Abstract

The invention discloses a novel linear tower structure which comprises a tower body, wherein the tower body is of a hollow structure, and a first amplification foot in the same direction as a power transmission line is arranged on the side surface of the lower end of the tower body. According to the novel linear tower structure provided by the invention, the linear tower with the single-side amplification foot is arranged, the direction of the single-side amplification foot is consistent with that of the power transmission line, when the tower is subjected to single-side tension, the single-side amplification foot on the side can increase the bearing area of the tower foundation, the action of the load from the tension of the upper power transmission line is diffused, the collapse of the end-point steel pipe tower and the corner steel pipe tower after long-time use is avoided, the safety is higher, and the popularization and the use are worth.

Description

Novel straight line pole tower structure
Technical Field
The invention belongs to the field of power transmission and transformation towers in the power industry, and particularly relates to a novel linear tower structure.
Background
Traditional shaft tower is mainly angle steel tower or steel pipe tower, and the steel pipe tower is connected with the pile foundation through the flange more, has terminal steel pipe tower and angle steel pipe tower in the steel pipe tower, only one direction and other shaft tower overhead transmission line on the terminal steel pipe tower, and later the electric wire is connected with electric power equipment nearby through terminal steel pipe tower inside, has two on the angle steel pipe tower not on same straight line direction with other shaft tower overhead transmission line. On the terminal steel pipe tower and the angle steel pipe tower, the following defects exist: because overhead transmission line only unilateral or not on same straight line, so the shaft tower can receive the effect of unbalanced force, shows on terminal steel pipe tower: the steel pipe tower at the end point inclines towards the side after being used for a long time due to the pulling force of the power transmission line at the side, which is used for erecting the line with other towers, and the major potential safety hazard of collapse exists; the angle steel pipe tower is characterized in that: both sides of erecting the circuit with other shaft towers all receive this side transmission line's pulling force, and these two power are not on same straight line, consequently can't offset each other, cause the corner steel pipe tower to receive the effect of the resultant of these two power, after long-time the use, can lead to angle steel pipe tower to incline towards this resultant, have the great potential safety hazard of collapsing.
Disclosure of Invention
Aiming at the defects in the prior art, the invention aims to provide a novel linear tower structure.
The purpose of the invention is realized by the following technical scheme.
The utility model provides a novel straight line shaft tower structure, includes the shaft tower body, the shaft tower body is hollow structure, and the lower extreme side of shaft tower body is provided with the first foot of enlarging the same with the transmission line direction.
The lower surface of the first amplification foot and the lower surface of the tower body are located on the same plane, and the cross-sectional area of the first amplification foot is gradually reduced from bottom to top until the area of the upper surface of the first amplification foot is zero.
The first amplification foot is a part of a first ellipse group, the first ellipse group comprises ellipses which are at least sequentially overlapped from bottom to bottom, short shafts of the ellipses in the first ellipse group are equal to and coincident with the diameter of the pole tower body, and the long shafts are gradually shortened from bottom to top.
The area ratio of the lower surface of the first amplification foot to the area of the lower surface of the tower body is 1-2.
The utility model provides a novel straight line shaft tower structure, includes shaft tower body, flange and basis, the basis includes cylinder pile foundation, and cylinder pile foundation is hollow structure, and the shaft tower body is hollow structure, and the lower extreme side of shaft tower body is provided with the first foot of amplifying the same with the transmission line direction, and the side of cylinder pile foundation is provided with the foot of amplifying the same with the first second of amplifying the foot direction, and flange fixed connection is passed through with the upper surface on cylinder pile foundation to the lower surface of shaft tower body.
The lower surface of the second amplification foot and the lower surface of the cylindrical pile foundation are positioned on the same plane, and the cross sectional area of the second amplification foot is gradually reduced from bottom to top until the upper surface of the second amplification foot and the upper surface of the cylindrical pile foundation are positioned on the same plane; the lower surface of the first amplification foot and the lower surface of the tower body are located on the same plane, and the cross-sectional area of the first amplification foot is gradually reduced from bottom to top until the area of the upper surface of the first amplification foot is zero.
The first amplification foot is part of a first ellipse group, the first ellipse group comprises ellipses which are sequentially overlapped from bottom to top, the minor axes of the ellipses in the first ellipse group are equal to and coincident with the diameter of the tower body, and the major axes are gradually shortened from bottom to top; the second is enlarged foot and is partly of the oval group of second, and the oval group of second includes from supreme superimposed ellipse in proper order down, and the ellipse in the oval group of second all equals and coincide with the diameter on cylindrical pile basis, and the major axis shortens from supreme down gradually.
The area ratio of the lower surface of the second amplification foot to the lower surface of the cylindrical pile foundation is 1-2, and the area ratio of the upper surface of the second amplification foot to the upper surface of the cylindrical pile foundation is 0-1/5; the sum of the areas of the lower surface of the first amplification foot and the lower surface of the tower body is not larger than the sum of the areas of the upper surface of the second amplification foot and the upper surface of the cylindrical pile foundation.
The flange comprises a first flange and a second flange, the first flange is connected with the upper surface of the foundation, the second flange is connected with the lower surface of the tower body, and the first flange is connected with the second flange through bolts.
The first amplification foot is welded with the tower body, and the second amplification foot is welded with the cylindrical pile foundation.
The invention has the beneficial effects that: according to the novel linear tower structure provided by the invention, the linear tower with the single-side amplification foot is arranged, the direction of the single-side amplification foot is consistent with that of the power transmission line, when the tower is subjected to single-side tension, the single-side amplification foot on the side can increase the bearing area of the tower foundation, the action of the load from the tension of the upper power transmission line is diffused, the collapse of the end-point steel pipe tower and the corner steel pipe tower after long-time use is avoided, the safety is higher, and the popularization and the use are worth.
Drawings
Fig. 1 is a schematic structural view of a final steel pipe tower according to the present invention.
Fig. 2 is a top view of the tower body and first enlarged foot of the present invention.
Fig. 3 is a plan view of the tower body and the first enlarged leg of the corner steel pipe tower of the present invention.
Fig. 4 is a schematic view of still another structure of the final steel pipe tower of the present invention.
In the figure, 1 is a tower body, 2 is a first amplification foot, 3 is a cylindrical pile foundation, 4 is a second amplification foot, 5 is a first flange, and 6 is a second flange.
Detailed Description
As shown in fig. 1, 2 and 3, a novel linear tower structure is suitable for steel pipe towers for power transmission and transformation in cities, particularly for end point steel pipe towers and corner steel pipe towers, can prevent the steel pipe towers from collapsing after being used for a long time, and has high safety. This novel straight line shaft tower structure includes the shaft tower body, and the upper end of shaft tower body is used for overhead transmission line, the shaft tower body is hollow structure, and the circuit can pass from the shaft tower body, and the lower extreme side of shaft tower body is provided with the first foot of amplifying the same with the transmission line direction, and first foot of amplifying is the welding with the shaft tower body.
The lower surface of the first amplification foot and the lower surface of the tower body are located on the same plane, and the cross-sectional area of the first amplification foot is gradually reduced from bottom to top until the area of the upper surface of the first amplification foot is zero. The first amplification foot is a part of a first ellipse group, the first ellipse group comprises ellipses which are at least sequentially overlapped from bottom to bottom, the minor axes of the ellipses in the first ellipse group are equal to and coincident with the diameter of the pole tower body, and the major axes are gradually shortened from bottom to top until the minor axes are zero. The area ratio of the lower surface of the first amplification foot to the area of the lower surface of the tower body is 1-2.
As shown in fig. 4, another kind of novel straight line tower structure, this straight line tower structure include shaft tower body, flange and basis, and the upper end of shaft tower body is used for overhead transmission line, and the foundation exists as straight line tower's pile foundation, increases the basic bearing area on straight line tower and ground, is indispensable foundation structure in the straight line tower, and for making straight line tower installation and transportation convenient, steel pipe tower straight line tower adopts the flange to connect usually.
The base includes the cylinder pile foundation, and cylindric basis is hollow structure, and the side of cylinder pile foundation is provided with the second amplification foot the same with the transmission line direction, and the quantity of second amplification foot is the same with transmission line's circuit quantity, and all the same with transmission line's direction, and the lower extreme side of shaft tower body is provided with the first amplification foot the same with the second amplification foot direction, and flange fixed connection is passed through with the upper surface on cylinder pile foundation to the lower surface of shaft tower body. Preferably, the second amplification foot is welded with the cylindrical pile foundation, and the first amplification foot is welded with the tower body.
The lower surface of the second amplification foot and the lower surface of the cylindrical pile foundation are positioned on the same plane, and the cross sectional area of the second amplification foot is gradually reduced from bottom to top until the upper surface of the second amplification foot and the upper surface of the cylindrical pile foundation are positioned on the same plane; the lower surface of the first amplification foot and the lower surface of the tower body are located on the same plane, and the cross-sectional area of the first amplification foot is gradually reduced from bottom to top until the area of the upper surface of the first amplification foot is zero.
The second amplification foot is part of a second ellipse group, the second ellipse group comprises ellipses which are sequentially overlapped from bottom to top, the minor axes of the ellipses in the second ellipse group are equal to and coincident with the diameter of the cylindrical pile foundation, and the major axes are gradually shortened from bottom to top; the area ratio of the lower surface of the second amplification foot to the lower surface of the cylindrical pile foundation is 1/2-1, and the area ratio of the upper surface of the second amplification foot to the upper surface of the cylindrical pile foundation is 0-1/5. For example, the following steps are carried out: assuming that the diameter of the cylindrical pile foundation is 2m, the minor axis of the ellipse in the second ellipse group is 2m, the length of the major axis is 4m-6m, and the major axis is gradually shortened from bottom to top. It should be noted that the area of the upper surface of the second enlarged foot may be zero.
The first amplification foot is part of a first ellipse group, the first ellipse group comprises ellipses which are sequentially overlapped from bottom to top, the ellipses in the first ellipse group are equal to and coincident with the diameter of the tower body, and the major axis of the first ellipse group is gradually shortened from bottom to top until the major axis of the first ellipse group is zero; the sum of the areas of the lower surface of the first amplification foot and the lower surface of the tower body is not larger than the sum of the areas of the upper surface of the second amplification foot and the upper surface of the cylindrical pile foundation.
The flange comprises a first flange and a second flange, the first flange is connected with the upper surface of the foundation, the second flange is connected with the lower surface of the tower body, and the first flange is connected with the second flange through bolts.
Specifically, the embodiment of the present invention is as follows: the diameter of the cylindrical pile foundation is 2m, the diameter of the tower body is 1.6m, the second amplification foot and the first amplification foot are prefabricated according to the diameters of the cylindrical pile foundation and the tower body, the minor axis of the ellipse of the lower surface of the second amplification foot is 2m, the major axis of the ellipse is 4m, and the major axis of the ellipse of the upper surface of the second amplification foot is 2m, which means that the area of the upper surface of the second amplification foot is zero, the minor axis of the ellipse of the lower surface of the first amplification foot is 1.6m, the major axis of the ellipse is 2m, and the longest ellipse of the first amplification foot and the longest ellipse of the second amplification foot are located on the same transition line, so that the cylindrical pile foundation and the tower body look like a whole. And respectively welding the second amplification foot and the first amplification foot on the cylindrical pile foundation and the tower body. The first flange and the second flange are respectively pre-arranged on the cylindrical pile foundation and the tower body and connected through bolts, and then the foundation and the tower body are connected.
It should be noted that, when the first amplification leg and the second amplification leg are welded to the corner steel pipe tower, it is to be ensured that the directions of the first amplification leg and the second amplification leg are completely consistent with the direction of the power transmission line, and the two first amplification legs or the two second amplification legs may be combined in a region where they may overlap.
The above description is only a preferred embodiment of the present invention, and is not intended to limit the technical solutions of the present invention, and it should be noted that, further improvements and changes can be made by those skilled in the art based on the technical solutions of the present invention, and these improvements and changes should be covered within the protection scope of the present invention.

Claims (10)

1.一种新型直线杆塔结构，包括杆塔本体，其特征在于：所述杆塔本体为中空结构，杆塔本体的下端侧面设置有与输电线路方向相同的第一放大脚。1. a novel linear pole tower structure, comprising a pole tower body, is characterized in that: the pole tower body is a hollow structure, and the lower end side of the pole tower body is provided with a first enlarged foot in the same direction as the transmission line. 2.根据权利要求1所述的新型直线杆塔结构，其特征在于：所述第一放大脚的下表面与杆塔本体的下表面位于同一平面，第一放大脚的横截面积从下至上逐渐变小，直至第一放大脚的上表面面积为零。2. The novel linear tower structure according to claim 1 is characterized in that: the lower surface of the first enlarged foot is positioned on the same plane as the lower surface of the tower body, and the cross-sectional area of the first enlarged foot gradually changes from bottom to top. small until the upper surface area of the first magnified foot is zero. 3.根据权利要求2所述的新型直线杆塔结构，其特征在于：所述第一放大脚为第一椭圆组的一部分，第一椭圆组包括从下至少依次叠加的椭圆，第一椭圆组中的椭圆的短轴均与杆塔本体的直径相等且重合，长轴从下至上逐渐变短。3. The novel linear tower structure according to claim 2 is characterized in that: the first enlarged foot is a part of the first ellipse group, and the first ellipse group comprises ellipses that are at least sequentially superimposed from the bottom, and in the first ellipse group The short axis of the ellipse is equal to and coincides with the diameter of the tower body, and the long axis gradually shortens from bottom to top. 4.根据权利要求3所述的新型直线杆塔结构，其特征在于：所述第一放大脚的下表面的面积与杆塔本体下表面的面积比为1-2。4 . The novel linear tower structure according to claim 3 , wherein the ratio of the area of the lower surface of the first enlarged foot to the area of the lower surface of the tower body is 1-2. 5 . 5.一种新型直线杆塔结构，包括杆塔本体、法兰和基础，其特征在于：所述基础包括圆柱桩基础，圆柱桩基础为中空结构，杆塔本体为中空结构，杆塔本体的下端侧面设置有与输电线路方向相同的第一放大脚，圆柱桩基础的侧面设置有与第一放大脚方向相同的第二放大脚，杆塔本体的下表面与圆柱桩基础的上表面通过法兰固定连接。5. A novel linear tower structure, comprising a tower body, a flange and a foundation, characterized in that: the foundation includes a cylindrical pile foundation, the cylindrical pile foundation is a hollow structure, the tower body is a hollow structure, and the lower end side of the tower body is provided with The first enlarged foot in the same direction as the transmission line, the side of the cylindrical pile foundation is provided with a second enlarged foot in the same direction as the first enlarged foot, and the lower surface of the tower body and the upper surface of the cylindrical pile foundation are fixedly connected by flanges. 6.根据权利要求5所述的新型直线杆塔结构，其特征在于：所述第二放大脚的下表面与圆柱桩基础的下表面位于同一平面，第二放大脚的横截面积从下至上逐渐变小，直至第二放大脚的上表面与圆柱桩基础的上表面位于同一平面；所述第一放大脚的下表面与杆塔本体的下表面位于同一平面，第一放大脚的横截面积从下至上逐渐变小，直至第一放大脚的上表面面积为零。6. The novel linear pole tower structure according to claim 5, characterized in that: the lower surface of the second enlarged foot and the lower surface of the cylindrical pile foundation are located on the same plane, and the cross-sectional area of the second enlarged foot gradually increases from bottom to top. become smaller until the upper surface of the second enlarged foot and the upper surface of the cylindrical pile foundation are on the same plane; the lower surface of the first enlarged foot and the lower surface of the tower body are on the same plane, and the cross-sectional area of the first enlarged foot is from It gradually decreases from bottom to top until the upper surface area of the first enlarged foot is zero. 7.根据权利要求6所述的新型直线杆塔结构，其特征在于：所述第一放大脚为第一椭圆组的一部分，第一椭圆组包括从下至上依次叠加的椭圆，第一椭圆组中的椭圆的短轴均与杆塔本体的直径相等且重合，长轴从下至上逐渐变短；所述第二放大脚为第二椭圆组的一部分，第二椭圆组包括从下至上依次叠加的椭圆，第二椭圆组中的椭圆均与圆柱桩基础的直径相等且重合，长轴从下至上逐渐变短。7. The novel linear tower structure according to claim 6 is characterized in that: the first enlarged foot is a part of the first ellipse group, and the first ellipse group comprises ellipses superimposed in turn from bottom to top, and in the first ellipse group The short axis of the ellipse is equal to and coincides with the diameter of the tower body, and the long axis gradually shortens from bottom to top; the second enlarged foot is a part of the second ellipse group, and the second ellipse group includes ellipses superimposed from bottom to top , the ellipses in the second ellipse group are all equal to and coincide with the diameter of the cylindrical pile foundation, and the long axis gradually shortens from bottom to top. 8.根据权利要求7所述的新型直线杆塔结构，其特征在于：所述第二放大脚的下表面的面积与圆柱桩基础的下表面的面积比为1-2，第二放大脚的上表面的面积与圆柱状基础的上表面的面积比为0-1/5；第一放大脚的下表面与杆塔本体的下表面的面积和不大于第二放大脚的上表面与圆柱桩基础的上表面的面积和。8. The novel linear pole tower structure according to claim 7 is characterized in that: the area ratio of the lower surface of the second enlarged foot to the area of the lower surface of the cylindrical pile foundation is 1-2, and the upper part of the second enlarged foot The ratio of the area of the surface to the upper surface of the cylindrical foundation is 0-1/5; the sum of the area of the lower surface of the first enlarged foot and the lower surface of the tower body is not greater than the area of the upper surface of the second enlarged foot and the cylindrical pile foundation. the area of the upper surface and the sum. 9.根据权利要求8所述的新型直线杆塔结构，其特征在于：所述法兰包括第一法兰和第二法兰，第一法兰和基础的上表面连接，第二法兰和杆塔本体的下表面连接，第一法兰和第二法兰通过螺栓连接。9. The novel linear pole tower structure according to claim 8 is characterized in that: the flange comprises a first flange and a second flange, the first flange is connected with the upper surface of the foundation, and the second flange is connected with the pole tower. The lower surface of the body is connected, and the first flange and the second flange are connected by bolts. 10.根据权利要求1或5所述的新型直线杆塔结构，其特征在于：所述第二放大脚与杆塔本体为焊接，第一放大脚与圆柱桩基础为焊接。10 . The novel linear pole tower structure according to claim 1 or 5 , wherein the second enlarged leg and the tower body are welded, and the first enlarged leg and the cylindrical pile foundation are welded. 11 .
