The utility model belongs to the technical field of machining, especially, a processingequipment of inner circle is used in winding of galvanized steel sheet, it is inconvenient to carry out the aligning to inner circle processing with galvanized sheet to current galvanized sheet inner circle processingequipment, the problem that the waste material production is big, the following scheme is put forward now, it includes the base, the welding of top one side of base has the stand, the rectangular hole has been seted up to one side of stand, slidable mounting has the slide bar in the rectangular hole, the one end welding of slide bar has one side of baffle, the frame has all been welded at the opposite side of baffle and one side top of stand, a plurality of compression rollers are installed in the inboard rotation of frame, worm and worm wheel are installed to the rectangular hole internal rotation, the front side welding of worm wheel has the gear, the bottom welding of slide bar. The utility model relates to a rationally, carry out flattening and straightening treatment to galvanized sheet through the compression roller, reduced waste material production, improved waste material utilization ratio.
Description
Technical Field
The utility model relates to the technical field of machining, especially, relate to a processingequipment of inner circle for the coiling of galvanized sheet steel.
Background
The galvanized sheet generally all overlaps with annular coil of strip when rolling up in inner circle to avoid inside scattering, the coil of strip processing is complicated and inconvenient for current inner circle, and current processingequipment is inconvenient to carry out the straightening treatment to the galvanized sheet for the processing of inner circle, and the waste material production is great, therefore we have proposed a processingequipment of inner circle for the winding of galvanized sheet steel and have been used for solving above-mentioned problem.
Disclosure of Invention
The utility model aims at solving the defects that the prior processing device is inconvenient to straighten the galvanized sheet for processing the inner ring and the waste material yield is large, and providing the processing device of the inner ring for winding the galvanized steel sheet.
In order to achieve the above purpose, the utility model adopts the following technical scheme:
the utility model provides a processingequipment of inner circle for coiling of galvanized steel sheet, the on-line screen storage device comprises a base, the welding of top one side of base has the stand, the rectangular hole has been seted up to one side of stand, and slidable mounting has the slide bar in the rectangular hole, and the one end welding of slide bar has one side of baffle, and the opposite side of baffle has all welded the frame with one side top of stand, and the inboard rotation of frame installs a plurality of compression rollers, and worm wheel are installed to the rectangular hole internal rotation, and the gear has been welded to the front side of worm wheel, and the bottom welding of slide bar has the rack, and wheel and rack mesh, and the worm wheel meshes with the worm mutually, and the outside thread bush of worm is equipped with splint, and splint are located the outside of stand, and the one end of worm extends to the outside of stand and welds the.
Preferably, the outside welding of splint has a plurality of anti-skidding balls, the crank is installed in one side bottom of rocker rotation, makes things convenient for rotating splint and worm.
Preferably, the inner wall of the bottom of the rectangular hole is provided with an accommodating groove, and the bottom side of the rack extends into the accommodating groove and is movably connected with the accommodating groove, so that the rack is placed and plays a role in guiding the rack.
Preferably, the outer side of the worm is fixedly sleeved with an inner ring of the bearing, and an outer ring of the bearing is welded on the inner wall of the rectangular hole, so that the worm is conveniently and rotatably arranged in the rectangular hole.
Preferably, the one end of oblique pull rod is all welded to one side that two frames kept away from each other, one side top of stand and the other side bottom of baffle weld with the other end of two oblique pull rods respectively mutually, the universal wheel is installed in the bottom four corners of base, and oblique pull rod makes the frame keep balance and stable.
In the utility model, because the processing device of the inner ring for winding the galvanized sheet steel is provided with the base, the stand column, the frames and the compression rollers, the galvanized sheet can be arranged between the two frames by pushing the base to move, the crank is shaken to drive the worm to rotate, the worm can drive the worm wheel and the gear to rotate in a labor-saving way, the gear pushes the sliding rod to move upwards through the rack, the sliding rod drives the frame below the sliding rod to move upwards through the baffle, and the galvanized sheet can be clamped between the compression rollers;
the worm, the worm wheel and the clamping plate are arranged, after clamping of the galvanized sheet is completed, the rocker is kept still, the clamping plate can be driven to move horizontally by rotating the clamping plate, the clamping plate can be abutted to the outer side of the stand column, the position of the worm is fixed, and the worm wheel and the worm have self-locking performance, so that the worm wheel cannot rotate automatically when the rocker is not subjected to external force, the position and the height of a rack below the rocker are fixed, the galvanized sheet can drive a plurality of compression rollers to rotate in the unreeling process, the galvanized sheet is pressed by the plurality of compression rollers, and when the galvanized sheet is unreeled to the end, the innermost ring of the galvanized sheet can be pressed and straightened by the compression rollers, waste materials are reduced, and;
the utility model relates to a rationally, can the galvanized sheet flatten and the aligning is handled through the compression roller, improve the roughness when galvanized sheet winds the book or unreels, reduced waste material production, improved waste material utilization ratio.
Drawings
Fig. 1 is a schematic structural view of a processing device of an inner ring for winding a galvanized steel sheet according to the present invention.
FIG. 2 is a schematic structural view of part A of the processing device of the inner ring for winding the galvanized steel sheet according to the present invention.
FIG. 3 is a schematic structural view of a part B of the processing device of the inner ring for winding the galvanized steel sheet according to the present invention.
Fig. 4 is the utility model provides a side view structure sketch map of frame and compression roller connecting piece of processingequipment of inner circle for galvanized steel sheet coiling.
In the figure: the device comprises a base 1, a column 2, a rectangular hole 3, a sliding rod 4, a baffle 5, a rack 6, a press roller 7, a worm 8, a rocker 9, a worm wheel 10, a gear 11, a rack 12, a splint 13, a limiting plate 14, a bearing 15, an anti-skid ball 16, a receiving groove 17, a diagonal draw bar 18 and a crank 19.
Detailed Description
The technical solutions in the embodiments of the present invention will be described clearly and completely with reference to the accompanying drawings in the embodiments of the present invention, and it is obvious that the described embodiments are only some embodiments of the present invention, not all embodiments.
Example one
Referring to fig. 1-4, a processing device of an inner ring for winding a galvanized sheet steel, comprising a base 1, wherein an upright post 2 is welded on one side of the top of the base 1, a rectangular hole 3 is formed on one side of the upright post 2, a slide rod 4 is slidably mounted in the rectangular hole 3, one end of the slide rod 4 is welded with one side of a baffle 5, a rack 6 is welded on the other side of the baffle 5 and the top of one side of the upright post 2, a plurality of press rollers 7 are rotatably mounted on the inner side of the rack 6, a worm 8 and a worm wheel 10 are rotatably mounted in the rectangular hole 3, a gear 11 is welded on the front side of the worm wheel 10, a rack 12 is welded on the bottom of the slide rod 4, the gear 11 is meshed with the rack 12, the worm wheel 10 is meshed with the worm 8, a clamp plate 13 is sleeved on the outer side of the worm 8 through a thread, the, one sides of the baffle plates 5, which are close to the limiting plates 14, are respectively connected with the two sides of the upright post 2 in a sliding manner.
In this embodiment, a plurality of anti-skid balls 16 are welded to the outer side of the clamp plate 13, and a crank 19 is rotatably mounted on the bottom of one side of the rocker 9.
In this embodiment, the inner wall of the bottom of the rectangular hole 3 is provided with a receiving groove 17, and the bottom side of the rack 12 extends into the receiving groove 17 and is movably connected with the receiving groove 17.
In this embodiment, the outer side of the worm 8 is fixedly sleeved with the inner ring of the bearing 15, and the outer ring of the bearing 15 is welded on the inner wall of the rectangular hole 3.
In this embodiment, the one side that two frames 6 kept away from each other all welds the one end of oblique pull rod 18, and the other end of one side top of stand 2 and the other side bottom of baffle 5 respectively with two oblique pull rod 18 welds mutually, and the universal wheel is installed in the bottom four corners of base 1.
Example two
Referring to fig. 1-4, a processing device of an inner ring for winding a galvanized thin steel sheet, comprising a base 1, wherein one side of the top of the base 1 is fixedly connected with a stand column 2 through a bolt, one side of the stand column 2 is provided with a rectangular hole 3, a slide rod 4 is slidably installed in the rectangular hole 3, one end of the slide rod 4 is fixedly connected with one side of a baffle 5 through a bolt, the other side of the baffle 5 and the top of one side of the stand column 2 are fixedly connected with a rack 6 through a bolt, the inner side of the rack 6 is rotatably provided with a plurality of press rollers 7, a worm 8 and a worm wheel 10 are rotatably installed in the rectangular hole 3, the front side of the worm wheel 10 is fixedly connected with a gear 11 through a bolt, the bottom of the slide rod 4 is fixedly connected with a rack 12 through a bolt, the gear 11 is meshed with the rack 12, the worm wheel 10 is meshed with the worm 8, the outer side of the worm 8, the other end of the sliding rod 4 is fixedly connected with a limiting plate 14 through a bolt, and one side, close to the limiting plate 14, of the baffle 5 is respectively connected with the two sides of the upright post 2 in a sliding mode.
In this embodiment, the outer side of the clamp plate 13 is fixedly connected with a plurality of anti-skid balls 16 through bolts, and the bottom of one side of the rocker 9 is rotatably provided with a crank 19, so that the clamp plate 13 and the worm 8 can be conveniently rotated.
In this embodiment, the inner wall of the bottom of the rectangular hole 3 is provided with a receiving groove 17, and the bottom side of the rack 12 extends into the receiving groove 17 and is movably connected with the receiving groove 17, so as to place the rack 12 and guide the rack 12.
In this embodiment, the fixed cover in outside of worm 8 is equipped with the inner circle of bearing 15, and the outer lane welding of bearing 15 is on the inner wall of rectangular hole 3, conveniently rotates worm 8 and sets up in rectangular hole 3.
In this embodiment, the one side that two frames 6 kept away from each other all through the one end of bolt fixedly connected with diagonal draw bar 18, one side top of stand 2 and the other side bottom of baffle 5 weld with the other end of two diagonal draw bars 18 respectively mutually, and the universal wheel is installed in the bottom four corners of base 1, and diagonal draw bar 18 makes frame 6 keep balance and stable.
In the utility model, before the galvanized sheet unreels or winds, promote base 1 to move, place the galvanized sheet between two frames 6, then rock crank 19, crank 19 drives worm 8 through rocker 9 and rotates, because transmission ratio is lower between worm 8 and worm wheel 10, so can laborsaving drive worm wheel 10 and gear 11 rotate when worm 8 rotates, gear 11 promotes slide bar 4 to move upwards through rack 12 when rotating, slide bar 4 drives frame 6 located below to move upwards through baffle 5, can clamp the galvanized sheet between a plurality of compression rollers 7, after the clamping of galvanized sheet is accomplished, keep rocker 9 motionless, rotate splint 13, because splint 13 is the threaded sleeve on worm 8, so can carry out the position removal on the horizontal direction when splint 13 rotates, can support splint 13 outside stand 2, fix the position of worm 8, and because of possess the auto-lock nature between worm wheel 10 and the worm 8, therefore, when the rocker 9 is not subjected to external force, the worm gear 10 cannot rotate by itself, the position and the height of the rack 6 below the rocker can be fixed, the galvanized sheet can drive the plurality of compression rollers 7 to rotate in the unreeling process, the galvanized sheet is flattened by the plurality of compression rollers 7, the galvanized sheet is unreeled or is coiled to the end, the innermost ring or the outermost ring of the galvanized sheet can be flattened and straightened by the compression rollers 7, waste materials are reduced, and the waste material utilization rate is improved.
The above, only be the concrete implementation of the preferred embodiment of the present invention, but the protection scope of the present invention is not limited thereto, and any person skilled in the art is in the technical scope of the present invention, according to the technical solution of the present invention and the utility model, the concept of which is equivalent to replace or change, should be covered within the protection scope of the present invention.
Claims (5)
1. The utility model provides a processingequipment of inner circle for the coiling of galvanized sheet steel, includes base (1), stand (2) have been welded to top one side of base (1), a serial communication port, rectangular hole (3) have been seted up to one side of stand (2), slidable mounting has slide bar (4) in rectangular hole (3), the one end welding of slide bar (4) has one side of baffle (5), frame (6) have all been welded at the opposite side of baffle (5) and one side top of stand (2), a plurality of compression rollers (7) are installed in the inboard rotation of frame (6), worm (8) and worm wheel (10) are installed to the internal rotation of rectangular hole (3), gear (11) have been welded to the front side of worm wheel (10), the bottom welding of slide bar (4) has rack (12), gear (11) mesh with rack (12), worm wheel (10) mesh with worm (8), the outside thread bush of worm (8) is equipped with splint (13), splint (13) are located the outside of stand (2), and the one end of worm (8) extends to the outside of stand (2) and welds and have rocker (9), the other end welding of slide bar (4) has limiting plate (14), baffle (5) and limiting plate (14) one side that is close to each other respectively with the both sides sliding connection of stand (2).
2. An inner ring processing device for a galvanized steel sheet winding as set forth in claim 1, characterized in that a plurality of anti-skid balls (16) are welded to the outer side of the clamping plate (13), and a crank (19) is rotatably mounted to one side bottom of the rocker (9).
3. The processing device of the inner ring for the winding of the galvanized thin steel sheet as claimed in claim 1, wherein the inner wall of the bottom of the rectangular hole (3) is provided with a receiving groove (17), and the bottom side of the rack (12) extends into the receiving groove (17) and is movably connected with the receiving groove (17).
4. A processing apparatus of an inner ring for a galvanized steel sheet winding according to claim 1, characterized in that an inner ring of a bearing (15) is fixedly sleeved on an outer side of the worm (8), and an outer ring of the bearing (15) is welded on an inner wall of the rectangular hole (3).
5. The processing device of the inner ring for the winding of the galvanized steel sheet as claimed in claim 1, wherein one ends of the diagonal draw bars (18) are welded to the sides of the two frames (6) away from each other, the top of one side of the upright (2) and the bottom of the other side of the baffle (5) are respectively welded to the other ends of the two diagonal draw bars (18), and universal wheels are installed at four corners of the bottom of the base (1).
