CN210049960U

CN210049960U - Automatic loading formula generating set container

Info

Publication number: CN210049960U
Application number: CN201920937173.4U
Authority: CN
Inventors: 刘建辉
Original assignee: Fujian Huagong Intelligent Equipment Co Ltd
Current assignee: Fujian Huagong Intelligent Equipment Co Ltd
Priority date: 2019-06-21
Filing date: 2019-06-21
Publication date: 2020-02-11
Anticipated expiration: 2029-06-21

Abstract

The utility model belongs to the technical field of generating set, in particular to an automatic loading type generating set container, which utilizes a motor, a box body, a threaded column, a groove, a sliding block, an electric push rod, a first bearing, a round hole, a rotating shaft, a roller, a supporting plate, a second bearing, a threaded hole, a generating set, an arc-shaped groove, a base, a universal wheel and a clamping groove, in application, the generating set can more easily enter the box body under the action of the universal wheel and the base, and the electric push rod can be clamped into the clamping groove in the arc-shaped groove aiming at the generating set entering the box body, the generating set is driven to move through the connection relation of the electric push rod, the sliding block, the threaded column and the motor, so that the generating set automatically moves to the position needing to be installed, thereby achieving the purpose of saving manpower, reducing the production time, increasing the production efficiency, ramps with thirty, the generator set can enter the box body more easily.

Description

Automatic loading formula generating set container

Technical Field

The utility model belongs to the technical field of generating set, concretely relates to automatic loading formula generating set container.

Background

The generator set is a complete set of mechanical equipment for converting energy of other forms into electric energy, and consists of a power system, a control system, a silencing system, a damping system and an exhaust system, and is driven by a water turbine, a steam turbine, a diesel engine or other power machines, so that energy generated by water flow, air flow, fuel combustion or atomic fission is converted into mechanical energy to be transmitted to a generator, the mechanical energy is converted into electric energy by the generator and is output to electric equipment for use, and the generator has wide application in industrial and agricultural production, national defense, science and technology and daily life. With the technical progress in recent years, as a high-quality choice of a household emergency power supply and a field trip power supply, a lightweight portable small-sized generator set also starts to enter the daily life of residents, and a container-type generator set is a larger and high-power generator set created on the basis of the generator set, but has the defects of huge size with the container-type generator set, difficult assembly in the production and manufacturing processes, manpower waste and low production efficiency.

SUMMERY OF THE UTILITY MODEL

To solve the problems set forth in the background art described above. The utility model provides an automatic loading formula generating set container has the characteristics of automatic loading.

In order to achieve the above object, the utility model provides a following technical scheme: an automatic loading type generator set container comprises a box body, wherein a groove and a sliding groove are formed in the box body, a roller is arranged in the sliding groove, a rotating shaft is fixedly connected inside the roller, second bearings are arranged at two ends of the rotating shaft, a supporting plate is embedded on the surface of each second bearing, a sliding block is fixedly connected to one side of each supporting plate, a threaded hole is formed in the sliding block, a threaded column is movably connected inside the threaded hole, a first bearing is movably connected to one end of the threaded column, the first bearing is fixedly connected inside the box body, a motor is fixedly connected to the other end of the threaded column, the motor is fixedly connected inside the box body, a bottom plate is arranged at one end of the box body, baffle plates are fixedly connected to two ends of the bottom plate, a round hole is formed in one end of each sliding block, an electric push, the output end of the electric push rod is arranged in the clamping groove, the clamping groove is formed in the arc-shaped groove, the arc-shaped groove is formed in the base, the generator set is arranged on the upper surface of the base, and the universal wheels are arranged on the lower surface of the base.

Preferably, the two ends of the bottom plate are provided with ramps with thirty-degree angles.

Preferably, the number of the rollers is two, and the number of the universal wheels is four.

Preferably, the number of the arc-shaped grooves is two, and the number of the clamping grooves in the arc-shaped grooves is not less than four.

Preferably, the motor, the threaded column, the sliding block and the first bearing are arranged in two, and are oppositely arranged on the left side and the right side of the box body.

Compared with the prior art, the beneficial effects of the utility model are that:

the utility model is provided with a motor, a box body, a threaded column, a groove, a sliding chute, a sliding block, an electric push rod, a first bearing, a round hole, a rotating shaft, a roller, a supporting plate, a second bearing, a threaded hole, a generating set, an arc-shaped groove, a base, a universal wheel and a clamping groove, in application, the generator set can more easily enter the box body under the action of the universal wheels and the base, and aiming at the generator set entering the box body, the electric push rod can be clamped into the clamping groove in the arc-shaped groove, the generator set is driven to move through the connection relation of the electric push rod, the sliding block, the threaded column and the motor, the generator set automatically moves to the position to be installed, thereby reach the purpose of practicing thrift the manpower, and make long reduction during production, increased production efficiency, be provided with the ramp that the angle is thirty degrees through the both ends that set up the bottom plate, make generating set easier entering box.

Drawings

The accompanying drawings are included to provide a further understanding of the invention, and are incorporated in and constitute a part of this specification, illustrate embodiments of the invention, and together with the description serve to explain the invention and not to limit the invention. In the drawings:

fig. 1 is a schematic structural view of a top view section of the present invention;

FIG. 2 is a schematic structural view of the middle slider in front view;

FIG. 3 is a schematic structural diagram of the side view of the middle slide block of the present invention;

fig. 4 is a schematic structural diagram of a generator set in the present invention;

fig. 5 is a schematic structural view of the middle bottom plate of the present invention;

in the figure: 1. a motor; 2. a box body; 3. a threaded post; 4. a groove; 5. a chute; 6. a slider; 7. an electric push rod; 8. a first bearing; 9. a baffle plate; 10. a base plate; 11. a circular hole; 12. a rotating shaft; 13. a roller; 14. a support plate; 15. a second bearing; 16. a threaded hole; 17. a generator set; 18. an arc-shaped slot; 19. a base; 20. a universal wheel; 21. a clamping groove.

Detailed Description

The technical solutions in the embodiments of the present invention will be described clearly and completely with reference to the accompanying drawings in the embodiments of the present invention, and it is obvious that the described embodiments are only some embodiments of the present invention, not all embodiments. Based on the embodiments in the present invention, all other embodiments obtained by a person skilled in the art without creative work belong to the protection scope of the present invention.

Examples

Referring to fig. 1-5, the present invention provides the following technical solutions: an automatic loading type generator set container comprises a box body 2, wherein a groove 4 and a sliding groove 5 are formed in the box body 2, a roller 13 is arranged in the sliding groove 5, a rotating shaft 12 is fixedly connected to the inside of the roller 13, second bearings 15 are arranged at two ends of the rotating shaft 12, a supporting plate 14 is embedded on the surface of the second bearing 15, a sliding block 6 is fixedly connected to one side of the supporting plate 14, a threaded hole 16 is formed in the sliding block 6, a threaded column 3 is movably connected to the inside of the threaded hole 16, a first bearing 8 is movably connected to one end of the threaded column 3, the first bearing 8 is fixedly connected to the inside of the box body 2, a motor 1 is fixedly connected to the other end of the threaded column 3, the motor 1 is fixedly connected to the inside of the box body 2, a bottom plate 10 is arranged at one end of the box body 2, and baffle plates, one end of the sliding block 6 is provided with a round hole 11, the inside of the round hole 11 is fixedly connected with an electric push rod 7, the output end of the electric push rod 7 is arranged inside a clamping groove 21, the clamping groove 21 is arranged inside an arc-shaped groove 18, the arc-shaped groove 18 is arranged inside a base 19, the upper surface of the base 19 is provided with a generator set 17, the lower surface of the base 19 is provided with a universal wheel 20, and by utilizing the motor 1, the box body 2, the threaded column 3, the groove 4, the sliding groove 5, the sliding block 6, the electric push rod 7, the first bearing 8, the round hole 11, the rotating shaft 12, the rolling wheel 13, the supporting plate 14, the second bearing 15, the threaded hole 16, the generator set 17, the arc-shaped groove 18, the base 19, the universal wheel 20 and the clamping groove 21, in application, the generator set 17 can more easily enter the box body 2 under the action of the universal wheel, can make electric putter 7 block go into in the inside draw-in groove 21 of arc 18, through electric putter 7, slider 6, screw post 3 and motor 1's relation of being connected, drive generating set 17 and move, make generating set 17 automatic advance the position that needs the installation to reach the purpose of practicing thrift the manpower, and make production time long reduce, increased production efficiency.

Specifically, ramps with an angle of thirty degrees are arranged at two ends of the bottom plate 10, and the generator set 17 can enter the box body 2 more easily by arranging ramps with an angle of thirty degrees at two ends of the bottom plate 10.

Specifically, the number of the rollers 13 is two, and the number of the universal wheels 20 is four.

Specifically, the number of the arc-shaped grooves 18 is two, and the number of the clamping grooves 21 in the arc-shaped grooves is not less than four.

Specifically, the motor 1, the threaded column 3, the sliding block 6 and the first bearing 8 are arranged in two, and are oppositely arranged on the left side and the right side of the box body 2.

The utility model discloses a theory of operation and use flow: the utility model discloses during the use, through bottom plate 10 and universal wheel 20, push away generator 1 along the inside of bottom plate 10 entering into box 2, use external switch to open electric putter 7 after that, make electric putter 7's top stretch out, thereby the card goes into the inside draw-in groove 21 of arc wall 18, open motor 1 after that, it is rotatory to make motor 1 drive screw post 3, slider 6 on screw post 3 surface can remove along with screw post 3's rotation through inside screw hole 16, when the place of reacing required installation, close motor 1 can, just the utility model discloses holistic setting makes generator 17's installation and dismantlement all very convenient and swift.

Finally, it should be noted that: although the present invention has been described in detail with reference to the foregoing embodiments, it will be apparent to those skilled in the art that modifications may be made to the embodiments described in the foregoing embodiments, or equivalents may be substituted for elements thereof. Any modification, equivalent replacement, or improvement made within the spirit and principle of the present invention should be included in the protection scope of the present invention.

Claims

1. An automatic loading formula generating set container, includes box (2), its characterized in that: the novel bearing box is characterized in that a groove (4) and a sliding groove (5) are formed in the box body (2), a roller (13) is arranged in the sliding groove (5), a rotating shaft (12) is fixedly connected to the inside of the roller (13), second bearings (15) are arranged at two ends of the rotating shaft (12), a supporting plate (14) is embedded on the surface of each second bearing (15), a sliding block (6) is fixedly connected to one side of the supporting plate (14), a threaded hole (16) is formed in the sliding block (6), a threaded column (3) is movably connected to the inside of the threaded hole (16), a first bearing (8) is movably connected to one end of the threaded column (3), the first bearing (8) is fixedly connected to the inside of the box body (2), a motor (1) is fixedly connected to the other end of the threaded column (3), and the motor (1) is fixedly connected to the inside of, the one end of box (2) is provided with bottom plate (10), both ends fixedly connected with baffle (9) of bottom plate (10), round hole (11) have been seted up to the one end of slider (6), inside fixedly connected with electric putter (7) of round hole (11), the output of electric putter (7) sets up the inside at draw-in groove (21), the inside at arc wall (18) is seted up in draw-in groove (21), the inside at base (19) is seted up in arc wall (18), the upper surface of base (19) is provided with generating set (17), the lower surface of base (19) is provided with universal wheel (20).

2. An auto-loader generator set container as in claim 1, wherein: ramps with thirty-degree angles are arranged at two ends of the bottom plate (10).

3. An auto-loader generator set container as in claim 1, wherein: the number of the rollers (13) is two, and the number of the universal wheels (20) is four.

4. An auto-loader generator set container as in claim 1, wherein: the number of the arc-shaped grooves (18) is two, and the number of the clamping grooves (21) in the arc-shaped grooves is not less than four.

5. An auto-loader generator set container as in claim 1, wherein: the motor (1), the threaded column (3), the sliding block (6) and the first bearing (8) are arranged in two modes and are oppositely arranged on the left side and the right side of the box body (2).
