plate (14) through a bolt, and the upper end of the inverted L-shaped fixing plate (9) is connected to the left side of the bottom of the host placing box (11) through a bolt; the front base (10) is glued to the lower part of the front support plate (14); the host placing box (11) is connected to the right side of the lower part of the front supporting plate (14) through an inverted L-shaped fixing plate (9) by bolts; the host placing box cover (12) is arranged on the upper part of the host placing box (11) through a hinge (13); the two L-shaped sliding blocks (15) are provided, one upper end screw is connected to the middle position of the lower part of the table plate (1), the lower part is arranged in the sliding groove (16), the other upper end screw is connected to the right side of the lower part of the table plate (1), and the lower end is arranged in the sliding groove (16); the sliding grooves (16) are formed in the left side and the right side of the upper part of the drawer (17); the drawer (17) is connected to the right side of the lower part of the desk plate (1) through a sliding groove (16) and an L-shaped sliding block (15); the case blower (18) is arranged in the middle of the front of the host placing case (11) through screws; the adjustable auxiliary table plate structure (6) comprises an auxiliary table plate (61), an internal threaded hole (62), an adjusting bolt (63), an auxiliary supporting plate (64) and an auxiliary base (65), wherein the auxiliary table plate (61) is connected to the lower part of the right side of the table plate inner groove (5) through the adjusting bolt (63); the internal thread hole (62) is formed in the lower portion of the left side of the auxiliary table board (61); the adjusting bolt (63) is connected to the lower part of the left side of the auxiliary table plate (61); the auxiliary supporting plate (64) is connected to the lower part of the right side of the auxiliary table plate (61) through screws; the auxiliary base (65) is glued on the lower part of the auxiliary support plate (64).
2. The multifunctional computer desk as claimed in claim 1, wherein the rotatable bookshelf structure (2) comprises a cylindrical bookshelf (21), bookshelf fastening strips (22), limiting plates (23), limiting bolts (24), storage box partitions (25), storage boxes (26) and rotary seats (27), and the rotary seats (27) are embedded in the lower part of the cylindrical bookshelf (21); the bookshelf fastening strips (22) are connected around the lower part of the cylindrical bookshelf (21) in a surrounding manner; the limiting plates (23) are respectively glued on the left side of the upper part of the storage box (26) and the right side of the upper part of the storage box (26); the limiting bolt (24) is in threaded connection with the right side of the limiting plate (23); the storage box clapboard (25) is glued at the middle position inside the storage box (26); the storage box (26) is connected to the left upper portion of the table plate (1) through screws, and the lower portion of the rotating seat (27) is embedded in the upper portion of the middle of the storage box (26).
3. The multifunctional computer desk as claimed in claim 1, wherein the notebook heat-dissipating mesh plate structure (4) comprises a ventilation mesh plate (41), a front fan (42), a rear fan (43), a heat-dissipating box (44), a fan battery (45) and a fan switch (46), the ventilation mesh plate (41) is glued on the upper part of the heat-dissipating box (44); the front fan (42) is glued to the lower part of the left side of the ventilation screen plate (41); the rear fan (43) is glued to the lower part of the right side of the ventilation screen plate (41); the heat dissipation box (44) is connected to the upper part of the right side of the table plate (1) through screws; the fan battery (45) is glued inside the left side of the heat dissipation box (44); the fan switch (46) is arranged on the left lower side of the heat dissipation box (44).
4. The multifunctional table for computer as claimed in claim 1, wherein the upper part of the cover (12) is embedded with a round or square stainless steel net.
5. The multifunctional table for computer as claimed in claim 1, wherein the right and lower sides of the mainframe placing box (11) are inlaid with mesh-shaped hole plates of stainless steel.
6. The multifunctional table for the computer as claimed in claim 1, wherein the periphery of the table plate (1) is glued with anti-knocking rubber strips.
7. A multifunctional table for a computer as set forth in claim 3, wherein said ventilation net plate (41) is a mesh-like orifice plate made of stainless steel, and said heat-dissipating box (44) is a rectangular box having an open lower portion.
8. The multifunctional table for computer as claimed in claim 1, wherein the lower part of the right side of the table plate (1) is provided with an internally threaded hole which is engaged with the internally threaded hole (62).
