Abstract

The invention discloses a processing device and a method for a seam allowance on the outer end face of a high-speed printed circuit board, and relates to the technical field of processing the seam allowance on the outer end face of an electronic element assembly, wherein two horizontally arranged clamping oil cylinders are fixedly arranged on the top surface of a support, a positioning table is fixedly arranged between cylinder barrels of the two clamping oil cylinders, two positioning columns are fixedly arranged on the top surface of the positioning table, a vertical plate of an L plate is welded on an acting end of a piston rod of the clamping oil cylinder, a clamping block is welded on the top of the vertical plate, a servo motor is fixedly arranged on the acting end of the piston rod of each lifting oil cylinder, and an output shaft of the servo motor is connected with a drill bit extending into a through groove; a compression oil cylinder is fixedly arranged on a cross beam of the portal frame, and two linear milling mechanisms are arranged below the cross beam of the portal frame. The invention has the beneficial effects that: the production efficiency of the finished high-speed printed circuit board is greatly improved, the production quality of the finished high-speed printed circuit board is greatly improved, and the automation degree is high.

Description

Processing device and method for outer end face stop of high-speed printed circuit board

technical field

The present invention relates to the technical field of processing a notch on the outer end face of an electronic component assembly, in particular to a processing device and method for the outer end face notch of a high-speed printed circuit board.

Background technique

Electronic component assemblies include single-sided circuit boards, double-sided circuit boards, flexible boards, multi-layer printed circuit boards, etc. These electronic component assemblies are the core components of the controller and can play an important role. The circuit board is processed through a series of processes such as etching, exposure, and silk screen printing. Among them, the high-speed printed circuit board has the technical characteristics of faster transmission frequency than the ordinary circuit board. The structure of the high-speed printed circuit board is shown in Figure 1. The process requires that the stop 26 be processed on the left and right outer end faces of the high-speed printed circuit board, and the bottom surface of the stop 26 is required to be a horizontal surface, and the horizontal surface is used as the mounting surface of the chip, so that the chip is hidden, so that the entire high-speed printing The circuit board is installed in a narrower space; it is also required to process a plurality of through holes 27 on the bottom surface of the stop 26, and the through holes 27 are used as heat dissipation holes or wire holes. Schematic diagram of the structure of the printed circuit board.

The existing method and steps of using a high-speed printed circuit board to process a finished high-speed printed circuit board are as follows: the worker first fixes the high-speed printed circuit board to be processed on the tooling table of the milling machine through the pressing plate clamping mechanism, and then operates the milling machine to make the high-speed printed circuit board. The milling cutter of the milling machine moves along the width direction of the high-speed printed circuit board. After the milling cutter passes through the circuit board, the two outer end faces of the high-speed printed circuit board can be machined to form the stop 26, and then the worker opens the Press plate clamping mechanism to remove the semi-finished high-speed printed circuit board from the tooling table, after removal, fix the semi-finished high-speed printed circuit board tooling to the positioning table of the drilling machine, and the worker operates the drilling machine to make the drill bit in the drilling machine A plurality of through holes 27 are drilled on the bottom surface of the stop 26 to finally produce a product.

However, although the existing processing method can process products with a stop, after mass production of a batch of products, the technicians found the following technical defects:

1. The bottom surface of the stop 26 of the product is not a horizontal plane, but an inclined plane 28. As shown in Figure 4 to Figure 5, it is the structural schematic diagram of the product actually processed, thereby greatly reducing the production quality of the product. The stop 26 needs to be calibrated, which undoubtedly increases the production process and greatly reduces the production efficiency of the product.

II. In the process of processing the stop 26, the high-speed printed circuit board needs to be positioned on the tooling table of the milling machine first. After processing the stop 26, the high-speed printed circuit board needs to be transferred to the positioning table of the drilling machine. , and make it a positioning tooling. There will undoubtedly be a positioning error through the two positioning tooling, which greatly reduces the positional accuracy of the through hole 27, that is, the position of the through hole 27 on the bottom surface of the stop 26 does not meet the requirements. The production quality of the product is reduced, and there is a technical defect of low production precision.

III. After the stop 26 is processed on the high-speed printed circuit board, it needs to be transferred to the drilling station, and the high-speed printed circuit board needs to be clamped twice, which undoubtedly increases the production cycle, and furthermore Greatly reduces the production efficiency of the product. Therefore, there is an urgent need for a processing device and method for greatly improving the production efficiency of finished high-speed printed circuit boards and greatly improving the production quality of finished high-speed printed circuit boards.

SUMMARY OF THE INVENTION

The purpose of the present invention is to overcome the shortcomings of the prior art, and to provide a high-speed printed circuit board with a compact structure, greatly improving the production efficiency of the finished high-speed printed circuit board, greatly improving the production quality of the finished high-speed printed circuit board, and having a high degree of automation for high-speed printing. The invention discloses a processing device and a method for making an outer end face stop of a circuit board.

The object of the present invention is achieved through the following technical solutions: a processing device for the outer end face of a high-speed printed circuit board, which includes a workbench, a support fixed on the workbench table, and a workbench fixed on the workbench. Gantry, the gantry is erected on the outside of the support, two horizontally arranged clamping oil cylinders are fixed on the top surface of the support, and a positioning table is fixed between the cylinders of the two clamping oil cylinders, and the positioning table Two positioning posts are fixed on the top surface of the cylinder, and L plates are arranged on the outer side of the support on the action ends of the two clamping cylinder piston rods. The vertical plate of the L plate is welded to the action end of the clamping cylinder piston rod. And the top of the vertical plate is welded with a clamping block, the upper end of the clamping block is provided with an L-shaped opening facing the direction of the positioning table, the bottom surface of the L-shaped opening is flush with the top surface of the positioning table, and the bottom surface of the L-shaped opening is along its longitudinal direction. A plurality of through grooves are opened in the direction, and a plurality of lifting oil cylinders corresponding to the through grooves are fixed on the horizontal plate of the L plate. A servo motor is fixed on the action end of the piston rod of each lifting oil cylinder. The shaft is connected with a drill bit extending into the through groove;

A pressing oil cylinder is fixed on the beam of the gantry, the piston rod of the pressing oil cylinder is arranged through the beam, and a pressure plate is fixed on the extension end, the pressure plate is arranged directly above the positioning table, and two guide holes are opened on the pressure plate , the two guide holes are respectively arranged directly above the two positioning columns, the lower part of the gantry beam is provided with two linear milling mechanisms, the two linear milling mechanisms are respectively arranged directly above the two clamping blocks, and the linear milling mechanism The milling cutter is set on the rear side of the clamping block.

The clamping blocks located on both sides of the positioning table are symmetrically arranged with respect to the positioning table.

The outer diameter of the positioning column is equal to the diameter of the guide hole.

Two pressing oil cylinders are fixed on the beam of the gantry, and the piston rods of the two pressing oil cylinders are fixed on the top surface of the pressing plate.

The height of the elevation of the L-shaped opening is smaller than the thickness of the high-speed printed circuit board.

A plurality of support legs supported on the ground are fixed on the bottom surface of the workbench.

The two linear milling mechanisms are arranged symmetrically on the left and right. The linear milling mechanism includes a hydraulic sliding table, a driving motor and a milling cutter. The hydraulic sliding table is longitudinally arranged and fixed on the bottom surface of the gantry beam. The driving motor is arranged vertically and drives The base of the motor is fixed on the moving table of the hydraulic sliding table through the flange, and the milling cutter is installed on the output shaft of the driving motor.

The processing device further includes a controller, which is electrically connected with the solenoid valve of the pressing oil cylinder, the solenoid valve of the lifting oil cylinder, the servo motor and the driving motor.

A processing method for the outer end face of a high-speed printed circuit board, which includes the following steps:

S1. The worker takes multiple high-speed printed circuit boards to be processed, then stacks multiple high-speed printed circuit boards neatly, and then drills two positioning holes on each layer of high-speed printed circuit boards to ensure that two The spacing between the positioning holes is equal to the spacing between the two positioning columns, and at the same time, ensure that the diameter of the positioning holes is equal to the outer diameter of the positioning columns;

S2, the positioning of the high-speed printed circuit board, the worker takes a high-speed printed circuit board, and then sets the two positioning holes on the high-speed printed circuit board on the two positioning posts respectively, and the high-speed printed circuit board It is supported on the top surface of the positioning table, thereby realizing the positioning of the high-speed printed circuit board. At this time, the left and right extension ends of the high-speed printed circuit board are respectively supported on the bottom surfaces of the two clamping blocks, and the left and right The end faces are opposite to the vertical faces of the two clamping blocks respectively;

S3. For the horizontal clamping of high-speed printed circuit boards, the worker controls the piston rods of the two clamping cylinders to retract, the piston rods drive the L plate to move inward, and the L plate drives the lifting cylinder and the clamping block to move synchronously. After the piston rod of the oil cylinder is fully retracted, the high-speed printed circuit board is clamped between the facades of the two clamping blocks, thereby realizing the horizontal clamping of the high-speed printed circuit board;

S4. Vertical clamping of high-speed printed circuit boards. The worker controls the piston rod of the pressing cylinder to extend downward. The piston rod drives the pressure plate to move downward. The positioning column first enters the guide hole, and then the pressure plate is pressed on the high-speed printing plate. on the top surface of the circuit board, thereby realizing the vertical clamping of high-speed printed circuit boards;

S5. For the forming of the semi-finished high-speed printed circuit board, the worker first controls the drive motor to start, and the drive motor drives the milling cutter to rotate. Then the worker controls the hydraulic slide table of the two linear milling mechanisms to start at the same time, and the hydraulic slide table drives the moving table to move forward. The moving table drives the drive motor and the milling cutter to move forward synchronously. At this time, the rotating milling cutter is attached to the top surface of the clamping block to gradually mill the material on the outer end face of the high-speed printed circuit board. When the milling cutter passes through the high-speed printed circuit board After that, the stops are formed on the left and right outer end faces of the high-speed printed circuit board;

S6. The forming of the finished high-speed printed circuit board, the worker controls each servo motor to start, the servo motor drives the drill bit to rotate, and then the worker controls the piston rod of each lift cylinder to extend upward, the piston rod drives the servo motor to move upward, and the drill bit passes through the through slot And drill a plurality of required through holes on the bottom surface of the stop, so as to finally produce a finished high-speed printed circuit board;

S7 , repeating the operations of steps S2 to S6 , a plurality of finished high-speed printed circuit boards can be produced in batches continuously.

The invention has the following advantages: the structure is compact, the production efficiency of the finished high-speed printed circuit board is greatly improved, the production quality of the finished high-speed printed circuit board is greatly improved, and the degree of automation is high.

Description of drawings

Figure 1 is a schematic diagram of the structure of a high-speed printed circuit board;

Figure 2 is a schematic diagram of the structure of the finished high-speed printed circuit board;

Fig. 3 is the top view of Fig. 2;

Figure 4 is a schematic diagram of the structure of the actual processed product;

Fig. 5 is the partial enlarged schematic diagram of part I of Fig. 4;

Figure 6 is a schematic structural diagram of the present invention;

Fig. 7 is the A-A sectional view of Fig. 6;

Figure 8 is a schematic diagram of the structure of the linear milling mechanism;

Fig. 9 is the bottom view of Fig. 8;

Figure 10 is a schematic structural diagram of a milling cutter;

Fig. 11 is the partial enlarged schematic diagram of II part of Fig. 6;

Figure 12 is a schematic diagram of the structure of the clamping block;

Fig. 13 is the top view of Fig. 12;

14 is a schematic diagram of two positioning holes processed on a high-speed printed circuit board;

15 is a schematic diagram of positioning a high-speed printed circuit board according to the present invention;

Fig. 16 is the sectional view of B-B of Fig. 15;

Figure 17 is a schematic diagram of two clamping blocks clamping the high-speed printed circuit board;

Fig. 18 is the C-C sectional view of Fig. 17;

Fig. 19 is a partial enlarged schematic view of part III of Fig. 17;

Figure 20 is a schematic diagram of pressing the high-speed printed circuit board by the pressing plate;

Figure 21 is a schematic diagram of forming a semi-finished high-speed printed circuit board;

Figure 22 is a schematic structural diagram of the processed semi-finished high-speed printed circuit board;

Figure 23 is a schematic structural diagram of the finished high-speed printed circuit board;

Fig. 24 is the top view of Fig. 23;

In the figure, 1- worktable, 2- support, 3- gantry, 4- clamping cylinder, 5- positioning table, 6- positioning column, 7- L plate, 8- clamping block, 9- L-shaped opening, 10-bottom, 11-through slot, 12-lifting cylinder, 13-servo motor, 14-drill, 15-pressing cylinder, 16-pressing plate, 17-guide hole, 18-linear milling mechanism, 19-milling cutter, 20 -Facade, 21-hydraulic slide table, 22-drive motor, 23-moving table, 24-positioning hole, 25-high-speed printed circuit board, 26-stop, 27-through hole, 28-slope.

Detailed ways

The present invention will be further described below in conjunction with the accompanying drawings, and the protection scope of the present invention is not limited to the following:

As shown in Figures 6 to 13, the processing device for the outer end face of the high-speed printed circuit board includes a worktable 1, a support 2 fixed on the table top of the worktable 1, and a table fixed on the table top of the worktable 1. The gantry 3 on the top of the table 1, a plurality of supporting legs supported on the ground are fixed on the bottom surface of the workbench 1, the gantry 3 is erected on the outside of the support 2, and the top surface of the support 2 is fixed on the There are two horizontally arranged clamping oil cylinders 4, a positioning table 5 is fixed between the cylinder barrels of the two clamping oil cylinders 4, two positioning columns 6 are fixed on the top surface of the positioning table 5, and the two clamping oil cylinders are 4. The action end of the piston rod is provided with an L plate 7 located on the outer side of the support 2. The vertical plate of the L plate 7 is welded to the action end of the piston rod of the clamping oil cylinder 4, and the top of the vertical plate is welded with a clamping block 8, located at the The clamping blocks 8 on both sides of the positioning table 5 are symmetrically arranged with respect to the positioning table 5 , and the upper end of the clamping block 8 is provided with an L-shaped opening 9 arranged in the direction of the positioning table 5 , and the bottom surface 10 of the L-shaped opening 9 is flat with the top surface of the positioning table 5 . A plurality of through grooves 11 are formed on the bottom surface 10 of the L-shaped opening 9 and along the longitudinal direction thereof, and a plurality of lifting cylinders 12 corresponding to the through grooves 11 are fixed on the horizontal plate of the L plate 7. A servo motor 13 is fixed on the action end of the piston rod of the lift cylinder 12 , and a drill bit 14 extending into the through groove 11 is connected to the output shaft of the servo motor 13 .

A pressing oil cylinder 15 is fixed on the beam of the gantry 3, the piston rod of the pressing oil cylinder 15 is arranged through the beam, and a pressing plate 16 is fixed on the extension end, and the pressing plate 16 is arranged directly above the positioning table 5. Two guide holes 17 are opened on the top, and the two guide holes 17 are respectively arranged directly above the two positioning columns 6. The outer diameter of the positioning columns 6 is equal to the diameter of the guide holes 17. The lower part of the beam of the gantry 3 is provided with Two linear milling mechanisms 18, two linear milling mechanisms 18 are respectively arranged directly above the two clamping blocks 8, and the milling cutter 19 of the linear milling mechanism 18 is arranged on the rear side of the clamping blocks 8; on the beam of the gantry 3 Two pressing oil cylinders 15 are fixed, and the piston rods of the two pressing oil cylinders 15 are fixed on the top surface of the pressing plate 16 . The height of the vertical surface 20 of the L-shaped opening 9 is smaller than the thickness of the high-speed printed circuit board 25 .

The two linear milling mechanisms 18 are arranged symmetrically on the left and right. The linear milling mechanism 18 includes a hydraulic slide table 21, a drive motor 22 and a milling cutter 19. The hydraulic slide table 21 is longitudinally arranged and fixed on the bottom surface of the beam of the gantry 3, and drives the The motor 22 is arranged vertically, and the base of the driving motor 22 is fixed on the moving table 23 of the hydraulic slide 21 through the flange, and the milling cutter 19 is installed on the output shaft of the driving motor 22 .

The processing device further includes a controller, which is electrically connected to the solenoid valve of the pressing cylinder 15, the solenoid valve of the lifting cylinder 12, the servo motor 13, and the driving motor 22. The worker can control the pressing cylinder 15 and the lifting and lowering through the controller. The extension or retraction of the piston rod of the oil cylinder 12 can also control the activation or deactivation of the servo motor 13 and the drive motor 22, which greatly facilitates the operation of workers and has the characteristics of high automation.

A processing method for the outer end face of a high-speed printed circuit board, which includes the following steps:

S1. The worker takes a plurality of high-speed printed circuit boards 25 to be processed, then stacks the plurality of high-speed printed circuit boards 25 neatly, and then drills two positioning holes 24 on each layer of high-speed printed circuit boards 25 , ensure that the spacing between the two positioning holes 24 is equal to the spacing between the two positioning posts 6, and at the same time ensure that the diameter of the positioning holes 24 is equal to the outer diameter of the positioning posts 6, as shown in Figure 14 on the high-speed printed circuit board Schematic diagram of processing two positioning holes;

S2, the positioning of the high-speed printed circuit board, the worker takes a high-speed printed circuit board 25, and then sets the two positioning holes 24 on the high-speed printed circuit board 25 on the two positioning posts 6 respectively, and sets the high-speed printed circuit board 25 The printed circuit board 25 is supported on the top surface of the positioning table 5, thereby realizing the positioning of the high-speed printed circuit board. As shown in FIGS. 15 to 16, the left and right extension ends of the high-speed printed circuit board 25 are supported on on the bottom surfaces 10 of the two clamping blocks 8, and the left and right end surfaces of the high-speed printed circuit board 25 are respectively opposite to the vertical surfaces 20 of the two clamping blocks 8;

S3. The horizontal clamping of the high-speed printed circuit board, the worker controls the piston rods of the two clamping cylinders 4 to retract, the piston rods drive the L plate 7 to move inward, and the L plate 7 drives the lifting cylinder 12 and the clamping block 8 to move synchronously, When the piston rods of the two clamping cylinders 4 are fully retracted, the high-speed printed circuit board 25 is clamped between the vertical surfaces 20 of the two clamping blocks 8, thereby realizing the horizontal clamping of the high-speed printed circuit board 25 , as shown in Figure 17~Figure 19;

S4. The vertical clamping of the high-speed printed circuit board, the worker controls the piston rod of the pressing cylinder 15 to extend downward, the piston rod drives the pressure plate 16 to move downward, the positioning column 6 first enters the guide hole 17, and then the pressure plate 16 Press on the top surface of the high-speed printed circuit board 25, thereby realizing the vertical clamping of the high-speed printed circuit board 25, as shown in FIG. 20;

S5. For the forming of the semi-finished high-speed printed circuit board, the worker first controls the drive motor 22 to start, the drive motor 22 drives the milling cutter 19 to rotate, and then the worker controls the hydraulic slides 21 of the two linear milling mechanisms 18 to start at the same time, and the hydraulic slides 21 drive The moving table 23 moves forward, and the moving table 23 drives the driving motor 22 and the milling cutter 19 to move forward synchronously. At this time, the rotating milling cutter 19 is attached to the top surface of the clamping block 8 and gradually mills the outside of the high-speed printed circuit board 25 from back to front. The material of the end face, the cutting direction of the milling cutter 19 is shown by the solid arrow in FIG. 18 , when the milling cutter 19 passes through the high-speed printed circuit board 25 , the left and right outer end faces of the high-speed printed circuit board 25 are formed. , as shown in Figure 21, the structure of the formed semi-finished high-speed printed circuit board is shown in Figure 22; in steps S3 to S5, since the high-speed printed circuit board 25 is clamped on the vertical surfaces of the two clamping blocks 8 20, and the left and right extension ends of the high-speed printed circuit board 25 are respectively supported on the bottom surfaces 10 of the two clamping blocks 8, so the clamping blocks 8 offset the downward cutting force exerted by the milling cutter 19 on the high-speed printed circuit board 25. , it is ensured that the bottom surface of the processed lip 26 is a horizontal plane, not the inclined surface 28, thereby greatly improving the molding quality of the lip 26, thereby greatly improving the production quality of the finished high-speed printed circuit board, and There is no need for subsequent correction, and redundant processes are omitted, thereby greatly improving the production efficiency of the product.

S6. The finished high-speed printed circuit board is formed. The worker controls each servo motor 13 to start, the servo motor 13 drives the drill bit 14 to rotate, and then the worker controls the piston rod of each lift cylinder 12 to extend upward, and the piston rod drives the servo motor 13 to move upward, The drill bit 14 passes through the through slot 11 and drills a plurality of required through holes 27 on the bottom surface of the stop 26, so as to finally produce a finished high-speed printed circuit board. The structure of the finished high-speed printed circuit board is shown in Figure 23~ 24; wherein, in the process from step S3 to step S6, the high-speed printed circuit board is clamped by one tooling, and the stop openings 26 can be formed on the left and right outer end faces of the high-speed printed circuit board 25, and then the stop openings 26 are formed at the stop. A plurality of through holes 27 are drilled on the bottom surface of the port 26. Therefore, compared with the traditional two-tool clamping high-speed printed circuit board, the error caused by the two positioning is greatly eliminated, thereby greatly improving the drilling The positional accuracy of the through hole 27 ensures that the position of the through hole 27 on the bottom surface of the stop 26 meets the requirements, thereby greatly improving the production quality of the finished high-speed printed circuit board, and has the characteristics of high molding accuracy. In addition, there is no operation of transferring the high-speed printed circuit board 25 in the middle, thereby greatly shortening the production cycle of the product, and thus greatly improving the production efficiency of the product.

S7 , repeating the operations of steps S2 to S6 , a plurality of finished high-speed printed circuit boards can be produced in batches continuously. During the molding process, since the positioning methods of each high-speed printed circuit board 25 are the same, and the clamping methods are also the same, it is ensured that the sizes of the two stops 26 in each product are the same, and the through holes 27 are on the bottom surface of the stop 26. The position on the board is also the same, which greatly improves the consistency of the product and further improves the molding quality of the finished high-speed printed circuit board.

Finally, it should be noted that the above are only preferred embodiments of the present invention, and are not intended to limit the present invention. Although the present invention has been described in detail with reference to the foregoing embodiments, for those skilled in the art, it is still The technical solutions described in the foregoing embodiments may be modified, or some technical features thereof may be equivalently replaced. Any modification, equivalent replacement, improvement, etc. made within the spirit and principle of the present invention shall be included within the protection scope of the present invention.

Claims (9)

1. A processing device for the outer end face of a high-speed printed circuit board, which includes a workbench (1), a support (2) fixed on the workbench (1), and a support (2) fixed on the workbench (1) The gantry (3) on the table, the gantry (3) is erected on the outside of the support (2), and is characterized in that: two horizontally arranged clamping oil cylinders are fixed on the top surface of the support (2). (4), a positioning table (5) is fixed between the cylinders of the two clamping cylinders (4), and two positioning columns (6) are fixed on the top surface of the positioning table (5). An L plate (7) located on the outer side of the support (2) is arranged on the action end of the piston rod of the oil cylinder (4), and the vertical plate of the L plate (7) is welded on the action end of the piston rod of the clamping oil cylinder (4), and The top of the vertical plate is welded with a clamping block (8), and the upper end of the clamping block (8) is provided with an L-shaped opening (9) arranged in the direction of the positioning table (5). The top surface of the platform (5) is flush, the bottom surface (10) of the L-shaped opening (9) is provided with a plurality of through grooves (11) along the longitudinal direction thereof, and the horizontal plate of the L-shaped plate (7) is fixed on the horizontal plate. There are a plurality of lift cylinders (12) respectively corresponding to the through grooves (11), and a servo motor (13) is fixed on the action end of the piston rod of each lift cylinder (12), and the output shaft of the servo motor (13) is connected to the output shaft. There is a drill bit (14) extending into the through groove (11); A pressing oil cylinder (15) is fixed on the beam of the gantry frame (3), the piston rod of the pressing oil cylinder (15) is arranged through the beam, and a pressing plate (16) is fixed on the extension end, and the pressing plate (16) is arranged Just above the positioning table (5), two guide holes (17) are opened on the pressing plate (16), and the two guide holes (17) are respectively arranged directly above the two positioning columns (6). (3) Two linear milling mechanisms (18) are arranged below the beam, and the two linear milling mechanisms (18) are respectively arranged directly above the two clamping blocks (8). The milling cutter (19) of the linear milling mechanism (18) ) on the rear side of the clamping block (8). 2. The processing device for the outer end face of a high-speed printed circuit board according to claim 1, wherein the clamping blocks (8) located on both sides of the positioning table (5) are symmetrically arranged with respect to the positioning table (5). . 3 . The processing device for the outer end face stop of a high-speed printed circuit board according to claim 1 , wherein the outer diameter of the positioning column ( 6 ) is equal to the diameter of the guide hole ( 17 ). 4 . 4. The processing device for the outer end face of a high-speed printed circuit board according to claim 1, characterized in that: two pressing oil cylinders (15) are fixed on the beam of the gantry (3), The piston rods of the two pressing oil cylinders (15) are fixed on the top surface of the pressing plate (16). 5. The processing device for the outer end face stop of a high-speed printed circuit board according to claim 1, characterized in that: the height of the vertical surface (20) of the L-shaped opening (9) is smaller than that of the high-speed printed circuit board (25) thickness. 6. The processing device for high-speed printed circuit board outer end face stop according to claim 1, characterized in that: a plurality of supports supported on the ground are fixed on the bottom surface of the worktable (1). leg. 7. The processing device for the outer end face of a high-speed printed circuit board according to claim 1, characterized in that: the two linear milling mechanisms (18) are arranged symmetrically on the left and right, and the linear milling mechanism (18) comprises a hydraulic sliding table (21), a driving motor (22) and a milling cutter (19), the hydraulic slide table (21) is longitudinally arranged and fixed on the bottom surface of the beam of the gantry (3), and the driving motor (22) is arranged vertically, And the base of the driving motor (22) is fixed on the moving table (23) of the hydraulic sliding table (21) through the flange, and the milling cutter (19) is installed on the output shaft of the driving motor (22). 8 . The processing device for the outer end face stop of a high-speed printed circuit board according to claim 1 , wherein the processing device further comprises a controller, the controller and the solenoid valve of the pressing oil cylinder ( 15 ). 9 . , The solenoid valve of the lifting oil cylinder (12), the servo motor (13), and the drive motor (22) are electrically connected. 9. The processing method for the outer end face of a high-speed printed circuit board, using the processing device for the outer end face of a high-speed printed circuit board according to any one of claims 1 to 8, characterized in that it comprises: The following steps: S1. The worker takes a plurality of high-speed printed circuit boards (25) to be processed, and then neatly stacks the plurality of high-speed printed circuit boards (25), and then drills the high-speed printed circuit boards (25) on each layer. Cut out two positioning holes (24), make sure that the distance between the two positioning holes (24) is equal to the distance between the two positioning posts (6), and at the same time ensure that the diameter of the positioning holes (24) is the same as that of the positioning posts (6) The outer diameters are equal; S2. The positioning of the high-speed printed circuit board. The worker takes a high-speed printed circuit board (25), and then sets the two positioning holes (24) on the high-speed printed circuit board (25) on the two positioning posts respectively. (6), and the high-speed printed circuit board (25) is supported on the top surface of the positioning table (5), thereby realizing the positioning of the high-speed printed circuit board. The extension ends are respectively supported on the bottom surfaces (10) of the two clamping blocks (8), and the left and right end surfaces of the high-speed printed circuit board (25) are respectively opposite to the vertical surfaces (20) of the two clamping blocks (8); S3. For the horizontal clamping of high-speed printed circuit boards, the worker controls the piston rods of the two clamping cylinders (4) to retract, the piston rods drive the L plate (7) to move inward, and the L plate (7) drives the lifting cylinder (12). ) and the clamping block (8) move synchronously, when the piston rods of the two clamping cylinders (4) are fully retracted, the high-speed printed circuit board (25) is clamped on the vertical surfaces ( 20), thereby realizing the horizontal clamping of the high-speed printed circuit board (25); S4. For vertical clamping of high-speed printed circuit boards, the worker controls the piston rod of the compression cylinder (15) to extend downward, the piston rod drives the pressure plate (16) to move downward, and the positioning column (6) first enters the guide hole (17), and the rear pressing plate (16) is pressed on the top surface of the high-speed printed circuit board (25), thereby realizing the vertical clamping of the high-speed printed circuit board (25); S5. For the forming of the semi-finished high-speed printed circuit board, the worker first controls the drive motor (22) to start, the drive motor (22) drives the milling cutter (19) to rotate, and then the worker controls the hydraulic slides ( 21) At the same time, the hydraulic slide table (21) drives the moving table (23) to move forward, and the moving table (23) drives the driving motor (22) and the milling cutter (19) to move forward synchronously, and the milling cutter (19) is rotated at this time. ) is attached to the top surface of the clamping block (8) to gradually mill the material on the outer end face of the high-speed printed circuit board (25) from back to front. When the milling cutter (19) passes through the high-speed printed circuit board (25), the Outlets (26) are formed on the left and right outer end faces of the printed circuit board (25); S6. For the forming of the finished high-speed printed circuit board, the worker controls each servo motor (13) to start, the servo motor (13) drives the drill bit (14) to rotate, and then the worker controls the piston rod of each lift cylinder (12) to extend upward, and the piston The rod drives the servo motor (13) to move upward, the drill bit (14) passes through the through slot (11) and drills a number of required through holes (27) on the bottom surface of the stop (26), thereby finally producing the finished product at high speed. printed circuit boards; S7 , repeating the operations of steps S2 to S6 , a plurality of finished high-speed printed circuit boards can be produced in batches continuously.
